Siemens SINAMICS V90 User manual

SINAMICS V90, SIMOTICS S-1FL6

SINAMICS/SIMOTICS
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions
PROFINET (PN) interface
04/2020
A5E37208830
-008
Preface
Fundamental safety
instructions
1
General information
2
Mounting
3
Connecting
4
Commissioning
5
Basic operator panel (BOP)
6
Control functions
7
PROFINET communication
8
Safety Integrated function
9
Tuning
10
Parameters
11
Diagnostics
12
Appendix
A

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E37208830-008
Ⓟ
04/2020 Subject to change
Copyright © Siemens AG 2016 - 2020.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2020, A5E37208830-008 3
Preface
Documentation components
Document
Content
Operating Instructions (this manual)
SIMOTICS S-1FL6 Servo Motors Instal-
lation Guide
Describes how to install the SMOTICS S-1FL6 servo
motor and relevant safety notices.
SINAMICS V90 Servo Drives Information
Guide
Introduces the basic information of the documentation and
describes how to find all the SINAMICS V90 documenta-
tion from the website.
SINAMICS V90 V-ASSISTANT Online
Help
Describes how to perform fast commissioning and diag-
nostics for the SINAMICS V90 drives via the SINAMICS
V-ASSISTANT engineering tool.
Target group
This manual provides information about the SINAMICS V90 PN servo system for planners,
operators, mechanical engineers, electrical engineers, commissioning engineers, and
service engineers.
Technical support
Country
Hotline
China
[phone]
Germany
[phone]
Italy
[phone]
India
[phone]
Turkey
[phone]
Further service contact information:
Support contacts (https://support.industry.siemens.com/cs/ww/en/)
Product maintenance
The components are subject to continuous further development within the scope of product
maintenance (improvements to robustness, discontinuations of components, etc.).
These further developments are "spare parts-compatible" and do not change the article
number.
In the scope of such spare parts-compatible further developments, connector positions are
sometimes changed slightly. This does not cause any problems with proper use of the
components. Take this fact into consideration in special installation situations (e.g. allow
sufficient clearance for the cable length).

Preface
SINAMICS V90, SIMOTICS S-1FL6
4Operating Instructions, 04/2020, A5E37208830-008
Use of third-party products
This document contains recommendations relating to third-party products. Siemens accepts
the fundamental suitability of these third-party products.
You can use equivalent products from other manufacturers.
Siemens does not accept any warranty for the properties of third-party products.
Compliance with the General Data Protection Regulation
Siemens respects the principles of data protection, in particular the data minimization rules
(privacy by design).
For this product, this means:
The product does not process neither store any person-related data, only technical function
data (e.g. time stamps). If the user links these data with other data (e.g. shift plans) or if he
stores person-related data on the same data medium (e.g. hard disk), thus personalizing
these data, he has to ensure compliance with the applicable data protection stipulations.
Recycling and disposal
For environmentally-friendly recycling and disposal of your old device, please contact a
company certified for the disposal of waste electrical and electronic equipment, and dispose
of the old device as prescribed in the respective country of use.

Preface
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2020, A5E37208830-008 5
Warranty
Details of warranty
●Warranty period
The warranty period for the product purchased (hereinafter called "product") is subject to
the signed contract and is up to 24 months since the date of manufacture of the product.
●Warranty scope
Siemens shall replace or repair a defective product free of charge if a defect attributable
to Siemens occurs during the warranty period stated above. This warranty does not cover
defects caused by the product reaching the end of its service life and replacement of
consumables or parts with limited service life.
This warranty does not cover failures that result from any of the following causes:
–Natural wear and tear
–Handling of the product not in conformity with the product instruction or user manual
–Unauthorized or inappropriate modifications, alterations or repairs
–Damages from faulty or negligent handling, use or maintenance, overload conditions
–Excessive strain or use of unsuitable appurtenances
–Defective installation or erection not carried out by Siemens
–Inappropriate storage or any other external impact on the product not explicitly
assumed by Siemen
–Device (drives, motors) damages due to use of the non-Siemens cable assemblies, for
example, improper cables that you made by yourself
–Improper handling, abuse, or use in unsuitable conditions or in environments not
described in product catalogs or manuals, or in any separately agreed-upon
specifications
–Causes not attributable to the product itself
–Abuse of the product in a manner in which it was not originally intended
–Causes that were not foreseeable with the scientific and technological understanding
at the time of shipment from Siemens
–Malfunctions arising from natural or man-made disasters or events not attributable to
Siemens
Limitations of liability
●In no event is Siemens responsible for any loss of use, production, profit, interest,
revenues, loss of information or data, damages or indemnification based on the
customer’s third party contracts or any indirect or consequential damages or losses,
regardless of whether those damages are foreseeable.
●The information provided in product catalogs or manuals is to help customer select the
appropriate product for the intended application. The use thereof does not guarantee that
there are no infringements of intellectual property rights or other proprietary rights of
Siemens or third parties, nor does it construe a license.

Preface
SINAMICS V90, SIMOTICS S-1FL6
6Operating Instructions, 04/2020, A5E37208830-008
●Siemens shall not be liable for any damage arising from infringements of intellectual
property rights or other proprietary rights of third parties as a result of using the
information described in catalogs or manuals.
●The indemnity obligation of Siemens for all losses of the customer attributable to Siemens
does not exceed the total amount paid by the customer for purchasing the relevant
product.
Suitability for use
●It is the customer’s responsibility to confirm conformity with any standards, codes, or
regulations that apply if the Siemens product is used in combination with any other
products.
●The customer must confirm that the Siemens product is suitable for the systems,
machines, and equipment used by the customer.
●Consult with Siemens to determine whether use in the following applications is
acceptable. If use in the application is acceptable, use the product with extra allowance in
ratings and specifications, and provide safety measures to minimize hazards in the event
of failure.
–Outdoor use, use involving potential chemical contamination or electrical interference,
or use in conditions or environments not described in product catalogs or manuals
–Nuclear energy control systems, combustion systems, railroad systems, aviation
systems, vehicle systems, medical equipment, amusement machines, and
installations subject to separate industry or government regulations
–Systems, machines, and equipment that may present a risk to life or property
–Systems that require a high degree of reliability, such as systems that supply gas,
water, or electricity, or systems that operate continuously 24 hours a day
–Other systems that require a similar high degree of safety
●Never use the product for an application involving risk to life or property without first
ensuring that the system is designed to secure the required level of safety with risk
warnings and redundancy, and that the Siemens product is properly rated and installed.
●The circuit examples and other application examples described in product catalogs and
manuals are for reference. Check the functionality and safety of the actual devices and
equipment to be used before using the product.
●Read and understand all use prohibitions and precautions, and operate the Siemens
product correctly to prevent accidental harm to third parties.
●Adhere to the instructions including but not limited to product manuals and safety notices
during the use of the product. Siemens does not accept any liability for personal injuries,
property damage, legal disputes or interest conflicts arising from non-adherence to
product manuals and safety notices or arising from Force Majeure.
Specifications change
The names, specifications, appearance, and accessories of products in product catalogs and
manuals may be changed at any time based on improvements and other reasons. The next
editions of the revised catalogs or manuals will be published with updated code numbers.
Consult with your Siemens representative to confirm the actual specifications before
purchasing a product.

SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2020, A5E37208830-008 7
Table of contents
Preface ................................................................................................................................................... 3
1 Fundamental safety instructions............................................................................................................ 13
1.1 General safety instructions .....................................................................................................13
1.2 Equipment damage due to electric fields or electrostatic discharge ......................................19
1.3 Warranty and liability for application examples ......................................................................19
1.4 Security information ................................................................................................................20
1.5 Residual risks of power drive systems....................................................................................21
2 General information .............................................................................................................................. 23
2.1 Scope of delivery ....................................................................................................................23
2.1.1 Drive components ...................................................................................................................23
2.1.2 Motor components ..................................................................................................................28
2.2 Device combination.................................................................................................................32
2.3 Product overview ....................................................................................................................35
2.4 Accessories.............................................................................................................................39
2.4.1 MOTION-CONNECT 300 cables and connectors ..................................................................39
2.4.2 PROFINET cable and connector ............................................................................................42
2.4.3 USB cable ...............................................................................................................................42
2.4.4 Connectors used on the drive front panel...............................................................................42
2.4.5 External 24 V DC power supply..............................................................................................43
2.4.6 Fuse/Type E combination motor controller.............................................................................44
2.4.7 Braking resistor .......................................................................................................................47
2.4.8 Line filter .................................................................................................................................48
2.4.9 Micro SD card/SD card ...........................................................................................................53
2.4.10 Replacement fans ...................................................................................................................53
2.5 Function list.............................................................................................................................54
2.6 Technical data.........................................................................................................................55
2.6.1 Technical data - servo drives..................................................................................................55
2.6.1.1 SINAMICS V90 PN 200 V variant...........................................................................................55
2.6.1.2 SINAMICS V90 PN 400 V variant...........................................................................................58
2.6.2 Technical data - servo motors ................................................................................................61
2.6.2.1 1FL6 servo motor - low inertia ................................................................................................61
2.6.2.2 1FL6 servo motor - high inertia...............................................................................................65
2.6.2.3 Power derating........................................................................................................................69
2.6.3 Technical data - cables...........................................................................................................69
2.6.4 Address of CE-authorized manufacturer ................................................................................71
3 Mounting............................................................................................................................................... 73
3.1 Mounting the drive ..................................................................................................................73
3.1.1 Mounting orientation and clearance........................................................................................74
3.1.2 Drill patterns and outline dimensions......................................................................................76

Table of contents
SINAMICS V90, SIMOTICS S-1FL6
8Operating Instructions, 04/2020, A5E37208830-008
3.1.3 Mounting the drive ................................................................................................................. 80
3.2 Mounting the motor ................................................................................................................ 80
3.2.1 Mounting orientation and dimensions .................................................................................... 81
3.2.2 Mounting the motor ................................................................................................................ 90
3.2.3 Attaching output elements ..................................................................................................... 91
3.2.4 Motor heat dissipation conditions........................................................................................... 92
4 Connecting ........................................................................................................................................... 93
4.1 System connection................................................................................................................. 93
4.1.1 Safety instructions.................................................................................................................. 93
4.1.2 Using several single-phase converters in machines and plants............................................ 95
4.1.3 EMC instructions.................................................................................................................... 95
4.1.4 System connection diagrams................................................................................................. 97
4.1.5 Cable connection ................................................................................................................. 101
4.2 Main circuit wiring................................................................................................................. 104
4.2.1 Line supply - L1, L2, L3........................................................................................................ 104
4.2.2 Motor power - U, V, W ......................................................................................................... 106
4.3 Control/status interface - X8 ................................................................................................ 109
4.3.1 Digital inputs/outputs (DIs/Dos) ........................................................................................... 110
4.3.1.1 DIs........................................................................................................................................ 110
4.3.1.2 DOs ...................................................................................................................................... 112
4.3.2 Standard application wiring (factory setting)........................................................................ 114
4.3.3 Connection example with PLCs........................................................................................... 116
4.3.3.1 SIMATICS S7-1200 ............................................................................................................. 116
4.3.3.2 SIMATICS S7-1500 ............................................................................................................. 117
4.4 24 V power supply/STO ....................................................................................................... 118
4.5 Encoder interface - X9 ......................................................................................................... 120
4.6 External braking resistor - DCP, R1..................................................................................... 123
4.7 Motor holding brake ............................................................................................................. 124
4.8 PROFINET interface - X150 ................................................................................................ 130
5 Commissioning ....................................................................................................................................133
5.1 General commissioning information..................................................................................... 133
5.2 Commissioning in JOG mode .............................................................................................. 135
5.3 Commissioning in basic positioner control mode (EPOS) ................................................... 137
5.4 Commissioning in speed control mode (S) .......................................................................... 138
6 Basic operator panel (BOP) .................................................................................................................139
6.1 BOP overview ...................................................................................................................... 139
6.1.1 LED status indicators ........................................................................................................... 140
6.1.2 BOP display ......................................................................................................................... 141
6.1.3 Control buttons..................................................................................................................... 144
6.2 Parameter structure ............................................................................................................. 145
6.3 Actual status display ............................................................................................................ 146
6.4 Basic operations................................................................................................................... 147

Table of contents
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2020, A5E37208830-008 9
6.4.1 Editing parameters................................................................................................................148
6.4.2 Viewing parameters ..............................................................................................................150
6.4.3 Searching parameters in "P ALL" menu ...............................................................................150
6.5 Auxiliary functions .................................................................................................................151
6.5.1 JOG.......................................................................................................................................152
6.5.2 Saving parameters (RAM to ROM).......................................................................................153
6.5.3 Setting parameters to default................................................................................................154
6.5.4 Transferring data (drive to SD) .............................................................................................155
6.5.5 Transferring data (SD to drive) .............................................................................................156
6.5.6 Updating firmware.................................................................................................................157
6.5.7 Adjusting an absolute encoder .............................................................................................158
7 Control functions................................................................................................................................. 159
7.1 General functions..................................................................................................................159
7.1.1 Motor direction of rotation .....................................................................................................159
7.1.2 300% overload capacity........................................................................................................160
7.1.3 Stopping method at servo OFF.............................................................................................160
7.1.4 Travel to fixed stop................................................................................................................162
7.1.5 Position tracking....................................................................................................................167
7.2 Basic positioner (EPOS) .......................................................................................................171
7.2.1 Setting the mechanical system .............................................................................................171
7.2.2 Configuring the linear/modular axis ......................................................................................172
7.2.3 Backlash compensation........................................................................................................173
7.2.4 Over-travel ............................................................................................................................174
7.2.5 Software position limit...........................................................................................................176
7.2.6 Speed limit ............................................................................................................................176
7.2.7 Torque limit ...........................................................................................................................176
7.2.8 Referencing...........................................................................................................................177
7.2.8.1 Setting reference point with the digital input signal REF (p29240 = 0) ................................178
7.2.8.2 Referencing with the external reference cam (signal REF) and encoder zero mark
(p29240 = 1)..........................................................................................................................179
7.2.8.3 Referencing with the encoder zero mark only (p29240 = 2).................................................185
7.2.9 Traversing blocks..................................................................................................................189
7.2.10 Direct setpoint input (MDI) ....................................................................................................194
7.2.11 EJOG ....................................................................................................................................198
7.3 Speed control (S) ..................................................................................................................199
7.3.1 Speed limit ............................................................................................................................199
7.3.2 Torque limit ...........................................................................................................................200
7.3.3 Ramp-function generator ......................................................................................................202
8 PROFINET communication ................................................................................................................. 205
8.1 Supported telegrams.............................................................................................................205
8.2 I/O data signals .....................................................................................................................208
8.3 Control word definition ..........................................................................................................210
8.3.1 STW1 control word (for telegrams 1, 2, 3, 5)........................................................................210
8.3.2 STW2 control word (for telegrams 2, 3, 5)............................................................................211
8.3.3 STW1 control word (for telegrams 102, 105)........................................................................211
8.3.4 STW2 control word (for telegrams 102, 105)........................................................................212
8.3.5 STW1 control word (for telegrams 7, 9, 110, 111)................................................................213
8.3.6 STW2 control word (for telegrams 9, 110, 111)....................................................................214

Table of contents
SINAMICS V90, SIMOTICS S-1FL6
10 Operating Instructions, 04/2020, A5E37208830-008
8.3.7 G1_STW encoder 1 control word......................................................................................... 215
8.3.8 SATZANW control word....................................................................................................... 216
8.3.9 MDI_MOD control word........................................................................................................ 216
8.3.10 POS_STW control word ....................................................................................................... 217
8.3.11 POS_STW1 positioning control word................................................................................... 218
8.3.12 POS_STW2 positioning control word................................................................................... 219
8.4 Status word definition........................................................................................................... 220
8.4.1 ZSW1 status word (for telegrams 1, 2, 3, 5) ........................................................................ 220
8.4.2 ZSW2 status word (for telegrams 2, 3, 5) ............................................................................ 220
8.4.3 ZSW1 status word (for telegrams 102, 105) ........................................................................ 221
8.4.4 ZSW2 status word (for telegrams 102, 105) ........................................................................ 221
8.4.5 ZSW1 status word (for telegrams 7, 9, 110, 111) ................................................................ 222
8.4.6 ZSW2 status word (for telegrams 9, 110, 111) .................................................................... 222
8.4.7 G1_ZSW encoder 1 status word .......................................................................................... 223
8.4.8 MELDW status word ............................................................................................................ 224
8.4.9 POS_ZSW1 positioning status word .................................................................................... 224
8.4.10 POS_ZSW2 positioning status word .................................................................................... 225
9 Safety Integrated function ....................................................................................................................227
9.1 Standards and regulations ................................................................................................... 227
9.1.1 General information ............................................................................................................. 227
9.1.1.1 Aims ..................................................................................................................................... 227
9.1.1.2 Functional safety.................................................................................................................. 228
9.1.2 Safety of machinery in Europe............................................................................................. 228
9.1.2.1 Machinery Directive ............................................................................................................. 228
9.1.2.2 Harmonized European Standards........................................................................................ 229
9.1.2.3 Standards for implementing safety-related controllers ........................................................ 230
9.1.2.4 DIN EN ISO 13849-1 ........................................................................................................... 231
9.1.2.5 EN 62061 ............................................................................................................................. 232
9.1.2.6 Series of standards EN 61508 (VDE 0803) ......................................................................... 233
9.1.2.7 Risk analysis/assessment.................................................................................................... 234
9.1.2.8 Risk reduction ...................................................................................................................... 235
9.1.2.9 Residual risk......................................................................................................................... 236
9.1.3 Machine safety in the USA................................................................................................... 236
9.1.3.1 Minimum requirements of the OSHA ................................................................................... 236
9.1.3.2 NRTL listing.......................................................................................................................... 237
9.1.3.3 NFPA 79............................................................................................................................... 237
9.1.3.4 ANSI B11 ............................................................................................................................. 238
9.1.4 Machine safety in Japan ...................................................................................................... 238
9.1.5 Equipment regulations ......................................................................................................... 239
9.2 General information about SINAMICS Safety Integrated .................................................... 239
9.3 System features ................................................................................................................... 240
9.3.1 STO functional safety data................................................................................................... 240
9.3.2 Certification .......................................................................................................................... 240
9.3.3 Safety instructions................................................................................................................ 240
9.3.4 Probability of failure of the safety function ........................................................................... 242
9.3.5 Response time ..................................................................................................................... 242
9.3.6 Residual risk......................................................................................................................... 243
9.4 Safety Integrated basic function........................................................................................... 243
9.4.1 Safe Torque Off (STO)......................................................................................................... 243

Table of contents
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2020, A5E37208830-008 11
9.4.2 Forced dormant error detection ............................................................................................246
10 Tuning ................................................................................................................................................ 247
10.1 Controller overview ...............................................................................................................247
10.2 Tuning mode .........................................................................................................................249
10.3 One-button auto tuning .........................................................................................................250
10.4 Real-time auto tuning............................................................................................................255
10.5 Manual tuning .......................................................................................................................258
10.6 Resonance suppression .......................................................................................................259
10.7 Low frequency vibration suppression ...................................................................................262
11 Parameters ......................................................................................................................................... 263
11.1 Overview ...............................................................................................................................263
11.2 Parameter list........................................................................................................................264
12 Diagnostics ......................................................................................................................................... 305
12.1 Overview ...............................................................................................................................305
12.2 List of faults and alarms........................................................................................................309
A Appendix............................................................................................................................................. 335
A.1 Overview ...............................................................................................................................335
A.2 Assembly of cable terminals/connectors on the drive side...................................................337
A.2.1 Power terminal assembly......................................................................................................337
A.2.2 Encoder connector assembly ...............................................................................................338
A.2.3 Brake terminal assembly.......................................................................................................339
A.2.4 Setpoint connector assembly................................................................................................340
A.3 Assembly of cable connectors on the motor side .................................................................341
A.3.1 Power connector assembly...................................................................................................341
A.3.2 Encoder connector assembly ...............................................................................................344
A.3.3 Brake connector assembly ...................................................................................................348
A.4 Motor selection......................................................................................................................349
A.4.1 Selection procedure ..............................................................................................................349
A.4.2 Parameter description...........................................................................................................350
A.4.3 Selection examples...............................................................................................................352
A.5 Replacing fans ......................................................................................................................355
Index................................................................................................................................................... 357

Table of contents
SINAMICS V90, SIMOTICS S-1FL6
12 Operating Instructions, 04/2020, A5E37208830-008

SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2020, A5E37208830-008 13
Fundamental safety instructions
1
1.1 General safety instructions
WARNING
Electric shock and danger to life due to other energy sources
Touching live components can result in death or severe injury.
•Only work on electrical devices when you are qualified for this job.
•Always observe the country-specific safety rules.
Generally, the following steps apply when establishing safety:
1. Prepare for disconnection. Notify all those who will be affected by the procedure.
2. Isolate the drive system from the power supply and take measures to prevent it being
switched back on again.
3. Wait until the discharge time specified on the warning labels has elapsed.
4. Check that there is no voltage between any of the power connections, and between any
of the power connections and the protective conductor connection.
5. Check whether the existing auxiliary supply circuits are de-energized.
6. Ensure that the motors cannot move.
7. Identify all other dangerous energy sources, e.g. compressed air, hydraulic systems, or
water. Switch the energy sources to a safe state.
8. Check that the correct drive system is completely locked.
After you have completed the work, restore the operational readiness in the inverse
sequence.
WARNING
Risk of electric shock and fire from supply networks with an excessively high impedance
Excessively low short-circuit currents can lead to the protective devices not tripping or
tripping too late, and thus causing electric shock or a fire.
•In the case of a conductor-conductor or conductor-ground short-circuit, ensure that the
short-circuit current at the point where the inverter is connected to the line supply at
least meets the minimum requirements for the response of the protective device used.
•You must use an additional residual-current device (RCD) if a conductor-ground short
circuit does not reach the short-circuit current required for the protective device to
respond. The required short-circuit current can be too low, especially for TT supply
systems.

Fundamental safety instructions
1.1 General safety instructions
SINAMICS V90, SIMOTICS S-1FL6
14 Operating Instructions, 04/2020, A5E37208830-008
WARNING
Risk of electric shock and fire from supply networks with an excessively low impedance
Excessively high short-circuit currents can lead to the protective devices not being able to
interrupt these short-circuit currents and being destroyed, and thus causing electric shock
or a fire.
•Ensure that the prospective short-circuit current at the line terminal of the inverter does
not exceed the breaking capacity (SCCR or Icc) of the protective device used.
WARNING
Electric shock if there is no ground connection
For missing or incorrectly implemented protective conductor connection for devices with
protection class I, high voltages can be present at open, exposed parts, which when
touched, can result in death or severe injury.
•Ground the device in compliance with the applicable regulations.
WARNING
Electric shock due to connection to an unsuitable power supply
When equipment is connected to an unsuitable power supply, exposed components may
carry a hazardous voltage. Contact with hazardous voltage can result in severe injury or
death.
•Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV-
(Protective Extra Low Voltage) output voltages for all connections and terminals of the
electronics modules.
WARNING
Electric shock due to damaged motors or devices
Improper handling of motors or devices can damage them.
Hazardous voltages can be present at the enclosure or at exposed components on
damaged motors or devices.
•Ensure compliance with the limit values specified in the technical data during transport,
storage and operation.
•Do not use any damaged motors or devices.
WARNING
Electric shock due to unconnected cable shields
Hazardous touch voltages can occur through capacitive cross-coupling due to unconnected
cable shields.
•As a minimum, connect cable shields and the cores of cables that are not used at one
end at the grounded housing potential.

Fundamental safety instructions
1.1 General safety instructions
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2020, A5E37208830-008 15
WARNING
Arcing when a plug connection is opened during operation
Opening a plug connection when a system is operation can result in arcing that may cause
serious injury or death.
•Only open plug connections when the equipment is in a voltage-free state, unless it has
been explicitly stated that they can be opened in operation.
WARNING
Electric shock due to residual charges in power components
Because of the capacitors, a hazardous voltage is present for up to 5 minutes after the
power supply has been switched off. Contact with live parts can result in death or serious
injury.
•Wait for 5 minutes before you check that the unit really is in a no-voltage condition and
start work.
NOTICE
Damage to equipment due to unsuitable tightening tools.
Unsuitable tightening tools or fastening methods can damage the screws of the equipment.
•Be sure to only use screwdrivers which exactly match the heads of the screws.
•Tighten the screws with the torque specified in the technical documentation.
•Use a torque wrench or a mechanical precision nut runner with a dynamic torque sensor
and speed limitation system.
NOTICE
Property damage due to loose power connections
Insufficient tightening torques or vibration can result in loose power connections. This can
result in damage due to fire, device defects or malfunctions.
•Tighten all power connections to the prescribed torque.
•Check all power connections at regular intervals, particularly after equipment has been
transported.
WARNING
Spread of fire from built-in devices
In the event of fire outbreak, the enclosures of built-in devices cannot prevent the escape of
fire and smoke. This can result in serious personal injury or property damage.
•Install built-in units in a suitable metal cabinet in such a way that personnel are
protected against fire and smoke, or take other appropriate measures to protect
personnel.
•Ensure that smoke can only escape via controlled and monitored paths.

Fundamental safety instructions
1.1 General safety instructions
SINAMICS V90, SIMOTICS S-1FL6
16 Operating Instructions, 04/2020, A5E37208830-008
WARNING
Active implant malfunctions due to electromagnetic fields
Inverters generate electromagnetic fields (EMF) in operation. Electromagnetic fields may
interfere with active implants, e.g. pacemakers. People with active implants in the
immediate vicinity of an inverter are at risk.
•As the operator of an EMF-emitting installation, assess the individual risks of persons
with active implants.
•Observe the data on EMF emission provided in the product documentation.
WARNING
Active implant malfunctions due to permanent-magnet fields
Even when switched off, electric motors with permanent magnets represent a potential risk
for persons with heart pacemakers or implants if they are close to converters/motors.
•If you have a heart pacemaker or implant, maintain a minimum distance of 2 m.
•When transporting or storing permanent-magnet motors always use the original packing
materials with the warning labels attached.
•Clearly mark the storage locations with the appropriate warning labels.
•IATA regulations must be observed when transported by air.
WARNING
Unexpected movement of machines caused by radio devices or mobile phones
Using radio devices or mobile telephones in the immediate vicinity of the components can
result in equipment malfunction. Malfunctions may impair the functional safety of machines
and can therefore put people in danger or lead to property damage.
•Therefore, if you move closer than 20 cm to the components, be sure to switch off radio
devices or mobile telephones.
•Use the "SIEMENS Industry Online Support app" only on equipment that has already
been switched off.
NOTICE
Damage to motor insulation due to excessive voltages
When operated on systems with grounded line conductor or in the event of a ground fault in
the IT system, the motor insulation can be damaged by the higher voltage to ground. If you
use motors that have insulation that is not designed for operation with grounded line
conductors, you must perform the following measures:
•IT system: Use a ground fault monitor and eliminate the fault as quickly as possible.
•TN or TT systems with grounded line conductor: Use an isolating transformer on the line
side.

Fundamental safety instructions
1.1 General safety instructions
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2020, A5E37208830-008 17
WARNING
Fire due to inadequate ventilation clearances
Inadequate ventilation clearances can cause overheating of components with subsequent
fire and smoke. This can cause severe injury or even death. This can also result in
increased downtime and reduced service lives for devices/systems.
•Ensure compliance with the specified minimum clearance as ventilation clearance for
the respective component.
NOTICE
Overheating due to inadmissible mounting position
The device may overheat and therefore be damaged if mounted in an inadmissible position.
•
Only operate the device in admissible mounting positions.
WARNING
Unrecognized dangers due to missing or illegible warning labels
Dangers might not be recognized if warning labels are missing or illegible. Unrecognized
dangers may cause accidents resulting in serious injury or death.
•Check that the warning labels are complete based on the documentation.
•Attach any missing warning labels to the components, where necessary in the national
language.
•
Replace illegible warning labels.
NOTICE
Device damage caused by incorrect voltage/insulation tests
Incorrect voltage/insulation tests can damage the device.
•Before carrying out a voltage/insulation check of the system/machine, disconnect the
devices as all converters and motors have been subject to a high voltage test by the
manufacturer, and therefore it is not necessary to perform an additional test within the
system/machine.
WARNING
Unexpected movement of machines caused by inactive safety functions
Inactive or non-adapted safety functions can trigger unexpected machine movements that
may result in serious injury or death.
•Observe the information in the appropriate product documentation before
commissioning.
•Carry out a safety inspection for functions relevant to safety on the entire system,
including all safety-related components.
•Ensure that the safety functions used in your drives and automation tasks are adjusted
and activated through appropriate parameterizing.
•Perform a function test.
•Only put your plant into live operation once you have guaranteed that the functions
relevant to safety are running correctly.

Fundamental safety instructions
1.1 General safety instructions
SINAMICS V90, SIMOTICS S-1FL6
18 Operating Instructions, 04/2020, A5E37208830-008
Note
Important safety notices for Safety Integrated functions
If you want to
use Safety Integrated functions, you must observe the safety notices in the
Safety Integrated manuals.
WARNING
Malfunctions of the machine as a result of incorrect or changed parameter settings
As a result of incorrect or changed parameterization, machines can malfunction, which in
turn can lead to injuries or death.
•Protect the parameterization against unauthorized access.
•Handle possible malfunctions by taking suitable measures, e.g. emergency stop or
emergency off.
WARNING
Injury caused by moving or ejected parts
Contact with moving motor parts or drive output elements and the ejection of loose motor
parts (e.g. feather keys) out of the motor enclosure can result in severe injury or death.
•Remove any loose parts or secure them so that they cannot be flung out.
•Do not touch any moving parts.
•Safeguard all moving parts using the appropriate safety guards.
WARNING
Fire due to inadequate cooling
Inadequate cooling can cause the motor to overheat, resulting in death or severe injury as a
result of smoke and fire. This can also result in increased failures and reduced service lives
of motors.
•Comply with the specified cooling requirements for the motor.
WARNING
Fire due to incorrect operation of the motor
When incorrectly operated and in the case of a fault, the motor can overheat resulting in fire
and smoke. This can result in severe injury or death. Further, excessively high
temperatures destroy motor components and result in increased failures as well as shorter
service lives of motors.
•Operate the motor according to the relevant specifications.
•Only operate the motors in conjunction with effective temperature monitoring.
•Immediately switch off the motor if excessively high temperatures occur.
