Siemens MODULARIS Uro Plus Installation instructions

MODULARIS Uro Plus
English
Print No.: SPL1-130.163.01.02.02 Doc. Gen. Date: 09.99
Replaces: SPL1-130.163.01.01.02
© Siemens AG 1998
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_design,_are_reserved.
SP
Disassembly and Disposal Instruc-
tions
LITHOSTAR MODULARIS

MODULARIS Uro Plus SPL1-130.163.01 Page 2 of 4 Siemens AG
Rev. 02 09.99 TD PS 24 Medical Engineering
2 Disassembly and Disposal Instructions1
Fig. 1 Fig. 2
Fig. 3
4
1
3
2
5
6

Disassembly and Disposal Instructions 3
Siemens AG SPL1-130.163.01 Page 3 of 4 MODULARIS Uro Plus
Medical Engineering Rev. 02 09.99 TD PS 24
General 1
The disposal of hazardous materials (materials that may be harmful to the environment) in
a responsible manner is as important when disposing of the system/equipment as it is
when replacing components and assemblies while the system is in use.
Disposal list 1
The following list shows the components/assemblies of the MODULARIS and the hazard-
ous materials which they contain.
The corresponding assemblies/parts are to be disposed of by an authorized waste dis-
posal company.
Component/Assembly Location Hazard/Hazardous material Qty
ESWT cooling system 1/Fig. 1 Coolant R 134 A 0.1 kg
Board D3 4/Fig. 2 Lithium 1
Capacitor 2/Fig. 1 Oil 0.2 L
Spark gap 3/Fig. 1 Implosion 1
Support 5/Fig. 1 carbon fiber laminate ca. 6 kg
(without mechanics)
Ultrasoundapplicator
holder 6/Fig. 3 Oil 0.1 L

MODULARIS Uro Plus SPL1-130.163.01 Page 4 of 4 Siemens AG
Rev. 02 09.99 TD PS 24 Medical Engineering
4 Disassembly and Disposal Instructions
Changes to previous version 1
Completion Ultrasoundapplicator holder and Fig. 3.
TD PS 24/Wendt
TD SP / M. Heinlein
