Siemens MAMMOMAT Novation DR Installation manual

Opdimar
English
Print No.: SPB7-230.814.01.01.02 Doc. Gen. Date: 10.04
Replaces: n.a. (66 31 944)
© Siemens AG 2004
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_design,_are_reserved.
SP
Installation
on MAMMOMAT NovationDR
Installation and Start-Up

Opdima SPB7-230.814.01 Page 2 of 4 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
0 - 2 Revision
Document revision level
The document corresponds to the version/revision level effective at the time of system delivery. Revi-
sions to hardcopy documentation are not automatically distributed.
Please contact your local Siemens office to order current revision levels.
Disclaimer
The installation and service of equipment described herein is to be performed by qualified personnel
who are employed by Siemens or one of its affiliates or who are otherwise authorized by Siemens or
one of its affiliates to provide such services.
Assemblers and other persons who are not employed by or otherwise directly affiliated with or autho-
rized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or
one of its affiliates before attempting installation or service procedures.
Chapter Page Revision
All All 01

Contents 0 - 3
Siemens AG SPB7-230.814.01 Page 3 of 4 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
1 _______Prerequisites __________________________________________________1 - 1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1
Training of customer support engineers. . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
Text emphasis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
Documents required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Meters and appliances required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Tools required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Additional installation material required . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 3
Start-up, DHHS and X-ray decree area of application. . . . . . . . . . . . . . . . . . 1 - 3
Notes on start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 3
Checking and recording for the area of application of the X-ray decree
(§16 Germany). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 4
Checking and data recording in the USA . . . . . . . . . . . . . . . . . . . . . . 1 - 4
2 _______Protective measures for CCD camera ______________________________2 - 1
3 _______Protective measures ____________________________________________3 - 1
4 _______Preparatory work_______________________________________________4 - 1
Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
Biopsy controller, miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
Optional equipment and update kits. . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
5 _______Installation ____________________________________________________5 - 1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1
Sub-assemblies, overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 1
Removal of MAMMOMAT NovationDR stand covers . . . . . . . . . . . . . . . . . . 5 - 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2
Installation of biopsy controller holders . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3
Connection of cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Cables to CCD camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
Installation of cable duct. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 8
Modification of cable outlet cover . . . . . . . . . . . . . . . . . . . . . . . . . .5 - 8
Installation of workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9
Preparing the workstation table (option). . . . . . . . . . . . . . . . . . . . . . . 5 - 9
Connecting the workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 12
Strain relieving the cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 17
Installation of input/output devices. . . . . . . . . . . . . . . . . . . . . . . . . 5 - 18
Installation of monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 19
Fine adjusting the monitor settings . . . . . . . . . . . . . . . . . . . . . . . . 5 - 19
Connecting the workstation to the network . . . . . . . . . . . . . . . . . . . . 5 - 21
Page

0 - 4 Contents
Opdima SPB7-230.814.01 Page 4 of 4 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
Installation of Opdima printer (option) . . . . . . . . . . . . . . . . . . . . . . .5 - 22
Functional test (workstation table) . . . . . . . . . . . . . . . . . . . . . . . . .5 - 23
6 ______ Final procedures _______________________________________________6 - 1
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
Starting up the MAMMOMAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Starting up the workstation and login. . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Starting up the MO unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
Installation of software on OPDIMA WORKSTATION . . . . . . . . . . . . . . . 6 - 2
Mounting of covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3
Filling in of IVK list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3
Performing of DHHS maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 3
7 ______ Changes to previous version _____________________________________7 - 1
Page

1 - 1
Siemens AG SPB7-230.814.01 Page 1 of 4 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
Prerequisites 1
General 1
This installation instruction is valid for MAMMOMAT NovationDR with serial numbers
> 1100.
•Thewallsocket forthe power supplyfor thecomputersof Opdimarmustbeconnected
tothesame branchcircuit as theMAMMOMAT NovationDR powersupply
•ThisInstallationand Start-UpInstruction is validfor Opdimarsystems:
-withSUN workstationpartNo. 8383 106/ SunBlade 150with ASW3.1 andwithserial
No.W 10000

Opdima SPB7-230.814.01 Page 2 of 4 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
1 - 2 Prerequisites
Training of customer support engineers 1
Due to the technology used in this equipment, setup, service and maintenance may only
be carried out by a customer support engineer who has attended a training workshop or
has participated in at least one installation.
Text emphasis 1
DANGER indicates when there is an immediate danger that leads
to death or serious physical injury.
WARNING indicates a risk of danger that may lead to death or to
serious physical injury.
CAUTION used with the safety alert symbol indicates a risk of
danger that leads to slight or moderate physical injury and/or
damage to property.
NOTICE used without the safety alert symbol indicates a risk of
danger that if disregarded leads or may lead to a potential situa-
tion which may result in an undesirable result or state other than
death, physical injury or damage to property.
NOTE contains information provided with special emphasis to
facilitate proper use of the equipment or proper execution of a
procedure, i.e. hints, tips
.
DANGER
WARNING
CAUTION
NOTICE
NOTE

Prerequisites 1 - 3
Siemens AG SPB7-230.814.01 Page 3 of 4 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
Documents required 1
•Supplementtothe Instructionsfor UseMAMMOMATNovationDR - Opdimar
(includedinthe Opdimar delivery)
•MAMMOMAT1000/3000/3000Nova -Opdimar Service Instructions
(includedinthe Opdimar delivery)
•MAMMOMAT300/3000,MAMMOMAT 3000Modular incl.StereotacticBiopsy
AttachmentandOpdimarDHHS MaintenanceInstructions
(includedinthe Opdimar delivery)
•MAMMOMAT300/3000,MAMMOMAT 3000Modular incl.StereotacticBiopsy
AttachmentandOpdimarMeasurement Certificates
(includedinthe Opdimar delivery)
•MAMMOMATNovationDR-Opdimar Planning Guide
•MAMMOMATNovationDR-OpdimarInstallation andStart-Up
•MAMMOMATNovationDR -OpdimarWiring Diagram
•MAMMOMAT3000Installation andSetting InstructionsUpdateKit forStereotactic
BiopsyAttachment(where applicable)
Meters and appliances required 1
•Protectivegroundwire tester(44 15899RV090)
•ServicePC (e.g.Siemens-Nixdorf PCD3NSX/20orsimilar)with connectingcable, PCto
generator(partNo. 9900 440 RE999)
•Stereocalibrationphantom (includedin thedelivery)(part No.6430 701)
•AECcalibrationplexiglass, fourplates measuring 150mm x 150mm x19mm andone
platemeasuring150 mmx150 mmx 9,7 mm,part No.6561 232and65 61224
respectively
•Resolutionphantomwith atleast10 linepairs permm
Tools required 1
•Standardinstallationtools
•Electricdrillwith 5mm drill
Additional installation material required 1
•Extensionmainscord withat least threeoutlets, of protectiveearth type
Start-up, DHHS and X-ray decree area of application 1
Notes on start-up 1
Opdimaris adjusted, programmed and tested in the factory, leaving only the connection
to the on-site mains voltage, the functional tests and customer dependent adjustments to
be performed.

Opdima SPB7-230.814.01 Page 4 of 4 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
1 - 4 Prerequisites
Checking and recording for the area of application of the X-ray decree
(§16 Germany) 1
An X-ray unit can only be put into operation if an acceptance test has been performed
according to §16 RoeV. It is recommended that the responsible Customer Service
Engineer is present to assist the person responsible for this acceptance test.
Checking and data recording in the USA 1
Maintenance measurements must be made according to the instructions in MAMMOMAT
300/3000, MAMMOMAT 3000 Modular incl. Stereotactic Biopsy Attachment and Opdimar
DHHS Maintenance Instructions.
Sections
•Requiredlabels
•Reproducibility
•Automaticexposurecontrol (AEC)
The result must be recorded in the document MAMMOMAT 300/3000, MAMMOMAT 3000
Modular incl. Stereotactic Biopsy Attachment and OpdimarMeasurement Certificates.

2 - 1
Siemens AG SPB7-230.814.01 Page 1 of 2 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
Protective measures for CCD camera 2
The camera shall be used within 10230i C.
The camera shall be transported or stored within 0240i C.
The CCD camera is very sensitive to mechanical shocks and tem-
perature changes. In the camera shock and temperature sensors
are integrated.
Risk of damaging the equipment.
The camera has to be handled with extreme care.
When disconnected from the biopsy controller, the camera shall
always be stored in the attaché case delivered with the system.
Do not touch the pins in the contacts of the camera.
CAUTION

Opdima SPB7-230.814.01 Page 2 of 2 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
2 - 2 Protective measures for CCD camera
This page intentionally left blank.

3 - 1
Siemens AG SPB7-230.814.01 Page 1 of 2 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
Protective measures 3
It is very important that any intervention in the equipment shall start with disconnecting it
from the power supply with the main circuit breaker. To prevent accidental triggering of
high voltage and radiation, set the switch S2 (SS) on board D750 to OFF.
When switching off the workstation use the power off procedure
described in the Supplement to the Instructions for Use MAMMO-
MAT NovationDR- Opdimar.
Switching off the workstation before the software has been
closed down may cause damage to the files on the hard disc.
If the system is only switched off at the control panel or with the
circuit breaker CB S700, there is still voltage present within the
generator. See the wiring diagram for MAMMOMAT NovationDR.
Life-threatening electric shock hazard exists.
Disconnect mains cable and comply with the information on this
page.
After shut-down of the system, there may still be about 380 V DC
present on the intermediate circuit of the MAMMOMAT generator.
Life-threatening electric shock hazard exists.
A bleader resistor is connected over the output DC capacitors.
The DC voltage will discharge below 60 Volt in 3 minutes.
The voltage level is indicated by LEDs H3 and H4.
Observe the currently valid guidelines for handling electronics
endangered by electrostatic discharge.
Use ESD-equipment, ground prior to making contact and place
the components on a conductive surface.
The boards contain electrostatic highly sensitive components
requiring particular care in their handling.
Risk of damaging components.
CAUTION
WARNING
WARNING
CAUTION

Opdima SPB7-230.814.01 Page 2 of 2 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
3 - 2 Protective measures
This page intentionally left blank.

4 - 1
Siemens AG SPB7-230.814.01 Page 1 of 2 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
Preparatory work 4
Scope of delivery 4
The following parts are always included in the delivery of your equipment:
•TechnicalManualcomprising informationforinstallation, operationand service
•CCDcamerawith afixedcable
•Biopsycontrollerwith fivecablesand cableduct
•Stereocalibrationphantom, 6430 701(seepage 1-3)
•Workstationincluding:
-powersupply cable
-networkcable
-KVMswitch withcables
-MOunit withone power supplycable andonedata cable
-Mainunit includingCD drive
-Insome deliveries,the monitor, keyboardand mousemaybe delivered.In such case
theKVMswitch isnot needed.
If ordered, the following is delivered:
•Biopsyunit
•Compressionplatefor biopsyexamination
•Printedcircuitboard D702
•MAMMOMATsoftwareV2.2 orhigher
•Isolationp.c.board D707kit
•DICOMlicensekey
•Workstationtable
•Printer

Opdima SPB7-230.814.01 Page 2 of 2 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
4 - 2 Preparatory work
Unpacking 4
General 4
Workstation 4
The workstation is packed in a card board box which also contains technical
documentation and CDs for application software and operating system1.
Biopsy controller, miscellaneous 4
The biopsy controller is packed in a card board box together with cables, miscellaneous
installation material.
CCD camera
The CCD camera is packed in an attaché case. Keep the case for future use.
Optional equipment and update kits 4
If optional equipment and/or update kits are ordered, these are packed in separate boxes.
Follow the directional marks on the box during transport, storage
and unpacking.
1. Only needed if a software reinstallation is necessary (see MAMMOMAT 1000/3000 Nova - OpdimarService
Instructions). Store the documentation and software CDs in a proper place for future service use.
The CCD camera is very sensitive to mechanical shocks and tem-
perature changes. In the camera shock and temperature sensors
are integrated.
Risk of damaging the equipment.
The camera has to be handled with extreme care.
When disconnected from the biopsy controller, the camera shall
always be stored in the attaché case delivered with the system.
Do not touch the pins in the contacts of the camera.
NOTE
CAUTION

5 - 1
Siemens AG SPB7-230.814.01 Page 1 of 24 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
Installation 5
General 5
Before starting the installation, a backup of the installation parameters of the
MAMMOMAT NovationDR can be carried out. This may be omitted, if backup already
available.
1. ConnectaPC tothe MAMMOMATNovationDR andstart theservice program.
2. Select
Mainmenu=> Backup =>Copyinstallation area todisk=> All .
Thiswillstore theinstallation parameters onthe harddiskof thePC.
3. Select
Mainmenu=> Backup =>Copyinstallation area tofloppy=> All .
Thiswillstore theinstallation parametersonthe servicediskette.
4. Switchoffthe MAMMOMAT.
Sub-assemblies, overview 5
The components shall be placed according to the figure below.
The workstation shall be placed at least 1.5 m from the object
table of the stand.
X
Y
Z
mm
mm
mm
X
Y
Z
X
Y
Z
Z
X
Y
OPD00597
Biopsy
controller
Biopsy unit
CCD camera
Generator
Workstation
Stand with
X-ray unit
Workstation table
Fig. 1 MAMMOMAT 3000 Nova with digital biopsy and spot imaging system Opdimar
NOTE

Opdima SPB7-230.814.01 Page 2 of 24 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
5 - 2 Installation
Removal of MAMMOMAT NovationDR stand covers 5
5
The right/rear side cover should be removed.
The holes for fastening of the biopsy controller BC and of the cable tray below the BC
have been drilled in the factory.
There are two cable trays of different lenghts delivered, use the suitable one.
High voltage!
Life-threatening electric shock hazard exists.
Switch off the power to the system with the main circuit breaker.
WARNING

Installation 5 - 3
Siemens AG SPB7-230.814.01 Page 3 of 24 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
Installation of biopsy controller holders 5
The biopsy controller is attached to the rear cover of the stand. To install the holders
proceed as follows:
1. Installthethree holders(2/Fig. 2)byusing thenuts(3/Fig. 2).
2. Installthetwo standoffs(4/Fig. 2) byusing thescrews (5/Fig. 2)and thewashers
(6/Fig.2).
UP
OPD00267
985 – 5 mm
3
45
2
1
A
B
6
Fig. 2 Rear cover, from the back side

Opdima SPB7-230.814.01 Page 4 of 24 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
5 - 4 Installation
3. Installtherear cover(2/Fig. 3) onthe standandattach thebiopsy controller
(1/Fig.3)to theholders.Switch onthe power-on switchon thebiopsycontroller.
OPD00152
1
2
Fig. 3 Biopsy controller

Installation 5 - 5
Siemens AG SPB7-230.814.01 Page 5 of 24 Opdima
Medical Solutions Rev. 01 10.04 CS PS 24 Installation
Connection of cables 5
The biopsy controller is the central unit for the cable connections of OPDIMA. The cables
are connected to the biopsy controller according to the figure 6 on page 2-6, see wiring
diagram doc No: SPB7-230.051.09.03.02.
Perform the connection of cables according to data in the wiring diagram.

Opdima SPB7-230.814.01 Page 6 of 24 Siemens AG
Installation Rev. 01 10.04 CS PS 24 Medical Solutions
5 - 6 Installation
5
Cables to CCD camera 5
The CCD camera including cable with connectors marked X201 and X202 is connected to
the biopsy controller.
1. Connectthecable toX201 and X202on thebiopsycontroller, seeFig. 4.
2. Removethescrews (1/Fig.5) and removethe cover(2/Fig.5) ofthe object table
arm.
Sensitive electronic equipment!
Risk of damaging the camera.
Do not touch the pins in the contacts of the CCD camera.
OPD00453
X201
X202
X203
X204
Ferrite
X205 X206 X207 Mains cable
Protective earth cable
Fig. 4 Connection of cables to the biopsy controller
CAUTION
OPD00161
1 2
Fig. 5 Object table arm before installation
