Siemens RWB27 Timeswitch User manual

RWB27 Timeswitch
Weekend/Weekday Programming

RWB27 Controls
MENU/SELECT
RESET
ON
WHEN LIT
EXTEND
ADVANCE
BACK/EXIT
UP & DOWN

Introduction
This booklet gives you easy to follow instructions allowing you to
set your RWB27 Timeswitch to the Weekday/Weekend, (same
times Monday - Friday, different times Saturday - Sunday if
required) program.
Contents
How do I change/set the ON/OFF times?
How do I review the current ON/OFF times?
What do the switching options mean?
How do I select my Switching Options?
How do I set my holiday program?
How do I activate my holiday program?
What do the buttons do?
Notes on RWB27 settings.
To make it easier to follow, the buttons you should be using are
coloured grey.
1
2
3
4
5
6
7
8

RWB27 Weekday/Weekend
At first installation
display will show as
above unless reset is
activated.
At first installation
display will show as
above when reset is
activated.
MENU
3:37 PM
CH OFF MAN
10:32 AM
Mon Tue Wed
Thu Fri Sat Sun
2P

How do I change/set the
ON/OFF times?
• Press left hand button MENU
• Press top middle button
until SET PROGRAM is shown
• Press left hand button SELECT,
SET WEEKDAYS will be shown, press
SELECT again display will show
(continued on next page)
MENU
3:37 PM
CH OFF MAN
SET PROGRAM
SELECT EXIT
CH OFF MAN
3:37 PM
SET 1st ON
SELECT BACK
CH
8:30
AM
Mon Tue Wed
Thu Fri

To change 1st ON time press
SELECT,time will flash, change
times by using +/- , when
desired time is in the display press
ENTER display will show
• Repeat as above until last OFF
time is entered display will show
SET WEEKDAYS, Press top middle
button display will show SET
WEEKEND, repeat as above until
all times are entered, display will
show SET WEEKEND press right
hand button BACK then right hand
button press EXIT to return to
MENU
SET THE TIME
ENTER +/- BACK
SET WEEKEND
SELECT BACK
SET 1st OFF
SELECT BACK
CH
10:30
AM
3:37 PM
CH
8:30
AM
Mon Tue Wed
Thu Fri
Mon Tue Wed
Thu Fri
Sat Sun

How do I review the current
ON/OFF times?
• Press left hand button MENU
• Press top middle button
until REVIEW PROG is shown
• Press left hand button SELECT
display shows
• Press left hand button VIEW
(continued on next page)
REVIEW PROG
SELECT EXIT
WEEKDAYS
VIEW BACK
MENU
3:37 PM
CH OFF MAN
3:37 PM
Mon
Mon
Mon Tue Wed
Thu Fri

VIEW 1st ON
BACK
CH
8:30
AM
• Display shows
• Press top middle button
1st OFF will be shown, continue
pressing this button until all
times have been reviewed
• Press right hand button BACK,
press top middle button
display shows
• Press left hand button VIEW
(continued on next page)
Mon Tue Wed
Thu Fri
VIEW 1st OFF
BACK
CH
10:30
AM
Mon Tue Wed
Thu Fri
WEEKEND
VIEW BACK
Sat Sun

VIEW 1st ON
BACK
CH
7:30
AM
• Display shows
• Press top middle button
1st OFF will be shown, continue
pressing this button until all
times have been reviewed
• Press right hand button BACK,
press BACK again then press EXIT
display shows
Sat Sun
VIEW 1st OFF
BACK
CH
9:30
AM
Sat Sun
MENU
3:37 PM
CH OFF MAN
Mon

What do the switching options mean?
AUTO
This means that the RWB27 will switch ON and OFF according to
the programmed times
MANUAL OFF
This means that the RWB27 will be permanently OFF
MANUAL ON
This means that the RWB27 will be permanently ON
ONCE
This means that the RWB27 will switch ON at the first ON time and
switch OFF at the last OFF time you have programmed ignoring
any ON/OFF times in between. This is also referred to as All Day.
