Sinteso™ Cerberus™ PRO
ASD Aspirating smoke detector
FDA241, FDA221
Siemens aspirating smoke detector (ASD) for the addressed FDnet/C-NET de-
tector line or for standalone operation
● Patented technology
● Early detection of a wider spectrum of particle sizes in the air
● Configuration using the USB interface or the control panel via FDCC221S (op-
tional)
● 'ASD Asyst-Tool' software to assist with pipe configuration
● Unique dust-resistant detection chamber
● Intuitive front indicator for airflow and smoke value
● Access to service functions
● Different event protocols
● Offline/online configuration supported
● Cleaning function (FDA241)
● 4…20mA output
A6V10331032_k_en_-- Smart Infrastructure
2021-06-28

2
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
Properties
● Extended optical detection thanks to dual wavelengths (blue and infrared): The aspirat-
ing smoke detectors FDA241 and FDA221 use dual-wavelength technology to trigger an
alarm at the earliest possible moment. They are designed to protect small and medium-
sized business-critical environments for monitoring areas of up to 800m2 (FDA241) or
500m2 (FDA221). The detectors continually suck in air through a pipe system via their
aspirating holes. The air is fed into a uniquely designed detection chamber, in which tiny
smoke particles are detected by scattered light.
● Lower mounting and service costs: The aspirating smoke detectors FDA241 and
FDA221 can be used on an FDnet/C-NET detector line. For this purpose, communication
transponder FDCC221S is required.
● Configuration using the USB interface or the control panel via FDCC221S (optional): All
detector configurations, maintenance work, and alarm and fault management processes
can be carried out at a central location – the fire control panel. This ensures better con-
trol while also reducing the costs of the overall solution.
● 'Out-of-the-box' mounting and commissioning: Installation is simple thanks to combined
functions for normalizing smoke values and airflow, as well as appropriate presettings for
alarm and fault thresholds.
● ASD filter box FDAZ292 available as an accessory: Dust and other dirt is filtered out of
the aspirated air and does not get into the aspirating smoke detector. The filters in the
ASD filter box are easy to replace.
Use
Aspirating smoke detectors are used for early detection of smoke-generating fires in rooms
and equipment. They are especially suited to applications in which point detectors are
pushed to their limits, cannot be used or can only be used with restrictions.
The aspirating smoke detector continually takes air from the monitored room using a connec-
ted pipe system with defined aspirating holes. The air is supplied to the detection chamber
and is analyzed for smoke particles using the detector installed there. The sensitivity of the
detector can be adjusted.
The position and size of the aspirating holes is calculated using the 'FXS2056ASDAsyst
ToolV2' software. The calculation ensures that the air passes from the aspirating hole to the
detector in the time specified and with the required calculated sensitivity.
The 'FXS2056ASDAsyst ToolV2' software replaces the 'FXS2055ASD Asyst Tool' soft-
ware.
Examples of application
● Cavities such as false ceilings or false floors
● Clean rooms
● Rooms the height of which is greater than that permitted for point detectors
● Rooms with electromagnetic fields which influence the function of point detectors
● Large rooms up to 800m²
● Separate monitoring of control cabinets and electronics cabinets
● Data centers
● Telecommunication centers
● Mounting lines
● Cable tunnels
● Conveyor belts
Applications with a filter box
● Rooms with polluted air, in which the pollution has impaired the performance of optical
point detectors
● Mounting lines
● Recycling facilities
● Cement factories

3
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
● Mining industry
● Subway stations
● Agricultural operations
● All other applications with visible dust load
Functions
Indication
The display contains clear, comprehensible bar graphs for smoke and airflow, as well as an
alarm indicator, an error indicator, and a dust indicator (FDA241).
When the housing cover is open, the operator has access to the 'Reset', 'Normalize Smoke',
and 'Normalize Flow' functions, as well as the mini USB connector.
Fig.1: Front indicatorFDA241
Fig.2: Front indicatorFDA221
Legend for the response indicators
Operation Flow warnings Smoke alarm Info alarm

4
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
Blowing
out
High flow
Normal flow
Low flow
Fire 2 No smoke
Error Fire 1
Pre-alarm
Fault/test
Dust
Opening the detector
CAUTION
Damage to the connection cable
In order to prevent damage to the connection cable when positioning the housing cover,
make sure that the connection cable has been routed correctly.
The service area for the detector can be accessed in two ways.
● Partial access:
– Remove the two screws on the top of the detector.
– Slide the housing cover up until you hear it snap into place.
● Full access:
– Remove the two screws on the top of the detector.
– Slide the housing cover up until you hear it snap into place.
– Pull the housing cover out slightly at the sides and lift it up.
– Remove the housing cover.
1 2

5
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
Service LED indicators and buttons
Flow OK
As soon as the selftest for normal operation has been completed successfully, the 'FlowOK'
LED starts to flash.
Smoke OK
As soon as the selftest for normal operation has been completed successfully, the
'SmokeOK' LED starts to flash.
Alarm
In the event of a smoke alarm, the 'Alarm' LED starts to flash.
Normalization of the airflow
To determine the nominal airflow of the detector, perform this function during commissioning.
The nominal value established during normalization of the airflow forms the setpoint value for
monitoring the airflow during normal operation.
To perform this function, use a thin object (such as a paper clip or a watchmaker's screw-
driver) to press the button in the opening.
Once you have finished with this function, press the button in the opening again.
The smoke detector uses standard values for monitoring during normalization.
Normalization of the smoke density
To determine the nominal air quality in relation to the smoke density, perform this function
during commissioning. The nominal value established during normalization forms the set-
point value for monitoring the smoke density during normal operation.
To perform this function, use a thin object (such as a paper clip or a watchmaker's screw-
driver) to press the button in the opening.
Once you have finished with this function, press the button in the opening again.
The smoke detector uses standard values for monitoring during normalization.
The detector provides information about the current normalization process via FDnet/C-
NET (no distinction is made between smoke and airflow).
Reset button
Use the reset button to reset all of the detector's status indicators. These indicators can refer
to fire alarms or airflow events. Resetting the fire alarm also resets the associated relay.
If the detector is operated on the FDnet/C-NET, the alarms and the associated relays are
not reset.
USB connection
You can use a mini USB cable to connect the detector to a Windows PC. To set up the de-
tector, use the configuration tool 'FXS2051ASD Configuration Tool'.
Test function LED
Hold the 'Buzzer silence' button down for 5seconds. The LEDs on the display are tested
with 3 different brightness settings.

6
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
If the aspirating smoke detector is to be operated on the FDnet/C-NET, the communication
interface FDCC221S (S24218-A201-A2) must be ordered separately.
Accessories
Communication interfaceFDCC221S
● For connecting the aspirating smoke detector to FDnet/C-NET
● Integrated 'line separator' function
● Additional MC link interface (port for 3.5 mm jack)
● Tool-free mounting on a designated PCB slot
● Supplied with:
– 2xspacers with thread
– 4-pin plug-in terminal
– ID adhesive label
Power supply kitFP120-Z1
● Standalone power supply(70W)
● Supply to external devices and components as per EN54-4 and VdS
● With operating and fault indicator, shown via a green and a yellow LED
● With potential-free relay contacts for fault messages
● Additional installation of an I/O module possible
● Uninterruptible power supply with battery charging
● Batteries: max.17Ah
● Dimensions: (WxHxD) 430x399x124mm
BatteryFA2003-A1 (12V, 7Ah, VdS)
● For supplying fire control panels and aspirating smoke detectors with power
● Compatible with:
– Fire control panels for the 'Sinteso' and 'CerberusPRO' product lines
– External power units for the aspirating smoke detectors FDA241 and
FDA221

7
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
BatteryFA2004-A1 (12V, 12Ah, VdS)
● For supplying fire control panels and aspirating smoke detectors with power
● Compatible with:
– Fire control panels for the 'Sinteso' and 'CerberusPRO' product lines
– External power units for the aspirating smoke detectors FDA241 and
FDA221
BatteryFA2005-A1 (12V, 17Ah, VdS)
● For supplying fire control panels and aspirating smoke detectors with power
● Compatible with:
– Fire control panels for the 'Sinteso' and 'CerberusPRO' product lines
– External power units for the aspirating smoke detectors FDA241 and
FDA221
FDAZ291 aspirator (FDA241/FDA221)
● Spare part for the aspirating smoke detectors FDA241 and FDA221
● You will find more information in document A6V10916366
FDAZ292 ASD filter box
● Filter box for installation in the pipe system for aspirating smoke detectors
● Filters dust and other dirt out of the air aspirated by the aspirating smoke
detector
● Minimizes internal contamination of the aspirating smoke detector
● Contains filter set FDAZ292‑AA with three filters, coarse/medium/fine
● Compatible with the aspirating smoke detectors FDA241 and FDA221
● You will find more information in document A6V10877841
FDAZ292-AA ASD filter set
● Spare part for the ASD filter box FDAZ292
● Filter set contains one coarse filter, one medium filter, and one fine filter

8
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
Type Overview
Type Designation Order number Weight [kg]
FDA241 Aspirating smoke detector(8H) S54333-F17-A1 1.495
FDA221 Aspirating smoke detector(5S) S54333-F15-A1 1.495
Accessories
FDCC221S Communications interface S24218-A201-A2 0.019
FP120-Z1 Power supply kitA(70W) S54400-S122-A1 3.920
FA2003-A1 Battery (12V, 7Ah, VdS) A5Q00019353 2.450
FA2004-A1 Battery (12V, 12Ah, VdS) A5Q00019354 3.930
FA2005-A1 Battery (12V, 17Ah, VdS) A5Q00019677 5.640
FDAZ292 ASD filter box S54333-C92-A1 0.220
Spare parts
FDAZ292-AA ASD filter set S54333-S91-A1 0.009
FDAZ291 Aspirator (FDA241/FDA221) S54333-G1-A1 0.106
Product documentation
Document ID Title
A6V10334410 Technical manual Aspirating smoke detector FDA241, FDA221
A6V10393194 Technical manual Power supply kit A 70 W FP120-Z1
A6V10345654 Installation, Mounting Aspirating smoke detector FDA241, FDA221
A6V10340094 User Manual 'ASD Asyst Tool FXS2055'
A6V10728226 User Manual 'ASD Asyst Tool V2 FXS2056'
A6V10334435 Planning, Installation ASD Pipe system
A6V10332759 Installation, Operation Manual, Configuration 'ASD Configuration Tool FXS2051'
A6V10877841 Installation ASD Filterbox FDAZ292
A6V10916591 Installation Aspirator (FDA241/FDA221) FDAZ291
Related documents such as environmental declarations, CE declarations, etc., can be down-
loaded at the following Internet address:
http://siemens.com/bt/download
Notes
Disposal
The device is considered an electronic device for disposal in accordance
with the European Guidelines and may not be disposed of as domestic
garbage.
● Dispose of the device through channels provided for this purpose.
● Comply with all local and currently applicable laws and regulations.

9
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
Technical data
FDA241 FDA221
Operating voltage DC19.5...30V
Operating current at DC24V 150mA (nominal), 250mA (during alarm)
Dimensions (WxHxD) 162x285x120mm
Protection category IP30
Installation position Vertically upward, vertically downward
Sound power level LWA[dBA]: 1) -
At suction speed
- High
- Medium
- Low
37
33
30
33
30
26
Operating temperature -20...+60°C
Air humidity 5…95% (no moisture condensation)
Dust indicator Yes -
Maximum pipe length
- Single line
- Branched lines
60m
2x60m
30m
2x25m
Options for aspirating holes Prefabricated option or the maximum pipe length must correspond to the
calculation made using the software 'FXS2056ASDAsystToolV2'
Air intake/exhaust pipe Metric: 25mm outer diameter (OD)
Monitoring area (dependent on
local provisions and standards)
Up to 800m² Up to500m²
System compatibility Compatible with all Siemens FC20/FC720 (FS20/FS720 systems)
Relay alarm outputs
Can be selected with/without self-
retention
Nominal current 2.0A at DC30V.
Contact: NO/NC
4 3
Fault relay 1 1
Cable inlet 10cm x 2.5cm on the rear or from above
Terminal configuration Screw terminals
Conductor cross section 0.2…2.5mm2 (AWG 12– 30)
Other interfaces Power supply, 4…20mA
Alarm threshold for parameter sets:
Fire 1 10 sets
0.05…2.0%/mobs
5sets
0.20…2.0%/mobs
Fire 2 10 sets
2.0…20%/mobs
5sets
6.0…20%/mobs
Alarm delay, can be set individually 0…300seconds: default value 0seconds smoke density and 15seconds
flow
Indication ● 4x alarm status indicators (FDA241)
● 3x alarm status indicators (FDA221)
● Faults
● Blowing out (FDA241)
● Dust (FDA241)
● Smoke density and flow indicator

10
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
FDA241 FDA221
Service area ● 'StatusOK' LED
● USB
● Settings for reset functions
● Settings for smoke density and airflow
Event log Non-volatile event memory with time and date stamp for: smoke density,
airflow, detector status, and faults
Event memory entries 20000 8000
Modification memory entries 20000 8000
Normalization of smoke value and
airflow
● Setting of threshold values for smoke alarms and faults
● User setting for normalization of smoke density and airflow
● Preset values are retained during the normalization period
Warranty period 2years
Approvals
● VdS
FDA241
G213050
FDA221
G213050
1A-weighted sound power level in [dB] as per DINENISO3744-2009,
measured with a pipe piece at the air inlet and at the air outlet

11
Smart Infrastructure A6V10331032_k_en_--
2021-06-28
Dimensional drawings
FDA241, FDA221
FDAZ292
73
95
214
174.2
74
5

Issued by
Siemens Switzerland Ltd
Smart Infrastructure
Global Headquarters
Theilerstrasse 1a
CH-6300 Zug
[phone]
www.siemens.com/buildingtechnologies
© Siemens Switzerland Ltd, 2013
Technical specifications and availability subject to change without notice.
Document ID A6V10331032_k_en_--
Edition 2021-06-28
