1 Introduction
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
4
Siemens AG 2017 All rights reserved
1 Introduction
1.1 Overview
With LOGO! 8 and integrated functions such as Astrotimer, Yearly and Weekly
Timer, you can quickly and easily solve many automation tasks. The LOGO! text
display (TDE) and the integrated web server of LOGO! 8 offer additional
possibilities for controlling and monitoring.
For communication in building automation, Siemens offers a solution for LOGO! 8
in form of the communication module CMK2000. The communication module
enables communication with any KNX devices via the KNX building system bus.
This application example offers you a complete time switch function for LOGO! 8
and shows you how to mount it into a KNX system via the CMK2000.
Figure 1-1: Hardware setup for the application example
LOGO! 8 LOGO! CMK2000
ETHERNET TCP/IP
LOGO! TDE
•Buttons
•Actuators
•…
Advantages
The combination of the time switch function in LOGO! 8 and the CMK2000 module
offers you the following advantages:
Switching of actuators at configurable times
Configuration of timer via the LOGO! display
Configuration of timer using the integrated Web server of the LOGO! 8
Integration of LOGO! inputs and output into a KNX system
Target group
This application example is aimed at experienced KNX users who seek to expand
their KNX system with the functionalities of a LOGO! 8.

1 Introduction
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
5
Siemens AG 2017 All rights reserved
1.2 Mode of Operation
Time switch function
The time switch function in LOGO! consists of weekly and yearly timers and offers
the following scope of functions:
Standard times:
Switching on and off on certain days of the week, at certain times.
Event times:
Switching on and off on a certain date, at a certain time (e.g. for evening
events).
Times for suppressing the time switch function:
Date and time at which the standard and event times are inoperative, e.g.
during school holidays.
Central switching on and off:
Manual switching on and off, regardless of the time settings, e.g. for
maintenance work.
Mounting into KNX
Via the LOGO! communication module CMK2000, the time switch function of the
LOGO! is integrated into a KNX system.
Via configurable communication channels of the LOGO! CMK2000, the data
between the LOGO! and the KNX devices are exchanged bi-directionally.
In this application example, a 3-Gang Button with status LEDs is used as KNX
device. A status LED indicates the status of the time switch function.
Operation The time switch function is configured by the user.
This requires no special programming knowledge. The following options are
available:
Displaying message texts with time and date parameters at the LOGO! TDE
Displaying message texts with time and date parameters using the integrated
web server of the LOGO!
For users with programming experience, the following additional options to
configure the LOGO! time switch function are available:
In LOGO! Soft Comfort during commissioning
Configuration mode at LOGO! display
Central switching on and off is done via configured KNX buttons, digital inputs of
the LOGO!, or function buttons of the LOGO! TDE.
LOGO! TDE is an optional component whose functions (message texts and
function buttons) can also be used via the web server. You can also use a LOGO!
basic device without display.

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
6
Siemens AG 2017 All rights reserved
2 Setup and description
2.1 Components used
This application example was created with the following components:
Table 2-1: Hardware and software components for the application example
Component
Number
Article number
Note
LOGO! Soft Comfort
V8.1
1
6ED1058-0BA08-0YA1
Upgrade to V8.1 can be
found at
http://www.siemens.com/
logo
ETS5 Demo
1
Download link, see \6\
A maximum of 5 KNX
devices per project
LOGO! Power
1
6EP1332-1SH43
-
LOGO! 8 12/24 RCE
1
6ED1052-1MD00-0BA8
-
LOGO! CMK2000
1
6BK1700-0BA20-0AA0
Product data base for
ETS4/5:
http://www.siemens.com/
gamma-td
LOGO! TDE
1
6ED1055-4MH00-0BA1
Optional components
2-Gang Button
1
-
24 V
Siemens GAMMA KNX
Power Supply
1
5WG1 125-1AB12
320 mA
Siemens GAMMA KNX
bus coupler
1
5WG1 117-2AB12
-
Siemens GAMMA KNX
3-Gang Button
1
5WG1 223-2DB13
Product data base for
ETS4/5:
http://www.siemens.com/
gamma-td
Siemens GAMMA KNX
USB Interface
1
5WG1 148-1AB12
Required for the
programming of the KNX
devices.
This application example consists of the following components:
Table 2-2: Components for the application example
Component
File name
Note
Documentation
109745699_LOGO8_TimeSwitch_KNX_DOC_en.pdf
-
LOGO! 8
Program
109745699_LOGO8_TimeSwitch_CODE_en.lsc
Requirement:
LOGO! Soft
Comfort V8.1
ETS5 project
109745699_ETS5_LOGO_for_KNX_Project_en.knxpr
oj
-

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
7
Siemens AG 2017 All rights reserved
2.2 Hardware setup
The following figure shows the hardware setup for this application example.
Note
LOGO! TDE is an optional component, as you can also use the functions
(message texts and function keys) via the integrated LOGO! web server.
Figure 2-1: Hardware setup
L
N
PE
24 V DC
ETHERNET TCP/IP
L N PE
-+
NL1 M
L+ I2I1
Button
LOGO! 8LOGO! Power
USB Interface
LOGO! CMK
KNX Power Supply
KNX Button
230 V
ML+
PA: 1.1.2
PA: 1.1.3
IP: 192.168.0.10
IP: 192.168.0.1
PA: 1.1.1
Button A1
GA: 1/1/2 Status LED A1
GA: 1/1/1
Button A2
GA: 1/1/3
IP: 192.168.0.2
ML+
LOGO! TDE
GA: Group address KNX
PA: Physical address KNX
KNX
2.3 LOGO! program
The time switch function consists of weekly and yearly timer function blocks.
The function blocks are logically linked with each other and with the input signals in
order to switch an output on or off at certain times or manually.
Note
A function description of the time switch function can be found in the program
commentary in LOGO! Soft Comfort:
“Tools > Select Hardware… > Offline settings > Comment”.
Tip: Under “Tools > Options… > Print”, activate the option box “Comment” for
the function description to be printed together with the program.

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
8
Siemens AG 2017 All rights reserved
2.3.1 Basics
Week timer
Every week timer has three setting cams via which you can parameterize a time
slot each. Via the cams, you can set the switch on and off times (see Table 3-1).
If the output has not yet been set, the week timer will switch it on at a switch-on
time.
If a switch-off time is configured, the output of the week timer will be reset at the
switch-off time.
The switching state of the week timer depends on all three cams, No 1, No 2 and
No 3.
Figure 2-2: Week timer function block
Yearly timer
On certain dates, the yearly timer switches the output on or off.
The switch-on time indicates month and day, on which the timer is set.
The switch-off time indicates month and day, on which the timer is reset again.
(see Table 3-2).
The function offers two repeat patterns:
Yearly:
Timer output switches on every year at the specified month and day of the
switch-on time and remains switched on until the specified month and day of
the switch-off time.
Every month:
Timer output switches on every month at the specified day of the switch-on
time and remains switched on until the specified day of the switch-off time.
The switch-on year specifies the first year in which the timer will be activated.
The switch-off year specifies the last year in which the timer will be switched off.
Figure 2-3: Yearly timer function block
Internal clock buffering
The internal clock of a LOGO! 8 is buffered by an accumulator and continues to run
in the event of a power supply failure.
The buffering time is influenced by the ambient temperature. At 25 °C (77 °F), it is
around 20 days.

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
9
Siemens AG 2017 All rights reserved
2.3.2 Functional principle of the switching program
The following figure provides an overview of the entire switching program for the
time switch function. The individual positions (1) to (4) will be discussed during the
course of this chapter.
Figure 2-4: Overview switching program
The following table shows the input and output signals of the time switch function:
Table 2-3: Signals in the LOGO!
Signals
Function
Description
Input I1
Central switching on of
output Q1
Button on the LOGO!
Function key F1
LOGO! TDE or, alternatively, via the
LOGO! web server
Flag M50
Connection to KNX
Input I2
Central switching off of
output Q1
Button on the LOGO!
Function key F2
LOGO! TDE or, alternatively, via the
LOGO! web server
Flag M51
Connection to KNX
Output Q1
Output signal of the
time switch function
Switching of a load (e.g. a lamp) and
connection to KNX (e.g. actuator)
1
2
3
4

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
10
Siemens AG 2017 All rights reserved
1. Time-controlled switching on and off
The combination of different switching times expands the time switch function as
follows.
Standard switching time
Via the week timer function block "B002 StandardTime”, the standard switching
time is defined.
Via the function block, it is set, on which weekdays and at which time the time
switch function switches the output Q1 on and off.
Event switching time
By linking the week timer "B001 EventTime" and yearly timer "B008 EventDay"
function blocks, an event switching time is defined.
Via the function blocks, the date and time is set for when the time switch function
switches the output Q1 on and off.
Figure 2-5: Blocks for time-controlled switching on and off
2. Suppress switching on at certain times
With the yearly timers “B006 SummerBreak”, “B020 EasterBreak” and “B049
WinterBreak”, a time period (e.g. holidays) can be defined during which the switch-
on via the standard switching times is suppressed.
With the weekly timer “B017 TimeLock”, it can be defined, on which weekdays and
at which time the switch-on via the standard switching times is suppressed.
The event switching times are not suppressed and continue to switch. This allows a
planned switch-on and off, despite the suppressed standard switching times.
Figure 2-6: Blocks for suppressing standard switching times

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
11
Siemens AG 2017 All rights reserved
3. Central switching on and off
1. Via the input I1, the function key F1 or the flag M50 (signal from the KNX), the
output of the time switch function is switched on centrally.
2. Via the input I2, the function key F2 or the flag M51 (signal from the KNX), the
output of the time switch function is switched off centrally.
The central switching on and off will be overwritten with the next impulse from the
set switching times.
Figure 2-7: Blocks for central switching on and off
1
2

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
12
Siemens AG 2017 All rights reserved
4. Adjust switching times in the message text
To comfortably adjust the switching times, the switching program contains
message text blocks. The content of the message texts is displayed at the LOGO!
TDE or in the web server (LOGO! TD).
Note
In this application example, the display via the LOGO! TD is preferred, whereby
more characters per line are available in the message text than via the LOGO!
display.
Additionally, the function keys and message texts of the LOGO! TD can be used
via the web server.
Figure 2-8: Message text blocks
In the message texts, individual parameters of the weekly and yearly timers are
inserted. The parameters are clearly named for an unequivocal identification.
During operation, an operator can select and change a parameter via the message
texts at the display or via the web server.(see 4.1.2).
Figure 2-9: Parameters in the message texts

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
13
Siemens AG 2017 All rights reserved
2.3.3 Simulation mode
With LOGO! Soft Comfort, you can simulate and test the time switch function and
the message texts prior to loading them to a LOGO! basic device.
The simulation is already possible with the demo version of LOGO! Soft Comfort.
Start the simulation in order to better comprehend the behavior of the switching
program and the function of the message texts.
Start simulation
Open the supplied LOGO! program
"109745699_LOGO8_TimeSwitch_CODE_de.lsc” with LOGO! Soft Comfort V8.1.
Start the simulation by clicking the “Simulation” button on the “Tool” toolbar of the
diagram editor.
Figure 2-10: Start simulation
Simulation mode
Upon starting the simulation mode, LOGO! Soft Comfort displays the simulation bar
in the lower window area with the following icons.
Figure 2-11: Simulation bar
1 2
3
Click on the button (1) of the simulation bar from Figure 2-11 to change the current
time in LOGO! Soft Comfort. By setting the time shortly before the switching time
occurs, you can, for example, test and check the set switching times of a weekly
timer.

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
14
Siemens AG 2017 All rights reserved
Via the button (2) of the simulation bar from Figure 2-11, you can open or close the
message text window.
In the message text window (Figure 2-12), you can switch between the
programmed message texts (1). To open the input field of a parameter in a
simulated message text, double-click on the parameter (2). Then, enter a new
value for the parameter (3).
Observe the functioning of the program with the changed parameters. If necessary,
change the current time in LOGO! Soft Comfort.
Figure 2-12: –Simulating a message text
Whether the signal "1" or "0" is switched at a connection line can be seen in the
color representation (Figure 2-13). In simulation mode, the connection lines with
signal “1” are, by default, displayed in red and the connection lines with signal “0” in
blue.
To simulate an active signal at input I1, for example, you click on the button (3) of
the simulation tab from Figure 2-11, or directly on the input block I1. The described
simulation is also possible with the function key, however, not with the flag.
Figure 2-13: Simulate input signal

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
15
Siemens AG 2017 All rights reserved
2.4 Mounting the LOGO! into KNX
The LOGO! 8 is mounted into a KNX system via the LOGO! communication
module CMK2000.
In this, you can define the communication channels in LOGO! CMK2000 from the
LOGO! to the KNX and vice versa. For the channels, you parameterize inputs and
outputs, flags or variable memories as signal in the LOGO!.
The following table shows the signals of the LOGO! for this application example
and the communication direction between LOGO! and KNX.
Table 2-4: Signal exchange between LOGO! and KNX
Signals in
the LOGO!
Group address
in KNX
Direction
Description
Output Q1
1/1/1
LOGO! → KNX
Status LED A1 at KNX button for
the display of the time switch
function as substitute for an
additional switch actuator.
Flag M50
1/1/2
KNX → LOGO!
Button A! at KNX button for
central switching on.
Flag M51
1/1/3
KNX → LOGO!
Button A2 at KNX button for
central switching off.
For the sake of completeness, chapters 2.4.1 and 2.4.2 describe the steps for the
configuration of the LOGO! CMK2000 and the integration of the LOGO! signals via
the ETS5 software. If you want to commence operation with the already configured
LOGO! CMK2000 from the supplied ETS5 project, follow the instructions from
chapter 3.4.

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
16
Siemens AG 2017 All rights reserved
2.4.1 LOGO! CMK2000 parameterization
The LOGO! CMK2000 is parameterized via the ETS software.
Note
It is assumed that all KNX devices as well as the LOGO! CMK2000 are
incorporated as devices in the ETS software.
Parameter
In the “Parameter” window, the general settings of the LOGO! CMK2000 and the
settings of the channels for the communication between LOGO! 8 and KNX are
made.
Table 2-5: LOGO! CMK2000 - Open parameter settings
No.
Action
1.
Open the ETS window “Devices” and select LOGO-KNX-Module-CMK2000.
2.
To open the parameter settings, select the “Parameter” tab from the lower tab of
the list view.

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
17
Siemens AG 2017 All rights reserved
Parameter: General
In the general parameters, you determine, inter alia, the LOGO! base module with
which the signal and data exchange is to be performed.
Table 2-6: LOGO! CMK2000 - Editing general parameters
No.
Action
1.
In the parameter settings view, select the “General” tab.
2.
Make the following settings for the LOGO! CMK2000:
1. Enter the IP address of your LOGO! basemodule.
Information on this matter can be found in the LOGO! Manual in chapter
3.8.1 “Configuring network settings”:
https://support.industry.siemens.com/cs/ww/en/view/109741041/893568026
99
2. Enter an IP address for the LOGO! CMK2000.
3. Enter a subnet mask for the LOGO! CMK2000.
4. Enter a password for the web interface of the LOGO! CMK2000 (required
for firmware updates).
1
2
3
4

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
18
Siemens AG 2017 All rights reserved
Parameter: Channel “From LOGO! to KNX”
The following table shows how to establish a channel for the data exchange from
LOGO! to KNX.
Table 2-7: LOGO! CMK2000 parameter: Establishing a channel “From LOGO! to KNX”
No.
Action
1.
In the list view of the parameter settings, select the tab of a freely available
channel (in this application example “Channel 1”).
2.
1. Set “From LOGO! to KNX” for the transmission direction.
2. Select a LOGO! data type (in this application example “Digital output”).
You can choose from inputs, outputs, flags and variable memories (VM) of
the LOGO!.
3. Select the address (in this application example “1”) for the selected data
type.
4. Select the data type via which the LOGO! signal is interpreted by KNX.
1
2
3
4

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
19
Siemens AG 2017 All rights reserved
Parameter: Channel “From KNX to LOGO!”
The following table shows how to establish a channel for the data exchange from
KNX to LOGO!.
Table 2-8: LOGO! CMK2000 parameters: Channel “From KNX to LOGO!”
No.
Action
1.
In the list view of the parameter settings, select the tab of a freely available
channel (in this application example “Channel 2”).
2.
1. Set “From KNX to LOGO!” for the transmission direction.
2. Select the KNX data type which is transmitted to LOGO!.
3. Select with which data type (in this application example “Digital flag”) the
KNX signal is interpreted in the LOGO!.
4. Select the address (in this application example “50”) for the selected data
type, in order to determine how you would like to use the KNX signal in the
LOGO! program.
5. Activate the monoflop function and set a monoflop time. This implements a
digital trigger from KNX towards LOGO! 8 as a signal with a defined period
(automatic reset).
1
2
3
4
5

2 Setup and description
Time Switch Function
Entry ID: 109745699, V1.0, 04/2017
20
Siemens AG 2017 All rights reserved
2.4.2 Connecting communication objects
In the “Group Objects” window, connect the LOGO! CMK communication channels
with the group addresses of the KNX devices (buttons, actuators, etc.).
Table 2-9: Communication objects
No.
Action
1.
Open the ETS window “Devices” and select the device “LOGO-KNX-Module-
CMK2000” together with the device with which the communication is to be
established.
2.
To display the communication objects in the list view, select the “Group Objects”
tab from the lower tab of the list view.
3.
1. Open the context menu for an object of the LOGO-KNX-Module by
right-clicking it (in this application example “Channel 1”).
2. Click on “Link with...” to connect the object with a group address.
4.
Specify the group address (in this application example “1/1/1” for the status LED
of the KNX button) of the communication object with which the object “Channel 1”
of the LOGO-KNX-Module will be connected with (e.g. “Group address of an
actuator”).
