Siemens SITRANS P series Administrator guide

SITRANS P
Pressure transmitter
SITRANS P200
Compact Operating Instructions
7MF1565
09/2020
A5E03304326-AA
Introduction 1
Safety instructions 2
Description 3
Installing/mounting 4
Connecting 5
Commissioning 6
Service and maintenance 7
Technical speci󹪝cations 8
Dimension drawings 9
Product documentation and
support A

Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage
to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices
referring only to property damage have no safety alert symbol. These notices shown below are graded according to
the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be
used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to property
damage.
Quali󹪝ed Personnel
The product/system described in this documentation may be operated only by personnel quali󹪝ed for the speci󹪝c
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Quali󹪝ed personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended or
approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance
are required to ensure that the products operate safely and without any problems. The permissible ambient
conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identi󹪝ed by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may
be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described.
Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this
publication is reviewed regularly and any necessary corrections are included in subsequent editions.
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
Document order number: A5E03304326
Ⓟ 09/2020 Subject to change
Copyright © Siemens AG 2020.
All rights reserved

Table of contents
1 Introduction ........................................................................................................................................... 5
1.1 Purpose of this documentation ............................................................................................ 5
1.2 Checking the consignment................................................................................................... 5
1.3 Transportation and storage .................................................................................................. 5
1.4 Notes on warranty ............................................................................................................... 6
2 Safety instructions................................................................................................................................. 7
2.1 Prerequisites for safe use...................................................................................................... 7
2.1.1 Laws and directives.............................................................................................................. 7
2.1.2 Conformity with European directives.................................................................................... 7
2.2 Improper device modi󹪝cations.............................................................................................. 8
2.3 Requirements for special applications................................................................................... 8
2.4 Use in hazardous areas......................................................................................................... 8
3 Description........................................................................................................................................... 11
3.1 Application ........................................................................................................................ 11
3.2 Hardware con󹪝guration ..................................................................................................... 11
3.3 Layout of the nameplate .................................................................................................... 12
4 Installing/mounting ............................................................................................................................. 15
4.1 Basic safety instructions ..................................................................................................... 15
4.2 Additional notes on installation of explosion protection devices.......................................... 16
4.3 Installation ........................................................................................................................ 16
5 Connecting .......................................................................................................................................... 17
5.1 Basic safety instructions ..................................................................................................... 17
5.1.1 Grounding for Ex (explosion protection) devices ................................................................. 17
5.2 Electrical connections ........................................................................................................ 19
6 Commissioning .................................................................................................................................... 21
6.1 Correction of zero point and span....................................................................................... 21
7 Service and maintenance .................................................................................................................... 23
7.1 Basic safety instructions ..................................................................................................... 23
7.2 Maintenance...................................................................................................................... 23
7.3 Return procedure ............................................................................................................... 23
7.4 Disposal............................................................................................................................. 24
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 3

8 Technical speci󹪝cations ....................................................................................................................... 25
8.1 General technical speci󹪝cations.......................................................................................... 25
8.2 Certi󹪝cates and approvals................................................................................................... 28
8.2.1 Explosion protection .......................................................................................................... 28
9 Dimension drawings............................................................................................................................ 29
9.1 Dimensional drawings process connections........................................................................ 29
9.2 Dimensional drawings electrical connections...................................................................... 30
A Product documentation and support .................................................................................................. 31
A.1 Product documentation ..................................................................................................... 31
A.2 Technical support............................................................................................................... 32
Index .................................................................................................................................................... 33
Table of contents
SITRANS P200
4Compact Operating Instructions, 09/2020, A5E03304326-AA

Introduction 1
1.1 Purpose of this documentation
These instructions contain all information required to commission and use the device. Read the
instructions carefully prior to installation and commissioning. In order to use the device
correctly, 󹪝rst review its principle of operation.
The instructions are aimed at persons mechanically installing the device, connecting it
electronically, con󹪝guring the parameters and commissioning it, as well as service and
maintenance engineers.
1.2 Checking the consignment
1. Check the packaging and the delivered items for visible damages.
2. Report any claims for damages immediately to the shipping company.
3. Retain damaged parts for clari󹪝cation.
4. Check the scope of delivery by comparing your order to the shipping documents for
correctness and completeness.
WARNING
Using a damaged or incomplete device
Risk of explosion in hazardous areas.
• Do not use damaged or incomplete devices.
1.3 Transportation and storage
To guarantee su󹪟cient protection during transport and storage, observe the following:
• Keep the original packaging for subsequent transportation.
• Devices/replacement parts should be returned in their original packaging.
• If the original packaging is no longer available, ensure that all shipments are properly
packaged to provide su󹪟cient protection during transport. Siemens cannot assume liability
for any costs associated with transportation damages.
NOTICE
Insu󹪟cient protection during storage
The packaging only provides limited protection against moisture and in󹪝ltration.
• Provide additional packaging as necessary.
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 5

Special conditions for storage and transportation of the device are listed in Technical
speci󹪝cations (Page 25).
1.4 Notes on warranty
The contents of this manual shall not become part of or modify any prior or existing agreement,
commitment or legal relationship. The sales contract contains all obligations on the part of
Siemens as well as the complete and solely applicable warranty conditions. Any statements
regarding device versions described in the manual do not create new warranties or modify the
existing warranty.
The content re󹪞ects the technical status at the time of publishing. Siemens reserves the right to
make technical changes in the course of further development.
Introduction
1.4 Notes on warranty
SITRANS P200
6Compact Operating Instructions, 09/2020, A5E03304326-AA

Safety instructions 2
2.1 Prerequisites for safe use
This device left the factory in good working condition. In order to maintain this status and to
ensure safe operation of the device, observe these instructions and all the speci󹪝cations relevant
to safety.
Observe the information and symbols on the device. Do not remove any information or symbols
from the device. Always keep the information and symbols in a completely legible state.
Symbol Explanation
Consult operating instructions
2.1.1 Laws and directives
Observe the safety rules, provisions and laws applicable in your country during connection,
assembly and operation. These include, for example:
• National Electrical Code (NEC - NFPA 70) (USA)
• Canadian Electrical Code (CEC) (Canada)
Further provisions for hazardous area applications are for example:
• IEC 60079-14 (international)
• EN 60079-14 (EU)
2.1.2 Conformity with European directives
The CE mark on the device is a sign of conformity with the following European directives:
Electromagnetic compatibil‐
ity EMC
2014/30/EU
Directive of the European Parliament and of the Council on the
harmonisation of the laws of the Member States relating to elec‐
tromagnetic compatibility.
Atmosphère explosible ATEX
2014/34/EU
Directive of the European Parliament and of the Council on the
harmonisation of the laws of the Member States relating to
equipment and protective systems intended for use in potentially
explosive atmospheres.
2011/65/EU RoHS Directive of the European Parliament and of the Council on the
restriction of the use of certain hazardous substances in electrical
and electronic equipment
The standards applied can be found in the EC declaration of conformity for the device.
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 7

2.2 Improper device modi󹪝cations
WARNING
Improper device modi󹪝cations
Risk to personnel, system and environment can result from modi󹪝cations to the device,
particularly in hazardous areas.
• Only carry out modi󹪝cations that are described in the instructions for the device. Failure to
observe this requirement cancels the manufacturer's warranty and the product approvals.
2.3 Requirements for special applications
Due to the large number of possible applications, each detail of the described device versions for
each possible scenario during commissioning, operation, maintenance or operation in systems
cannot be considered in the instructions. If you need additional information not covered by
these instructions, contact your local Siemens o󹪟ce or company representative.
Note
Operation under special ambient conditions
We highly recommend that you contact your Siemens representative or our application
department before you operate the device under special ambient conditions as can be
encountered in nuclear power plants or when the device is used for research and development
purposes.
2.4 Use in hazardous areas
Quali󹪝ed personnel for hazardous area applications
Persons who install, connect, commission, operate, and service the device in a hazardous area
must have the following speci󹪝c quali󹪝cations:
• They are authorized, trained or instructed in operating and maintaining devices and systems
according to the safety regulations for electrical circuits, high pressures, aggressive, and
hazardous media.
• They are authorized, trained, or instructed in carrying out work on electrical circuits for
hazardous systems.
• They are trained or instructed in maintenance and use of appropriate safety equipment
according to the pertinent safety regulations.
Safety instructions
2.4 Use in hazardous areas
SITRANS P200
8Compact Operating Instructions, 09/2020, A5E03304326-AA

WARNING
Use in hazardous area
Risk of explosion.
• Only use equipment that is approved for use in the intended hazardous area and labelled
accordingly.
• Don't use devices that have been operated outside the conditions seci󹪝ed for hazardous
areas. If you have used the device outside the conditions for hazardous areas permanently
make all Ex markings unrecognizable on the nameplate.
WARNING
Loss of safety of device with type of protection "Intrinsic safety Ex i"
If the device has already been operated in non-intrinsically safe circuits or the electrical
speci󹪝cations have not been observed, the safety of the device is no longer ensured for use in
hazardous areas. There is a risk of explosion.
• Connect the device with type of protection "Intrinsic safety" solely to an intrinsically safe
circuit.
• Observe the speci󹪝cations for the electrical data on the certi󹪝cate and/or in Technical
speci󹪝cations (Page 25).
Safety instructions
2.4 Use in hazardous areas
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 9

Safety instructions
2.4 Use in hazardous areas
SITRANS P200
10 Compact Operating Instructions, 09/2020, A5E03304326-AA

Description 3
3.1 Application
The pressure transmitter is used for measuring the gauge pressure and absolute pressure of
gases and liquids in the following industrial areas:
• Mechanical engineering
• Power engineering
• Water supply
• Shipbuilding
• Chemical industry
• Pharmaceuticals
3.2 Hardware con󹪝guration
Device structure without explosion protection
The pressure transmitter consists of a piezo-resistive measuring cell with a diaphragm installed
in a stainless steel enclosure. It can be electrically connected using a plug complying with
EN 175301-803-A (IP65), a round plug M12 (IP67), a cable (IP67) or a fast-󹪝t cable gland (IP67).
The output signal is between 4 and 20 mA or 0 and 10 V.
Device structure with explosion protection
The pressure transmitter consists of a piezo-resistive measuring cell with a diaphragm installed
in a stainless steel enclosure. It can be connected electrically with a connector ful󹪝lling EN
175301-803-A (IP65) or a round plug M12 (IP67). The output signal amounts to between 4 and
20 mA.
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 11

Table 3-1 Overview of the di󹪜erent variants

7MF1565 with plug in
accordance with
EN 175301-803-A
• Type
7MF1565-.....-1..1
• Type
7MF1565-.....-5..1
7MF1565 with plug
M12x1
• Type
7MF1565-.....-2..1
7MF1565 with cable
(2 m)
• Type
7MF1565-.....-3..1
7MF1565 with fast-󹪝t
cable gland
• Type
7MF1565-.....-4..1
3.3 Layout of the nameplate
Separator
Single part number
Order item
3 digits of the order number
Date in format“Year-Month-Day”*)
Manufacturer short name
Manufacturing date is visible on the label of the pressure transmitter, e.g.: LKK-YMDD-XXX-XX-XXX
*) Decoding for year, month and day information
Code Year
A 2010
B 2011
C 2012
D 2013
E 2014
F 2015
H (G)1) 2016
J 2017
K 2018
L 2019
M 2020
Description
3.3 Layout of the nameplate
SITRANS P200
12 Compact Operating Instructions, 09/2020, A5E03304326-AA

Code Year
N 2021
P 2022
R 2023
S 2024
T 2025
U 2026
V 2027
W 2028
X 2029
Code Month
1 January
2 February
3 March
4 April
5 May
6 June
7 July
8 August
9 September
O October
N November
D December
Code 01-31
Day of month 1st to 31st day
1) Conforming to DIN EN 60062
2) The letter G is not permitted for new applications since it deviates from DIN EN 60062. It serves
only for coding back.
Description
3.3 Layout of the nameplate
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 13

Description
3.3 Layout of the nameplate
SITRANS P200
14 Compact Operating Instructions, 09/2020, A5E03304326-AA

Installing/mounting 4
4.1 Basic safety instructions
DANGER
Pressure applications
Danger to personnel, system and environment will result from improper disassembly.
• Never attempt to loosen, remove, or disassemble process connection while vessel contents
are under pressure.
CAUTION
Direct sunlight
Device damage.
The device can overheat or materials become brittle due to UV exposure.
• Protect the device from direct sunlight.
• Make sure that the maximum permissible ambient temperature is not exceeded. Refer to
the information in Technical speci󹪝cations (Page 25).
WARNING
Wetted parts unsuitable for the process media
Risk of injury or damage to device.
Hot, toxic and corrosive media could be released if the process medium is unsuitable for the
wetted parts.
• Ensure that the material of the device parts wetted by the process medium is suitable for the
medium. Refer to the information in Technical speci󹪝cations (Page 25).
Note
Material compatibility
Siemens can provide you with support concerning selection of sensor components wetted by
process media. However, you are responsible for the selection of components. Siemens accepts
no liability for faults or failures resulting from incompatible materials.
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 15

4.2 Additional notes on installation of explosion protection devices
Operation is permitted only when connected to certi󹪝ed intrinsically-safe resistive circuits with
the following maximum values:
Ui ≤ 30 V
Ii ≤ 100 mA
Pi ≤ 750 mW
Internal inductance Li = 0 nH
Internal capacitance Ci = 0 nF
A maximum ambient air temperature Ta of -25 °C to +85 ºC is permitted for the pressure
transmitter.
Use as a resource belonging to Category 1/2:
The pressure transmitters can be mounted in the wall separating the area with Category 1
requirements (Zone 0) and the area with Category 2 requirements (Zone 1). In this case, the
process connection must be adequately sealed in compliance with IEC/EN 60079-26, Clause 4.3,
for example by providing degree of protection IP67 in compliance with EN60529. The supply
must be e󹪜ected via intrinsically safe circuits with type of protection ia. The measuring cell may
only be used for 󹪞ammable materials to which the diaphragms of the measuring cells are
adequately resistant both chemically and in terms of corrosion.
4.3 Installation
• The location of the device has no in󹪞uence on the measurement accuracy.
• Before installation, compare the process data with the data of the rating plate.
• The medium being measured must be suitable for the parts of the pressure transmitter in
contact with the medium.
• The overload limit must not be exceeded.
• Connect the devices with 󹪝xed cable installation.
• High-frequency electromagnetic interferences may result in measurement deviations of up
to 1%.
Installing/mounting
4.3 Installation
SITRANS P200
16 Compact Operating Instructions, 09/2020, A5E03304326-AA

Connecting 5
5.1 Basic safety instructions
WARNING
Unsuitable cables, cable glands and / plug-in connectors
Danger of explosion in hazardous areas.
• Only use cable glands/plug-in connectors that ful󹪝ll the requirements of the relevant type
of protection.
• Only use cables that have been designed for an ambient temperature of at least 20 K higher.
• Close cable openings for electrical connections that are unused.
• When replacing cable glands, only use ones of the same type.
• After installation check that the cables are seated 󹪝rmly.
WARNING
Improper power supply
Risk of explosion in hazardous areas as result of incorrect power supply, e.g. using direct current
instead of alternating current.
• Connect the device in accordance with the speci󹪝ed power supply and signal circuits. The
relevant speci󹪝cations can be found in the certi󹪝cates, in Technical speci󹪝cations
(Page 25) or on the nameplate.
5.1.1 Grounding for Ex (explosion protection) devices
WARNING
Lack of equipotential bonding
Danger of explosion through compensating currents or ignition currents through lack of
equipotential bonding.
• Make sure that equipotential bonding exists for the device.
• The pressure transmitter must be connected to the equipotential bonding system of the
plant via the metal housing (process connection) or the ground conductor of the plug.
Exception: It may be permissible to omit connection of the equipotential bonding for devices
with type of protection "Intrinsic safety Ex i".
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 17

WARNING
Unprotected cable ends
Risk of explosion through unprotected cable ends in hazardous areas.
• Protect unused cable ends in accordance with IEC/EN 60079-14.
WARNING
Connecting device in an energized state / Disconnecting device from power supply in an
energized state
Risk of explosion in hazardous areas.
• In hazardous areas, only connect the device in a de-energized state and only disconnect the
device from the power supply in a de-energized state.
Exceptions:
• Devices with the "Intrinsic safety Ex i" type of protection may also be connected or
disconnected in an energized state in hazardous areas.
• Exceptions for "Non-sparking nA" type of protection (Zone 2) are regulated in the relevant
certi󹪝cate.
Note
Electromagnetic compatibility (EMC)
You can use this device in industrial environments, households and small businesses.
For metal enclosures there is an increased electromagnetic compatibility compared to high-
frequency radiation. This protection can be increased by grounding the enclosure.
Note
Improvement of interference immunity
• Lay signal cables separately to cables with voltages > 60 V.
• Use cable with twisted wires.
• Keep the device and the cables at a distance from strong electromagnetic 󹪝elds.
Note
Power supply
The device should only be supplied with limited energy according to UL61010-1 Second Edition,
Section 9.3 or LPS (Low Power Supply) in accordance with UL60950-1 or Class 2 in accordance
with UL1310 or UL1585.
Connecting
5.1 Basic safety instructions
SITRANS P200
18 Compact Operating Instructions, 09/2020, A5E03304326-AA

5.2 Electrical connections
Legend
I0Output current UBAuxiliary power
U0Output voltage Grounding
RLLoad
Connecting with current output and connector in accord‐
ance with EN 175301
Connecting with voltage output and connector in accord‐
ance with EN 175301
*06#3-$POOFDUJPO
606#3-$POOFDUJPO6#6
Connecting with current output and connector M12x1 Connecting with voltage output and connector M12x1
&RQQHFWLRQ

+
UB
RL
IO
3-
1+
1
3
6#3-60$POOFDUJPO6#6
Connecting with current output and cable Connecting with voltage output and cable
UB
RL
IO+
%URZQ*UHHQ&RQQHFWLRQ%URZQ*UHHQ
UB
RL
UO+
Green
White
Brown
&RQQHFWLRQ%URZQ8%:KLWH*UHHQ8
Connecting with current output and fast-󹪝t cable gland Connecting with voltage output and fast-󹪝t cable gland
*06#3-$POOFDUJPO
606#3-$POOFDUJPO6#6
Version with explosion protection: 4 to 20 mA
The grounding connection is conductively bonded to the transmitter enclosure.
Connecting
5.2 Electrical connections
SITRANS P200
Compact Operating Instructions, 09/2020, A5E03304326-AA 19

Connecting with current output and connector in accordance with EN 175301 (Ex)
*06#3-$POOFDUJPO
Connecting with current output and connector M12x1 (Ex)
6#3-*0$POOFDUJPO
Connecting
5.2 Electrical connections
SITRANS P200
20 Compact Operating Instructions, 09/2020, A5E03304326-AA
