Siemens N148/23 User manual

N 148/23
IP Interface Secure
Application program description
A6V11689762_en--_d Smart Infrastructure
2023-07-27

Supplementary information
Purpose of the application program description
The application program description contains detailed information on the paramet-
ers and communication objects of the ETS application program as well as a de-
scription of the functions that can be set via the different parameters.
Target audience of the application program de-
scription
The application program description is intended for people who want to commis-
sion IP interface or reconfigure it, who have a basic understanding of network tech-
nology and have successfully attended the following courses:
● KNX basics course
● IP fundamentals KNXnet/IP
Product documentation and support
Product documentation
Documents related the product, such as operating and installation instructions, ap-
plication program description, product database, additional software and CE de-
clarations can be downloaded from the following website:
http://www.siemens.com/gamma-td
Frequently asked questions
For frequently asked questions about the product and their solutions, see:
https://support.industry.siemens.com/cs/products?dtp=Faq&mfn=ps&lc=en-WW
FAQ
Support
Contact details for additional questions relating to the product:
Tel.: [phone]
http://www.siemens.com/supportrequest
2 | 18 A6V11689762_en--_d

A6V11689762_en--_d 3 | 18
Contents
1 Information on IP Interface Secure and on the application program 5
1.1 Cyber security disclaimer ......................................................................... 5
2 Function .................................................................................................. 6
2.1 Security functions of IP Interface Secure ................................................. 6
2.2 Functions of IP Interface Secure .............................................................. 6
3 Notes on secure data transfer............................................................... 8
4 Structure of the setting options in ETS................................................ 9
5 Parameter................................................................................................ 10
6 Commissioning ...................................................................................... 11
6.1 Function in factory settings....................................................................... 11
6.2 Location of the device certificate QR code............................................... 11
6.3 Commissioning the device ....................................................................... 11
6.4 Specifying the name and physical address of the device......................... 12
6.5 Assigning an IP address........................................................................... 12
6.6 Setting up additional physical addresses ................................................. 13
6.7 Setting up remote access......................................................................... 13
7 Help in case of errors and problems .................................................... 14
7.1 Frequently asked questions ..................................................................... 14
7.2 Possible errors ......................................................................................... 14
7.3 Troubleshooting using ETS ...................................................................... 14
7.4 Checking device certificates..................................................................... 15
8 Resetting the device to factory settings .............................................. 16
Index .................................................................................................................. 17

4 | 18 A6V11689762_en--_d

1 Information on IP Interface Secure and on
the application program
Product family: System device
Product type: Interface
Manufacturer: Siemens
Name: IP Interface Secure N148/23
Order no.: 5WG1 148-1AB23
Application: 07B0 CO IP Interface Secure 7205 03
System requirement:
● At least ETS 5.7.3 or above
1.1 Cyber security disclaimer
Siemens provides a portfolio of products, solutions, systems and services that in-
cludes security functions that support the secure operation of plants, systems, ma-
chines and networks. In the field of Building Technologies, this includes building
automation and control, fire safety, security management as well as physical secur-
ity systems.
In order to protect plants, systems, machines and networks against cyber threats, it
is necessary to implement – and continuously maintain – a holistic, state-of-the-art
security concept. Siemens’ portfolio only forms one element of such a concept.
You are responsible for preventing unauthorized access to your plants, systems,
machines and networks which should only be connected to an enterprise network
or the internet if and to the extent such a connection is necessary and only when
appropriate security measures (e.g. firewalls and/or network segmentation) are in
place. Additionally, Siemens’ guidance on appropriate security measures should be
taken into account. For additional information, please contact your Siemens sales
representative or visit https://www.siemens.com/global/en/home/company/topic-
areas/future-of-manufacturing/industrial-security.html.
Siemens’ portfolio undergoes continuous development to make it more secure.
Siemens strongly recommends that updates are applied as soon as they are avail-
able and that the latest versions are used. Use of versions that are no longer sup-
ported, and failure to apply the latest updates may increase your exposure to cyber
threats. Siemens strongly recommends to comply with security advisories on the
latest security threats, patches and other related measures, published, among oth-
ers, under https://www.siemens.com/cert/en/cert-security-advisories.htm.
Information on IP Interface Secure and on the application program
Cyber security disclaimer
1
A6V11689762_en--_d 5 | 18

2 Function
2.1 Security functions of IP Interface Secure
IP Interface Secure supports the “KNX IP Secure” security standard and offers the
following security functions, among others:
● Secured access only from authenticated devices
● Secure commissioning via ETS
During secure commissioning via ETS, the device certificate printed onto the
device (FDSK = Factory Default Setup Key) is imported and stored for this exact
device in the ETS project.
For more information on KNX IP Secure, refer to the ETS software help or go to
the following website: https://support.knx.org
Alternatively, insecure commissioning without KNX IP Secure is also possible. In
this case, the device is insecure and responds like other KNX devices without IP
Secure.
2.2 Functions of IP Interface Secure
IP Interface Secure is a rail-mounted device for installation in distributions. The
device uses the KNXnet/IP standard and acts as an interface to KNX/EIB via data
networks using the internet protocol (IP). To do so, this device enables bus access
from a PC or other data processing devices.
Connections and power
supply
The connection to KNX is established using a bus connector terminal (black and
red terminals). The connection to the data network (IP via 10 or 100BaseT (de-
pending on the switch)) is established using an RJ–45 socket.
IP Interface Secure also needs operating voltage in order to operate. IP Interface
Secure can obtain this operation voltage via the network line using “Power over
Ethernet” as per IEEE 802.3af. Alternatively, the operating voltage can be obtained
via the second terminal block (white-yellow terminals) from an AC/DC 24 V safety
extra low voltage supply or from a bus voltage supply (unchoked voltage, DC 29
V). As soon as the safety extra low voltage supply is connected to the second ter-
minal block, operating voltage is drawn from it.
Remote access Even if there is no direct network connection between a PC and an IP router, you
can use a suitable network infrastructure for remote access to a KNX installation.
Five simultaneous connections (remote accesses) are possible.
Setting up remote access [➙13]
Function
Security functions of IP Interface Secure
2
6 | 18 A6V11689762_en--_d

LAN
IP interface
KNX device
KNX device
KNX device
DSL router with VPN or ISDN/
dial-in router
LAN
Internet (via VPN connection
or dial-in modem)
DSL router
or modem
KNX
Fig. 1: Secure remote access
Additional functions IP Interface Secure has the following attributes:
● Easy to connect to higher-level systems by using the internet protocol (IP)
● Direct access to the KNX installation from every point in the IP network
(KNXnet/IP tunneling)
● Up to five KNXnet/IP tunneling connections are possible at the same time
● LED displays for operational readiness, KNX communication and IP communic-
ation
● Easy and secure configuration using ETS
● Easy to connect to visualization systems and facility management systems
● Slot for SD card (not in use)
Function
Functions of IP Interface Secure
2
A6V11689762_en--_d 7 | 18

3 Notes on secure data transfer
Instructions for secure operation of KNX IP Secure products
● Only operate the device in a protected network environment and do not allow
direct access from the Internet.
● Additionally secure remote access to the device via a VPN connection.
A virtual private network (VPN) establishes an encrypted and authorized con-
nection (VPN tunnel) from a remote connection to a network via the internet.
This VPN connection enables secure communication protected from eaves-
dropping between a remote device and the KNX installation.
● Only operate the device in secure mode. The device is in secure mode when
the device has been commissioned via secure commissioning, secure tunnel-
ing is enabled and strong and different passwords are used.
● Set up a separate IP network with its own hardware for KNX communication.
● Use user IDs and strong passwords to restrict access to the (KNX) IP network.
● Restrict access to the (KNX)IP network to an authorized group of people using
user IDs and strong passwords..
● Document network settings and give them to the building owner/operator or
LAN administrator.
● Coordinate the administration of access rights to this KNXnet/IP device in an IP
network with the respective IP network administrator.
Measures after replacing a device in the network
If an IP Router Secure or an IP Interface Secure in secure mode is stolen from a
network or replaced due to a defect, secure commissioning has to be repeated for
all other devices in the network. To do this, deactivate the“Secure commissioning“
option for each device in the settings of the project, activate the option again and
load the data to the devices again. (There is no need to load the data into the
device between deactivation and reactivation.)
Secure commissioning has to be repeated because it is not possible to exclude the
possibility that the keys that are in the secure section of the device can be read.
Recommissioning has the effect that new keys are generated and the old keys be-
come worthless. The removed device no longer works in the network.
More information on KNX security
For more information on KNX security, including, for example, a security check,
refer to the “KNX Secure” section on the KNX website (http://www.knx.org).
Notes on secure data transfer
3
8 | 18 A6V11689762_en--_d

4 Structure of the setting options in ETS
123
4
Fig. 2: ETS overview
1 Tree view of the different sections
(e.g. devices, topology and group
addresses)
2 Listing of parameter cards
3 Parameter section
In this area, parameters are set,
enabled or disabled.
4 “Properties” section (e.g. configur-
ation of IP and security, additional
physical addresses)
You can use the ‘Highlight changes’ button to highlight in yellow any parameters
that do not have the default settings.
Structure of the setting options in ETS 4
A6V11689762_en--_d 9 | 18

5 Parameter
Parameters of the “IP settings” parameter card
TTL (Time-to-Live) Uni-
cast Parameter Settings
TTL (Time-to-Live) Unicast 0 ... 255
Function:
This parameter can be used to set the TTL value for the IP protocol. The default
value is “128.” If the local network administrator specifies a different value, this
value can be entered here.
The value specifies the number of intermediate stations (e.g. routers) which a data
package may pass through between sender and receiver. If the value is set too
low, data packages can get lost and are not received by the recipient.
Parameter
5
10 | 18 A6V11689762_en--_d

6 Commissioning
6.1 Function in factory settings
In the factory settings, the configuration parameters are set as follows:
● Physical address of IP Interface Secure: Setting: “15.15.255” (=FFFF hex)
– Specifying the name and physical address of the device [➙12]
● IP address assignment: Setting: “Obtain IP address automatically”
– Assigning an IP address [➙12]
6.2 Location of the device certificate QR code
Fig. 3: Device certificate
The QR code of the device certificate is affixed to the device as a sticker. There is
a duplicate QR code, which can be removed for easy commissioning.
6.3 Commissioning the device
Commissioning the device with “KNX IP Secure”
wA project is open in ETS.
1. Add the device to the project.
aIf the project is not yet password-protected, the ‘Set project password’ win-
dow appears.
2. Enter the password in the ‘New password’ and ‘Confirm password’ input fields,
then click ‘OK’ to confirm.
aThe ‘Add device certificate’ window appears.
3. If you have a webcam, press the ‘...’ button and then scan the QR code sticker
on the device.
4. If you do not have a webcam or are unable to read the QR code, enter the 6x6-
character certificate key on the sticker on the device.
aOnce the certificate key has been entered correctly, a green checkmark ap-
pears at the end of the line. In addition, the serial numbers and the factory
key of the device are displayed.
Commissioning
Function in factory settings
6
A6V11689762_en--_d 11 | 18

5. Compare the displayed serial number to the serial number on the device.
aIf the serial numbers do not match, the certificate key of a different device
was entered and transfer of data will not work later on.
6. Press ‘OK’ to confirm the entries.
aThe device has been added to the project. The security functions of “KNX
IP Secure” are activated automatically.
Commission device without “KNX IP Secure”
Commissioning without “KNX IP Secure”
Alternatively, the device can also be commissioned without KNX IP Secure. In
this case, the device is insecure and responds like other KNX devices without the
KNX IP Secure function.
To commission the device without KNX IP Secure, select the device in the ‘Topo-
logy’ or ‘Devices’ section and set the ‘Secure commissioning option’ to ‘Deactiv-
ated’ in the ‘Properties’ area of the ‘Settings’ tab.
6.4 Specifying the name and physical address of
the device
A unique device name helps recognize and find the device in a KNXnet/IP visualiz-
ation or within a project in ETS.
wThe device has been added to the project.
1. Select the device in the ‘Topology’ or ‘Devices’ section.
2. In the ‘Properties’ section, switch to the ‘Settings’ tab.
3. In the ‘Name’ input field, enter a unique name of 30 characters maximum for
the selected device.
4. In the ‘Physical address’ input field, enter the physical address of the device
The address must be as yet unassigned.
aThe settings are saved automatically.
6.5 Assigning an IP address
For details on the IP address and additional network settings, contact your local
network administrator.
wThe device has been added to the project.
1. Select the device in the ‘Topology’ or ‘Devices’ section.
2. In the ‘Properties’ section, switch to the ‘IP’ tab.
3. Make the desired IP address settings.
aThe settings are saved automatically in the ETS project.
4. Saving settings in the device. To do so, use the ETS software for full program-
ming (menu item: “Program” > “Physical address & application program”).
The following settings are possible:
●Obtain IP address automatically
If you select this option, the device is automatically assigned an IP address.
This happens either via an DHCP service in the network or, if no DHCP service
Commissioning
Specifying the name and physical address of the device
6
12 | 18 A6V11689762_en--_d

has been configured, via the device itself (AutoIP).
The MAC address required for configuring the DHCP service can be read un-
derneath this setting option or on a sticker on the device.
●Use fixed IP address
When this option is selected, additional input fields are displayed in which the
desired IP address for the device as well as a subnetwork screen and the
standard gateway can be entered.
6.6 Setting up additional physical addresses
For stable device communication via KNXnet/IP tunneling, the device must use a
separate physical address for each connection.
These additional addresses must not be identical to the physical address of the
device and must not be used by any other bus device either.
When inserting the device into a project in ETS, additional physical addresses are
automatically created for the device. These can be changed, if necessary.
For additional information on assigning and changing physical addresses, refer to
the ETS software help.
When the entire device is reset to factory settings, the physical addresses are re-
set: Resetting the device to factory settings [➙16]
6.7 Setting up remote access
Even if there is no direct network connection between a PC and an IP router, you
can use a suitable network infrastructure for remote access to a KNX installation.
Five simultaneous connections (remote accesses) are possible.
LAN
IP interface
KNX device
KNX device
KNX device
DSL router with VPN or ISDN/
dial-in router
LAN
Internet (via VPN connection
or dial-in modem)
DSL router
or modem
KNX
Fig. 4: Secure remote access
wThe device must be reachable from outside of the own network.
◈In the DSL router with VPN or in the ISDN/analogous dial-in router, create two
separate protocol release (port extension tunnels) for the same port number for
the UDP and TCP protocol.
The default port for KNX devices is port “3671.” The ports can be masked be-
cause the external port number differs from the internal port number.
Commissioning
Setting up additional physical addresses
6
A6V11689762_en--_d 13 | 18

7 Help in case of errors and problems
7.1 Frequently asked questions
Frequently asked questions
For frequently asked questions about the product and their solutions, see:
https://support.industry.siemens.com/cs/ww/en/ps/faq
FAQ
7.2 Possible errors
Description Possible cause Solution
When the device is
commissioned, the fol-
lowing error message
appears: “The physical
address: x.y.z is being
used by another
device.”
Physical addresses have been used mul-
tiple times.
Check and/or reset physical ad-
dresses and re-assign.
Setting up additional physical ad-
dresses [➙13]
Troubleshooting using ETS [➙14]
When the device is
commissioned, the fol-
lowing error message
appears: “This is the
certificate of another
device.”
An incorrect device certificate was scanned
or an incorrect certificate key entered.
Checking device certificates [➙15]
Changes to the settings
for the IP address were
not copied to the
device.
Only partial programming was performed. Perform full programming of the
device (physical address and applic-
ation program) via the ETS software
(menu item: ‘Program’ > ‘Physical
address & application program’).
KNX IP Secure routing
is not possible.
The ETS detects dummy applications as
non-secure.
Remove the dummy applications
from the project.
The project cannot be
opened.
The project password is unknown. The project password cannot be re-
set.
Create the project again, reset all
devices to factory settings, and com-
mission it again.
A device cannot be ad-
ded to the project.
A QR code for the device certificate is no
longer available or cannot be assigned to a
device.
The 6X6-digit certificate key for the device
certificate is unknown or can no longer be
assigned to a device.
The device can no longer be com-
missioned and must be disposed of.
7.3 Troubleshooting using ETS
These are some of the troubleshooting options in ETS:
‘Diagnostics’ section
Help in case of errors and problems
Frequently asked questions
7
14 | 18 A6V11689762_en--_d

This section lets you check the physical address, group monitor, and bus monitor
among other things.
‘Reports’ section
This area lets you export details on different areas of the project or print them dir-
ectly.
For more information on ETS, see the online help of the ETS software.
7.4 Checking device certificates
1. Click the ‘ETS’ button in the menu bar.
2. Select the project from the list.
aDetails on the project are shown on the right side.
3. Select the ‘Security’ tab page.
aA list of device certificates belonging to the project is displayed.
Help in case of errors and problems
Checking device certificates
7
A6V11689762_en--_d 15 | 18

8 Resetting the device to factory settings
NOTICE
Loss of data due to resetting device!
When you reset the device, all parameters and settings entered are deleted.
● Ensure that the device is really supposed to be reset.
Resetting the device to factory settings
◈Press the Learn button (at least 20 seconds) until the programming LED starts
flashing quickly.
aThe programming LED flashes for 8 seconds.
aThe device has been reset to factory settings. All parameter settings have been
deleted.
Resetting the device to factory settings
8
16 | 18 A6V11689762_en--_d

Index
A
Application ......................................................... 5
Application program description ..................... 2
Assigning an IP address ................................. 12
C
Check certificate .............................................. 15
Check device certificate ................................. 15
Commissioning
With KNX IP Secure ..................................... 11
Without KNX IP Secure ................................ 12
Connections ....................................................... 6
Courses .............................................................. 2
Customer service .............................................. 2
D
Diagnostics ...................................................... 14
E
Error analysis using ETS ................................ 14
F
Factory settings ............................................... 11
Reset device ................................................. 16
FAQ ............................................................... 2, 14
Frequently asked questions ....................... 2, 14
Functions ........................................................... 6
H
Help ......................................................... 2, 14, 15
I
IP Secure ............................................................ 6
K
KNX IP Secure ................................................... 6
O
Order number .................................................... 5
P
Physical address
Additional ...................................................... 13
Specify .......................................................... 12
Power supply ..................................................... 6
Problem solving ...... 14, 000, 000, 000, 000, 000
Product family ................................................... 5
Product name .................................................... 5
Product type ...................................................... 5
Q
QR code ............................................................ 11
R
Remote access ........................................ . 6, 13,
Replacing a device .......................................... . 8
Reports ........................................................... . 15
S
Security functions ........................................... . 6
Service .............................................................. . 2
Specify device name ..................................... . 12
Support ............................................................. . 2
System requirement ........................................ . 5
T
Target audience ............................................... . 2
Theft .................................................................. . 8
Time-to-Live ................................................... . 10
Troubleshooting .... . 14, 000, 000, 000, 000, 000
TTL .................................................................. . 10
U
Unicast ............................................................ . 10
Index
A6V11689762_en--_d 17 | 18

A6V11689762_en--_d
Issued by
Siemens Switzerland Ltd
Smart Infrastructure
Global Headquarters
Theilerstrasse 1a
CH-6300 Zug
[phone]
www.siemens.com/buildingtechnologies
© Siemens 2023
Technical specifications and availability subject to change without notice.
