Siemens DB-ADPT User manual

The SIEMENS Model DB-ADPT detector/base adapter
interfaces Series 11 detectors with previously installed
DB-3S bases For Series 3 air duct detector models
AD-3P, AD-3ILP, and SA-3P, use Series 11 Air Duct
Update Kit AD-11UK, which contains both the DB-ADPT and
the required DA-304 air duct cover for Series 11 detectors
WARNING:
When replacing a detector with a different model, be
aware that existing detector accessories connected
to the base or air duct housing that were compatible
with the old detector may not be compatible with the
new detector Always read the Installation Instruc-
tions accompanying the detector to determine detec-
tor and accessory compatibility
P/N 315-094200-6
Installation Instructions
Model DB-ADPT
Detector/Base Adapter
Fire Safety
Siemens Building Technologies, Inc.
Fernwood Road
Florham Park, New Jersey 07932
Siemens Building Technologies, Ltd.
2 Kenview Boulevard
Brampton, Ontario L6T 5E4 CN

2
INSTALLATION
For DB-3S Bases:
1 Remove the existing detector from the DB-3S base
2 To install the DB-ADPT adapter into the DB-3S base,
align the notch in the outer flange of the adapter to the
raised surface on the outer ring of the base (Refer to
Figure 1)
3 Push the adapter into the base and rotate clockwise to
engage the electrical connections The adapter will
automatically stop and lock into place
4 To make the adapter to DB-3S interface tamperproof
in the base, use the Model DB-LK
5 Install a Series 11 detector following the installation
instructions included with the detector
NOTE: If it becomes necessary to remove the
adapter, push the adapter up into the base
while rotating the adapter counterclockwise
Continue to rotate counterclockwise until stop
is reached Then pull downward to disengage
from the base When the DB-LK lock is used,
disengage the locking mechanism prior to
removing the adapter

3
Figure 1
Installing the DB-ADPT to the DB-3S Base
For Series 3 Airduct Housings using the AD-11UK
Air Duct Update Kit:
1 Remove the sensing compartment cover from the
existing duct housing
2 Remove the existing detector from the duct housing
3 To install the adapter into the duct housing, rotate
the adapter counterclockwise on the outer ring of
the base located in the duct housing until the
adapter drops into place

P/N 315-094200-6
4 Push the adapter down into the base and rotate
clockwise to engage electrical connections The
adapter will automatically stop and lock into place
5 Install a Series 11 detector following the installation
instructions included with the detector and then
install the new DA-304 sensing compartment cover
Tighten the cover snugly, but not so tightly as to
warp cover and cause leakage around the edges
NOTE: If it becomes necessary to remove the
adapter, push the adapter down into the
duct housing while rotating the adapter
counterclockwise Continue to rotate
counterclockwise until stop is reached
Then pull upward to disengage from the
housing
