SINAMICS
DCM
SINAMICS DCM DC Converter
Operating Instructions
Firmware Version V1.5
12/2018
A5E34763375A
Preface
Safety instructions
1
Type spectrum,
ordering information
2
Description
3
Technical data
4
Transportation,
unpacking, installation
5
Connecting
6
Additional system
components
7
Commissioning
8
Operation
9
Descriptions of functions
10
Maintenance
11
Applications
12
Functional safety
13
Appendix A
A
Appendix B
B

Siemens AG
Division Process Industries and Drives
Postfach 48 48
90026 NÜ
RNBERG
GERMANY
A5E34763375A
Ⓟ
11/2018 Subject to change
Copyright © Siemens AG 2009 - 2018.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by
personnel qualified
for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A 3
Preface
Note
Information on connecting the unit
The inside front cover of the SINAMICS DC MASTER Operating Instructions contains a
summary of the key information required for connecting the unit.
Product name
The SINAMICS DCM documentation uses the following product names:
●SINAMICS DCM
●SINAMICS DC MASTER
Device firmware version
As these Operating Instructions went to print, SINAMICS DCM converters were being
supplied from the factory with the firmware release specified on the inside front page.
However, these Operating Instructions can, in principle, also apply to other firmware
versions.
●
Older firmware versions:
It is possible that not all of the functions described here are actually available.
●
Newer firmware versions:
It is possible that SINAMICS DCM may feature additional functions that are not described
in these Operating Instructions. Do not change any parameters that you cannot find in the
List Manual from their factory setting, and do not give parameters any values that are not
specified in the List Manual.
The firmware version is displayed using r50060[6].
Example:
01010203 displayed on the BOP20 means 01.01.02.03 →Version 1.1, Service Pack 2,
Hotfix 3
When required, you can obtain the current firmware from your local Siemens sales office.
Download of the current firmware version for registered users
(https://support.industry.siemens.com/cs/ww/en/view/44029688)

Preface
SINAMICS DCM DC Converter
4Operating Instructions, 12/2018, A5E34763375A
Note
Hardware/firmware compatibility
The hardware version of the Control Unit (CUD) must be taken into account when updating
the device firmware, see the following table.
The hardware version can be read from the labe
l on the right-hand side of the CUD.
CUD (print on label)
Executable firmware versions
C98043-A7100-
L1
-...
C98043-A7100-
L2
-...
C98043-A7100-
L100
-...
C98043-A7100-L200-...
1.1, 1.2, 1.3
C98043-A7100-
L3
-...
C98043-A7100-
L4
-...
C98043-A7100-
L103
-...
C98043-A7100-L204-...
All versions
A5E...
All versions
SINAMICS DCM documentation available
SINAMICS DCM DC Converters Operating Instructions
C
ontains all information on
ordering, installation, connecting, commissioning, maintaining, description of functions,
and service
SINAMICS DCM Control Modules Operating Instructions
C
ontains all information on
ordering, installation, connecting, commissioning, maintaining, descri
ption of functions,
and service
SINAMICS DCM List Manual (for DC converters and control modules)
Contains
parameter list, function diagrams, list of faults and alarms
SINAMICS free function blocks, function description
Includes a general description, list of parameters, the function block diagrams as well as
the list of faults and alarms.
Manuals and application notes on the Internet
The manuals and application documents are also available in the Internet:
Manuals (https://support.industry.siemens.com/cs/ww/en/ps/13298/man)
The list of general conditions available there include current supplements to the manuals.
The notes included in the general condition lists have a higher priority than the statements
made in the manuals.

Preface
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A 5
FAQ in the Internet
FAQ (https://support.industry.siemens.com/cs/ww/en/ps/13298/faq)
Service
You can find information on our services and regional contact persons in the Internet
(https://support.industry.siemens.com/sc/ww/en/sc)
Technical Support
Our technical support can provide you with technical assistance for products, systems, and
solutions:
Service (https://support.industry.siemens.com/sc/ww/en/sc)
Central hotlines for SINAMICS DCM technical support
European and African time
zone
Service Request
(https://support.industry.siemens.com/My/ww/en/requests
#createRequest)
America time zone
24-hour hotline: [phone]
Tel.: [phone]
Fax: [phone]
email (mailto:[e-mail])
8:00 to 17:00
Eastern Standard Time
Asia/Australia time zone Tel.: [phone]
Fax: [phone]
email (mailto:[e-mail])
7:30 to 17:30
Beijing local time
Spare parts
You can find information on spare parts
●In catalog D23.1
●Via the electronic spare parts catalog Spares On Web, after entering the serial number
and article number of your SINAMICS DCM in the Internet (registration required)
Spares on Web (https://www.sow.siemens.com/)
Websites of third parties
This publication contains hyperlinks to websites of third parties. Siemens does not take any
responsibility for the contents of these websites or adopt any of these websites or their
contents as their own, because Siemens does not control the information on these websites
and is also not responsible for the contents and information provided there. Use of these
websites is at the risk of the person doing so.

Preface
SINAMICS DCM DC Converter
6Operating Instructions, 12/2018, A5E34763375A
Use of OpenSSL
This product contains software that has been developed by the OpenSSL project for use in
the OpenSSL toolkit.
This product contains cryptographic software created by Eric Young.
This product contains software developed by Eric Young.
Compliance with the General Data Protection Regulation
Siemens respects the principles of data protection, in particular the data minimization rules
(privacy by design).
For this product, this means:
The product does not process neither store any person-related data, only technical function
data (e.g. time stamps). If the user links these data with other data (e.g. shift plans) or if he
stores person-related data on the same data medium (e.g. hard disk), thus personalizing
these data, he has to ensure compliance with the applicable data protection stipulations.
Further Internet links
Generic station description file (GSD) for
PROFIBUS (https://support.industry.siemens.com/cs/ww/en/view/98206128)
PROFINET (https://support.industry.siemens.com/cs/ww/en/view/98207877)

SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A 7
Table of contents
Preface ................................................................................................................................................... 3
1 Safety instructions................................................................................................................................. 17
1.1 General safety instructions .....................................................................................................17
1.2 Hearing protection...................................................................................................................21
1.3 Warning note relating to the off button of the AOP30.............................................................21
1.4 ESD-sensitive components.....................................................................................................22
1.5 Industrial security ....................................................................................................................23
1.6 Residual risks of power drive systems....................................................................................24
2 Type spectrum, ordering information ..................................................................................................... 25
2.1 Device article numbers ...........................................................................................................25
2.2 Key for the device article numbers .........................................................................................28
2.3 Rating plates, packaging label................................................................................................29
2.4 Ordering information for options and accessories ..................................................................30
2.5 Accessories.............................................................................................................................33
2.5.1 Mounting kit to increase the degree of protection to IP20 ......................................................33
3 Description............................................................................................................................................ 35
4 Technical data ...................................................................................................................................... 39
4.1 Load classes ...........................................................................................................................39
4.2 Duty cycles for 2Q applications ..............................................................................................40
4.3 Duty cycles for 4Q applications ..............................................................................................42
4.4 Environmental requirements...................................................................................................44
4.5 Unit data..................................................................................................................................45
4.6 Derating ..................................................................................................................................75
5 Transportation, unpacking, installation .................................................................................................. 77
5.1 Transportation, unpacking ......................................................................................................77
5.2 Installation...............................................................................................................................77
5.2.1 Dimension drawings................................................................................................................80
5.2.2 Installing options and accessories ..........................................................................................89
5.2.2.1 AOP30 operator panel ............................................................................................................89
5.2.2.2 Installing a second CUD .........................................................................................................89

Table of contents
SINAMICS DCM DC Converter
8Operating Instructions, 12/2018, A5E34763375A
6 Connecting ........................................................................................................................................... 91
6.1 Instructions for EMC-compliant drive installation................................................................... 92
6.1.1 Basic information about EMC ................................................................................................ 92
6.1.2 EMC-compliant drive installation (installation instructions).................................................... 95
6.1.3 Example of a cabinet configuration........................................................................................ 98
6.1.4 Arranging components for converter units........................................................................... 102
6.1.5 RFI suppression filter ........................................................................................................... 103
6.1.6 Information on line-side harmonics produced by converter units in a fully-controlled
two-pulse bridge circuit configuration (B6C and (B6)A(B6)C) ............................................. 104
6.1.7 Data on the line-side harmonics from converter units in a fully-controlled AC bridge
circuit B2C............................................................................................................................ 106
6.2 Cable routing into the unit .................................................................................................... 107
6.3 Block diagram with connection suggestion.......................................................................... 114
6.4 Power connections............................................................................................................... 123
6.5 Field supply .......................................................................................................................... 143
6.6 Line reactors ........................................................................................................................ 146
6.7 Fuses ................................................................................................................................... 149
6.7.1 Fuses for the field circuit ...................................................................................................... 149
6.7.2 Fuses for the armature circuit .............................................................................................. 150
6.7.3 Fuses in the Power Interface ............................................................................................... 155
6.8 Arrangement of terminals and connectors........................................................................... 156
6.9 Assignment of terminals and connectors............................................................................. 168
6.9.1 Power unit ............................................................................................................................ 169
6.9.2 Field circuit ........................................................................................................................... 172
6.9.3 Electronics power supply ..................................................................................................... 173
6.9.4 Fan ....................................................................................................................................... 174
6.9.5 Open-loop and closed-loop control section ......................................................................... 175
6.9.6 Assignment of the RS485 cable to the AOP30.................................................................... 187
6.9.7 Terminal assignment functional safety ................................................................................ 188
6.10 Installation notes for installation according to UL 508C....................................................... 189
7 Additional system components.............................................................................................................191
7.1 Option Board: Communication Board Ethernet CBE20 ....................................................... 192
7.1.1 Description ........................................................................................................................... 192
7.1.2 Safety instructions................................................................................................................ 192
7.1.3 Interface description............................................................................................................. 193
7.1.3.1 Overview .............................................................................................................................. 193
7.1.3.2 X1400 Ethernet interface ..................................................................................................... 194
7.1.4 Meaning of the LEDs ........................................................................................................... 195
7.1.5 Installation ............................................................................................................................ 197
7.1.6 Technical data...................................................................................................................... 197
7.2 SMC10 Sensor Module Cabinet-Mounted ........................................................................... 198
7.2.1 Description ........................................................................................................................... 198
7.2.2 Interface description............................................................................................................. 198
7.2.2.1 Overview .............................................................................................................................. 198
7.2.2.2 X500 DRIVE-CLiQ interface ................................................................................................ 199
7.2.2.3 X524 Electronics power supply............................................................................................ 199

Table of contents
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A 9
7.2.2.4 X520 encoder system interface ............................................................................................200
7.2.3 Connection example .............................................................................................................201
7.2.4 Meaning of the LED ..............................................................................................................201
7.2.4.1 Meaning of the LED on the Sensor Module Cabinet-Mounted SMC10................................201
7.2.4.2 Cause and rectification of faults............................................................................................202
7.2.5 Dimension drawing ...............................................................................................................202
7.2.6 Mounting ...............................................................................................................................203
7.2.7 Technical data.......................................................................................................................204
7.3 Sensor Module Cabinet-Mounted SMC30 ............................................................................206
7.3.1 Description ............................................................................................................................206
7.3.2 Safety instructions.................................................................................................................207
7.3.3 Interface description..............................................................................................................209
7.3.3.1 Overview ...............................................................................................................................209
7.3.3.2 X500 DRIVE-CLiQ interface .................................................................................................210
7.3.3.3 X524 electronic power supply...............................................................................................210
7.3.3.4 X520 encoder system interface ............................................................................................211
7.3.3.5 X521/X531 alternative encoder system interface .................................................................212
7.3.4 Connection examples ...........................................................................................................214
7.3.5 Meaning of the LEDs ............................................................................................................216
7.3.6 Dimension drawing ...............................................................................................................217
7.3.7 Mounting ...............................................................................................................................217
7.3.8 Protective conductor connection and shield support ............................................................219
7.3.9 Technical data.......................................................................................................................220
7.4 Terminal Module TM15 .........................................................................................................224
7.4.1 Description ............................................................................................................................224
7.4.2 Safety instructions.................................................................................................................224
7.4.3 Interface description..............................................................................................................225
7.4.3.1 Overview ...............................................................................................................................225
7.4.3.2 X500 and X501 DRIVE-CLiQ interface.................................................................................226
7.4.3.3 X524 electronic power supply...............................................................................................227
7.4.3.4 X520 bidirectional digital inputs/outputs ...............................................................................227
7.4.3.5 X521 bidirectional digital inputs/outputs ...............................................................................228
7.4.3.6 X522 bidirectional digital inputs/outputs ...............................................................................228
7.4.4 Connection example .............................................................................................................229
7.4.5 Meaning of the LEDs on the Terminal Module TM15 ...........................................................230
7.4.6 Dimension drawing ...............................................................................................................231
7.4.7 Installation.............................................................................................................................231
7.4.8 Protective conductor connection and shield support ............................................................233
7.4.9 Connector coding..................................................................................................................234
7.4.10 Technical data.......................................................................................................................235
7.5 Terminal Module TM31 .........................................................................................................237
7.5.1 Description ............................................................................................................................237
7.5.2 Safety instructions.................................................................................................................238
7.5.3 Interface description..............................................................................................................239
7.5.3.1 Overview ...............................................................................................................................239
7.5.3.2 X500/X501 DRIVE-CLiQ interfaces ......................................................................................240
7.5.3.3 X524 electronic power supply...............................................................................................241
7.5.3.4 X520, X530 digital inputs ......................................................................................................242
7.5.3.5 X521 analog inputs ...............................................................................................................243
7.5.3.6 Analog inputs current/voltage switch ....................................................................................244
7.5.3.7 X522 analog outputs/temperature sensor.............................................................................244

Table of contents
SINAMICS DCM DC Converter
10 Operating Instructions, 12/2018, A5E34763375A
7.5.3.8 X540 auxiliary voltage for the digital inputs ......................................................................... 245
7.5.3.9 X541 bidirectional digital inputs/outputs .............................................................................. 246
7.5.3.10 X542 relay outputs ............................................................................................................... 247
7.5.4 Connection example ............................................................................................................ 248
7.5.5 Meanings of the LEDs on the Terminal Module TM31 ........................................................ 249
7.5.6 Dimension drawing .............................................................................................................. 250
7.5.7 Installation ............................................................................................................................ 251
7.5.8 Protective conductor connection and shield support ........................................................... 252
7.5.9 Connector coding................................................................................................................. 253
7.5.10 Technical data...................................................................................................................... 254
7.6 Terminal Module TM150 ...................................................................................................... 255
7.6.1 Description ........................................................................................................................... 255
7.6.2 Safety instructions................................................................................................................ 256
7.6.3 Interface description............................................................................................................. 257
7.6.3.1 Overview .............................................................................................................................. 257
7.6.3.2 X500 and X501 DRIVE-CLiQ interfaces .............................................................................. 258
7.6.3.3 X524 Electronics power supply............................................................................................ 259
7.6.3.4 X531-X536 temperature sensor inputs ................................................................................ 259
7.6.4 Connection examples .......................................................................................................... 261
7.6.5 Meaning of the LEDs on the Terminal Module TM150 ........................................................ 263
7.6.6 Dimension drawing .............................................................................................................. 264
7.6.7 Installation ............................................................................................................................ 265
7.6.8 Protective conductor connection and shield support ........................................................... 266
7.6.9 Technical data...................................................................................................................... 267
8 Commissioning ....................................................................................................................................269
8.1 Commissioning checklist...................................................................................................... 270
8.1.1 Commissioning checklist...................................................................................................... 270
8.2 Switching on......................................................................................................................... 272
8.3 Commissioning using the BOP20 operator panel................................................................ 273
8.3.1 Preconditions ....................................................................................................................... 273
8.3.2 Commissioning steps........................................................................................................... 274
8.4 Commissioning using the AOP30 operator panel................................................................ 281
8.4.1 First commissioning ............................................................................................................. 281
8.4.1.1 First power-up ...................................................................................................................... 281
8.4.1.2 Full drive commissioning...................................................................................................... 283
8.4.2 Status after commissioning.................................................................................................. 286
8.4.3 Resetting parameters to factory settings ............................................................................. 287
8.5 Commissioning with the STARTER commissioning tool ..................................................... 287
8.5.1 STARTER commissioning tool............................................................................................. 287
8.5.1.1 Installing the STARTER commissioning tool ....................................................................... 288
8.5.1.2 Layout of the STARTER user interface ............................................................................... 288
8.5.2 Procedure for commissioning with STARTER ..................................................................... 289
8.5.2.1 Creating the project.............................................................................................................. 289
8.5.2.2 Configuring a drive unit ........................................................................................................ 298
8.5.2.3 Starting the drive project ...................................................................................................... 317
8.6 Activating function modules ................................................................................................. 321
8.6.1 Activating offline with STARTER.......................................................................................... 321
8.6.2 Activating online through parameters .................................................................................. 323

Table of contents
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A 11
8.7 Commissioning optional additional modules ........................................................................324
8.7.1 Terminal Modules (TM31, TM15, TM150) ............................................................................325
8.7.1.1 Commissioning with STARTER ............................................................................................325
8.7.1.2 Commissioning via parameter assignment...........................................................................328
8.7.2 Encoder evaluation (SMC10, SMC30)..................................................................................328
8.7.2.1 Add/commissioning (with STARTER) ...................................................................................329
8.7.2.2 Removal (with STARTER) ....................................................................................................333
8.7.3 CBE20 Communication Board Ethernet ...............................................................................333
8.7.3.1 Adding online into the drive ..................................................................................................333
8.7.3.2 Adding offline in STARTER ..................................................................................................334
8.7.3.3 Deleting from the drive online ...............................................................................................335
8.7.3.4 Deleting offline with STARTER.............................................................................................335
8.8 Drive optimization .................................................................................................................336
8.9 Manual optimization ..............................................................................................................344
8.9.1 Optimization of closed-loop armature current control...........................................................344
8.9.2 Optimization of closed-loop field-current control ..................................................................346
8.9.3 Optimizing the speed controller ............................................................................................347
9 Operation............................................................................................................................................ 349
9.1 Basic information ..................................................................................................................349
9.1.1 Parameter .............................................................................................................................349
9.1.2 Data sets...............................................................................................................................353
9.1.2.1 Function diagrams and parameters ......................................................................................355
9.1.2.2 Using data sets .....................................................................................................................356
9.1.3 Drive objects .........................................................................................................................357
9.1.4 Memory card functions..........................................................................................................359
9.1.5 BICO technology: Interconnecting signals............................................................................364
9.1.5.1 Binectors, connectors ...........................................................................................................365
9.1.5.2 Interconnecting signals using BICO technology ...................................................................366
9.1.5.3 Internal encoding of the binector/connector output parameters ...........................................367
9.1.5.4 Example: Interconnecting digital signals...............................................................................367
9.1.5.5 Information on BICO technology...........................................................................................368
9.2 Parameterizing using the BOP20 (Basic Operator Panel 20)...............................................368
9.2.1 General information about the BOP20..................................................................................368
9.2.2 Displays and using the BOP20 .............................................................................................373
9.2.3 Displaying faults and alarms.................................................................................................378
9.2.4 Controlling the drive using the BOP20..................................................................................379
9.3 Controlling via the AOP30 operator panel ............................................................................380
9.3.1 Overview and menu structure...............................................................................................381
9.3.2 Menu: Operation screen .......................................................................................................383
9.3.3 Parameterization menu.........................................................................................................384
9.3.4 Menu: Fault/alarm memory ...................................................................................................385
9.3.5 Menu: Commissioning/Service .............................................................................................386
9.3.5.1 Drive commissioning.............................................................................................................386
9.3.5.2 Device commissioning ..........................................................................................................387
9.3.5.3 AOP settings .........................................................................................................................387
9.3.5.4 Lists of signals for the operation screen ...............................................................................389
9.3.5.5 AOP30 diagnostics ...............................................................................................................392
9.3.6 Sprachauswahl/Language selection .....................................................................................393
9.3.7 Operation via the operator panel (LOCAL mode).................................................................393

Table of contents
SINAMICS DCM DC Converter
12 Operating Instructions, 12/2018, A5E34763375A
9.3.7.1 LOCAL/REMOTE key .......................................................................................................... 393
9.3.7.2 ON key/OFF key .................................................................................................................. 394
9.3.7.3 CCW/CW changeover.......................................................................................................... 395
9.3.7.4 Jogging................................................................................................................................. 395
9.3.7.5 Increase setpoint/Decrease setpoint ................................................................................... 395
9.3.7.6 AOP setpoint ........................................................................................................................ 396
9.3.7.7 Inhibiting AOP LOCAL mode ............................................................................................... 396
9.3.7.8 Acknowledging errors via the AOP ...................................................................................... 397
9.3.7.9 Timeout monitoring .............................................................................................................. 397
9.3.7.10 Operator inhibit lock/Parameters disable............................................................................. 397
9.3.8 Faults and alarms................................................................................................................. 399
9.3.9 Saving the parameters permanently .................................................................................... 401
9.3.10 Parameterization errors ....................................................................................................... 401
9.3.11 Assigning parameters to make AOP30 time-of-day master ................................................ 402
10 Descriptions of functions ......................................................................................................................403
10.1 Inputs/outputs....................................................................................................................... 403
10.1.1 Overview of inputs/outputs................................................................................................... 403
10.1.2 Digital inputs/outputs............................................................................................................ 403
10.1.3 Analog inputs ....................................................................................................................... 404
10.1.4 Analog outputs ..................................................................................................................... 405
10.2 Communication, IT security ................................................................................................. 405
10.3 Communication according to PROFIdrive ........................................................................... 405
10.3.1 Application classes .............................................................................................................. 408
10.3.2 Cyclic communication .......................................................................................................... 410
10.3.2.1 Telegrams and process data ............................................................................................... 410
10.3.2.2 Description of control words and setpoints .......................................................................... 413
10.3.2.3 Description of status words and actual values..................................................................... 419
10.3.2.4 Control and status words for encoders ................................................................................ 424
10.3.2.5 Extended encoder evaluation .............................................................................................. 433
10.3.2.6 Central control and status words ......................................................................................... 433
10.3.2.7 Diagnostics channels for cyclic communication................................................................... 436
10.3.3 Parallel operation of communication interfaces ................................................................... 438
10.3.4 Acyclic communication......................................................................................................... 441
10.3.4.1 General information about acyclic communication .............................................................. 441
10.3.4.2 Structure of orders and responses....................................................................................... 443
10.3.4.3 Determining the drive object numbers ................................................................................. 449
10.3.4.4 Example 1: Read parameters .............................................................................................. 449
10.3.4.5 Example 2: Write parameters (multi-parameter request) .................................................... 452
10.4 Communication via PROFIBUS DP ..................................................................................... 455
10.4.1 PROFIBUS connection ........................................................................................................ 455
10.4.2 General information about PROFIBUS................................................................................ 457
10.4.2.1 General information about PROFIBUS for SINAMICS ........................................................ 457
10.4.2.2 Example of a telegram structure for acyclic data acquisition............................................... 459
10.4.3 Commissioning PROFIBUS ................................................................................................. 461
10.4.3.1 Setting the PROFIBUS interface.......................................................................................... 461
10.4.3.2 PROFIBUS interface in operation ........................................................................................ 462
10.4.3.3 Commissioning PROFIBUS ................................................................................................. 463
10.4.3.4 Diagnostics options.............................................................................................................. 464
10.4.3.5 SIMATIC HMI addressing .................................................................................................... 464
10.4.3.6 Monitoring, telegram failure ................................................................................................. 466

Table of contents
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A 13
10.4.4 Direct data exchange ............................................................................................................468
10.4.4.1 Setpoint assignment in the subscriber..................................................................................470
10.4.4.2 Activating/parameterizing slave-to-slave communication.....................................................470
10.4.4.3 Commissioning of the PROFIBUS slave-to-slave communication .......................................472
10.4.4.4 GSD during operation ...........................................................................................................481
10.4.4.5 Diagnostics of the PROFIBUS slave-to-slave communication in STARTER .......................482
10.4.5 Messages via diagnostics channels .....................................................................................482
10.5 Communication via PROFINET IO .......................................................................................485
10.5.1 Activating online mode: STARTER via PROFINET IO .........................................................485
10.5.2 General information about PROFINET IO ............................................................................491
10.5.2.1 Real-time (RT) and isochronous real-time (IRT) communication .........................................492
10.5.2.2 Addresses .............................................................................................................................493
10.5.2.3 Data transmission .................................................................................................................494
10.5.2.4 Communication channels for PROFINET .............................................................................496
10.5.3 Drive control with PROFINET ...............................................................................................496
10.5.3.1 Media redundancy ................................................................................................................499
10.5.4 RT classes for PROFINET IO...............................................................................................499
10.5.5 PROFINET GSDML ..............................................................................................................505
10.5.6 Communication with CBE20 .................................................................................................505
10.5.7 Messages via diagnostics channels .....................................................................................506
10.5.8 Support of I&M data sets 1...4 ..............................................................................................510
10.6 Communication via SINAMICS Link .....................................................................................512
10.6.1 Basic principles of SINAMICS Link.......................................................................................512
10.6.2 Topology ...............................................................................................................................514
10.6.3 Configuring and commissioning............................................................................................515
10.6.4 Example ................................................................................................................................520
10.6.5 Communication failure when booting or in cyclic operation..................................................522
10.6.6 Examples: Transmission times for SINAMICS Link..............................................................523
10.6.7 Function diagrams and parameters ......................................................................................524
10.7 EtherNet/IP ...........................................................................................................................525
10.7.1 Connection of SINAMICS DCM with EtherNet/IP to Ethernet networks...............................525
10.7.2 Configuration of SINAMICS DCM for EtherNet/IP................................................................526
10.7.2.1 Setting the IP address and activating the EtherNet/IP protocol ...........................................526
10.7.2.2 Communication with the SINAMICS DCM............................................................................527
10.7.3 Examples of the use of a Rockwell PLC...............................................................................533
10.7.3.1 Configuration of a Rockwell PLC for the communication with SINAMICS DCM ..................533
10.7.3.2 Writing and reading parameters with Class 4xx ...................................................................536
10.8 Communication via Modbus TCP .........................................................................................538
10.8.1 Overview ...............................................................................................................................538
10.8.2 Configuring Modbus TCP via interface X1400 .....................................................................539
10.8.3 Mapping tables......................................................................................................................540
10.8.4 Read and write access using function codes .......................................................................543
10.8.5 Communication via data set 47 ............................................................................................545
10.8.5.1 Communication details..........................................................................................................546
10.8.5.2 Examples: Read parameter ..................................................................................................547
10.8.5.3 Examples: Write parameter ..................................................................................................548
10.8.6 Communication sequence ....................................................................................................549
10.8.7 Messages and parameters ...................................................................................................550
10.9 Serial interface with USS protocol ........................................................................................551

Table of contents
SINAMICS DCM DC Converter
14 Operating Instructions, 12/2018, A5E34763375A
10.10 Switch on, switch off, enable................................................................................................ 552
10.10.1 Switch on/Switch off (ON/OFF1) – Control word bit 0.......................................................... 552
10.10.2 OFF2 (disconnection) – Control word bit 1 .......................................................................... 555
10.10.3 OFF3 (quick stop) – Control word bit 2 ................................................................................ 555
10.10.4 Operation enable (enable) – Control word bit 3 ................................................................... 557
10.11 Safety shutdown (E-STOP).................................................................................................. 557
10.12 Setpoint channel .................................................................................................................. 558
10.12.1 Ramp-function generator ..................................................................................................... 558
10.12.2 Jog ....................................................................................................................................... 563
10.12.3 Creep ................................................................................................................................... 564
10.12.4 Fixed setpoint....................................................................................................................... 565
10.13 Encoder evaluation .............................................................................................................. 566
10.13.1 Actual speed values............................................................................................................. 567
10.13.2 Control and status words for encoders ................................................................................ 568
10.14 Speed controller................................................................................................................... 568
10.15 Adaptation of the armature and field current controller ....................................................... 572
10.16 Technology controller........................................................................................................... 575
10.17 Switch-on command for holding or operational brake ......................................................... 578
10.18 Switching on auxiliary circuits .............................................................................................. 581
10.19 Operating hours counter, unit fan ........................................................................................ 581
10.20 Thermal overload protection for the DC motor (I2t monitoring of the motor) ....................... 582
10.21 Measuring the motor temperature........................................................................................ 587
10.22 Speed-dependent current limitation ..................................................................................... 588
10.23 Dynamic overload capability of the power unit .................................................................... 591
10.23.1 Overview of functions........................................................................................................... 591
10.23.2 Configuring for dynamic overload capability ........................................................................ 592
10.24 Sensor for the ambient and/or air intake temperature ......................................................... 595
10.25 Calculating the thyristor blocking voltage ............................................................................ 596
10.26 Automatic restart.................................................................................................................. 598
10.27 Operation on a single-phase line supply.............................................................................. 598
10.28 Connecting units in parallel and in series ............................................................................ 600
10.28.1 6-pulse parallel connection .................................................................................................. 603
10.28.2 12-pulse parallel connection ................................................................................................ 609
10.28.3 6-pulse series connection .................................................................................................... 611
10.28.4 6-pulse series connection: controlled converter + uncontrolled converter .......................... 614
10.28.5 12-pulse series connection .................................................................................................. 616
10.28.6 12-pulse series connection: controlled converter + uncontrolled converter ........................ 618
10.28.7 Switchover of the power unit topology - option S50............................................................. 619
10.29 Field reversal........................................................................................................................ 620
10.29.1 Direction of rotation reversal using field reversal................................................................. 620
10.29.2 Braking using field reversal.................................................................................................. 622

Table of contents
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A 15
10.30 Serial interface with peer-to-peer protocol............................................................................624
10.30.1 Examples of peer-to-peer connections .................................................................................626
10.31 Expanding the SINAMICS DCM to include a second CUD ..................................................628
10.32 Terminal Module Cabinet TMC (option G63)........................................................................631
10.33 Runtime (operating hours counter) .......................................................................................631
10.34 Diagnostics ...........................................................................................................................632
10.34.1 Diagnostic memory ...............................................................................................................632
10.34.2 Trend recorder function.........................................................................................................633
10.34.3 Thyristor diagnostics .............................................................................................................633
10.34.4 Description of the LEDs on the CUD ....................................................................................635
10.34.5 Diagnostics via STARTER....................................................................................................638
10.34.5.1 Function generator................................................................................................................639
10.34.5.2 Trace function .......................................................................................................................642
10.34.6 Faults and alarms .................................................................................................................648
10.34.6.1 General information ..............................................................................................................648
10.34.6.2 Buffer for faults and alarms...................................................................................................651
10.34.6.3 Configuring messages ..........................................................................................................654
10.34.6.4 Parameters and function diagrams for faults and alarms .....................................................656
10.34.6.5 Forwarding faults and alarms ...............................................................................................657
10.35 CPU time load with SINAMICS DCM....................................................................................657
10.35.1 Maximum configuration.........................................................................................................659
10.35.2 Computation examples .........................................................................................................660
10.36 Free function blocks..............................................................................................................661
10.37 Drive Control Chart (DCC)....................................................................................................663
10.37.1 Loading the DCC technology option into the drive unit memory ..........................................664
10.37.2 CPU time load through DCC.................................................................................................666
10.37.3 Memory load through DCC ...................................................................................................667
10.37.4 Backing up the DCC diagrams .............................................................................................668
10.38 Write and know-how protection ............................................................................................669
10.38.1 Write protection.....................................................................................................................669
10.38.2 Know-how protection ............................................................................................................671
10.38.2.1 Copy protection.....................................................................................................................674
10.38.2.2 Configuring know-how protection .........................................................................................674
10.38.2.3 Loading know-how protected data to the file system............................................................678
10.38.3 Overview of important parameters........................................................................................683
11 Maintenance ....................................................................................................................................... 685
11.1 Upgrading firmware releases................................................................................................686
11.1.1 Upgrading the device firmware .............................................................................................687
11.1.2 Upgrading the DCC technology option .................................................................................690
11.2 Replacing components .........................................................................................................692
11.2.1 Replacing the fan ..................................................................................................................692
11.2.2 Replacing fuses ....................................................................................................................698
11.2.3 Replacing the CUD ...............................................................................................................700
11.3 Replacing the back-up battery in the AOP30 operator panel ...............................................702

Table of contents
SINAMICS DCM DC Converter
16 Operating Instructions, 12/2018, A5E34763375A
12 Applications .........................................................................................................................................705
12.1 Using SINAMICS DCM in shipbuilding ................................................................................ 705
12.2 Connecting an incremental encoder .................................................................................... 705
12.3 Use of the SINAMICS DCM in galvanizing and dip-painting plants..................................... 706
12.4 Using SINAMICS DCM as thyristor controller in heating applications................................. 708
13 Functional safety..................................................................................................................................709
13.1 Functional safety: Deactivated – Activated .......................................................................... 709
13.2 General technical specifications of the DCM (6RA80)......................................................... 709
13.3 Standards............................................................................................................................. 710
13.4 Fundamental safety technology principles........................................................................... 711
13.4.1 Standard stop functions ....................................................................................................... 711
13.4.1.1 Emergency Off and Emergency Stop .................................................................................. 711
13.4.2 Standard safety functions according to EN 61800-5-2 ........................................................ 712
13.4.2.1 Safe Torque Off (STO)......................................................................................................... 712
13.4.2.2 Safe Stop 1 (SS1-t, time controlled) .................................................................................... 712
13.4.3 Safety functions of the SINAMICS DC MASTER................................................................. 713
13.5 Application examples ........................................................................................................... 714
13.6 Validating/checking the safety functions.............................................................................. 722
13.7 Diagnostics test.................................................................................................................... 722
13.8 Relationship between the test stop interval and SIL or PL and Cat. ................................... 722
13.9 Circuit breakers and power contactors ................................................................................ 723
13.10 Recommended safety relays ............................................................................................... 728
A Appendix A ..........................................................................................................................................729
A.1 Certifications and standards ................................................................................................ 729
A.2 List of abbreviations ............................................................................................................. 732
A.3 Environmental compatibility ................................................................................................. 740
A.4 Servicing .............................................................................................................................. 741
B Appendix B ..........................................................................................................................................743
B.1 Runtimes of the DCC blocks for SINAMICS DCM............................................................... 743
B.2 BOP20 status display during power-up ............................................................................... 748
Index ...................................................................................................................................................749

SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A 17
Safety instructions
1
1.1
General safety instructions
WARNING
Electric shock and danger to life due to other energy sources
Touching live components can result in death or serious injury.
•Only work on electrical equipment if you are appropriately qualified.
•Always observe the country-specific safety rules for all work.
Generally, the following six steps apply when establishing safety:
1. Prepare for disconnection. Notify all those who will be affected by the procedure.
2. Isolate the drive system from the power supply and take measures to prevent it being
switched back on again.
3. Wait until the discharge time specified on the warning labels has elapsed.
4. Check that there is no voltage between any of the power connections, and between any
of the power connections and the protective conductor connection.
5. Check whether the existing auxiliary supply circuits are de-energized.
6. Ensure that the motors cannot move.
7. Identify all other dangerous energy sources, e.g. compressed air, hydraulic systems, or
water. Switch the energy sources to a safe state.
8. Check that the correct drive system is completely locked.
After you have completed the work, restore the operational readiness by following the
above steps in the reverse order.
WARNING
Electric shock due to connection to an unsuitable power supply
When equipment is connected to an unsuitable power supply, exposed components may
carry a hazardous voltage that might result in serious injury or death.
•Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV
(Protective Extra Low Voltage) output voltages for all connections and terminals of the
electronics modules.

Safety instructions
1.1 General safety instructions
SINAMICS DCM DC Converter
18 Operating Instructions, 12/2018, A5E34763375A
WARNING
Electric shock due to equipment damage
Improper handling may cause damage to equipment. For damaged devices, hazardous
voltages can be present at the enclosure or at exposed components; if touched, this can
result in death or severe injury.
•Ensure compliance with the limit values specified in the technical data during transport,
storage and operation.
•Do not use any damaged devices.
WARNING
Electric shock due to unconnected cable shield
Hazardous touch voltages can occur through capacitive cross-coupling due to unconnected
cable shields.
•Connect cable shields and unused conductors of power cables (e.g. brake conductors)
at least on one side to the grounded housing potential.
WARNING
Electric shock if there is no ground connection
For missing or incorrectly implemented protective conductor connection for devices with
protection class I, high voltages can be present at open, exposed parts, which when
touched, can result in death or severe injury.
•Ground the device in compliance with the applicable regulations.
WARNING
Arcing when a plug connection is opened during operation
Opening a plug connection when a system is in operation can result in arcing that may
cause serious injury or death.
•Only open plug connections when the equipment is in a voltage-free state, unless it has
been explicitly stated that they can be opened in operation.
WARNING
Electric shock due to residual charges in power components
Because of the capacitors, a hazardous voltage is present for up to 5 minutes after the
power supply has been switched off. Contact with live parts can result in death or serious
injury.
•Wait for 5 minutes before you check that the unit really is in a no-voltage condition and
start work.
