Siemens SIMATIC TD 200 User manual

Preface, Contents
Product Overview and
Installation 1
Configuring the TD 200 2
Operating the TD 200 3
Creating Sample
Programs 4
Specifications and
Reference A
Multiple CPU Configura-
tions B
Troubleshooting C
TD 200 Parameters and
Messages D
Index
TD 200
Operator Interface
User Manual
This manual has the order number:
6ES7272-0AA00-8BA0
SIMATIC

Positioniermodul für Abschaltpunktepositionierung
This manual contains notices which you should observe to ensure your own personal safety,
as well as to protect the product and connected equipment. These notices are highlighted in
the manual by a warning triangle and are marked as follows according to the level of danger:
!Danger
indicatesthatdeath,severepersonalinjury,orsubstantialpropertydamagewillresultifproper
precautions are not taken.
!Warning
indicates that death,severe personal injury, orsubstantial property damagecan result ifproper
precautions are not taken.
!Caution
indicatesthatminorpersonalinjuryorpropertydamagecanresultifproperprecautionsarenot
taken.
The device/system may only be set up and operated in conjunction with this manual.
Only qualified personnel should be allowed to install and work on this equipment.
Qualified persons are defined as persons who are authorized to commission, to ground, and
to tag circuits, equipment, and systems in accordance with established safety practices and
standards.
Note the following:
!Warning
This device and its components may only be used for the applications described in the catalog
or the technical description, and only in connection with devices or components from other
manufacturers which have been approved or recommended by Siemens.
This product can only function correctly and safely if it is transported, stored, set up, and
installed correctly, and operated and maintained as recommended.
SIMATIC, SIMATIC NET and SIMATIC HMIare registered trademarks of
Siemens AG.
Wehavecheckedthecontentsofthismanualforagreementwiththe
hardware and software described. Since deviations cannot be
precluded entirely, we cannot guarantee full agreement. However,
the data in this manual are reviewed regularly and any necessary
corrections included in subsequent editions. Suggestions for
improvement are welcomed.
 Siemens AG 1997
Technical data subject to change.
Disclaimer of LiabilityCopyright Siemens AG 1997 All rights reserved.
The reproduction, transmission, or use of this document or its
contents is not permitted without express written authority.
Offenders will be liable for damages. All rights, including rights
createdbypatentgrantorregistrationofautilitymodelordesign,are
reserved.
Siemens AG
Bereich Automatisierungs- und Antriebstechnik
GeschaeftsgebietIndustrie-Automatisierungssysteme
Postfach 4848, D-90327 Nuernberg
Siemens Aktiengesellschaft 6ES7272-0AA00-8BA0
Safety Guidelines
Qualified Personnel
Correct Usage
Trademarks

iii
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Preface
Purpose
The
SIMATIC TD 200 Operator Interface User Manual is a combination user and reference
manual that describes the operation of the TD 200 Operator Interface Module with an S7-200
programmable logic controller.
Audience
This manual is designed for engineers, programmers, and maintenance personnel who have
a general knowledge of programmable logic controllers and operator interfaces.
Scope of This Manual
This manual describes the operation of version 1.1 and later of the TD 200. This release
includes new features and other operational enhancements.
Release Notes
Version 1.1 of the TD 200 includes the following new features:
SSupports real (floating-point) numbers
SProvides password protection for editable variables and for the Menu mode of operation
SSupports multiple parameter blocks in a single S7-200 CPU (with a setup menu for
entering the V memory address)
SSupports 19.2 Kbaud communication rate (with a setup menu for changing the baud rate)
SSets a bit in the parameter block every time an arrow key is pressed, thus allowing your
program to have more control of the TD 200
SIncludes an alternative character set for creating bar charts
Other enhancements (such as using any key—not just the ESC key—to cancel the scrolling
of the messages, or using SHIFT-ENTER to set a variable to 0) either improve the
performance of the TD 200 or make it easier to use. For example, you can now use the
SHIFT-UP/DOWN arrow keys to perform a character-by-character edit of a variable that is
embedded in a message.
Version 1.2 of the TD 200 includes the following new features:
SCorrects problems with multi-master networks
SMakes the editors more consistent
For upgrades to version 1.2 of the TD 200, contact your distributor.

iv SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Agency Approvals
The SIMATIC S7-200 series meets the standards and regulations of the following agencies.
SUnderwriters Laboratories, Inc.:
UL 508 Listed
(Industrial Control Equipment)
SCanadian Standards Association:
CSA C22.2 Number 142 Certified
(Process Control Equipment)
SEuropean Community EMC Directive 89/336/EEC and Low Voltage Directive 73/23/EEC
How to Use This Manual
If this is your first experience using an operator interface, read the entire manual. If you are
an experienced user, refer to the Table of Contents or Index to find specific information.
Related Information
Refer to the following documentation for more detailed information about selected topics:
S SIMATIC S7-200 Programmable Controller System Manual: provides information about
installing and programming the S7-200 Micro PLCs, including the following topics:
– Installing and wiring the S7-200 CPU and expansion I/O modules, and installing the
STEP 7–Micro/WIN software
– Designing and entering a program
– Understanding features of the CPU, such as data types and addressing modes, the
CPU scan cycle, password-protection, and network communication
This manual also includes descriptions and examples for the programming instructions,
typical execution times for the instructions, and the data sheets for the S7-200
equipment.
S SIMATIC STEP 7–Micro/DOS User Manual: describes how to use the
STEP 7–Micro/DOS programming software package for the SIMATIC S7-200 series of
programmable logic controllers.
Preface

v
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Contents
1 Product Overview and Installation
Chapter Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Hardware Features 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Components of the TD 200 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TD 200 Keyboard Features 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Installing the TD 200 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing the Mounting Surface 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preparing the TD 200 for Mounting 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting the TD 200 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Connecting the Communication Cable 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing Cable for One-to-One Communication 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing a Multiple CPU Network 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Connecting a Power Cable 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplying Power from the S7-200 CPU 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplying Power from an External Power Supply 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Configuring the TD 200
Chapter Overview 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Starting the STEP 7–Micro/WIN TD 200 Configuration Wizard 2-2. . . . . . . . . . . . . . . .
Selecting Language and Bar Graph Character Set 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . .
Enabling Time-of-Day, Force Function, and Password Protection 2-4. . . . . . . . . . . . . .
Specifying Function Key Memory Bits and Display Update Rate 2-4. . . . . . . . . . . . . . .
Selecting Message Size and Number of Messages 2-6. . . . . . . . . . . . . . . . . . . . . . . . . .
Specifying Parameter Block Address, Message Enable Address, and
Message Location 2-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Creating A Text-Only Message 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Embedding Data Values in a Text Message 2-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Formatting the Embedded Data Value 2-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Creating a Message That Requires Acknowledgement 2-14. . . . . . . . . . . . . . . . . . . . . . .
Viewing the TD 200 Parameter Block and Messages 2-17. . . . . . . . . . . . . . . . . . . . . . . .
2.2 Creating a Sample Program 2-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Operating the TD 200
Chapter Overview 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Using the Display Message Mode 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functions Available 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scrolling through Messages 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Editing a Value 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Acknowledging a Message 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Using the Menu Mode 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Menus Available 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting Menu Options 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exiting Menu Mode 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vi SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
3.3 Viewing Messages 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessing the Menu 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Viewing CPU Status Menu 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessing the Menu 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Viewing Fatal and Non-fatal Errors 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fatal Error Messages 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Non-fatal Error Messages 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5 Forcing I/O 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessing the Menu 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Entering a Password 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Correcting a Password 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting a Force I/O Option 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Forcing and Unforcing an I/O Point 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6 Setting Time and Date in the CPU 3-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessing the Menu 3-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Editing the Time and Date 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.7 Releasing the Password 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Restoring the Password Protection 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.8 Using the TD 200 Setup Menu Option 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting the Network Address of the TD 200 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting the CPU Address 3-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Entering the Parameter Block Address 3-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting the Baud Rate 3-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Creating Sample Programs
Chapter Overview 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Using a Text Message to Create a Clock for a CPU 214 4-2. . . . . . . . . . . . . . . . . . . . . .
Creating a Sample Program 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the STEP 7–Micro/WIN TD 200 Configuration Wizard 4-2. . . . . . . . . . . . . . . . . .
4.2 Using the Bar Graph Character Set 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A Specifications and Reference
Chapter Overview A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.1 Specifications for Model Number 6ES7 272–0AA00–0YA0 A-2. . . . . . . . . . . . . . . . . . . .
A.2 ASCII Characters A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.3 ALT Key Combinations for International and Special Characters A-4. . . . . . . . . . . . . . .
B Multiple CPU Configurations
Chapter Overview B-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.1 Configuring for Multiple CPU Communication B-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.2 Building a TD/CPU Cable B-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Making a Cable That Supplies Power to the TD 200 B-4. . . . . . . . . . . . . . . . . . . . . . . . .
Making a Cable That Does Not Supply Power to the TD 200 B-4. . . . . . . . . . . . . . . . . .
C Troubleshooting
D TD 200 Parameters and Messages
Software Support for Configuring a TD 200 D-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter Overview D-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents

vii
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
D.1 TD 200 Parameter Block D-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Understanding How Messages Are Displayed D-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Understanding How the TD 200 Uses the Parameter Block D-2. . . . . . . . . . . . . . . . . . .
Description of the Parameter Block Format D-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D.2 Building the Parameter Block D-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parameter Block ID Bytes 0 and 1 D-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TD 200 Configuration Bytes 2 and 3 D-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Number of Messages Byte 4 D-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Prioritizing Messages D-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M Area Address Byte 5 D-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Message Address Bytes 6 and 7 D-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Message-Enable Address Bytes 8 and 9 D-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Edit Password Byte 10 and 11 (Optional) D-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D.3 Formatting Messages D-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Twenty-Character Message Format D-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Forty-Character Message Format D-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D.4 Embedding Data Values in a Text Message D-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Data Value Format Options D-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Defining the Data Value Format D-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Acknowledgement Bit 0 D-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Acknowledge-Notification Bit 1 D-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Edit-Notification Bit 2 D-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Password Protection Bit 3 D-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Edit-Allowed Bit 4 D-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Data Size/Format, and Decimal Bits 0, 1, 2 and 4, 5, 6 D-17. . . . . . . . . . . . . . . . . . . . . . .
D.5 Understanding Message Types D-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
No Acknowledgement, No Edits Allowed D-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Acknowledgement, No Edits Allowed D-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
No Acknowledgement, Edits Allowed D-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Acknowledgement, Edits Allowed D-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D.6 Editing Variables with the TD 200 D-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Acknowledging and Editing a Message D-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aborting an Edit D-23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents

viii SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Figures
1-1 Major Components of the TD 200 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 Mounting Surface Hole Dimensions 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 Removing the Three Mounting Screws 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-4 Positioning Spacers 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-5 One-to-One Configuration 1-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-6 Supplying Power with the TD/CPU Cable 1-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-7 Supplying Power Using an External Power Supply 1-7. . . . . . . . . . . . . . . . . . . . . . . . . .
2-1 Accessing the TD 200 Configuration Wizard 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Wizard: Language and Character Set 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-3 Wizard: Time-of-Day Clock, Force I/O, and Password Protection 2-4. . . . . . . . . . . . . .
2-4 Bits Set by Each Function Key 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-5 Wizard: Function Key Memory Bits and Update Rate 2-5. . . . . . . . . . . . . . . . . . . . . . . .
2-6 Wizard: Message Size and Number of Messages 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . .
2-7 Wizard: Block Address, Enable Flags, and Message Location 2-7. . . . . . . . . . . . . . . . .
2-8 Wizard: 40-Character Message 2-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-9 Wizard: Embedding Variable Data Value in a Message 2-10. . . . . . . . . . . . . . . . . . . . . . .
2-10 TD 200 Message: Creating a Word Embedded Data 2-11. . . . . . . . . . . . . . . . . . . . . . . . .
2-11 Wizard: Embedded Data Value Place Holder in Message 2-12. . . . . . . . . . . . . . . . . . . . .
2-12 Embedded Data: Making the Data Editable and Password Protected. 2-13. . . . . . . . . .
2-13 Wizard: Completed Second Message 2-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-14 Wizard: Embedding Data to Require Acknowledgement 2-14. . . . . . . . . . . . . . . . . . . . . .
2-15 Embedded Data: Requiring Acknowledgement of Message 2-15. . . . . . . . . . . . . . . . . . .
2-16 Wizard: Message Requires Acknowledgement 2-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2-17 Data Block Editor Showing a Sample TD 200 Parameter Block 2-17. . . . . . . . . . . . . . . .
2-18 Sample Program in the Ladder and Statement List Editors 2-19. . . . . . . . . . . . . . . . . . . .
3-1 Display Message Mode 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-2 Menu Mode 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-3 Incorrect Password Display 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-4 Force I/O Menu Display 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-5 Changing the Force Status of an I/O Point 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3-6 No Clock in CPU Display 3-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-1 Accessing the TD 200 Configuration Wizard 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-2 Data Block of the Clock Message 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-3 Sample Program for Creating a Clock 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-4 Data Block of the Bar Graph Sample Program 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4-5 Sample Program for Creating a Bar Graph 4-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B-1 A Typical Multiple CPU Network B-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B-2 TD/CPU Cable with Power Connections B-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B-3 TD/CPU Cable without Power Connections B-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-1 Displaying Different Messages on Two TD 200 Units D-2. . . . . . . . . . . . . . . . . . . . . . . . .
D-2 TD 200 Parameter Block D-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-3 Information Contained in Byte 2 of the TD 200 Parameter Block D-4. . . . . . . . . . . . . . .
D-4 Information Contained in Byte 3 of the TD 200 Parameter Block D-5. . . . . . . . . . . . . . .
D-5 Message-Enable Bits for up to 80 Messages D-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-6 Bits Set by Each Function Key D-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-7 Twenty-Character Message Format D-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-8 Forty-Character Message Format D-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-9 Format Word Usage D-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-10 Bit Values of the Format Word D-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-11 Acknowledgement Bit of Byte 0 of the Format Word D-12. . . . . . . . . . . . . . . . . . . . . . . . .
D-12 Acknowledge-Notification Bit of Byte 0 of the Format Word D-13. . . . . . . . . . . . . . . . . . .
D-13 Sample Program for Using the Acknowledge-Notification Bit D-14. . . . . . . . . . . . . . . . . .
D-14 Edit-Notification Bit of Byte 0 of the Format Word D-14. . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-15 Sample Program for Using the Edit-Notification Bit D-15. . . . . . . . . . . . . . . . . . . . . . . . . .
D-16 Password Protection Bit of Byte 0 of the Format Word D-16. . . . . . . . . . . . . . . . . . . . . . .
D-17 Edit-Allowed Bit of Byte 0 of the Format Word D-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-18 Bit Values of Byte 1 of the Format Word D-17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents

ix
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Tables
1-1 Components of the TD 200 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-2 Description of Command Keys 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1-3 Description of Function Keys 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A-1 ASCII Characters for the TD 200 A-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A-2 ALT Key Combinations for International and Special Characters A-4. . . . . . . . . . . . . . .
C-1 Troubleshooting Table C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D-1 Required Display Characters for Each Display Format D-19. . . . . . . . . . . . . . . . . . . . . . .
Contents

xSIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Contents

1-1
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Product Overview and Installation
The Text Display 200 (TD 200) is a text display and operator interface for the S7-200 family
of programmable logic controllers. This manual uses the terms programmable logic controller
and S7-200 CPU (or CPU) interchangeably.
The following is a list of TD 200 features:
SDisplays messages read from the S7-200 CPU.
SAllows adjustment of designated program variables.
SProvides ability to force/unforce I/O points.
SProvides ability to set the time and date for CPUs that have real-time clocks.
The TD 200 receives its power either from the S7-200 CPU through the TD/CPU cable or
from a separate power supply.
The TD 200 functions as a point-to-point interface (PPI) master when it is connected to one
or more S7-200 CPUs. The TD 200 is also designed to operate with any other PPI master in
a network. Multiple TD 200s can be used with one or more S7-200 CPUs connected to the
same network.
This manual provides you with hardware configuration directions and programming
examples that require additional equipment. The following is a list of additional equipment
that is necessary to set up and use your TD 200:
SS7-200 series programmable logic controller
SS7-200 programming device
SProgramming cable appropriate for your programming device
Chapter Overview
Section Description Page
1.1 Hardware Features 1-2
1.2 Installing the TD 200 1-4
1.3 Connecting the Communication Cable 1-6
1.4 Connecting a Power Cable 1-7
1

1-2 SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
1.1 Hardware Features
Components of the TD 200
The TD 200 is a small, compact device that provides all the necessary components for
interfacing with your S7-200 CPU. Figure 1-1 shows the major components of the TD 200.
These components are described in Table 1-1. For further information on the technical
specifications of the TD 200, see Appendix A.
Text Display Area
User Label
SIEMENS TD 200
F1
F5 F2 F6 F3 F7 F4 F8
SHIFT ESC ENTER
TD/CPU Cable
Power
Connection
Communication
Port
Gasket
Spacers
Figure 1-1 Major Components of the TD 200
Table 1-1 Components of the TD 200
Component Description
Text Display Area The text display area is a backlit liquid crystal display (LCD) with two
20-character lines. It allows you to see messages received from the
S7-200 CPU.
Gasket A gasket is provided with the TD 200 for installation in inclement
environments.
Communication Port The communication port is a 9-pin D-connector that allows you to
connect the TD 200 to an S7-200 CPU using the supplied TD/CPU
cable.
Power Connection You can connect an external power supply to the TD 200 through the
power connection access located on the right side of the TD 200. This
connection is not required when you use the TD/CPU cable.
TD/CPU Cable The TD/CPU cable provides communication and power to your TD 200.
It is a 9-pin, straight-through cable that is supplied with your TD 200.
User Label The user label is a pull-out label that you can use to customize the
function key labels for your applications.
Keys The TD 200 has nine keys. Five of these keys provide predefined,
context-sensitive functions, and four keys provide user-defined functions.
Spacers Self-adhesive spacers are included for mounting the TD 200 to a
mounting surface. See Figure 1-4.
Product Overview and Installation

1-3
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
TD 200 Keyboard Features
The TD 200 keyboard has a total of nine keys. Table 1-2 describes the five predefined,
context-sensitive command keys.
Table 1-2 Description of Command Keys
Command Keys Description
ENTER Use this key to write new data and to acknowledge a message(s).
ESC Use this key to toggle between Display Message mode and Menu mode or to
abort an edit.
UP ARROW The UP arrow increments data and scrolls the cursor to the next higher priority
message.
DOWN ARROW The DOWN arrow decrements data and scrolls the cursor to the next lower
priority message.
SHIFT The SHIFT key modulates the value of all of the function keys. See Table 1-3
for examples. A flashing “S” is displayed in the lower right of the TD 200
display when you press the SHIFT key.
Table 1-3 describes the four user-defined function keys (F1, F2, F3, F4). You define these
four function keys in your S7-200 CPU program. Pressing a function key sets an M bit. Your
program can use this bit to trigger a specific action.
Table 1-3 Description of Function Keys
Function Keys Description
F1 Function key F1 sets the Mx.0 bit.
If you press the SHIFT key along with, or prior to, pressing the F1 key, F1 sets
the Mx.4 bit.
F2 Function key F2 sets the Mx.1 bit.
If you press the SHIFT key along with, or prior to, pressing the F2 key, F2 sets
the Mx.5 bit.
F3 Function key F3 sets the Mx.2 bit.
If you press the SHIFT key along with, or prior to, pressing the F3 key, F3 sets
the Mx.6 bit.
F4 Function key F4 sets the Mx.3 bit.
If you press the SHIFT key along with, or prior to, pressing the F4 key, F4 sets
the Mx.7 bit.
Product Overview and Installation

1-4 SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
1.2 Installing the TD 200
Preparing the Mounting Surface
Use the template in Figure 1-2 to cut a 138 mm x 68 mm or 5.4 in. x 2.7 in. hole in the
mounting surface (DIN 43700).
138 mm
(5.4 in.)
68 mm
(2.7 in.)
Figure 1-2 Mounting Surface Hole Dimensions
Preparing the TD 200 for Mounting
Use the following steps to prepare the TD 200 for mounting.
1. Remove the three screws from the rear of the TD 200 using a flat-head screwdriver. See
Figure 1-3.
2. Remove the backplate of the TD 200.
Mounting
Screws
Figure 1-3 Removing the Three Mounting Screws
Product Overview and Installation

1-5
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Self-adhesive spacers are included with the TD 200 for mounting the TD 200 to a mounting
surface. The number of spacers you require depends on the thickness of the mounting
surface. Use the following steps to install the spacers.
1. Use the following guidelines to determine the number of spacers required for proper
mounting.
– One spacer for door thickness from 0.3 mm to 1.5 mm (0.01 in. to 0.06 in.)
– Two spacers on top of each other for door thickness of 1.5 mm to 4.0 mm
(0.06 in. to 0.16 in.)
2. Place the spacers over the screw holes on the inside of the backplate. The spacers
maintain pressure on the TD 200 circuit board when the TD 200 is reassembled. See
Figure 1-4.
ÉÉ
ÉÉ
ÉÉ
ÉÉ
ÉÉ
ÉÉ
Backplate
Frontplate
Cabinet Door
or Control Panel
Gasket Spacers
Mounting
Screws
Figure 1-4 Positioning Spacers
Mounting the TD 200
Use the following steps and refer to Figure 1-4 to complete the mounting of your TD 200.
1. Place the supplied gasket on the frontplate of the TD 200.
2. Fit the frontplate into the cutout you made in the mounting surface.
3. Secure the backplate onto the frontplate of the TD 200 using the screws you removed
from the backplate. Tighten the screws.
Product Overview and Installation

1-6 SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
1.3 Connecting the Communication Cable
The TD 200 communicates to the S7-200 CPU through the TD/CPU cable. You can
configure the TD 200 using the TD/CPU cable in the following ways:
SOne-to-one configuration
SMultiple S7-200 CPU configuration
Installing Cable for One-to-One Communication
Use a one-to-one network configuration when you have just one S7-200 CPU to connect to
one TD 200. A one-to-one configuration consists of a TD 200, an S7-200 CPU, and a
TD/CPU cable that is supplied with the TD 200.
Figure 1-5 shows you a one-to-one configuration. The TD 200 communicates to and is
powered by the S7-200 CPU using the TD/CPU cable.
SIEMENS TD 200
TD 200
SIMATIC
S7-200
S7-200 CPU
TD/CPU Cable
Figure 1-5 One-to-One Configuration
Installing a Multiple CPU Network
Use a multiple CPU network configuration when you have several S7-200 CPUs to connect
to one or more TD 200s. For more information on configuring for multiple CPU
communication, refer to Appendix B.
Note
The TD 200 defaults to address 1 and attempts to communicate to a CPU at address 2.
See Section 3.8 to change the network address if other addresses are used.
Product Overview and Installation

1-7
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
1.4 Connecting a Power Cable
The TD 200 receives power either from the S7-200 CPU or from an external plug-in power
supply unit.
Note
If you are using the TD 200 with a network of S7-200 CPUs, special consideration must be
taken with the communication and power connections. See Appendix B.
Supplying Power from the S7-200 CPU
Figure 1-6 shows you the TD 200 receiving its power from the CPU through the TD/CPU
cable. Use this type of power supply when the distance between the TD 200 and the S7-200
CPU is less than 2.5 m (8.2 ft.).
SIEMENS TD 200
TD 200
SIMATIC
S7-200
S7-200 CPU
TD/CPU Cable
Figure 1-6 Supplying Power with the TD/CPU Cable
Supplying Power from an External Power Supply
Figure 1-7 shows the TD 200 receiving its power from an external power supply. Use this
type of power supply when the distance between the TD 200 and the S7-200 CPU is greater
than 2.5 m (8.2 ft.). If you choose to connect the TD 200 to the CPU with a longer cable
(2.5 m/8.2 ft.), use PROFIBUS components (see the SINEC IK10 Catalog). The power
supply is available from your Siemens distributor. See Appendix A for part numbers.
AC
SIEMENS TD 200
TD 200 To CPU
Figure 1-7 Supplying Power Using an External Power Supply
Product Overview and Installation

1-8 SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Product Overview and Installation

2-1
SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
Configuring the TD 200
The TD 200 is a text display device that displays messages enabled by the S7-200 CPU.
You do not have to configure or program the TD 200. The only operating parameters stored
in the TD 200 are the address of the TD 200, the address of the CPU, the baud rate, and the
location of the parameter block. The configuration of the TD 200 is stored in a TD 200
parameter block located in the variable memory (V memory) of the CPU. The operating
parameters of the TD 200, such as language, update rate, messages, and message-enabled
bits, are stored in the TD 200 parameter block in the CPU.
Upon power-up, the TD 200 reads the parameter block from the CPU. All of the parameters
are checked for legal values. If everything is acceptable, the TD 200 starts actively polling
the message-enabled bits to determine what message to display, reads the message from
the CPU, and then displays the message.
Chapter Overview
Section Description Page
2.1 Starting the STEP 7–Micro/WIN TD 200 Configuration Wizard 2-2
2.2 Creating a Sample Program 2-18
2

2-2 SIMATIC TD 200 Operator Interface
C79000-G7076-C205-04
2.1 Starting the STEP 7–Micro/WIN TD 200 Configuration Wizard
STEP 7–Micro/WIN provides a “wizard” that makes it easy to configure the parameter block
and the messages in the data memory area of the S7-200 CPU. The TD 200 Configuration
Wizard automatically writes the parameter block and message texts to the data block editor
after you finish choosing the options and creating the messages. This data block can then be
downloaded to the CPU. For detailed information about the TD 200 parameter block and
message formats, see Appendix D.
This chapter contains the procedure for creating a sample TD 200 application. Use the
instructions in this example to create a TD 200 parameter block and three messages using
the TD 200 Configuration Wizard. The first message is text only. The second message
contains both text and embedded data. The third message is a text message that requires
acknowledgement by the operator.
The example also shows how to use the function keys to enable a message and how to use
the acknowledge- and edit-notification bits within your program.
To open the wizard, select the menu command Tools "TD 200 Wizard... as shown in
Figure 2-1.
To navigate through the dialog boxes of the wizard, click on “Next>.” At any time during the
procedure, click on the “<Prev” button to go back to a previous dialog box if you need to
change or review any of the parameters you have defined. In the final dialog box, click on
“Finish” to validate and save the parameter block and close the wizard.
You can view the configured parameter block and messages by opening the
STEP 7–Micro/WIN data block editor.
✂
Project Edit View CPU Debug Tools Setup Window Help
STEP 7-Micro/WIN – c:\microwin\project1.prj
TD 200 Configuration Wizard
CancelNext >
This wizard will help you configure TD 200 messages quickly and
easily. When you are finished, the wizard will generate the supporting
data block code for you.
< Prev
To begin configuring TD 200 messages, click Next.
1, 1
Tools
Instruction Wizard..
TD 200 Wizard...
Project Services ...
Edit/Add Tools...
Figure 2-1 Accessing the TD 200 Configuration Wizard
Configuring the TD 200
