About this document
1
Applicable documents
1About this document
Goal and purpose
This document contains all the information you'll need to mount and install the
following aspirating smoke detectors:
FDA241
FDA221
Following the instructions consistently will ensure that the devices can be mounted
and installed safely and without any problems.
You will find more information about the aspirating smoke detectors in document
A6V10334410. See the chapter 'Applicable documents [➙ 5]'.
Intended use
Aspirating smoke detectors FDA241 and FDA221 may only be used for fire
detection and fire control purposes.
1.1 Applicable documents
Document ID
Title
007023 Technical manual Input module, input/output module FDCI222,
FDCIO222, FDCIO224
008331 List of compatibility (for 'Sinteso™' product line)
009052 FS20 Fire detection system - Commissioning, Maintenance,
Troubleshooting
A6V10210416 FS720 Fire detection system - Commissioning, Maintenance,
Troubleshooting
A6V10229261 List of compatibility (for 'Cerberus™ PRO' product line)
A6V10331032 Data sheet Aspirating Smoke Detectors FDA221, FDA241
A6V10332759 Installation, Operation Manual, Configuration 'ASD
Configuration Tool FXS2051'
A6V10334410 Technical manual Aspirating smoke detector FDA241, FDA221
A6V10334435 Planning, Installation ASD Pipe system
A6V10393194 Technical manual Power supply kit A 70 W FP120-Z1
1.2 Technical terms
Term
Explanation
ASD Aspirating smoke detector
FDnet/C-NET Addressed detector line
GPI
G
eneral
P
urpose
I
nput, connection for an external switch
n.c.
n
ormally
c
losed, connection closed in normal condition
n.o.
n
ormally
o
pen, connection open in normal condition
5
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

1
About this document
Revision history
1.3 Revision history
The reference document's version applies to all languages into which the reference
document is translated.
The first edition of a language version or a country variant may, for example, be
version 'd' instead of 'a' if the reference document is already this version.
The table below shows this document's revision history:
Modification index
Edition date
Brief description
h 2015-05-29 'Connection to the input/output module' chapter added; 'Applicable
documents' and ' 'Dust' relay output for dust value (FDA241 only)' chapters
amended
g 2015-02-19 Power supply FP120-Z1 added
Battery FA2003-A1 added
Editorial changes
f 2013-11-14 Data sheet updated in 'Applicable documents' chapter
Chapter 'External power unit and batteries' reinserted
e 2013-01-02 Change of function when opening housing cover.
d 2012-11-02 Editorial adjustments
c 2012-03 Document adapted to the following type designation: communication
transponder FDCC221S; additional mounting note
b 2011-12 Revised version
a 2011-10 First edition
The language versions and country variants produced by a local company have
the same modification index as the corresponding reference document. They are
not however included in the table below.
The table below shows the published language versions and country variants with
the corresponding modification index:
Modification index
en_--
de_--
fr_--
it_--
es_--
h X X X X X
g X X X X X
f - X - - -
e X X X X X
d X X - - -
c - X - - -
b - X - - -
a X X - - -
X = published
– = no publication with this modification index
6
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

Preparatory work
2
Opening and closing the housing cover when the power supply is switched off
2Preparatory work
2.1 Opening and closing the housing cover when the
power supply is switched off
When the housing cover is open, the mini USB connection and the internal
indicators are accessible.
NOTICE
Electrostatic discharge
Damage to electronic components in the aspirating smoke detector
●When working on the open aspirating smoke detector, use anti-static floor
mats and anti-static work surfaces.
●Ground yourself immediately before opening the housing, e.g. by touching a
ground point or wearing an anti-static belt.
1 2
Opening the housing cover
Opening the housing cover
The housing is free from dust.
1. Remove the two screws on the top of the aspirating smoke detector using a
size 2 Phillips screwdriver (step 1).
2. Slide the housing cover in the direction of the arrow until it snaps into place
(step 2).
The housing cover is open.
7
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

2
Preparatory work
Opening and closing the housing cover when the power supply is switched off
Closing the housing cover
The size 2 Phillips screwdriver and the two screws are available.
The power supply is switched off.
1. Slide the housing cover in the opposite direction to the arrow (step 2) until it
reaches the end position at the bottom.
2. NOTICE! Connection cable clamped between the back box and the housing
cover. Damage to the cable! Be aware of the connection cable when closing
the housing cover.
3. Screw the housing cover to the housing base with the two screws. Tighten the
screws by hand (step 1).
The housing cover is closed.
8
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

Preparatory work
2
Removing and installing the housing cover when the power supply is switched off
2.2 Removing and installing the housing cover when
the power supply is switched off
NOTICE
Electrostatic discharge
Damage to electronic components in the aspirating smoke detector
●When working on the open aspirating smoke detector, use anti-static floor
mats and anti-static work surfaces.
●Ground yourself immediately before opening the housing, e.g. by touching a
ground point or wearing an anti-static belt.
When the housing cover is removed, you have access to:
The fixing screws
The cable entry
All the mechanical components
The electrical connections
The rear of the front indicator
1 2
345
A
A
B
B
Removing the housing cover
9
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

2
Preparatory work
Removing and installing the housing cover when the power supply is switched off
Removing the housing cover
The housing is free from dust.
Do not disconnect the connection cable running between the housing cover
and the back box.
1. Remove the two screws on the top of the aspirating smoke detector using a
size 2 Phillips screwdriver (step 1).
2. Slide the housing cover in the direction of the arrow until it snaps into place
(step 2).
The housing cover is open.
3. Take hold of the housing cover on the left and right (A) and pull the side walls
apart (step 3).
4. Lift the housing cover off the back box (B). When doing this, be aware of the
connection cable (step 3).
The housing cover is removed.
The removed housing cover can be hung on the back box.
Hanging the removed housing cover on the back box
10
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

Preparatory work
2
Removing and installing the housing cover when the power supply is switched off
Installing the housing cover
2
2
1
Markings on the housing cover and back box
The size 2 Phillips screwdriver and the two screws are available.
1. Connect the connection cable plug to the interface card!
2. Place the housing cover on the back box so that marking (1) is located
between both of the (2) markings.
3. Push the housing cover onto the back box in the direction of the arrow until the
housing cover snaps into place.
4. NOTICE! Connection cable clamped between the back box and the housing
cover. Damage to the cable! Be aware of the connection cable when closing
the housing cover.
5. Slide the housing cover in the opposite direction to the arrow (step 2) until it
reaches the end position at the bottom.
6. Screw the housing cover to the housing base with the two screws. Tighten the
screws by hand.
The aspirating smoke detector's housing cover is installed.
11
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

2
Preparatory work
Installation position and space requirements
2.3 Installation position and space requirements
Installation site requirements
Only to be installed within a building where the ambient conditions are
permissible
No direct sunlight
Take into account the additional space required by and the need to access the
following:
– External power unit and batteries
– Blowing-out unit (optional)
– Water trap (optional)
The aspirating smoke detector can be installed either horizontally or vertically
on a level surface.
The dust load should be low at the installation site, because the aspirating
smoke detector housing is opened for maintenance purposes.
Ensure that there is at least 150 mm of free space on each side of the installed
aspirating smoke detector to ensure the pipe system and electrical connections
can be installed with ease.
Connecting to the pipe system
The aspirating smoke detector can be installed in different installation locations.
The installation location to be used depends on the pipe system's connection to the
aspirating smoke detector.
A
D
Aspirating smoke detectors with different installation locations
12
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

Preparatory work
2
Installation position and space requirements
Four connection types are possible:
Standard: From above (A)
From below (B) when the aspirating smoke detector is installed rotated by 180°
From left (D) or right (E) when the aspirating smoke detector is installed
horizontally
When the aspirating smoke detector is installed horizontally, no adapted
alignment of the front panel is possible. See 'Adapting the front indicator to the
installation position'.
410 mm
170mm
120mm
A B C
D E
Installation position
A
Aspiration from above
B
Aspiration from below
C
Space required by the aspirating smoke detector when the housing cover is
open
D
Aspiration from left
E
Aspiration from right
13
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

2
Preparatory work
Installation position and space requirements
Cable entry
Position of hole
Size of hole
Breakthrough on rear 25 x 100 mm
Breakthrough on left side of housing Diameter 25 mm
Breakthrough on top of housing Diameter 25 mm
If the aspirating smoke detector is installed rotated by 180°, the circular
breakthroughs are found on the bottom at the right-hand side.
110 mm
25 x 100 mm
25 mm
20 mm
Cable entry with standard installation position
To prepare the electrical connections, perform the following steps:
1. Break through the necessary cable entries (e.g., using a screwdriver).
2. Attach the plastic cable entries (usual size M20) to the housing.
3. Insert the cables through the relevant cable entries.
14
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

Preparatory work
2
External power unit and batteries
2.4 External power unit and batteries
External power unit
The aspirating smoke detector must be supplied with electricity by an external
power unit. The power unit must satisfy the following requirements:
Version according to EN 54-4
Output voltage: DC 24 V
Output current: 250 mA
The power unit must be connected to the aspirating smoke detector with as
short a cable as possible.
Suitable power unit:
Company
Type
VdS
For battery type
Siemens FP120-Z1 G214130 2x FA2003-A1 (12 V, 7 Ah)
Or
2x FA2004-A1 (12 V, 12 Ah)
Or
2x FA2005-A1 (12 V, 17 Ah)
You will find more information on the power supply kit FP120-Z1 in
document A6V10393194. See the 'Applicable documents' chapter.
Batteries
If the power supply via the external power unit fails, the power supply of the
aspirating smoke detector must be guaranteed using batteries.
If the aspirating smoke detector is in standalone operation: Observe local
regulations for the minimum detector operation period for power supply failure.
The capacity of the batteries must be selected according to the local
regulations.
If the aspirating smoke detector is being operated on a FDnet/C-NET detector
line: The capacity of the batteries must match the runtime of the connected fire
detection installation if the power supply fails. Observe local regulations for the
fire detection installation.
The batteries are charged using the external power unit. The charging current
for the batteries depends on the battery capacity. You should therefore select
your external power unit to match the batteries' capacity.
15
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

3
Mounting
Adapting the front indicator to the installation position
3Mounting
3.1 Adapting the front indicator to the installation
position
The aspirating smoke detector can be installed rotated by 180° if required. The
front indicator must then also be installed rotated by 180°.
180°
8x
8x
124
3
Adapting the front indicator to the installation position
The housing cover has been removed (step 1).
1. Loosen the 8 screws on the inside of the housing cover (step 2).
2. Rotate the front indicator by 180° (step 3).
3. Fasten the front indicator to the housing cover using the 8 screws (step 4).
The front indicator is adapted to the installation position.
16
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

Mounting
3
Fastening on a level substructure
3.2 Fastening on a level substructure
A drilling template is punched in the inner packaging of the aspirating smoke
detector packaging.
The punched symbol in the center of the packaging indicates the airflow direction
(air inlet and air outlet).
The mounting holes in the back box are not symmetrical, so use the drilling
template.
13
2
4x
Using the drilling template
4 screws with a shaft diameter of 5…6 mm and a head diameter of 8…10 mm
are available.
A suitable tool for drilling and screwing is available.
The housing cover is removed and the cable loosened.
The product must be installed on a level, non-combustible base.
1. Use the unfolded packaging as the drilling template.
– Note the arrow symbol for the direction of the pipe connections (step 3).
2. Drill the mounting holes.
3. If necessary: Use suitable dowels.
17
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

3
Mounting
Connecting the pipe system to the aspirating smoke detector
4. Screw the four screws into the mounting holes.
– Do not screw in the screws as far as the stop. A gap of approx. 10 mm
must remain between the screw head and the wall.
5. Hang the back box on the screws.
6. Carefully tighten the four screws.
The back box is fastened.
7. Reconnect the cable and close the housing cover.
The aspirating smoke detector is installed.
3.3 Connecting the pipe system to the aspirating smoke
detector
NOTICE
Connection between pipe system and aspirating smoke detector
Damage to the pipe system and/or the aspirating smoke detector
●Do not glue the pipe system to the aspirating smoke detector! If the pipe
system has to be separated from the aspirating smoke detector for
maintenance work or repairs, components may be damaged.
The pipe system is installed.
The last 500 mm of the pipe system on the aspirating smoke detector must be
straight, such that flow turbulences can be eliminated before entering the
aspirating smoke detector.
1. Press a short pipe securely into the air inlet on the aspirating smoke detector.
2. Connect the pipe system and the pressed-in pipe piece to the aspirating smoke
detector.
The pipe system is connected to the aspirating smoke detector.
You will find more information in document A6V10334435.
See also
Applicable documents [➙ 5]
18
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

Mounting
3
Connecting the pipe system to the aspirating smoke detector
3.3.1 Return line
If there is an air pressure difference of >45 Pa between the monitored area and the
aspirating fire detector, a return line is required.
NOTICE
Connection between aspirating smoke detector and return line
Damage to the return line and/or the aspirating smoke detector
●Do not glue the return line to the aspirating smoke detector! If the return line
has to be separated from the aspirating smoke detector for maintenance work
or repairs, the return line or the aspirating smoke detector may be damaged.
Press the return line securely into the air outlet on the aspirating smoke
detector.
You will find more information in document A6V10334435.
See also
Applicable documents [➙ 5]
19
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com

3
Mounting
Installing communication transponder FDCC221S
3.4 Installing communication transponder FDCC221S
Communication transponder FDCC221S may only be installed if the aspirating
smoke detector is connected to FDnet/C-NET. Installation is not permitted in the
case of standalone operation.
Communication transponder FDCC221S has its own ID. The ID of communication
transponder FDCC221S is made visible to the detector line and it replaces the ID
of the aspirating smoke detector.
Installing communication transponder FDCC221S in an aspirating smoke detector
Changes on the type plate when the FDCC221S is installed
1 Mark indicating that the FDCC221S is installed
2 ID adhesive label from FDCC221S for aspirating smoke detector
3 Tear-off adhesive label for installation plan
20
Building Technologies A6V10345654_h_en_--
Fire Safety 2015-05-29
firealarmresources.com
