Siemens TITANUS 3000 User manual

Air sampling smoke detection system
TITANUS 3000
Quick Guide for Commissioning
1 Installation
§Connect power (24V)
§Connect outputs for info- (AL1), pre- (AL2) and mainalarm (AL3) as well as “fault”
(switchover relay contacts)
§Connect reset input
§Connect ext. input “night” (LowSens., 2.Sens) (if required)
§Connect pipe system or test pipe
2 Set Up
Set DIP switches on pcb “basis E597.1” and on pcb “interface K3I 100” according to
tables below:
Selectable Settings ext. input “LowSens”:
function “day” switch combination on basis pcb (G,F,E)passive or not used
function “night”switch combination on interface pcb (1,2,3,4)active (24V)
Algorithms
switch
1 /G 2 /F 3 /E 4 DO1151A DO1153A DO1161A
OFF OFF OFF OFF 1) 1) 1)
ON OFF OFF OFF real estate 3% slow *) 1% *) 0,8% *)
OFF ON OFF OFF equipment 3% med. 0,5% 0,35%
ON ON OFF OFF equipment 3% fast 0,3% 0,25%
OFF OFF ON OFF life safety 1,5% med. 0,3% -> 0,2% 0,15%
ON OFF ON OFF life safety 1,5% fast 1) 0,15 -> 0,1%
OFF ON ON OFF life safety 1,5% slow 1) 1)
ON ON ON OFF detector test mode detector test mode detector test mode
1) = invalid combination; algorithm is set to *)
Air flow monitoring
switch delay time switch range
AB CD
OFF ON short 30 s ON OFF small I
ON OFF middle 2 min. (standard) OFF ON middle II
ON ON long 15 min. OFF OFF large III (standard)
OFF OFF very long 1 h ON ON very large IV
Fault Modus
switch switch
JHI
OFF Fault not latching (standard) OFF OFF normal operation (standard)
ON Fault latching until reset OFF ON direct mode normal on
ON ON direct mode high on
Atmospheric pressure compensation
R34 MP1 (+) MP2 (-) see correction table for atm.pressure or 2,50 V (standard)
Fire & Security Products
Siemens Building Technologies Group

3 Commissioning
Initializing of airflow monitoring
1. press button S2 “Init”
2. Fix cover and tighten screws. ( within the next 2 min.!)
3. after approx. 20 min the unit will memorise the “air flow normal” value of the tubing connected.
(front LED green flashing)
Internal LED’s on Interface pcb K3I100 (below detector)
LED’s
KO H1 gn detector communication normal
MA H2 gn detector answering normal, short flashing
ST H3 ye general fault. interface pcb
AW H4 ye application warning 35 / 100 sec.: detector programming
MS H5 ye detector fault detector defective, try push button “Reset”
Note : Press of button “Reset” only required, when detector was changed on running unit.
1
X8
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
1
2
3
4
X11
Rückstellen
Reset
2.Sens.
(LowSens)
Störung
Fault
Hauptalarm
Alarm
Voralarm
Prealarm
Infoalarm
-Ub
+Ub
24VDC
AL1
(GS1)
AL2
(GS2)
AL3
(GS3)
A
nschlussklemmen
Connection block
TITANUS 3000
(normal)
(gestört)
(fault)
-
+24V
2.Sens
Reset
Speisung
Supply
-
+24V
-
+24V
-
+24V
-
+24V
external internal
1
2
3
4
5
6
7
8
9
10
A
B
C
D
E
F
G
H
I
J
ON OFF
ON
OFF ON
1234
Switches
pcb basis
Function Values
Modus
Algorithms
on function “Day”
Air flow
range
Function
V
alues
Algorithms
on function “Night”
Switches
pcb interface
Fault latching
Air flow
monitoring
delay time
