Siemens SIMATIC NET PS598-1 Administrator guide

SIMATIC NET
Industrial Ethernet switches
Power supply unit PS598-1 for
SCALANCE XR-500
Compact Operating Instructions
02/2023
A5E03275848-05
Introduction 1
Safety notes 2
Description 3
Mounting 4
Connection 5
Upkeep and maintenance 6
Technical data 7
Dimension drawings 8
Approvals 9

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of SiemensAG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E03275848-05
Ⓟ 02/2023 Subject to change
Copyright © SiemensAG 2011 - 2023.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 5
1.1 Security information ............................................................................................................ 5
2 Safety notes ........................................................................................................................................... 7
3 Description............................................................................................................................................. 9
3.1 Product characteristics ......................................................................................................... 9
3.2 Unpacking and checking .................................................................................................... 10
4 Mounting ............................................................................................................................................. 11
4.1 Safety notices for installation ............................................................................................. 11
4.2 19" rack mounting of the PS598-1...................................................................................... 11
4.3 Mounting the PS598-1 on the rear panel of an XR500......................................................... 12
5 Connection........................................................................................................................................... 15
5.1 Connecting devices with 100 to 240 VAC power supply ...................................................... 15
5.2 LED display ........................................................................................................................ 19
6 Upkeep and maintenance.................................................................................................................... 21
7 Technical data...................................................................................................................................... 23
8 Dimension drawings............................................................................................................................ 25
9 Approvals............................................................................................................................................. 27
9.1 EMCdirective (industrial areas) .......................................................................................... 27
9.2 Mechanical stability (in operation) ..................................................................................... 28
Index .................................................................................................................................................... 31
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 3

Table of contents
Power supply unit PS598-1 for SCALANCE XR-500
4Compact Operating Instructions, 02/2023, A5E03275848-05

Introduction 1
Purpose of the compact operating instructions
Based on the compact operating instructions, you will be able to install and connect up the
PS598-1 correctly.
Validity of these compact operating instructions
These compact operating instructions apply to the product PS598-1 as of product version 1.
Security information
1.1 Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, systems, machines and networks.
In order to protect plants, systems, machines and networks against cyber threats, it is
necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial
security concept. Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems,
machines and networks. Such systems, machines and components should only be connected
to an enterprise network or the internet if and to the extent such a connection is necessary
and only when appropriate security measures (e.g. 󹪝rewalls and/or network segmentation)
are in place.
For additional information on industrial security measures that may be implemented, please
visit
https://www.siemens.com/industrialsecurity (https://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more
secure. Siemens strongly recommends that product updates are applied as soon as they are
available and that the latest product versions are used. Use of product versions that are no
longer supported, and failure to apply the latest updates may increase customer’s exposure
to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS
Feed under
https://www.siemens.com/cert (https://www.siemens.com/cert).
Device defective
If a fault develops, send the device to your SIEMENS representative for repair. Repairs on-site are
not possible.
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 5

Recycling and disposal
The products are low in pollutants, can be recycled and meet the requirements of the WEEE
directive 2012/19/EU for the disposal of electrical and electronic equipment.
Do not dispose of the products at public disposal sites.
For environmentally friendly recycling and the disposal of your old device contact a certi󹪝ed
disposal company for electronic scrap or your Siemens contact (Product return (https://
support.industry.siemens.com/cs/ww/en/view/109479891)).
Note the di󹪜erent national regulations.
Trademarks
The following and possibly other names not identi󹪝ed by the registered trademark sign ® are
registered trademarks of Siemens AG:
SCALANCE, C-PLUG, OLM
Introduction
1.1Security information
Power supply unit PS598-1 for SCALANCE XR-500
6Compact Operating Instructions, 02/2023, A5E03275848-05

Safety notes 2
CAUTION
To prevent injury and damage, read the manual before using the device.
Safety notices on the use of the devices
The following safety notices must be adhered to when setting up and operating the device and
during all work relating to it such as installation, connecting up, replacing devices or opening the
device.
Important notices 100 to 240 VAC
DANGER
Danger from line voltage
Devices with this mark have a 100 to 240 VAC power supply.
This product can only function correctly and safely if it is transported, stored, set up, and
installed correctly, and operated and maintained as recommended.
Connecting and disconnecting may only be performed by an electrical specialist. Connect or
disconnect power supply cables only when the power is turned o󹪜!
General notices
WARNING
Opening the device
Do not open when energized. Note that this does not apply to opening the panel in the housing.
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 7

Safety notes
Power supply unit PS598-1 for SCALANCE XR-500
8Compact Operating Instructions, 02/2023, A5E03275848-05

Description 3
3.1 Product characteristics
Power supply units
Type Power Input voltage Output voltage Article number
PS598-1 300 W 100 to 240 VAC 24 VDC 6GK5 598-1AA00-3AA0
Note
Two connectors for the 24VDC output voltage
The PS598-1 has two connectors with the output voltage 24 VDC. Note that you can only use one
connector on the front or the connector on the rear of the PS598-1. You cannot operate the
device with the connectors on the front and rear at the same time.
Note
Requirement for connecting at the rear
Note that the connector on the rear of the PS598-1 can only be used if the power supply is
mounted on the SCALANCE XR500.
Note
Replacing the 󹪝lter pad
To replace the 󹪝lter pad, use the material Viledon P 15/150 G2 EN 779. The dimensions of the
󹪝lter pad are 38 x 135 x 8 mm (H x W x D).
Components of the product
The following parts make up the components of the PS598‑1:
• 4-pin terminal block for the 24 VDC power supply.
• 2 mounting brackets
• 8 screws (M3 x 6 countersunk, drive: Torx) for mounting the 󹪝xing brackets for 19" rack
installation
• Compact operating instructions
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 9

3.2 Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to the
speci󹪝cation.
If you use damaged parts, this can lead to the following problems:
• Injury to persons
• Loss of the approvals
• Violation of the EMC regulations
Use only undamaged parts.
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
If the consignment is incomplete or if there is damage to the exterior, contact your supplier
or your local Siemens o󹪟ce.
Description
3.2Unpacking and checking
Power supply unit PS598-1 for SCALANCE XR-500
10 Compact Operating Instructions, 02/2023, A5E03275848-05

Mounting 4
4.1 Safety notices for installation
NOTICE
Damage to the device due to inadequate cooling
If the ventilation slits are fully or partly covered, the temperature inside the housing can rise
and exceed the maximum permitted temperature causing damage to the device.
The ventilation slits are located on the side panels of the housing. During installation, select a
mounting position so that the ventilation slits are always free so that the air can circulate. The
clearance to the ventilation slits of the housing must be at least 10 cm.
You will 󹪝nd information about cleaning the air 󹪝lter in the section "Upkeep and maintenance".
Close unused module slots of modular devices with dummy covers. Open module slots impair
the air circulation and can damage the device.
4.2 19" rack mounting of the PS598-1
Notes on 19" rack mounting of the PS598-1 power supply unit
The PS598-1 was developed speci󹪝cally for use with the SCALANCE XR528-6M and SCALANCE
XR552-12M devices. This power supply unit can be mounted directly above or below a
SCALANCE XR-500 since the ventilation slits are on the sides of both the basic device and the
power supply unit.
CAUTION
Risk of injury if subjected to irregular mechanical strain
The device must be mounted in the rack so that even if there is irregular mechanical strain, no
dangerous situation can result.
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 11

Procedure


Figure4-1 19" rack mounting of the power supply unit
To mount the PS598-1 power supply unit in a 19" rack, follow the steps below:
1. Secure the two mounting brackets with four screws each (M3 x 6 supplied with the product)
to the side panels of the power supply unit ①.
The maximum tightening torque for these screws is 0.5 Nm.
2. Screw the PS598-1 power supply unit to the 19" rack ②.
4.3 Mounting the PS598-1 on the rear panel of an XR500
You can mount the PS598-1 power supply unit on the rear panel of the following devices:
• SCALANCE XR528-6M
• SCALANCE XR552-12M
Mounting
4.3Mounting the PS598-1 on the rear panel of an XR500
Power supply unit PS598-1 for SCALANCE XR-500
12 Compact Operating Instructions, 02/2023, A5E03275848-05

Procedure


;50
Figure4-2 Rear panel mounting of the SCALANCE XR552-12M. SCALANCE XR528-6M is used
analogously.
On the rear panel of an IE switch, there are sockets for the direct connection of a maximum
of two PS598-1 power supply units. On the rear of the PS598-1 power supply unit there is a
corresponding plug.
To mount the PS598-1 power supply unit on the rear panel of an IE switch, follow the steps
below:
1. Fit the PS598-1 power supply unit and the IE switch together ①.
The two devices are equipped with positioning elements that must engage during
installation and protect the plug from excessive bending strain.
2. Screw the two devices to the mounting plates supplied with the main device ②.
The maximum tightening torque of the screws is 0.5 Nm.
Mounting
4.3Mounting the PS598-1 on the rear panel of an XR500
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 13

Mounting
4.3Mounting the PS598-1 on the rear panel of an XR500
Power supply unit PS598-1 for SCALANCE XR-500
14 Compact Operating Instructions, 02/2023, A5E03275848-05

Connection 5
5.1 Connecting devices with 100 to 240 VAC power supply
Switches for the input voltage
The socket X1 (position ①) and the switch S1 Power (position ③) for the input voltage are
located on the right-hand side of the front panel of the housing:
123
①Socket X1
②Fuse holder
③Switch S1 Power
Figure5-1 Position of the socket X1 and the switch S1 Power on the PS598-1 power supply unit
Notes on the power supply 100 to 240 VAC
NOTICE
Connect and disconnect the power supply unit only when it is not energized
The PS598-1 power supply unit is not capable of hot plugging. Connecting or disconnecting the
PS598-1 when the 100 to 240 VAC power supply is on can damage the PS598-1 power supply
unit and the IE switch.
Before connecting or disconnecting the PS598-1 power supply unit, make sure that the switch
for the input voltage (position ③) is set to position "0".
NOTICE
CAUTION/DOUBLE POLE
The fuses FUSE1 and FUSE2 are in the fuse holder (position ②). The fuses are of the type
F6.3AH / 250 VAC.
NOTICE
Overvoltage protection for the power supply cables
If there is any possible overload of the power supply cables, suitable overvoltage protection is
necessary. Refer to the values on the type plate.
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 15

NOTICE
Reliable grounding
Reliable grounding of the devices mounted in the rack must be guaranteed. This applies, in
particular, to power supply cables that are not connected directly to the power supply circuit.
With the PS598-1 power supply unit, the IEC power connector (IEC 60320-1) provides the
connection to protective earth.
Pin assignment of the X2 socket on the front
L M ML
Figure5-2 Position of the socket X2 on the PS598-1 power supply unit
Contact Assignment
L +24 VDC
M Ground
M Ground
L +24 VDC
Pin assignment of the X3 plug on the rear
Connector X3 is located on the back of the PS598-1. Connector X3 is intended only to connect
the PS598-1 directly to SCALANCE XR-528-6M and SCALANCE XR552-12M.
L L LM M M
Figure5-3 Position of the plug X3 on the PS598-1 power supply unit
Connection
5.1Connecting devices with 100 to 240 VAC power supply
Power supply unit PS598-1 for SCALANCE XR-500
16 Compact Operating Instructions, 02/2023, A5E03275848-05

Contact Assignment
L +24 VDC
L
L
M Ground
M
M
One PS598-1 per device, no redundancy
Figure5-4 Connecting a power supply unit to a SCALANCE XR552-12M. SCALANCE XR528-6M is
used analogously.
Connect the IE switch and the PS598-1 with one cable for 24 VDC and a cable for ground. As
an alternative, you can also mount the PS598-1 on the rear of the IE switch and secure it with
screws. In this case, no extra cables are necessary. You will 󹪝nd detailed information in the
section "Installation".
Two PS598-1 per device, 1-out-of-2 redundancy
Figure5-5 Connecting two power supply units to a SCALANCE XR552-12M. SCALANCE XR528-6M is
used analogously.
Connect the IE switch and the PS598-1 with one cable for 24 VDC and a cable for ground. As
an alternative, you can also mount the two PS598-1 power supply units on the rear of the IE
switch and secure them with screws. In this case, no extra cables are necessary. You will 󹪝nd
detailed information in the section "Mounting (Page11)". It is also possible to operate the
IE switch even after the failure of one PS598-1. The IE switch detects the failure of a power
source and signals the failure. The PS598-1 units share the applied load automatically and
uniformly.
Connection
5.1Connecting devices with 100 to 240 VAC power supply
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 17

Three PS598-1 units for two devices - 2-out-of-3 redundancy
Figure5-6 Connecting three power supply units to a SCALANCE XR552-12M. SCALANCE XR528-6M
is used analogously.
Connect each IE switch to its own PS598-1. In addition to this, connect both IE switches to
the third PS598-1. Both IE switches devices can now continue to operate after the failure of
one PS598-1. The IE switch detects the failure of a power source and signals the failure. The
PS598-1 units share the applied load automatically and uniformly.
Note
Two connectors for the 24VDC output voltage
The PS598-1 has two connectors with the output voltage 24 VDC. Note that you can only use the
connector on the front or the connector on the rear of the PS598-1. You cannot operate the
device with the connectors on the front and rear at the same time.
Note
To wire up the power supply connector, use copper cable of the category 14 AWG to 10 AWG or
cable with a cross-sectional area of 1.5 to 4 mm2.
WARNING
Safety notice for connecting with a LAN ID (Local Area Network)
A LAN or LAN segment with all the interconnected devices should be contained completely in
a single low voltage power distribution in a building. The LAN is designed either for
“Environment A” according to IEEE802.3 or "Environment 0" according to IEC TR 62102.
Do not connect any electrical connectors directly to the telephone network (telephone network
voltage) or a WAN (Wide Area Network).
Connection
5.1Connecting devices with 100 to 240 VAC power supply
Power supply unit PS598-1 for SCALANCE XR-500
18 Compact Operating Instructions, 02/2023, A5E03275848-05

5.2 LED display
LED display
A PS598-1 has two LEDs each, one green and one red. If the green LEDs is lit (24V OK), the output
voltage is correctly applied. If the red LED is lit (SHUTDOWN) an error has occurred.
Possible errors/faults:
• The output voltage is not correct.
• Temperature of the PS598-1 is too high.
Connection
5.2LED display
Power supply unit PS598-1 for SCALANCE XR-500
Compact Operating Instructions, 02/2023, A5E03275848-05 19

Connection
5.2LED display
Power supply unit PS598-1 for SCALANCE XR-500
20 Compact Operating Instructions, 02/2023, A5E03275848-05
