Siemens SICLOCK PCON User manual

04/2012
A2B00056366E-01
SICLOCK®PCON
Operating Instructions
Preface, Table of contents
Safety instructions
Functional description
Mounting and installation
Configuration
Outputs
Optical input and output
Technical specifications
Appendix
ESD guidelines
Index

Siemens AG
Industry Sector
P.O. Box 48 48
90026 Nuremberg
GERMANY
© Siemens AG 2008
Subject to technical changes without prior notice.
Ⓟ 09/2011
A2B00056366E-01
Safety information
This manual contains information that must be observed to ensure your personal safety and to prevent
property damage. The notices referring to your personal safety are highlighted in the manual by a safety
alert symbol. Notices referring only to equipment damage have no safety alert symbol. Warnings are
shown in descending order according to the degree of danger as follows.
If multiple levels of hazards can occur, the highest level warning is always displayed. A warning with a
warning triangle indicating possible injury to personnel may also include a warning relating to property
damage.
Qualified personnel
Startup and operation of the device / system in question may only be performed using this documentation.
The device / system must always be commissioned and operated by qualified personnel. Qualified per-
sonnel as referred to in the safety information in this documentation are those who are authorized to start
up, ground and label units, systems and circuits in accordance with the relevant safety standards.
Proper use
Note the following:
Trademarks
All designations with the trademark symbol ® are registered trademarks of Siemens AG. Other designa-
tions in this documentation may be trademarks whose use by third parties for their own purposes can vio-
late the rights of the owner.
Disclaimer of liability
We have checked the contents of this publication for consistency with the hardware and software
described. Nevertheless, we cannot assume responsibility for any deviations that may arise. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subse-
quent editions.
Danger
indicates that death or serious injury will result if proper precautions are not taken.
Warning
indicates that death or serious injury may result if proper precautions are not taken.
Caution
with a safety alert symbol indicates that minor personal injury can result if proper precautions are not taken.
Caution
without a safety alert symbol indicates that damage to property may result if proper precautions are not
taken.
Notice
means an undesirable result or state can occur if the corresponding instruction is not followed.
Warning
The unit may be used only for the applications described in the catalog or the technical description, and
only in combination with the equipment, components and devices of other manufacturers where recom-
mended or permitted by Siemens. Smooth and safe operations demand proper transport, proper storage,
installation and assembling as well as careful operations and maintenance.

Preface-3SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Preface
This document is a compilation of the information required for the operation and
parameterization of the SICLOCK®PCON pulse converter.
Scope
This manual is valid for the SICLOCK®PCON with product version ES03
(order no.: 2XV9450-1AR63-1SA3).
Recycling and disposal
The SICLOCK®PCON can be recycled owing to its low pollutant content. For
ecologically compatible recycling and disposal of your old device, contact a
certificated disposal service for electronic scrap.
Hotline and Internet addresses
If you have any questions, please contact our hotline:
The latest information about SICLOCK products, product support and FAQs can
always be found in the Internet.
Tel.:
Fax:
Email:
Internet:
[phone]
[phone]
[email protected]
http://www.siemens.de/siclock (German)
http://www.siemens.com/siclock (international)

Contents-4SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Table of contents
Preface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Preface-3
Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Contents-4
1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2 Functional description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
3 Mounting and installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
4 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4.1 Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
4.2 Operating modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
4.2.1 Transparent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
4.2.2 Pulse mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
4.3 Parameter assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
5 Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
5.1 Voltage output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
5.2 Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
6 Optical input and output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
6.1 Multimode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
7 Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17
A Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-19
A.1 Directives and declarations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-19
A.2 Certificates and approvals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-20
B ESD guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-21
B.1 Electrostatic sensitive devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-21
B.2 Electrostatic charging of persons . . . . . . . . . . . . . . . . . . . . . . . . . . . B-22
B.3 Fundamental measures to protect against
static discharge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-23
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Index-24

1-5SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Safety instructions 1
If you have questions about the validity of the installation in the planned
environment, please contact your service representative.
Smooth and safe operations demand proper
transport, proper storage, installation and assembling as well as careful
operations and maintenance.
Caution
Please observe the safety instructions on the back of the cover sheet
of this documentation. You should not expand your device unless you have read
the relevant safety instructions.
Warning
Danger from line voltage
●Connection and disconnection may only be performed by a
qualified electrician!
●Connect or disconnect power supply cables only when the power is turned off.
Warning
Life-threatening > 60 VDC/VAC dangerous contact voltage
Take the following safety precautions when supplying the device with a
> 60 VDC/VAC dangerous contact voltage:
●Ensure that the protective conductor (PE) in the power supply cable is
connected to the PE terminal .
●There must be a means (main switch or circuit breaker) of
disconnecting the devices upstream in the supply system or the building
installation.
Caution
Danger from lines carrying a
> 60 VDC/VAC dangerous contact voltage
Ensure that connection cables carrying a
> 60 VDC/VAC dangerous contact voltage are secured against disconnection
by being pulled out. Lay the cables in cable ducts or cable channels and, if
necessary, secure the cables with cable ties.

1-6SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Repairs
Repairs to the device may only be performed by authorized specialists.
ESD guidelines
Modules containing electrostatic sensitive devices (ESDs) can be identified by the
following label:
Strictly follow the guidelines mentioned below when handling modules containing ESDs:
•Before working with modules containing ESDs, you must discharge all your
personal static e.g. by touching a grounded object.
•All devices and tools must be free of static charge.
•Always pull out the power plug before connecting or disconnecting modules
containing ESDs.
•Handle modules containing ESDs by their edges only.
•Do not touch any pins.
Warning
Unauthorized opening or improperly performed repairs can cause considerable
damage to property and/or danger to users.

2-7SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Functional description 2
The SICLOCK PCON pulse converter enables electrical and optical distribution
of time message frames and pulses. The advantage of data transmission via
fiber-optic cables lies in the high degree of interference immunity and the ability
to bridge great distances. The device has three electrical inputs and one optical
input as well as five electrical outputs and one optical output. The ES03 device
version is intended for connection to multimode fiber-optic cables.
The pulse converter can be operated in two different modes. In transparent mode,
the input signal is transmitted in parallel to all outputs without any change in the
pulse length. In pulse mode, the rising or falling edge of the input signal triggers
a pulse with a parameterizable length. This pulse is transmitted in parallel to all
electrical outputs. The device parameters are assigned via a DIP switch on the
front of the housing.
The device is equipped with a floating alarm contact for monitoring the data
transfer. The devices can be operated with a power supply in the range of
24 to 230 VDC or 48 to 230 VAC.

3-8SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Mounting and installation 3
The SICLOCK PCON is mounted on a 35mm DIN rail. The power supply is con-
nected to terminals 14 and 15 of the terminal strip X1, and must generally be con-
nected by a separate cable. The electrical inputs are also found on terminal strip
X1. All electrical outputs are found on terminal strip X2. In general, signal lines
should always be twisted and shielded control lines. The shield should be con-
nected to the equipotential bonding terminal of the electronics cabinet.
Fig. 3-1 Front plate with terminal marking

4-9SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Configuration 4
4.1 Block diagram
The following diagram shows the connection of the input and output interfaces.
All inputs are joined together internally by means of an OR function so that only
one input is allowed to be connected for transmission of an explicit signal. The
optical output is connected directly to the OR gate and cannot be influenced by
the device parameter assignment. The operating modes described in the follow-
ing sections can be used for electrical outputs. The parameters are assigned
exclusively via a DIP switch on the front of the housing.
Fig. 4-1 Block diagram
,QSXWV 2XWSXWV
',3VZLWFK
'LJLWDOORJLF
3&21 $ODUP
9
9
56
56
77<
)2&
! 
9
9
56
56
)2&

4-10SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
4.2 Operating modes
4.2.1 Transparent mode
In transparent mode, the input signal is transmitted unchanged to the output. It is
simply transferred to another electrical interface. This mode is always used to
transfer telegrams, DCF77 and IRIG signals.
4.2.2 Pulse mode
In this mode, a pulse with a constant pulse length is emitted at the output. In pulse
mode, it is possible to choose between three triggering methods. Pulse mode is
always used to transmit second and minute pulses
•In the case of automatic triggering triggering always occurs on the first pulse
edge of the input signal, i.e. triggering always occurs on the positive edge of a
high-active pulse and on the negative edge of a low-active pulse. This type of
triggering only functions for pulse widths of less than 300ms, and is therefore
used only in the SICLOCK environment. A pulse with the specified pulse
length is then emitted at all electrical outputs. This pulse can still be inverted
at the output, if required.
Fig. 4-2 Pulse mode with automatic triggering with a high-active input signal
Fig. 4-3 Pulse mode with automatic triggering with a low-active input signal
WSPD[PV
2XWSXWVLJQDO
,QSXWVLJQDO
WSPVPVPV
WS
+LJK
+LJK
/RZ
/RZ
WSPD[PV
2XWSXWVLJQDO
,QSXWVLJQDO
WSPVPVPV
WS
+LJK
+LJK
/RZ
/RZ

4-11SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
•Triggering on the positive edge of the input signal.
This type of triggering is only useful for a high-active input signal. A high-active
pulse with the specified pulse length is generated at all electrical outputs. The
output pulse can still be inverted, if required.
Fig. 4-4 Pulse mode with triggering on the positive edge of the input signal
•Triggering on the negative edge of the input signal.
This type of triggering is only useful for a low-active input signal. A low-active
pulse with the specified pulse length is generated at all electrical outputs. The
output pulse can still be inverted, if required.
Fig. 4-5 Pulse mode with triggering on the negative edge of the input signal
2XWSXWVLJQDO
,QSXWVLJQDO
WSPVPVPV
WS
+LJK
+LJK
/RZ
/RZ
2XWSXWVLJQDO
,QSXWVLJQDO
WSPVPVPV
WS
+LJK
+LJK
/RZ
/RZ

4-12SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
4.3 Parameter assignment
All device settings can be made by means of the DIP switch S1 on the front of the
housing.
•The mode is set with switches 1 and 2. The following table lists all possible
operating modes.
•The pulse length is set with switches 3 and 4. Four different pulse lengths can
be set in pulse mode.
Table 4-2 Switches 3 and 4
Table 4-1 Switches 1 and 2
Switch 1 Switch 2 Significance
OFF OFF Transparent mode
OFF ON Pulse mode with triggering on the positive edge
ON OFF Pulse mode with triggering on the negative edge
ON ON Pulse mode with automatic triggering
Switch 3 Switch 4 Significance
OFF OFF 1ms
OFF ON 100ms
ON OFF 10ms
ON ON 100ms

4-13SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
•Switch 5 can be used to invert the output signal of all electrical outputs.
•The SICLOCK PCON provides the option of monitoring all inputs or the
120 VDC voltage output. For this purpose, a check is made to determine
whether a status change takes place on the signal lines. If a steady signal of
an appropriate length is detected, an alarm contact is activated. Switch 6 can
be used to activate this monitoring function. Switch 7 is used to specify
whether the inputs or the output is to be monitored. Switch 8 can be used to
specify whether the alarm relay switches after 3 seconds or 3 minutes in the
event of a missing signal change.
Table 4-3 Switches 5 to 8
Switches Item Significance
5 OFF Electrical output signals not inverted
5 ON Electrical output signals inverted
6 OFF Monitoring deactivated
6 ON Monitoring activated
7 OFF Monitoring of inputs
7 ON Monitoring of 120 VDC voltage output
8 OFF Alarm after 3 seconds without signal change
8 ON Alarm after 3 minutes without signal change

5-14SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Outputs 5
5.1 Voltage output
The power supplies for the 24V/0.8A output and the 24 to 120 VDC/0.1A output
must also be connected externally. The amplitude of the output voltage for the
24V/0.8A output corresponds to the connected supply voltage (12 to 30 VDC).
For the 24 to 120 VDC/0.1 A output, the amplitude of the output voltage corre-
sponds to the connected supply voltage (24 to 120 VDC) minus at least 4V.
The following figure shows the interconnection of the 24V/0.8A output with the
associated power supply.
Fig. 5-1 24V/0.8A voltage output
/RDG
*1'
2XW
9
3&21
6,&/2&.



;

5-15SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
5.2 Redundancy
For highly reliable transmissions, two redundant transmission lines can be config-
ured and the isolated voltage outputs of the two devices at the end of the line can
be connected in parallel to the input of the device to be synchronized. If input
signal monitoring is activated, the voltage outputs will be disabled when an alarm
occurs. This setting must be assigned for low-active output signals. For a
high-active output signal, monitoring of the output circuit can be activated at the
120 VDC voltage output
Fig. 5-2 Redundancy at the isolated 120 VDC/0.1A voltage output
6,&/2&.
3&21
/RDG
9
2XW
0
9
2XW
0
6,&/2&.
3&21
;



;




6-16SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Optical input and output 6
The SICLOCK PCON has an optical input and output. They are provided for
connecting an 820nm multimode fiber-optic cable.
6.1 Multimode
The following table summarizes the launchable transmission power and the
receiving sensitivity of the SICLOCK PCON for various types of glass fiber. The
permissible line attenuation is returned as the result.
Table 6-1 Line attenuation
Type of glass fiber Fiber-optic cable
50/125µm
2.8 dB/km
Fiber-optic cable
62.5/125µm
2.8 dB/km
Fiber-optic cable
100/140µm
3.3 dB/km
Wavelength 820nm 820nm 820nm
Launchable transmis-
sion power PCON
-15.8 dBm -12 dBm -6.5 dBm
Receiving sensitivity of
the PCON
-25.4 dBm -25.4 dBm -25.4 dBm
Permissible fiber-optic
line attenuation includ-
ing plug connectors
and couplings (sys-
tem reserve 3dB)
6.6dB 10.4dB 15.9dB
Permissible lengths of
fiber-optic cable
Up to 2000m Up to 3500m Up to 4500m

7-17SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Technical specifications 7
Supply
Inputs
Voltage: 24-230 VDC or 48-230 VAC 50/60Hz
Power consumption: 0.03 to 0.5A
Connection: Terminal strip X1
Protection of mains power input: Miniature circuit breaker 6A with C characteristic
Display: Green LED
Electrical inputs: RS422, RS232
Voltage input 5 to 35V and 35 to 60V isolated
Connection: Terminal strip X1
Optical input: Version 2XV9450-1AR63-1SA2 multimode FOC 820nm
Connector: BOFC (ST-compatible with IEC 874/10)

7-18SICLOCK®PCON
Operating Instructions, 04/2012, A2B00056366E-01
Outputs
Alarm output
Dimensions, weight, and environment
Electrical outputs: RS422, RS232, TTY/20mA isolated
Voltage output 24 VDC/0.8A
(Supply voltage 12 to 30 VDC, maximum current 800mA),
Voltage output 120 VDC/0.1A isolated
(Supply voltage 24 to 120 VDC, maximum current 100mA)
Short-circuit strength: Permanently short-circuit-proof and monitored for temperature
Connection: Terminal strip X2
Optical output: Version 2XV9450-1AR63-1SA2 multimode FOC 820nm
Connector: BOFC (ST-compatible with IEC 874/10)
Display: Yellow LED
Relay contact: 1 changeover contact
DC: 120V 1A/30W
AC: 120V 1A/30W
Alarm monitoring time 3 secs or 3 min
Display: Red LED
Dimensions (WxDxH): 100x70x135mm
Weight: 460g
Ambient temperature: Operating mode: 0°C to +50°C
Storage: -25°C to +85°C
Relative humidity: Operating mode: 10% to 95% (no condensation)
Storage: 10% to 95%

A-19SICLOCK®PCON
Operating instructions, 04/2012, A2B00056366E-01
Appendix A
A.1 Directives and declarations
Notes on CE marking
The following applies to the product described in this documentation:
EMC Directive
The devices fulfill the requirements of EC Directive "89/336/EEC Electromagnetic
Compatibility", and in accordance with this CE marking are designed for the
following fields of application:
Declaration of conformity
The EC declaration of conformity and the corresponding documentation are made
available to authorities in accordance with the EC directives stated above. Your
sales representative can provide these on request.
Observance of installation guidelines
The installation guidelines and safety instructions given in this documentation
must be followed during commissioning and operation.
Connecting peripherals
The requirements for noise immunity are met when you connect a peripheral
suitable for an industrial environment according to EN 61000-6-2:2001.
Peripheral devices may only be connected by shielded cables.
Table A-1 Fields of application
Field of application Requirement for
Interference emission Interference immunity
Industrial environment EN 61000-6-4: 2001 EN 61000-6-2: 2001

A-20SICLOCK®PCON
Operating instructions, 04/2012, A2B00056366E-01
A.2 Certificates and approvals
DIN ISO 9001 certificate
The Siemens quality management system for all production processes
(development, production and sales) meets DIN EN ISO 9001 requirements.
This has been certified by DQS (the German society for the certification of quality
management systems).
EMC
Note
The approval or certification is located on the rating plate.
Table A-2 EMC guidelines USA
USA
General This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1 This device may not cause harmful interferences.
2 This device must accept any interference received, including inter-
ference that may cause undesired operation.
Shielded cables The use of shielded I/O cables is required when connecting this
equipment to any and all optional peripheral or host devices. Failure
to do so may violate FCC rules.
Modifications Siemens AG is not responsible for any radio television interference
caused by unauthorized modifications of this equipment or the
substitution or attachment of connecting cables and equipment other
than those specified by Siemens AG. The correction of interference
caused by such unauthorized modification, substitution or
attachment will be the responsibility of the user.
Canadian notice This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
