s
SIMEASP
Power Meter
7KG7550/7KG7650/7KG7660
Operating Instructions Order no: E50417-B1076-C263-A5
Edition 07/2004

i
1 Operating Instructions.....................................................2
1.1 Compliance .....................................................................2
1.2 General Information.........................................................3
1.3 Qualified Personnel .........................................................5
1.4 Ordering Data..................................................................6
1.5 Note Concerning Transport .............................................7
1.6 Range of Application .......................................................7
1.7 Mode of Operation..........................................................8
1.8 Block Diagram .................................................................9
1.9 Measured Values ..........................................................11
1.10 Technical Data...............................................................13
1.11 Communication Interface ..............................................19
1.12 Dimensions ...................................................................20
1.13 Connection Terminals....................................................24
1.13.1 For Devices 7KG7550 and 7KG7650 .........................24
1.13.2 For Devices 7KG7660 ...............................................26
1.14 Mounting and Operation ...............................................29
1.14.1 Mounting the Device ................................................30
1.15 Cable Connections ........................................................32
1.16 Storage..........................................................................33
1.17 Electrical Connections ...................................................33
1.18 Connection Examples....................................................35
1.19 Commissioning .............................................................39
1.20 Configuration Overview.................................................41
1.20.1 Operating Notes .......................................................41
1.20.2 Button Functions ......................................................41
1.20.3 Window Structure.....................................................42
1.20.4 Notes........................................................................43
1.20.5 Overview of the Programming Levels: 7KG7550 ......44
1.20.6 Overview of the Programming Levels:
7KG7650/7KG7660
.....................................................45
1.21 Testing and Calibration..................................................46
1.22 Maintenance, Repair and Cleaning ................................47

2
The warnings and information contained in these
operating instructions are provided
to ensure personal safety and maximize the useful
life of the product.
Please follow them!
This product is UL-certified to Standard UL 61010B-1, based
on the specification stated in Chapter 1.10 (Technical Data).
UL File No.: E228586
Measuring Equipment
2UD1
Note:
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of the
equipment in a residential area is likely to cause harmful
interference in which case the user will be required to
correct the interference at his own expense.

2
1Operating Instructions
1.1 Compliance
This product complies with the directives of the Council of
the European Communities in accordance with the laws of
the Member States regarding electromagnetic compatibility
(EMC Council Directive 89/336/EEC) and the application of
electrical equipment within specified voltage limits (Low
Voltage Directive 73/23/EEC).
Compliance has been verified via testing performed by
Siemens AG as per article 10 of the Council Directives in
accordance with the generic standards EN 61000-6-4 and
EN 61000-6-2 (for EMC Directive) as well as EN 61010-1
(for Low Voltage Directive).
The device is designed and manufactured for application in
industrial environments as defined in the standard
EN 61000-6-4.
The device is designed and manufactured in accordance
with the international standard IEC 60688.

3
1.2 General Information
These operating instructions include the information
required for proper use of the corresponding products.
These operating instructions are intended for technically
qualified personnel with sufficient competence and
knowledge in the areas of instrumentation and control
engineering, which will be referred to as automation
engineering throughout the rest of these operating
instructions.
In order to ensure safe installation and commissioning, as
well as safe operation and maintenance, all personnel
should fully understand and comply with all safety
information and warnings contained in this document in a
technically correct manner. Only personnel who meet the
requirements outlined in Chapter 1.3 for qualified personnel
possess the expertise and knowledge required to apply the
general safety information and warnings of this document
correctly for each specific and individual scenario.
While these operating instructions are included with the
product, it is important to note that not every aspect of the
product, nor every possible installation, operation and
maintenance scenario, can be thoroughly discussed.
If more information is required, or if specific problems arise
which are not discussed in this document, additional
information can be requested from your local Siemens
subsidiary or from the address given on the back cover of
this document.

4
WARNING!
If the equipment described in these operating instructions is used
in a manner other than that specified by the manufacturer, the
protection provided by the equipment may be impaired.
Furthermore, the contents of this operating instructions are
not part of an earlier or existing agreement, consent, or a
legal regulation and do not represent a modification of any
of these. All commitments of Siemens are specified in the
specific purchase contract, which also includes the entire
and unique warranty regulations. The contractual warranty
regulations are neither extended nor restricted by the
information in this document.
Explanation of symbols marked on the equipment
Direct current
Alternating current
Three-phase alternating current
Documentation needs to be consulted
Protective ground

5
WARNING!
During operation of electric devices, certain parts of the device are
subject to dangerous voltages. Ignoring the warning notes can
result in severe injury or damage to property.
Only qualified personnel should be allowed to operate this device.
Appropriate transportation, storage, installation and assembly, as
well as careful operation and maintenance, are basic requirements
for proper and safe operation of this device.
In particular, the general mounting and safety regulations (e. g. IEC
or national standards) regarding the correct use of power systems
must be observed and complied with. Non-compliance can result in
death, personal injury or substantial property damage.
1.3 Qualified Personnel
are persons who are familiar with the installation, assembly,
commissioning and operation of the product and who
possess the following qualifications:
•training or instruction and authority to operate and
service devices/systems according to all applicable
safety standards and rules for electric circuits and
devices
•education or instruction in the maintenance and use of
appropriate safety equipment according to all applicable
safety standards
•first aid training

6
1.4 Ordering Data
Description Order-No.
Power Meter with grahic-display
SIMEAS P500 7KG7 5 5 0 - 0
A
A
0-0
A
A
0
Standard built-in device for control panels 144x144
with graphic display
Front protection class
IP 41 1
IP 54 2
SIMEAS P600 7KG7 6 0 - 0 0 - 0 0
Extended built-in device for control panels 144x144
with graphic display, real time clock module,
battery and memory for recording of measured quantities
V
ersion
without I/O modules 5
A
A
A
A
with additional I/O modules 6
I/O module in slot
A
without
A
2 binary outputs B
2 binary inputs C
2
ana
l
og ou
t
pu
t
s
(0
t
o
20
m
A
DC
)
D
2
ana
l
og
i
npu
t
s
(0
t
o
20
m
A
DC
)
E
3 relais outputs G
I/O module in slot B
without
A
2 binary outputs B*)
2 binary inputs C
2
ana
l
og outputs
(0
to
20
m
A
DC
)
D
2
ana
l
og
i
nputs
(0
to
20
m
A
DC
)
E
Front protection class
IP 41 1
IP 54 2
I/O module in slot C
without
A
2 binary inputs C
2
ana
l
og ou
t
pu
t
s
(0
t
o
20
m
A
DC
)
D
2
ana
l
og
i
npu
t
s
(0
t
o
20
m
A
DC
)
E
I/O module in slot D
without
A
2 binary inputs C
2
ana
l
og outputs
(0
to
20
m
A
DC
)
D
2
ana
l
og
i
npu
t
s
(0
t
o
20
m
A
DC
)
E
*) only if position 9 (I/O module in Slot A) ≠G

7
1.5 Note Concerning Transport
The Lithium-batteries in our equipment are subject to
Special Provision 188 of the UN Recommendations on the
Transport of Dangerous Goods Model Regulations and
Special Provision A45 of the IATA Dangerous Goods
Regulation and the ICAO Technical Instructions.
This is only valid for the original battery or original spare
batteries.
1.6 Range of Application
The SIMEAS P is capable of recording several different
power system measurements. In addition, the SIMEAS P is
designed to be utilized in a number of different industries.
The display of measured quantities can be easily configured
to the specific requirements of the user.
Network linking is possible with the integral RS 485 port
equipped with the standard PROFIBUS DP V1 or Modbus
RTU/ASCII protocol which provide for indication, evaluation
and processing of several SIMEAS P measurements at a
central master station.

8
1.7 Mode of Operation
Input voltages and currents are sampled for calculation of
the corresponding r.m.s. values. All measurements derived
from sampled values are calculated by a processor.
Measured quantities can be displayed on the screens and/or
transmitted via the serial interface.
With the SIMEAS P, it is possible to program limit value
groups for various measured quantities to activate limit
violations when the value of a specific measured quantity
exceeds a programmed threshold. In addition, it is possible
use logical elements (AND, OR, etc.) to combine two or
more measured quantities for the purpose of generating a
limit violation. Limit violations are counted, indicated on the
screen and/or utilized to operate the binary output contacts.
The oscilloscope may be triggered via a limit violation as
well.
All measured quantities can be displayed on the
SIMEAS P screens as required by the user. Up to 20
screens can be selected with the front keys. The number,
type, content and sequence of the screens are configurable.
SIMEAS P is delivered with pre-programmed default
settings.
A status line displayed in the measured value screens
indicates status, interfacing and diagnostic messages for
the SIMEAS P.
The display is automatically refreshed every second.

9
1.8 Block Diagram
Basic device:
The housing of the RS 485 interface is connected with protective
ground (PG).

10
Additional input and output modules are available for the device
7KG7660 (optional):
•binary input (2 contacts with common contact)
•binary output (2 contacts with common contact)
•relay output (3 contacts with common contact)
•analog input (2 channels)
•analog output (2 channels)

11
1.9 Measured Values
Measured values Measuring
path 1Menu Tolerances 2
Voltage A-N, B-N,
C-N, (N-G) dah±0.2%
Voltage A-B, B-C,
C-A, Σ3dah±0.2%
Current A, B, C, N,
Σ3dah±0.2%
Real power P
+ import, - export A, B, C, Σdah±0.5%
Reactive power Q
+ leading, - lagging A, B, C, Σdah±0.5%
Apparent power S A, B, C, Σdah±0.5%
Power factor |cosφ| 4A, B, C, Σdah±0.5%
Active power factor
cosφ4A, B, C, Σdah±0.5%
Phase angle 4A, B, C, Σdah±2°
Frequency 5A-N
dah±10 mHz
Real power import A, B, C, Σda±0.5%
Real power export A, B, C, Σda±0.5%
Real power absolute A, B, C, Σda±0.5%
Real power net Σda±0.5%
Reactive power leading A, B, C, Σda±0.5%
Reactive power lagging A, B, C, Σda±0.5%

12
Measured values Measuring
path 1Menu Tolerances 2
Reactive power absolute A, B, C, Σda±0.5%
Apparent power A, B, C, Σda±0.5%
Unbalanced voltage Four-wire
system dah±0.5%
Unbalanced current Four-wire
system dah±0.5%
THD voltage A, B, C dah±0.5%
THD current A, B, C dah±0.5%
Harmonic voltage V
5. 7. 11. 13. 17. 19. H. A, B, C dah±0.5%
Harmonic current I
5. 7. 11. 13. 17. 19. H. A, B, C dah±0.5%
Limit violations counter 1
to 4 da
Analog inputs 6external
da±0.5%
Binary inputs 6external
da
1) Phases are displayed based on the type of connection.
2) Tolerances are applicable to 0.5 to 1.2 times nominal value.
3) Average value of all phases.
4) Measurement beginning at 2% of the internal apparent power
5) Measurement beginning at 30% of the input voltage L1-N
6) 7KG7660 only
dMeasurements can be displayed on measured value screens
aMeasurements selectable over communication
hMeasurements selectable for list screens and oscilloscope

13
1.10 Technical Data
Input signals Only for connection to AC systems
Max. system voltage 600 V (phase-to-phase)
Overload 20%
Frequency of fundamental
component 40 ... 65 Hz
Frequency range fi+/- 5 Hz, min. > 30% VIN
Waveform Sinusoidal or distorted up to the
21st harmonic
AC current inputs II 3 current inputs
Input current Ii1 A; 5 A
Continuous overload
Surge withstand capability
10 A
100 A for 1s
AC voltage inputs VI3 voltage inputs
Input voltage VIN 100/110 V; 190 V; 480 V; 600 V (L-L)
Continuous voltage capability
Surge withstand capability
1.5 x VIN
2.0 x VIN
Input resistance (L - N) 2.663 MΩ
Binary inputs (optional, only 7KG7660)
Max. input voltage 300 V DC
Current consumption for high
level
1.8 mA
Threshold voltage low ≤10 V
Threshold voltage high ≥19 V
Signal delay max. 3 ms
Analog inputs (optional, only 7KG7660)
Measuring range 0 to 20 mA DC
Input range 0 to 24 mA DC
Input resistance 50 Ω±0.1%
Accuracy 0.5% of the measuring range limit

14
Binary outputs Via isolated solid-state relay
Permissible voltage 230 V/AC; 250 V/DC
Permissible current 100 mA continuous
300 mA for 100 ms
Internal resistance 50 Ω
Permissible operating
frequency
10 Hz
Analog outputs (optional, only 7KG7660)
Nominal output current 0 to 20 mA DC
Output range 0 to 24 mA DC
Max. load resistance 250 Ω
Accuracy 0.2% (typical); max. 1.1% of the
nominal value
Relay outputs (optional, only 7KG7660)
Rated voltage 250 V AC / 150 V DC
Max. permanent current 5 A
Min. permanent current 0,1 mA at 100 mV DC
Rating (resistive) 5 A / 250 V AC or 5 A / 30 V DC
Max. response time 10 ms
Max. release time 7 ms
Overvoltage category According to IEC 61010 Part1
VIN to 480 V (L-L) Cat III
VIN to 600 V (L-L) Cat II
Power Supply Cat II
Binary outputs, binary inputs
and relay outputs Cat II

15
Auxiliary power Multi-range power supply unit
AC /DC
Nominal range 24 to 250 V DC or 100 to 230 V AC;
50/60 Hz
Total range
7KG7550 and 7KG7650:
7KG7660:
+/- 20% of nominal range
-10% ... +20% of nominal range DC
+/- 20% of nominal range AC
Power consumption
7KG7550 and 7KG7650:
7KG7660:
max. 4 W or 10 VA
max. 10 W or 35 VA
Battery (only 7KG7650 and 7KG7660)
Type VARTA CR2032, 3 V, Li-Mn
Display Graphic display
Resolution 120 x 240 pixels
Dimensions 4-1/6" x 2-3/8" (103 x 60 mm)
Dimensions, Weight
Panel mounted housing 5-11/16" x 5-11/16"
(144 mm x 144 mm)
Weight
without I/O modules:
with 4 I/O modules and
connection board
Approx. 2.0 lbs (0.9 kg)
Approx. 2.1 lbs (0.95 kg)
Communication interface
Connection 9-pole D-sub. female connector
Data transfer
PROFIBUS DP V1
interface transmission
speed
Modbus RTU/ASCII
9.600 bit/s to 12 Mbit/sec
Baud rate (bit/s):
300, 600, 1200, 3400, 4800, 9600,
19200, 38400, 57600, 115200

16
Electromagnetic compatibility
Immunity according to IEC 61000-6-2
Emission according to CISPR 11, Class A
and 47 CFR, Part 15, Class A
Dielectric test,
routine test, 2 s
according to IEC 61010-1
and UL 61010B-1
Signal inputs mutually
(current to current and
current to voltage) 2.2 kV; AC
Current inputs to serial
interface, PG, binary outputs
and power supply 2.2 kV; AC
Power supply, serial interface
and binary outputs mutually 3.1 kV; DC
Power supply to PG 3.1 kV; DC
Voltage inputs, binary outputs
to PG 1.35 kV; AC
Serial interface to PG 500 V; AC
Additional for 7KG7660
Binary inputs and
binary/relay outputs to PG 2.2 kV; AC
Analog inputs and analog
outputs to PG 500 V; AC

17
Impulse voltage withstand
test, test type
according IEC 60688 and
IEC 60255-5
All circuits mutually except
serial interface
5 kV; 1.2 / 50 µs
Insulation type of inputs and outputs
Signal inputs (current) Reinforced,
max. 600 V AC, Cat II or
max. 300 V AC, Cat III
Signal inputs (voltage) Protective impedance,
max. 600 V AC, Cat II or
max. 300 V AC, Cat III
Power supply Reinforced,
max. 230 V AC/250V DC, Cat II
Binary inputs and binary/relay
outputs
Reinforced,
max. 230 V AC/250V DC, Cat II
Serial interface Optical isolated
Analog inputs and analog
outputs Optical isolated
Reference conditions The stated error limits apply for
reference conditions
Input current IiI
IN ± 1%
Input voltage ViV
IN ± 1%
Frequency 45 ... 65 Hz
Waveform AC, harmonic distortion ≤5%
Ambient temperature TA73.4 °F ± 1.8 °F (23 °C ± 1 °C)
Power supply voltage VHV
HN ± 1%
Warm-up time ≥15 min
External fields no

18
Environmental conditions The device is designed for indoor
use only
Ambient Temperature According to IEC 60688
Operating Temperature Range 32° F to 131° F (0° C to 55° C)
Storage Temperature Range -13° F to 158° F (-25° C to 70° C)
Max. relative humidity 80 % for temperatures up to 87 °F
decrease linearly to 50 % at 104 °F
Max. altitude above sea level 6,560 ft (2000 m)
Pollution degree 2, no condensation
Additional Technical Data
Internal fuse, primary Not replaceable
Type T500mA/250V according
IEC 60127 and UL 248-14
Internal fuse, secondary Not replaceable
Type F2A/125 V according
UL 248-14
Protection class according IEC 60529
Device
- Front
- Rear
IP41
IP54 see ordering data
IP20
Personal protection IP1x
