Siemens Prisma 3T User manual

Revision Date: 3/13/2019
Siemens Prisma 3T MRI Scanner
User Guide
Ahmanson-Lovelace Brain Mapping Center
University of California, Los Angeles

Revision Date: 3/13/2019
BMC Contacts............................................................................................................................... 1
Scanner Operation........................................................................................................................ 2
How to do a “Standby” Reboot............................................................................... 2
How to Turn Off the MRI Scanner/Computer (Full Shutdown)............................. 3
How to Turn on the MRI Scanner/Computer ......................................................... 4
MR Scanner Error Save Log................................................................................... 4
How to Check the System Manager........................................................................ 5
How to Restart the Coldhead.................................................................................. 6
How to Reboot the Chiller...................................................................................... 7
Export and Save Raw Data Files (.RDA and Raw) ................................................................... 8
How to Map a Non-Dicom Network Folder on the Scanner Console.................... 8
How to Create a Spectroscopy .RDA File .............................................................. 8
How to Transfer Raw Data Using TWIX Software................................................ 9
Prisma Cleanup Procedures....................................................................................................... 10
General Cleanup Guidelines................................................................................. 10
Squeeze Ball/Button Alarm........................................................................................................ 11
What to do when the Squeeze Ball/Button Alarm Goes Off................................ 11
Reset the Table...................................................................................................... 11
How to Run the Daily Stability Warmup ................................................................................. 12
Setting up the Phantom......................................................................................... 12
Register Phantom.................................................................................................. 12
Running Scans ...................................................................................................... 12
Registration Pictures............................................................................................. 13
How to Run the ABCD Phantom QA........................................................................................ 14
Setting up the Phantom......................................................................................... 14
Register the Phantom............................................................................................ 15
Running Scans ...................................................................................................... 16
Registration Pictures............................................................................................. 17
How to Trigger Test Stimuli/Tasks........................................................................................... 18
Setting up the Phantom......................................................................................... 18
Register Phantom.................................................................................................. 18
Running Scans ...................................................................................................... 18
Registration Pictures............................................................................................. 19
Coil Warnings - Protocol Was Fixed......................................................................................... 20
Main Reasons for Coil Warnings.......................................................................... 20
Anterior or Posterior Protocol Fixed Warning Messages..................................... 20
Resolution............................................................................................................. 20
Wrong Coil Protocol Fixed Warning Messages ................................................... 20
Prisma VE11C Software Bugs................................................................................................... 22
AutoAlign Re-Run Failure.................................................................................... 22
AP/PA Copy Reference Issue............................................................................... 22
Reconstruction Error (aka Blob error).................................................................. 23
Prisma VE11C Scanner Warnings/Messages/Errors.............................................................. 24
Adjustment Measurement Was Aborted............................................................... 24
Gradient Power Amplifier Warning...................................................................... 24
Participant Registration Errors.............................................................................. 25

Revision Date: 3/13/2019
Slice Timing for BOLD Sequences and other BOLD Questions ............................................ 26
Preparation Scans related to Regular BOLD Sequences........................................................ 27
Current Designs Button Box and Trigger Setup (FORP 932)................................................ 28
Device Selection ................................................................................................... 28
Response Settings ................................................................................................. 28
Troubleshooting.................................................................................................... 29
Goggle Setup................................................................................................................................ 31
Tech Remote (Talk Box) ...................................................................................... 31
Visuastim Controller............................................................................................. 31
Troubleshooting.................................................................................................... 32
Resonance Technology Tech Remote (Talk Box) Setup.......................................................... 33
Volume Settings.................................................................................................... 33
Audio Input........................................................................................................... 33
Comm. Mode settings........................................................................................... 33
Tech Remote Reset ............................................................................................... 34
Siemens Talk Box Setup............................................................................................................. 35
Optoacoustics Headphone and Microphone Setup.................................................................. 36
Positioning the Participant.................................................................................... 36
Setting up the Opto Console................................................................................. 36
Using Active Noise Cancellation.......................................................................... 37
Troubleshooting Tips............................................................................................ 38
BOLDScreen LCD...................................................................................................................... 39
Specifications........................................................................................................ 39
Turning on the LCD.............................................................................................. 39
Positioning the Participant.................................................................................... 39
Troubleshooting Tips............................................................................................ 40
How to use E-Prime with the Desktop Computer and LCD................................................... 41
Duplicate/Mirrored Display with E-Prime............................................................ 41
Extended Display with E-Prime............................................................................ 41
Switching from Extended Display to Duplicate/Mirrored Display ...................... 41
HCP Physiological Device Setup................................................................................................ 42
ECG/Respiratory Setup......................................................................................... 42
Pulse Setup............................................................................................................ 42
How to Use FIRMM to Monitor Motion during BOLD scans................................................ 43
Quick Overview.................................................................................................... 43
Setup the Scanner Console.................................................................................... 43
Setup the Computer to View FIRMM .................................................................. 43
Using FIRMM....................................................................................................... 44
HCP Guidelines (see full HCP SOP for more details).......................................... 46
After the Scan is Complete................................................................................... 46
How to Use the MR Camera...................................................................................................... 47
Quick Overview.................................................................................................... 47
Equipment............................................................................................................. 47
Camera Setup........................................................................................................ 47
Participant Setup................................................................................................... 48
Camera Cleanup.................................................................................................... 48

Revision Date: 3/13/2019
Troubleshooting Tips............................................................................................ 48
Equipment Manuals.................................................................................................................... 49
Current Designs Button Box and Trigger Manual - Forp 932.............................. 49
ViewPoint Eyetracker User Guide*...................................................................... 49
ViewPoint Eyetracker Data Analysis Guide*....................................................... 49
Optoacoustics Manual........................................................................................... 49
MRI Safety Manual............................................................................................... 49
Movie List.................................................................................................................................... 50

Revision Date: 3/13/2019
1
BMC Contacts
1. Ludmila Budilo
Building Manager
x52699
2. Mary Susselman
PET/MRI Tech
x64291
3. Trent Thixton
Lead MRI Tech
x59217
4. Darin Williams
Engineer
x64291
5. Dr. Roger Woods
Center Director
x44057
6. BMC Techs
[email protected]
[phone]
7. BMC Emergency ONLY Line: 323-999-1593

Revision Date: 3/13/2019
2
Scanner Operation
How to do a “Standby” Reboot
This type of reboot clears most errors and takes approximately 10 minutes
1. Make sure the scanner bed is at the home position (all the way up and all the way out)
2. If a coil is on the table, all element should be plugged in
3. Click the “System” tab at the top of the screen
4. Click on “Control”
5. Click the “Meas & Recon” Tab
6. Click “Standby”
7. Click “Yes” to the pop up message if needed
8. The system will take 1-2 minutes to turn off –you will hear a “clunk” when the
equipment shutdowns and the LCD screen in the scanner room will turn off

Revision Date: 3/13/2019
3
9. Wait a few seconds and then press the “system on” button on the Siemens scanner control
box located on the wall next to the MR Scanner window
10. When the scanner starts booting up, the LCD screen in the scanner room will turn back
on
11. It will take approximately 6 minutes for the system to completely boot up
How to Turn Off the MRI Scanner/Computer (Full Shutdown)
This type of full shutdown takes approximately 20 minutes –try this method if a “Standby”
reboot did clear the issue
1. Make sure the scanner bed is at the home position (all the way up and all the way out)
2. If a coil is on the table, all element should be plugged in
3. Click the “System” tab at the top of the screen
4. Click on “End Session”
5. Click “Shutdown System”
6. It will take approximately 5 minutes before you see “it is now safe to turn off your
computer”

Revision Date: 3/13/2019
4
7. Press the blue “system off” button on the Siemens scanner control box located on the
wall next to the MR Scanner window
How to Turn on the MRI Scanner/Computer
1. You must first press the “system on” button on the Siemens scanner control box located
on the wall next to the MR Scanner window
2. It will take approximately 15 minutes for the system to completely boot up
3. After a successful reboot you will hear 3 beeps
MR Scanner Error Save Log
1. If you ever have a scanner problem that requires you to reboot, it is very important to
make a MR Save Log entry BEFORE you reboot the system
2. This log entry helps the Siemens engineer isolate the scanner problem and expedite the
system repair. To make a MR Save Log entry, you must do the following:
At the top of the screen –click system, then control, then tools
Click on “Save system log files”
oYou will see a box pop up with script on a black background, LEAVE
THIS ALONE!
oAnother box will pop up where you can input the problem
oFill out the “User” section and then click OK
oYou must wait until the black pop box with script closes before you can
proceed to reboot, scan etc
3. Please email [email protected] with details of the problem

Revision Date: 3/13/2019
5
How to Check the System Manager
1. Click the “System”tab at the top of the screen
2. Click on “Control”
3. You will get a “System Manager” pop-up box - within the “System Manager” box you
can check that the “Host,” “Meas & Recon ” and “Periphery” components are working
properly

Revision Date: 3/13/2019
6
How to Restart the Coldhead
1. In case of a power-surge, or other problem, the Coldhead may need to be restarted
2. You will know the Coldhead has been shut off if you do NOT hear the steady “chirping”
noise in the scanner room
3. Enter the equipment room (through the sliding glass door) and look at the south wall (as
shown below)
4. The coldhead is the white “box” next to the large cabinet
5. Walk over and look at the front of the coldhead and you will see the Coldhead controls
(shown above)
6. Press the ON button and the Coldhead should turn back on
7. Please be sure to notify BMCTec[email protected] and/or Dr. Woods if this occurs

Revision Date: 3/13/2019
7
How to Reboot the Chiller
1. If you get “cooling errors”while scanning you can try to reboot the chiller to clear the
faults, some examples include:
Cooling System: EPC Temperature High
Cooling System: Return Pressure Low
Cooling bypass
2. Enter the equipment room (through the sliding glass door) and look at the south wall (as
shown below)
3. Locate the key to the chiller cabinet on the ledge (red circle)
4. Unlock the cabinet (green circles)
5. Turn off the 3 breakers in the chiller cabinet (orange squares), wait 5 seconds and then
turn them back on
6. Then do a “Standby”scanner reboot (not a restart or full shutdown) –this takes 10
minutes
7. Please be sure to notify [e-mail] and/or Dr. Woods if this occurs
1
2
3

Revision Date: 3/13/2019
8
Export and Save Raw Data Files (.RDA and Raw)
How to Map a Non-Dicom Network Folder on the Scanner Console
1. Enable the advanced user mode (you will need a tech for this step)
2. Click control and click escape key
3. Click Computer
4. Disconnect any other MRIFILE drives that may still be mapped –right click on the drive
and choose disconnect
5. Click on “Map Network Drive” on the top tool bar
6. When the box pops up choose an available drive, Z drive is the default, if it is being used
choose the next available letter (i.e. Y, X, W etc) –DO NOT use drive A
7. Under “Folder” choose the path \\10.2.0.135\”PI NAME”MRIFILE (i.e.
MAYERMRIFILE) or enter the path name manually if this is your first time mapping the
drive
8. This drive will allow you to save raw data etc into the network folder instead of on a usb
drive
9. Click on “Connect using different credentials" then click finish
10. Log in with your NRB credentials (don't forget the \bmap) before your name
bmap\username
Password
11. When you are done close the non-dicom folder windows
12. Right click on the drive you mapped and click disconnect - this will log you out
13. If your non-dicom NRB account is not working –save the raw data on the C: Drive in
Temp/YourName/SubjectID folder
14. Note –please remember to periodically delete saved data from your non-dicom folder
and scanner console temp folder –data is not meant to stay in these folders indefinitely as
there is limited space
How to Create a Spectroscopy .RDA File
1. Enable the advanced user mode (you will need a tech for this step)
2. Click control and click escape key
3. Pull the scan back from the server if necessary
4. Go to the spectroscopy tab
5. Click the file browser
6. Load the spectrum of interest in the spectroscopy tab
7. Then click on the spectrum you want to create an .rda file for
8. Click options on the tool bar
9. Then click export raw data
10. Copy and paste these files into a temp folder on the C drive - typically your group will
have their own temp folder
11. You can then move/copy it to a flash drive or a non-dicom folder
12. This data does not get over written as long as you have the scan data
13. Data needs to be manually deleted from the temp folder and non-dicom folder

Revision Date: 3/13/2019
9
How to Transfer Raw Data Using TWIX Software
1. Enable the advanced user mode (you will need a tech for this step)
2. Click control and click escape key
3. Open the command terminal
4. Type: TWIX - then press enter
5. All raw data will be listed
6. Select the raw data you wish to save by choosing the correct participant ID and sequence
7. Right click on it and choose the top option "copy total raid file"
8. Copy and paste these files into a temp folder on the C drive - typically your group will
have their own temp folder
9. These files can then be copied to a non-dicom folder or flash drive
10. Data needs to be manually deleted from the temp folder and non-dicom folder

Revision Date: 3/13/2019
10
Prisma Cleanup Procedures
General Cleanup Guidelines
1. Put the head coil away in the coil cabinet with top attached
2. All cables should be untangled and placed on the appropriate hooks completely off the
ground to prevent being stepped on (please see below pictures)
3. All equipment (goggles, headphones, button box, squeeze ball/button etc) that you used
should be wiped down with alcohol wipes for cleanliness
4. The button response box should be disconnected and store in the appropriately labelled
drawer - the button response box sleeve should be removed if used
5. The squeeze ball should be coiled at the end of the bed
6. One sandbag should be left on the white cart
7. The Opto box should be turned off at back of box
8. The Opto audio cable should be unattached from audio source and coiled up in the
drawer
9. The trigger, LCD HMDI, goggle VGA and EPI cables should be coiled and stored
10. The Res Tech system should be turned to “Off” under “System” – you do not need to turn
off the “Visor”
11. The LCD switch box should be turned off
12. The goggles, EXT and EPI buttons should be turned off on the desktop switch box
13. Everything is labelled for your convenience
14. Note: the top of the cart is now a suitable place to set the top of the coil and/or mirror
when you are setting up your participant

Revision Date: 3/13/2019
11
Squeeze Ball/Button Alarm
What to do when the Squeeze Ball/Button Alarm Goes Off
1. Stop the scanner using the mouse and clicking the stop icon in the lower left on the
console screen
2. To clear the alarm, press the talk button on the intercom associated with the squeeze ball
- Siemens (#2 talk or #3 alarm) or headphones button - Res Tech (TALK) you gave the
participant
3. Talk to your participant through the intercom system associated with the headphones you
gave your participant (res tech, siemens or opto system)
4. DO NOT press the “Stop” button (#1) on the Siemens Talk Box
5. If you press this, you will need to reset the table
6. To reset the table follow the below instructions
Reset the Table
1. Press the (#7) button on the side of the intercom box
2. Go into the scanner room and simultaneously press the Table Up and Table Down button

Revision Date: 3/13/2019
12
How to Run the Daily Stability Warmup
Setting up the Phantom
1. Place the phantom and phantom cushion inside the either the 20, 32 or 64 channel head
coil (round end at top of coil)
2. Secure the top half of the head coil by clicking it in and plugging in cable(s) if necessary
3. Raise the table
7. Turn on the laser light and set the landmark
8. Slide the table fully into the scanner
9. Close and flip the air seal on the scanner door
Register Phantom
1. Press the “little person” key on the keyboard to bring up the registration screen
2. Enter phantom information (all required fields are indicated in bold except required data
destination= Referring physician)
Last Name = enter information in the following format –Stability-date-of-
scan_name-of-scanner.
e.g. “Stability082609_Prisma”
Patient ID = copy the information from the Last Name field to the Patient ID
field.
Sex = “other”
Age = “18”
Height = “5ft”
Weight = “125 lbs”
Referring Physician = select “QC Group”
Patient Position = select “Head First Supine”
3. Click “Exam”
4. Another box will pop up
Choose Study = Daily_Stability_Test _Prisma
Choose stability sequence based on the head coil you used (BMC_20ch,
BMC_32ch or BMC_64ch etc)
Click “Confirm”
Running Scans
1. Press the green play button to start the first localizer
2. First stability sequence will open itself –center the box on the phantom and then click
“the green check”
3. The other stability sequences will automatically copy the slice locations from the first
stability sequence and will automatically start (you will not need to click continue)
4. When scanning is complete, remove the phantom/holder and place them securely in the
phantom cabinet bin

Revision Date: 3/13/2019
13
Registration Pictures

Revision Date: 3/13/2019
14
How to Run the ABCD Phantom QA
The ABCD phantom should be run at least once per week. This QA protocol may take
the place of the daily warmup. The full version takes 29min and the quick version takes
16min.
Setting up the Phantom
1. Place the spherical ABCD phantom inside 32 (ABCD/HCP protocols) or 64 (Other) head
coil on top of the white cushion
2. Place the gray cushion in front to secure the phantom (32ch coil only)
3. Cushions are located next to the phantom in the bin
4. The cap of the phantom should be center as if it were the nose –it should line up with the
laser landmark line on the coil
5. Secure the top half of the head coil by clicking it in and plugging in cable(s) if necessary
6. Raise the table
7. Turn on the laser light and set the landmark to run through the cap
8. Slide the table fully into the scanner
9. Close and flip the air seal on the scanner door
32 Ch Coil
64 CH Coil

Revision Date: 3/13/2019
15
Register the Phantom
1. Press the “little person” key on the keyboard to bring up the registration screen
2. Enter phantom information (all required fields are indicated in bold except required data
destination= Referring physician)
Last Name = ABCDPhantom017_32CH or ABCDPhantom017_64CH
Patient ID = copy the information from the Last Name field to the Patient ID
field.
Sex = “other”
Age = “18”
Height = “5ft”
Weight = “100 lbs”
Referring Physician = select “ABCDPHANTOMGROUP”
Patient Position = select “Head First Supine”
3. Click “Exam”
4. Another box will pop up
Under ABCD choose the appropriate protocol:
oABCD_QA_full__32ch (29:04min)
oABCD_QA_quick__32ch (15:36min)
oABCD_QA_full__64ch (29:04min)
oABCD_QA_quick__64ch (15:36min)
Click “Confirm”

Revision Date: 3/13/2019
16
Running Scans
1. Press the green play button to start the first localizer
2. Set up sequence #3: SNR_Map by centering the yellow box on the phantom –it should
be placed right through the cap (the cap is circled in red below) then click the green
check (green circle)
3. Set up sequence #4 by centering the yellow box on the phantom –click the green check
4. Press ok to the “Stimulation Monitor Warning” that will pop up after #3 finishes running
–you can step away to let the sequences auto run after this step
5. The rest of the sequences will automatically copy the slice locations from #4 and run
automatically
6. When scanning is complete, remove the phantom/cushions and place them securely in the
phantom cabinet bin
