Signature Hardware LATTIMORE User manual

LATTIMORE SHOWER SET INSTALLATION
GETTING STARTED
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing fixtures. Signature
Hardware accepts no liability for any damage to the
plumbing, floor, walls, tub, or for personal injury during
installation.
Observe all local plumbing and building codes.
Unpack and inspect the items for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
Ensure that you have gathered all the required
materials that are needed for the installation.
For the following installation instructions, it is
assumed that the wall has been opened and that the
existing shower set has been removed.
Before you begin, the main water supply to your home
should be shut off.
TOOLS AND MATERIALS:
Plumbers
Tape
Adjustable
Wrench
1Lattimore Shower Set Installation Instructions
Tape Measure
Drill
Wood Blocking Soldering Kit
(for copper pipe) ½" Test Plug
Level
Hex Wrench
SKU(s): 931419

LATTIMORE SHOWER SET INSTALLATION
Step 1: Valve Installation
3. Route, assemble, and connect all in-wall piping to and
from the shower valve. Make connections appropriately
depending upon the type of pipe that is being used. For
copper pipe, soldering will be required and should be
completed by a licensed plumber. Apply plumber’s tape
to any threaded connections if applicable. Install any
wood blocking that is necessary to support the piping
and valve.
Notes:
• Female fittings will need to be installed where the
hand shower’s cradle and the shower arm will mount.
• The piping for the overhead shower should be
connected to the bottom outlet of the rough-in valve.
Piping for the hand held shower should connect to the
top.
1. To prepare for installation, wood blocking should be
installed between the two studs where the valve will
mount. Use the guide printed on the valve’s protective
sleeve as a reference when installing the wood block-
ing.
Important: Take into consideration the thickness of
the finished wall materials, such as tile, when calculating
measurements. If the finished wall extends beyond the
maximum guideline marked, the trim pieces will not
install.
2. Secure the valve to the prepared wood blocking
using the provided hardware. Ensure that the hot
outlet is pointing to the left, and the cold outlet is
pointing to the right. Use a level to ensure that the
valve is installed straight.
Tip: Leave the protective sleeves on the valve stems
until your finished wall is complete, and you are ready
to install the trim pieces.
2Lattimore Shower Set Installation Instructions
HOT
COLD
OUT
OUT
handheld
shower
overhead
shower

LATTIMORE SHOWER SET INSTALLATION
2. Slide the decorative back plate onto the valve.
3Lattimore Shower Set Installation Instructions
Step 2: Trim Installation
4. Once all piping is routed and connections have been
made, use a ½” test plug to perform a water pressure
test. Turn on the main water supply to your home and
water test the installed plumbing. Ensure that there are
no leaks, then shut the water off. Remove the test plug.
Note: Water pressure testing should be performed by a
licensed plumber if you are not familiar with this proce-
dure.
IMPORTANT: COMPLETE THE CONSTRUCTION OF
YOUR WALL, INCLUDING ANY FINISHED WALL
MATERIALS SUCH AS TILE, BEFORE PROCEEDING
WITH THE REMAINDER OF THE INSTALLATION.
STOP
1. Once the finished wall is complete, remove the
protective sleeves from the valve. If the test plug has
not yet been removed, remove that as well.

3. Remove the decorative screw cover from the valve
handle. Slide the handle onto the valve stem and
secure it by tightening the set screw with the provided
hex wrench. Reinsert the screw cover to conceal the
screw.
LATTIMORE SHOWER SET INSTALLATION
6. Slide the decorative back plate onto the shower arm,
and install the shower arm by threading it into its
prepared female fitting. Apply thread sealant or plumb-
er’s tape to the threads before tightening. Hand tighten
firmly.
4. Install the hand shower cradle by threading it into its
prepared female fitting. Apply thread sealant or
plumber’s tape to the threads before tightening. Hand
tighten firmly.
5. Attach the hand shower to the cradle using the
hand shower hose. Insert one of the provided rubber
O-rings into each end of the hose, and apply thread
sealant or plumber’s tape to the threads before
tightening. Hand tighten the connections firmly.
4Lattimore Shower Set Installation Instructions

7. Install the shower head using the provided swivel
joint. Apply thread sealant or plumber’s tape to the
threads before tightening. Once secure, tighten the
set screw located on the swivel joint using the provided
hex wrench.
LATTIMORE SHOWER SET INSTALLATION
8. Turn the main water supply back on, and test the
completed shower system. Ensure that there are no
leaks and that all functions are working properly.
5Lattimore Shower Set Installation Instructions
