Siemens SONOLINE G50 User manual

October 2002
7482255 Rev 01
Wiedergabe sowie Vervielfältigung dieser Unterlage, Verwertung und Mitteilung
ihres Inhalts nicht gestattet, soweit nicht ausdrücklich zugestanden. Zuwieder-
handlungen verpflichten zu Schadenersatz. Alle Rechte für den Fall der Patent-
erteilung oder GM-Eintragung vorbehalten.
Copyright  2002 Siemens Corporation.
Proprietary data, company confidential. All rights reserved.
Confié à titre de secret d´entreprise. Tous droits réservés.
Confiado como secreto industrial. Nos reservamos todos los derechos.
SONOLINE G50 and G60 S
Ultrasound Systems
Service Manual

Page ii 7482255 Rev 01 Siemens
October 2002
G50 and G60 S - Service Manual
Copyright
This document and its contents may not be copied, duplicated, reproduced,
translated, or converted to any electronic or machine-readable form in whole or
in part without prior written approval and authorization of Siemens Medical
Solutions USA, Inc.
Disclaimer
The installation and service of equipment described herein is to be performed
by qualified personnel who are employed by Siemens or one of its affiliates or
who are otherwise authorized by Siemens or one of its affiliates to provide such
services.
Assemblers and other persons who are not employed by or otherwise directly
affiliated with or authorized by Siemens or one of its affiliates are directed to
contact one of the local offices of Siemens or one of its affiliates before attempt-
ing installation or service procedures.
Siemens reserves the right to change system specifications at any time.
Trademarks
SONOLINE and syngo are registered trademarks of Siemens AG. DIMAQ,
SieScape, 3-Scape, Ensemble, Crescendo, microCase, Multi-D, MultiHertz,
QuickSet, SuppleFlex, and microCase are either registered trademarks or
trademarks of Siemens Medical Solutions USA, Inc.
CIDEX, Metricide, Omnicide, Klenzyme and Centronics are registered trade-
marks of their respective owners.
Microsoft, Windows, Windows CE, and Windows NT are registered trademarks
of Microsoft Corporation in the United States and/or other countries. Adobe,
Acrobat, and Reader are registered trademarks of Adobe Systems Incorpo-
rated.

Siemens 7482255 Rev 01 Page iii
October 2002
G50 and G60 S - Service Manual
Preface
This manual provides the customer service engineer (CSE) with detailed ser-
vice information for the G50 and G60 S ultrasound systems.
Document Conventions
The following conventions are employed in this document:
Italic formatted text indicates emphasis or the titles of books and manuals:
Call the UPTIME Service Center, The ANSI Standard, The User Manual.
The names of keys located on the system keyboard are presented upper-
case, bold font: CTRL, ALT, DELETE.
The names of controls, switches, and buttons located on the control panel
are presented in uppercase, bold font: SET.
Double quotes enclose chapter names and headings referenced in this
document: "Document Conventions" (page iii).
Device names are presented in uppercase: LPT1.
The names of spare parts are presented in lower case: power module,
DIMAQ-IP module, E module, and control panel.
Hazard Alerts
Alerts that notify the user and service personnel of potential hazards to the
equipment are presented in the following format:
Alerts that notify the user and service personnel of potential hazards to the
user, the patient, or to service personnel are presented in the following format:
Notes
Additional information, not related to a specific sequence of steps in the proce-
dure, is presented in the note format:
!
Warning: This manual is intended for use by trained service personnel. There are high voltages
present inside of the G50 and G60 S. Bodily harm and damage to the system may result from
untrained individuals opening the system.
!
Caution: Electrostatic discharge (ESD) can destroy the electronics contained
inside of this equipment. Don an ESD strap and observe ESD precautions when
servicing this equipment.
!
Warning: The G50 contains hazardous voltages that can range from 90 Vac to 264 Vac. These
voltages can cause serious injury or death. Only authorized service personnel are permitted to
remove protective covers and access the energized components of this system.
Note: The UPTIME Service Center maintains a list of the current options for this
equipment.

Page iv 7482255 Rev 01 Siemens
October 2002
G50 and G60 S - Service Manual

Siemens 7482255 Rev 01 Page v
October 2002
G50 and G60 S - Service Manual
Table of Contents
Preface .......................................................................................................... i-iii
Table of Contents .......................................................................................... i-v
Chapter 1: Introduction and System Requirements ........................1-1
1.0 Introduction ........................................................................................... 1-2
2.0 Performance Specifications .................................................................. 1-4
3.0 Mechanical and Electrical Specifications .............................................. 1-8
Chapter 2: System Architecture.........................................................2-1
1.0 System Architecture ............................................................................. 2-2
2.0 Component Locations .......................................................................... 2-8
3.0 System Bus Description ....................................................................... 2-15
Chapter 3: Power Distribution............................................................3-1
1.0 Power Connections .............................................................................. 3-2
Chapter 4: Removing and Replacing Spare Parts............................4-1
1.0 Introduction ........................................................................................... 4-2
2.0 Removing and Installing the Monitor .................................................... 4-3
3.0 Removing and Installing the Black and White Printer ........................... 4-10
4.0 Installing the Color Printer and the VCR ............................................... 4-14
5.0 Removing and Installing the DIMAQ-IP Module ................................... 4-24

Page vi 7482255 Rev 01 Siemens
October 2002
G50 and G60 S - Service Manual
6.0 Removing and Installing the Control Panel ........................................... 4-28
7.0 Removing and Installing the Keyboard ................................................. 4-33
8.0 Removing and Installing the MO Drive ................................................. 4-36
9.0 Removing and Installing the Host Module ............................................ 4-41
10.0 Removing and Installing the E Module ................................................. 4-44
11.0 Removing and Installing the Power Module .......................................... 4-47
12.0 Replacing the OEM Outlet Fuse ........................................................... 4-50
13.0 Removing and Installing the Third Array Port ....................................... 4-52
Chapter 5: Installing Equipment Options......................................... 5-1
1.0 Installing the G50 DIMAQ-IP ................................................................. 5-2
2.0 Installing the G50 Third Array Port ........................................................ 5-11
Chapter 6: Troubleshooting .............................................................. 6-1
1.0 Verifying the System Operation ............................................................ 6-2
2.0 Diagnostic Messages ............................................................................ 6-3
3.0 Diagnostic Indicators ............................................................................. 6-9
4.0 Troubleshooting the DIMAQ-IP ............................................................. 6-11
5.0 Rebooting the System Software ........................................................... 6-12
6.0 Diagnostic Flow Charts ......................................................................... 6-13
Chapter 7: Installing the Version 1.2 Software Update on the G60 S7-1
1.0 Installing the Version 1.2 Software Update ........................................... 7-2

Siemens 7482255 Rev 01 Page vii
October 2002
G50 and G60 S - Service Manual
2.0 Verifying the Operation of the Software ................................................ 7-7
Chapter 8: Software ...........................................................................8-1
1.0 Installing or Updating the System Software .......................................... 8-2
2.0 Installing or Updating the DIMAQ-IP Software ..................................... 8-7
3.0 Installing the Product Feature Keys ...................................................... 8-10
4.0 Uninstalling the Product Feature Keys ................................................. 8-14
5.0 Service Software Operation .................................................................. 8-17
6.0 Service Screens and Menus ................................................................ 8-19
Chapter 9: Planned Maintenance.......................................................9-1
1.0 Introduction ........................................................................................... 9-2
2.0 Required Tools and Documents ........................................................... 9-2
3.0 Required Materials ............................................................................... 9-2
4.0 Preparations ......................................................................................... 9-3
5.0 Cleaning the System ............................................................................ 9-3
6.0 Cleaning Subsystems ........................................................................... 9-3
7.0 Cleaning and Inspecting Transducers .................................................. 9-4
8.0 Safety Checks ...................................................................................... 9-5
9.0 System Test .......................................................................................... 9-6
10.0 Concluding the Maintenance ................................................................ 9-7
Appendix A: Installation Procedure ..................................................A-1

Page viii 7482255 Rev 01 Siemens
October 2002
G50 and G60 S - Service Manual
1.0 Unpacking the G50 and the G60 S ....................................................... A-2
2.0 Installing the G50 or the G60 S ............................................................. A-4
Appendix B: Installation Report........................................................ B-1
Appendix C: Spare Parts ................................................................... C-1
1.0 G50 and G60 S Spare Parts ................................................................. C-2
2.0 G50 and the G60 S Common Parts Photographs ................................. C-5
3.0 G50 Spare Parts Photographs .............................................................. C-11
4.0 G60 S Spare Parts Photographs ........................................................... C-15
Appendix D: Video Formats .............................................................. D-1
Appendix E: Output Data File Structure........................................... E-1
Appendix F: Component Designations ............................................ F-1
Appendix G: Maintenance Report..................................................... G-1
Siemens Office ..............................................................................................G-4
Measurement Devices ...................................................................................G-4
Comments .....................................................................................................G-4
System Information .......................................................................................G-4
Open Issues ..................................................................................................G-5
System Status ...............................................................................................G-5
Customer Service Engineer Sign-off .............................................................G-5
Planned Maintenance Checklist ....................................................................G-6

Siemens 7482255 Rev 01 Page ix
October 2002
G50 and G60 S - Service Manual
Appendix H: Fastener Reference.......................................................H-1

Page x 7482255 Rev 01 Siemens
October 2002
G50 and G60 S - Service Manual

Siemens 7482255 Rev 01 Page 1 of 12
October 2002
Chapter 1 - Introduction and System Requirements
Chapter 1: Introduction and System
Requirements
This chapter provides introductory information on the G50 and G60 S.
The following topics are included in this chapter:
1.0 Introduction ...................................................................................1-2
2.0 Performance Specifications ..........................................................1-4
3.0 Mechanical and Electrical Specifications ......................................1-8

Page 2 of 12 7482255 Rev 01 Siemens
October 2002
Introduction
1.0 Introduction
This section describes the G50 and the G60 S ultrasound systems and their
respective features, specifications, and options.
These systems both provide the following features:
2D imaging in fundamental and harmonic modes
M-mode
Color Doppler Velocity mode
Power Doppler mode
Directional Doppler mode
PW spectral Doppler mode
Duplex mode
Triplex mode
MultiHertz multiple frequency imaging with three selectable transmit fre-
quencies; resolution and speed selection for standard, penetration, and
detail
1.1 The G50
The SONOLINE G50 imaging system is a general purpose, high resolution
digital ultrasound system which uses a Microsoft Windows® operating system.
This ultrasound system supports linear and convex arrays using two ports.
The G50 is an economical version of the G60 S. It supports various options, but
it cannot be upgraded to the G60 S.
Table 1-1 lists the features available with the G60 S that are not present on the
G50; see Table 1-2 for a comparison of the G50 and the G60 S specifications.
Note: See "Installation Procedure" (page A-1) for instructions on unpacking,
installing, and licensing of the G50 and the G60 S.
Table 1-1 G60 S Features Not Present on G50
G60 S Feature G50 Feature or Comment
MultiBeam formation in B-mode or Color Not supported
Parallel or quad color processing Not supported
Precision motion capture Not supported
SynAps synthetic aperture Not supported
Linear B-mode steering Not supported
Color M-mode Not supported
CINE memory with P4-2 511 Not supported
C6-2 abdominal transducer G50 uses C5-2
P4-2 transducer Not supported

Siemens 7482255 Rev 01 Page 3 of 12
October 2002
Chapter 1 - Introduction and System Requirements
The current version of the G50 provides a choice of keyboard overlays in
English, German, French, Spanish, and Italian.
A third array port and the DIMAQ-IP image processor are offered as options for
the G50.
Three output devices are also available for the G50:
Black and white printer: P91W (Standard)
Color printer: CP900 (Option)
VCR (SVO 9500 or SVO 3500) with mounting kit and cables (Option)
1.2 The G60 S
The SONOLINE G60 S imaging system is a general purpose, high resolution,
digital ultrasound system which uses a Microsoft Windows® operating system.
This ultrasound system supports 2D, M-mode, pulsed-wave spectral doppler,
color flow, power mode, and continuous wave doppler.
The G60 S is a medium range (M3) ultrasound system designed for a wide
variety of applications.
See Table 1-1 for a list of the G60 S features that are not included in the G50.
See Table 1-2 for a comparison of the G50 and the G60 S specifications.
The current version of the G60 S provides a choice of keyboard overlays in
English, German, French, Spanish, and Italian.
The DIMAQ-IP (image processor) is provided as a standard component of the
G60 S.
Three output devices are also available for the G60 S:
Black and white printer: P91W (Standard)
Color printer: CP900 (Option)
VCR (SVO 9500 or SVO 3500) with mounting kit and cables (Option)
Note: The Operating Instructions [kit] for the G50 includes three documents:
Instructions for Use, System Reference, and the Transducer Reference. These
documents are available in various languages.
For information on the operation of the G50 and a detailed description of all con-
trols, consult the Instructions for Use.
Note: See "Installation Procedure" (page A-1) for instructions on unpacking,
installing, and licensing of the G60 S.
Note: The Operating Instructions [kit] for the G60 S includes three documents:
Instructions for Use, System Reference, and the Transducer Reference. These
documents are available in various languages.
For information on the operation of the G60 S and a detailed description of all
controls, consult the Instructions for Use.

Page 4 of 12 7482255 Rev 01 Siemens
October 2002
Performance Specifications
2.0 Performance Specifications
The following sections provide the performance specifications for the G50 and
G60 S.
2.1 System Specifications and Configurations
Table 1-2 lists the system specifications and configuration options for the
G60 S and the G50.
Table 1-2 System Configurations (Sheet 1 of 3)
Category Item G50 Specifications G60 S Specifications
Channels Process Channels Up to 256 process chan-
nels
Up to 768 process
channels
Transducer Max. Elements 192 192
Transducer Connectors 2 4 (3 array and 1 CW)
Display Mode A Mode Std Std
B Mode Std Std
Steer N/A Std
M Mode Std Std
PWD Mode (not on mechan-
ical sector)
Std Std
Hi-PRF 15.8 kHz 15.8 kHz
Steer Std (L/R/C) Std
CWD Mode(Blind) N/A Std
SCWD Mode N/A Std
CFM Mode Std Std
Steer Std (L/R/C) Std
Power Mode Std Std
Mc Mode Std Std
BcD(Triplex) Mode Std Std
Beamforming B-mode Single Single | PSP
CFM (color flow mode) Single PSP | QSP
Synthetic Aperture N/A Std (C6-2)
THI Std (C5-2) Std (P4-2, C6-2)
CINE B Mode 255 511
2B Mode 127 255
M Mode 15 s 15 s
D Mode 15 s 15 s
CFM Mode 255 511

Siemens 7482255 Rev 01 Page 5 of 12
October 2002
Chapter 1 - Introduction and System Requirements
Power Mode 255 511
Mc Mode 15 s 15 s
BcD(Triplex Mode) Std (only update mode) Std (only update mode)
DICOM N/A N/A
Stress Echo N/A Opt
Hard Drive Std w/ DIMAQ-IP Option Std w/ DIMAQ-IP
CINE clips Std w/ DIMAQ-IP Option Std w/ DIMAQ-IP
Monitor CRT 15-inch Color 15-inch Color
Video In / Out RGB In / Out 0 / 2 0 / 2
S-Video In/Out 1 / 2 1 / 2
Composite Video (BW) In/
Out
0 / 1 0 / 1
Composite Video (color) In/
Out
1 / 1 1 / 1
Audio In/Out 1 / 1 1 / 1
Remote In/Out 0 / 2 0 / 2
OEM Output Devices P91 B/W Std Std
CP900 Option Option
SVO-9500 Option Option
SVO-3500 Option Option
Communication Port Serial Port (RS-232-C) 2 2
USB (for DIMAQ-IP Stress
Echo printer only)
1with DIMAQ-IP Opt 1
Ethernet (from DIMAQ-IP) 1with DIMAQ-IP Opt 1
Storage Media 640 MB MO Drive Standard Standard
HDD Std w/ DIMAQ-IP Option Std w/ DIMAQ-IP
CD-RW Std w/ DIMAQ-IP Option Std w/ DIMAQ-IP
AC Outlets Four outlets providing 480
VA total
Standard Standard
Control Panel Stroke key Yes Yes
Full key Yes(Stroke) Yes(Stroke)
Track ball 1 track ball 1 track ball
LCD (Sub Control Panel) Yes Yes
Languages Std 5 language overlays
(English, German,
French, Spanish, Italian)
Std 5 language overlays
(English, German,
French, Spanish, Ital-
ian)
Table 1-2 System Configurations (Sheet 2 of 3)
Category Item G50 Specifications G60 S Specifications

Page 6 of 12 7482255 Rev 01 Siemens
October 2002
Performance Specifications
2.2 Supported Transducer Specifications
Table 1-3 lists the specifications for the transducers supported by the G50 or by
the G60 S.
Physio Input ECG N/A Std
ECG DC In Opt Opt
Foot SW Opt Opt
Table 1-2 System Configurations (Sheet 3 of 3)
Category Item G50 Specifications G60 S Specifications

Siemens 7482255 Rev 01 Page 7 of 12
October 2002
Chapter 1 - Introduction and System Requirements
Table 1-3 Supported Transducers
Transducer
G50 Compatible
G60 S Compatible
Type
Manufacturer
Elements
Radius
2D Fundamental
2D Tissue Harmonic Imaging
(Receive Frequencies)
Color, PW, CW Doppler
2D Steering
Doppler Steering
C5-2 (128 Ch) Yes C MCI 128 55 2.6 / 3.5 / 5.0 4.4 T / 5.0 T 2.6 / 3.5 C6-2(SPAT) Yes C MCI 192 55 2.8 / 3.5 / 5.0 4.2 T / 5.2 T 2.6 / 3.5 EV9-4(SPAT) Yes Yes C (Endo-V) MCI 192 13 4.2 / 6.5 / 8.0 5.2 / 7.0 EC9-4 Yes Yes C (Endo-C) STI 128 10 4.2 / 6.5 / 9.0 5.2 / 7.0 7.5L70 Yes Yes L MCI 192 - 5.0 / 7.5 / 10 5.2 / 7.0 6° 6° L10-5(SPAT) Yes Yes L MCI 192 - 6.5 / 7.5 / 10 5.2 / 7.0 12° 12° / 22° VF13-5 Yes Yes L STI/SMS 192 - 8.0 / 10 / 12 7.0 6° 6° P4-2 Yes PA MCI 64 - 2.1 / 2.5 / 3.0 3.2 T / 3.6 T 2.1 / 2.6 CW2 Yes Pencil CW STI 2 - 2.0

Page 8 of 12 7482255 Rev 01 Siemens
October 2002
Mechanical and Electrical Specifications
3.0 Mechanical and Electrical Specifications
This section provides the mechanical and electrical specifications for the G50
and the G60 S.
3.1 Mechanical Specifications
This section lists the dimensions and weight of the G50 and the G60 S.
3.1.1 Dimensions
Table 1-4 lists the dimensions of the G50 and the G60 S system.
3.1.2 Weight
Without peripherals (OEMs) installed, the G50 and the G60 S weigh 130 kg
(287 lb).
3.2 Operating and Storage Environments
This section defines the environmental conditions under which the G50 and the
G60 S can operate.
Table 1-4 G60 S Dimensions
Dimension Value
Width 510 mm (20.1 inches)
Depth 798 mm (31.4 inches)
Height 1422 mm (55.98 inches)
!
Warning: The G50 and the G60 S weighs 130 kg (287 lb) and represents a lifting hazard;
attempting to lift this system manually can cause serious injury. Instructions for lifting the G50
and the G60 S, when enclosed in its shipping container, are provided on the container. Once
un-boxed from the shipping container, the system is not designed for lifting; transport it on its
casters.
!
Caution: Excessive temperature, humidity, vibration and other environmental
parameters can affect the operation and reliability of the G50 and the G60 S. Do
not attempt to operate this system in extreme environments. Refer to the envi-
ronmental specifications provided.

Siemens 7482255 Rev 01 Page 9 of 12
October 2002
Chapter 1 - Introduction and System Requirements
3.2.1 Temperature Specifications
The G50 and the G60 S can be operated in the environment listed in Table 1-5.
3.2.2 Humidity Specifications
The G50 and the G60 S are designed to operate in an environment that can
experience humidity conditions ranging from 30% to 85% relative humidity,
non-condensing. During storage and transport, the G50 and the G60 S can
withstand from 0% to 95% relative humidity, non-condensing.
3.2.3 Altitude
The G50 and the G60 S design can operate at altitudes from 1060 hPa (-400 m
or -1312 feet) to 700 hPa (3050 m or 10,000 feet).
!
Caution: The G50 and the G60 S and the installed peripherals (OEMs) contain
cooling fans that are required to maintain the equipment at acceptable operating
temperatures. Over-temperature conditions can impair the accuracy of the sys-
tem and damage its components. Do not attempt to operate the G50, the G60 S,
or the installed peripherals if any fan becomes inoperable.
See "Diagnostic Indicators" (page 6-9): LED 8 illuminates when the temperature
in the E module exceeds the over-temperature limit of 80 °C (176 °F). Consult
the Instructions for Use for information on the warning message displayed when
operating temperatures are exceeded.
Table 1-5 Temperature Specifications
Specification Value
System Operating Temperature(a) 10 °C to 40 °C (50 °F to 104 °F)
System Transport Temperature -10 °C to 55 °C (14 °F to 131 °F)
Array Transducer Operating Temperature 10 °C to 40 °C (50 °F to 104 °F)
Array Transducer Transport Temperature -10 °C to 60 °C (14 °F to 140 °F)
Mechanical Sector Transducer Operating Temperature 20 °C to 40 °C (68 °F to 104 °F)
Mechanical Sector Transducer Transport Temperature -5 °C to 50 °C (23 °F to 122 °F)
Pencil CW Transducer Operating Temperature 10 °C to 40 °C (50 °F to 104 °F)
Pencil CW Transducer Transport Temperature -10 °C to 60 °C (14 °F to 140 °F)
(a) Operation of the MO drive is guaranteed to 35 °C (95 °F)

Page 10 of 12 7482255 Rev 01 Siemens
October 2002
Mechanical and Electrical Specifications
3.3 Power Specifications
The G50 and the G60 S can be provided in the three power supply
configurations listed in Table 1-6. See Figure 3-2 for internal voltages and
connections.
Table 1-7 lists the power demand of the G50 and the G60 S system.
Table 1-8 presents the fuse ratings for the three versions of the G50 and the
G60 S.
!
Warning: The G50 and the G60 S contain hazardous voltages that can range from 90 Vac to
264 Vac. These voltages can cause serious injury or death. Only authorized service personnel
are permitted to remove protective covers and access the energized components of this sys-
tem.
Table 1-6 Voltage Supply Specifications
Nominal Voltage
Supply
Specification
Acceptable Voltage Supply
Range
Supply Frequency
Specification
100 Vac 90.0 Vac to 110.0 Vac 50 Hz or 60 Hz
115 Vac 97.75 Vac to 132.25 Vac 50 Hz or 60 Hz
230 Vac(a) 195.5 Vac to 264.5 Vac 50 Hz or 60 Hz
(a) The 230 V rated system and OEM peripherals will operate properly with a supply of 195.5 Vac to
264.5 Vac and 47 Hz to 63 Hz. 250 Vac rated components can be employed with this configura-
tion.
Note: The voltage supply for a specific G50 or G60 S is fixed and cannot be
changed.
Table 1-7 Power Supply Specifications
Device Demand Specification(a)
(a) The VA values provided in this table includes the 480 VA consumed by the system out-
lets.
100 Vac System 1050 VA demand at nominal operating voltage
115 Vac System 1050 VA demand at nominal operating voltage
230 Vac System 1050 VA demand at nominal operating voltage
Note: The system outlets are capable of supplying a total of 480 VA; this 480 VA
is included in the total demand specification listed in Table 1-7.
Table 1-8 Fuse Ratings
Nominal System Voltage Rating Fuses Required Part Number
100 Vac 6.3 A, 250V, slow blow (2 fuses) 07478774
115 Vac 6.3 A, 250V, slow blow (2 fuses) 07478774
230 Vac 4.0 A, 250V, slow blow (2 fuses) 07478782
