Siemens LIM-1 User manual

P/N 315-049552-6
OPERATION
The Model LIM-1 Loop Isolator module from Siemens
Industry, Inc., isolates short circuits on MXL and
FireFinder-XLS intelligent device loops. By placing
devices between LIM-1s during installation, a short in
the wiring within that group is disconnected from the
rest of the loop. The remainder of the devices
continue to operate. The LIM-1 operates in both
Class A and Class B circuits.
A yellow LED flashes when a device detects a short
circuit. The LIM-1 then isolates that part of the loop.
When the short is removed, the LIM-1 automatically
restores the loop to normal operation. The LIM-1
does not have a loop address and therefore does not
require address programming nor does it reduce the
loop capacity below 60 (MXL) or 252 (XLS) devices.
ELECTRICAL RATINGS
Installation Instructions
MODEL LIM-1
Loop Isolator Module
Siemens Industry, Inc.
Building Technologies Division
Florham Park, NJ
Siemens Canada Limited
Building Technologies Division
2 Kenview Boulevard
Brampton, Ontario L6T 5E4 Canada
INSTALLATION
Remove all system power before installation, first
the battery and then the AC.
Refer to Figure 1 for the location and number of the
screw terminals on the LIM-1. The LIM-1 has two
input terminals, two output terminals and an earth
ground as listed below:
Terminal Number Description
1 Loop + IN
2 Loop - IN
3 Loop + OUT
4 Loop - OUT
5 Earth Ground
MECHANICAL INSTALLATION (See Figure 2)
1. Use a standard 3 1/2-inch deep, double gang
electrical switchbox or a 4-inch square electrical
box that is 2 1/8inches deep.
2. Connect the field wiring. Press the LIM-1 into the
box and fasten the module plate to the box.
3. Cover the module front plate with the plate
supplied and fasten with screws supplied.
Figure 2
Mounting the LIM-1
Figure 1
Model LIM-1
SWITCHPLATE
5-INCHES SQUARE
(SUPPLIED)
SWITCHPLATE
5-INCHES SQUARE
(SUPPLIED)
4-INCH SQUARE BOX
2 1/8-INCHES DEEP
DOUBLE GANG BOX
3 1/2-INCHES DEEP
tnerruCeludoMCDV5evitcAAm0
tnerruCeludoMCDV42evitcAAu067
tnerruCeludoMCDV42ybdnatSAu067

NOTES for Figure 3:
1. All wiring must comply with national and local codes.
2. In order to provide adequate protection, it is recommended
that you do not install more than 20 devices on a single LIM-1.
3. Minimum wire gauge is 18 AWG.
4. The total wire resistance (both wires) between LIM-1s
cannot exceed 10 ohms.
5. Do not install more than 12 LIM-1s per loop.
6. All circuits are supervised.
7. Refer to the MXL/MXLV Manual, P/N 315-092036, the MLC
Installation Instructions, Document ID A6V10328217, or the
DLC Installation Instructions, Document ID A6V10239107,
for the list of compatible devices.
8. All terminals are power limited.
ANALOG LOOP
IN
+ -
IN
+
OUT
+
+
+
-
OUT EARTH IN
+ -
IN
+
OUT
+
+
+
OUT
-
EARTH IN
+ -
IN OUT
+
+
+
+
OUT
-
EART
H
NOTE: WHEN USING THE
LIM-1 WITH THE DLC,
THE FOLLOWING
POLARITY MUST BE
OBSERVED AT THE LIM-1.
DLC LINE 1 = +
DLC LINE 2 = -
Figure 3
LIM-1 Wiring Diagram
Class B Installation
The LIM-1 may be used in two circuit configurations.
Class B (See Figure 3)
In Class B wiring each LIM-1 isolates a branch on the
circuit. Note that a short on the main branch causes
the entire loop to fail. To prevent this, mount the
LIM-1s at the MXL or FireFinder-XLS enclosure and
run each branch independently.
TO ANALOG
LOOP RETURN
INSIDE ENCLOSURE
T
O ANALOG
LOOP FEED
IN IN OUT OUT
IN
+++
+
+
+
+++
+
+
+
--
+
+
---
-
--
---
-
--
IN
OUTOUT
EARTH
EARTH
ININ
OUTOUT
EARTH ININ
OUTOUT
EARTH
IN IN OUT OUT EARTH IN IN OUT OUT EARTH
+
--
+
+
--
+
+
--
+
+
--
+
NOTE: WHEN USING THE LIM-1 WITH THE
DLC, THE FOLLOWING POLARITY MUST BE
OBSERVED AT THE LIM-1.
DLC LINE 1 = +
DLC LINE 2 = -
Figure 4
LIM-1 Wiring Diagram
Class A Installation (Single Loop)
Class A Single Loop (See Figure 4)
In Class A wiring the LIM-1s are wired in series with
the loop wiring. This results in a single continuous
loop. If any group in the loop has a short, that group is
lost and a Class A circuit failure results. The MXL or
FireFinder-XLS displays communication errors for the
devices and a Class A failure for the loop itself.
NOTES for Figure 4:
1. All wiring must comply with national and local codes.
2. In order to provide adequate protection, it is recommended
that you do not install more than 20 devices on a single LIM-1.
3. Minimum wire gauge is 18 AWG.
4. The total wire resistance (both wires) between LIM-1s
cannot exceed 10 ohms.
5. Do not install more than 12 LIM-1s per loop.
6. All circuits are supervised.
7. Refer to the MXL/MXLV Manual, P/N 315-092036, the MLC
Installation Instructions, Document ID A6V10328217, or the
DLC Installation Instructions, Document ID A6V10239107,
for the list of compatible devices.
8. All terminals are power limited.
P/N 315-049552-6 Document ID A6V10239166
