Siemens SIMATIC NET PS598-1 Administrator guide

©Siemens AG 2011 - 2013. All rights reserved
A5E03275848-04, 05/2013 1
Legal information
Qualified Personnel
The product/system described in this documentation may be operated only by personnel
qualified for the specific task in accordance with the relevant documentation, in particular its
warning notices and safety instructions. Qualified personnel are those who, based on their
training and experience, are capable of identifying risks and avoiding potential hazards when
working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the
relevant technical documentation. If products and components from other manufacturers are
used, these must be recommended or approved by Siemens. Proper transport, storage,
installation, assembly, commissioning, operation and maintenance are required to ensure that
the products operate safely and without any problems. The permissible ambient conditions
must be complied with. The information in the relevant documentation must be observed.
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as
well as to prevent damage to property. The notices referring to your personal safety are
highlighted in the manual by a safety alert symbol, notices referring only to property damage
have no safety alert symbol. These notices shown below are graded according to the degree of
danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest
degree of danger will be used. A notice warning of injury to persons with a safety alert symbol
may also include a warning relating to property damage.

Power supply unit PS598-1 for SCALANCE XR500
2A5E03275848-04, 05/2013
Table of contents
1 Introduction..................................................................................................3
2 Safety notes.................................................................................................3
3 Description...................................................................................................4
3.1 Product characteristics ......................................................................... 4
3.2 Unpacking and checking ...................................................................... 5
4 Mounting......................................................................................................6
4.1 19" rack mounting of the PS598-1........................................................ 6
4.2 Mounting the PS598-1 on the rear panel of an XR500......................... 8
5 Connection ................................................................................................11
5.1 Connecting devices with 100 to 240 VAC power supply .................... 11
5.2 LED display ........................................................................................ 16
6 Upkeep and maintenance...........................................................................17
7 Technical data............................................................................................18
8 Dimension drawings ...................................................................................19
9 Approvals...................................................................................................20
9.1 EMC directive ..................................................................................... 20
9.2 Mechanical stability (in operation) ...................................................... 22

Power supply unit PS598-1 for SCALANCE XR500
A5E03275848-04, 05/2013 3
1 Introduction
Purpose of the compact operating instructions
Based on the compact operating instructions, you will be able to install and connect
up the PS598-1 correctly.
Validity of these compact operating instructions
These compact operating instructions apply to the product PS598-1 as of product
version 1.
2 Safety notes
Safety notices on the use of the devices
The following safety notices must be adhered to when setting up and operating the
device and during all work relating to it such as installation, connecting up, replacing
devices or opening the device.
Important notices 100 to 240 VAC
DANGER
Danger from line voltage
Devices with this mark have a 100 to 240 VAC power supply.
This product can only function correctly and safely if it is transported, stored, set up,
and installed correctly, and operated and maintained as recommended.
Connecting and disconnecting may only be performed by an electrical specialist.
Connect or disconnect power supply cables only when the power is turned off!
General notices
WARNING
Opening the device
Do not open when energized. Note that this does not apply to opening the panel in
the housing.

Power supply unit PS598-1 for SCALANCE XR500
4A5E03275848-04, 05/2013
3 Description
3.1 Product characteristics
Connectors
Type
Power
Input voltage
Output voltage
PS598-1
300 W
100 to 240 VAC
24 VDC
Note
Two connectors for the 24 VDC output voltage
The PS598-1 has two connectors with the output voltage 24 VDC. Note that you can
only use one connector on the front or the connector on the rear of the PS598-1. You
cannot operate the device with the connectors on the front and rear at the same time.
Note
Requirement for connecting at the rear
Note that the connector on the rear of the PS598-1 can only be used if the power
supply is mounted on the SCALANCE XR500.
Components of the product
The following parts make up the components of the PS598-1:
●4-pin terminal block for the 24 VDC power supply.
●2 mounting brackets
●8 screws (M3 x 6 countersunk, drive: Torx) for mounting the fixing brackets for
19" rack installation
●Compact Operating Instructions

Description
Power supply unit PS598-1 for SCALANCE XR500
A5E03275848-04, 05/2013 5
Order numbers
Type
Order number
PS598-1 (300 W)
6GK5 598-1AA00-3AA0
Note
Replacing the filter mat
To replace the filter mat, use the material Viledon P 15/150 G2 EN 779. The
dimensions of the filter mat are 38 x 135 x 8 mm (H x W x D).
3.2 Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function
according to the specification.
If you use damaged parts, this can lead to the following problems:
●Injury to persons
●Loss of the approvals
●Violation of the EMC regulations
Use only undamaged parts.
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
If the consignment is incomplete or if there is damage to the exterior, contact your
supplier or your local Siemens office.

Power supply unit PS598-1 for SCALANCE XR500
6A5E03275848-04, 05/2013
4 Mounting
4.1 19" rack mounting of the PS598-1
Power supply unit for 19" rack installation
The PS598-1 was developed specifically for use with devices of the XR500 product
group. This power supply unit can be mounted directly above or below a SCALANCE
XR500 since the ventilation grilles are on the sides of both the basic device and the
power supply unit.
CAUTION
Risk of injury if subjected to irregular mechanical strain
The device must be mounted in the rack so that even if there is irregular mechanical
strain, no dangerous situation can result.
NOTICE
Damage to the device due to inadequate cooling
If the ventilation grilles are fully or partly covered or the air filters are contaminated,
the temperature inside the housing can rise and exceed the maximum permitted
temperature and damage the device.
During installation, select a mounting position so that the ventilation grilles are
always free so that the air can circulate. The ventilation grilles are located on the
side panels of the housing. You will find information about cleaning the air filter in
the section "Upkeep and maintenance".

Mounting
Power supply unit PS598-1 for SCALANCE XR500
A5E03275848-04, 05/2013 7
Procedure
Follow the steps below to install the PS598-1 in a 19" rack:
1. Secure the two mounting brackets with four screws each (M3 x 6 supplied with
the product) to the side panels of the power supply unit. The maximum tightening
torque for these screws is 0.5 Nm.
2. Screw the PS598-1 to the 19" rack.

Mounting
Power supply unit PS598-1 for SCALANCE XR500
8A5E03275848-04, 05/2013
4.2 Mounting the PS598-1 on the rear panel of
an XR500
NOTICE
Damage to the device due to inadequate cooling
If the ventilation grilles are fully or partly covered or the air filters are contaminated,
the temperature inside the housing can rise and exceed the maximum permitted
temperature and damage the device.
During installation, select a mounting position so that the ventilation grilles are
always free so that the air can circulate. The ventilation grilles are located on the
side panels of the housing. You will find information about cleaning the air filter in
the section "Upkeep and maintenance".

Mounting
Power supply unit PS598-1 for SCALANCE XR500
A5E03275848-04, 05/2013 9
Procedure
Figure 4-1 Rear panel mounting of the SCALANCE XR552-12M. SCALANCE
XR528-6M is used analogously.

Mounting
Power supply unit PS598-1 for SCALANCE XR500
10 A5E03275848-04, 05/2013
On the rear panel of a SCALANCE XR500, there are sockets for the direct
connection of a maximum of two PS598-1 power supply units. On the rear of the
PS598-1 there is a corresponding plug. Follow the steps below to install the PS598-1
on the rear panel of a SCALANCE XR500:
1. Fit the PS598-1 and the SCALANCE XR500 together. The two devices are
equipped with positioning elements that must engage during installation and
protect the plug from excessive bending strain.
2. Screw the two devices to the mounting plates supplied with the main device. The
maximum tightening torque of the screws is 0.5 Nm.

Power supply unit PS598-1 for SCALANCE XR500
A5E03275848-04, 05/2013 11
5 Connection
5.1 Connecting devices with 100 to 240 VAC
power supply
Switches for the input voltage
The socket X1 (position ①) and the switch S1 Power (position ③) for the input
voltage are located on the right-hand side of the front panel of the housing:
NOTICE
Connect and disconnect the power supply unit only when it is not energized!
The PS598-1 is not capable of hot plugging. Connecting or disconnecting the
PS598-1 when the 100 to 240 VAC power supply is on can damage the PS598-1
and the SCALANCE XR500.
Before connecting or disconnecting the PS598-1, make sure that the switch for the
input voltage is set to position "0".
NOTICE
CAUTION/DOUBLE POLE
The fuses FUSE1 and FUSE2 are in the fuse holder (position ②). The fuses are of
the type F6.3AH / 250 VAC.
NOTICE
Overvoltage protection for the power supply cables
If there is any possible overload of the power supply cables, suitable overvoltage
protection is necessary. Refer to the values on the type plate.

Connection
Power supply unit PS598-1 for SCALANCE XR500
12 A5E03275848-04, 05/2013
NOTICE
Reliable grounding
Reliable grounding of the devices mounted in the rack must be guaranteed. This
applies, in particular, to power supply cables that are not connected directly to the
power supply circuit. With the PS598-1, the IEC power connector (IEC 60320-1)
provides the connection to protective earth.
Pin assignment of the X2 socket on the front
Contact
Assignment
L
+24 VDC
M
Ground
M
Ground
L
+24 VDC

Connection
Power supply unit PS598-1 for SCALANCE XR500
A5E03275848-04, 05/2013 13
Pin assignment of the X3 plug on the rear
Connector X3 is located on the back of the PS598-1. Connector X3 is intended only
to connect the PS598-1 directly to an XR500.
Contact
Assignment
L
+24 VDC
L
L
M
Ground
M
M

Connection
Power supply unit PS598-1 for SCALANCE XR500
14 A5E03275848-04, 05/2013
One PS598-1 per device, no redundancy
Figure 5-1 Connecting a power supply unit to a SCALANCE XR552-12M.
SCALANCE XR528-6M is used analogously.
Connect the SCALANCE XR500 and the PS598-1 with one cable for 24 VDC and a
cable for ground. As an alternative, you can also mount the PS598-1 on the back of
the SCALANCE XR500 and secure it with screws. In this case, no extra cables are
necessary. You will find detailed information in the section "Installation".
Two PS598-1 per device, 1-out-of-2 redundancy
Figure 5-2 Connecting two power supply units to a SCALANCE XR552-12M.
SCALANCE XR528-6M is used analogously.
Connect the SCALANCE XR500 and the PS598-1 with one cable for 24 VDC and a
cable for ground. As an alternative, you can also mount the two PS598-1 units on the
back of the SCALANCE XR500 and secure it with screws. In this case, no extra
cables are necessary. You will find detailed information in the section "Mounting
(Page 6)". It is also possible to operate the SCALANCE XR500 even after the failure
of a PS598-1. The SCALANCE XR500 detects the failure of a power source and
signals the failure. The PS598-1 units share the applied load automatically and
uniformly.

Connection
Power supply unit PS598-1 for SCALANCE XR500
A5E03275848-04, 05/2013 15
Three PS598-1 units for two devices - 2-out-of-3 redundancy
Figure 5-3 Connecting three power supply units to a SCALANCE XR552-12M.
SCALANCE XR528-6M is used analogously.
Connect each SCALANCE XR500 to its own PS598-1. In addition to this, connect
both SCALANCE XR500 devices to the third PS598-1. Both SCALANCE XR500
devices can now continue to operate after the failure of one PS598-1. The
SCALANCE XR500 detects the failure of a power source and signals the failure. The
PS598-1 units share the applied load automatically and uniformly.
Note
Two connectors for the 24 VDC output voltage
The PS598-1 has two connectors with the output voltage 24 VDC. Note that you can
only use the connector on the front or the connector on the rear of the PS598-1. You
cannot operate the device with the connectors on the front and rear at the same time.
Note
To wire up the power supply connector, use copper cable of the category 14 AWG to
10 AWG or cable with a cross-sectional area of 1.5 to to 4 mm2.

Connection
Power supply unit PS598-1 for SCALANCE XR500
16 A5E03275848-04, 05/2013
In areas subject to the NEC or CEC:
WARNING
Safety notice for connectors with LAN (Local Area Network) marking
A LAN or LAN segment, with all its associated interconnected equipment, shall be
entirely contained within a single low-voltage power distribution and within a single
building. The LAN is considered to be in an "environment A" according to
IEEE802.3
or "environment 0" according to IEC TR 62102, respectively.
Never connect directly to TNV-circuits (Telephone Network) or
WAN (Wide Area Network).
5.2 LED display
LED display
A PS598-1 has two LEDs each, one green and one red. If the green LEDs is lit
(24V OK), the output voltage is correctly applied. If the red LED is lit (SHUT DOWN)
an error has occurred.
Possible errors/faults:
●The output voltage is not correct.
●Temperature of the PS598-1 is too high.

Power supply unit PS598-1 for SCALANCE XR500
A5E03275848-04, 05/2013 17
6 Upkeep and maintenance
The PS598-1 has a service panel, behind which there is a removable air filter. The air
filter can be replaced during operation.
Procedure
1. Open the service panel.
2. Take the air filter out of the device.
3. Clean the air filter.
4. Place the cleaned air filter in the device again.
5. Close the panel.
NOTICE
A badly contaminated air filter reduces air flow and can cause the device to be
damaged.
Check the degree of contamination of the air filter regularly and clean it when
necessary.

Power supply unit PS598-1 for SCALANCE XR500
18 A5E03275848-04, 05/2013
7 Technical data
Device variants
The following technical specifications apply to the following device:
●PS598-1
Connectors
Interface
Execution
Power
●4-pin terminal block for 2 x 24 VDC on the front of the device.
●Plug on the rear of the housing for direct connection to a
SCALANCE XR500.
Construction
Property
Value / version / exists
Dimensions without brackets for rack
mounting
(W x H x D)
446 x 44 x 140 mm
(1 height unit)
Weight
1700 g
Surface of the housing
Powder coating
Degree of protection
IP20 (with closed panel in housing)
Installation in a 483 mm rack (19" rack)
Yes
DIN rail mounting
No
S7-300 standard rail mounting
No
Wall mounting
No
Electrical data
Property
Value
Rated power
300 W
Input voltage
100 to 240 VAC / 50/60 Hz
Output voltage
24 VDC
Output current
12.5 A
Input current at 300 W
3,6 ... 1.6 A
Overcurrent protection of the power supply
F6.3 AH / 250 VAC
