1Ballantine Wall-Mount Faucet Installation Instructions
BALANTINE WALL-MOUNT FAUCET INSTALLATION
GETTING STARTED
TOOLS AND MATERIALS:
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing bathroom fixtures and
plumbing. Signature Hardware accepts no liability for
any damage to the floor, walls, plumbing, or personal
injury during installation.
For the following installation instructions for your new
Wall-Mount Faucet, it is assumed that any old fixtures
have been removed and the water supply lines have
been relocated to the proper installation location.
Unpack and inspect the item for damage. If any
damage is found, contact our
Customer Relations team at 1-866-855-2284.
Ensure that you have gathered all of the required
materials that are needed for the installation.
Plumber’s Tape
Shut off the main water supply where the new faucet
is being installed.
Drill Thread Sealant
Tape Measure Level Hex Wrench
Pipe Clamps
SKU(s): 911574, 911575

2Ballantine Wall-Mount Faucet Installation Instructions
BALANTINE WALL-MOUNT FAUCET INSTALLATION
INSTALLATION
1. Prepare for installation by installing wood blocking
between the two studs where the faucet will mount.
Important: Take into consideration the thickness of
your finished wall materials. If your valve is installed too
far behind your finished wall, you may be left with
insufficient clearance to attach the spout and handles.
3. Attach the main water lines to the valve. Apply
thread sealant or plumber’s tape to the threaded
connection to ensure a watertight seal.
2. Mount the rough-in valve into its prepared location.
Attach the valve body to the wood blocking using
glavanized pipe clamps. Use a level to ensure that the
valve is mounted straight.
IMPORTANT: COMPLETE THE CONSTRUCTION OF
YOUR WALL, INCLUDING ANY FINISHED WALL
MATERIALS SUCH AS TILE, BEFORE PROCEEDING
WITH THE REMAINDER OF THE INSTALLATION.
STOP
Wood Blocking
Finished Wall
Apply
thread
sealant or
plumber’s
tape

3Ballantine Wall-Mount Faucet Installation Instructions
BALANTINE WALL-MOUNT FAUCET INSTALLATION
5. Attach the handle escutcheons to the installed valve
body. Thread each escutcheon onto each stem until
hand-tight. Ensure that the rubber washers remain
seated in the escutcheons.
6. Attach the hot and cold handles to the valve stems,
as shown. Ensure that the hot handle is on the left, and
the cold is on the right.
7. When your installation is complete, turn on the main
water supply. Remove the aerator from the spout. Turn
the water on to allow any dust or loose sediment to
clear the system. Allow the water to flow through the
spout for approximately 60 seconds, and verify that hot
and cold water are running properly. Reattach the
aerator once testing is complete.
60 sec
4. Once your finished wall has been completed, slide the
decorative ring onto the base of the spout. Attach the
spout to the installed valve body. Once in place, tighten
the set screw underneath to secure.
Decorative
Ring
Hot
Handle
Cold
Handle

Ballantine Wall-Mount Faucet Installation Instructions 4
DRAIN INSTALLATION
1. Dissasemble the drain assembly and lay the parts
aside, in the same order they were removed. See the
illustration below as a reference if needed.
2. Apply plumber’s tape to the threading on the
tailpiece, then reattach the tail piece to the pop-up
drain flange.
3. Slide the flat rubber gasket up the tailpiece until it
meets the lip of the pop-up drain flange.
BALANTINE WALL-MOUNT FAUCET INSTALLATION
Pop-Up Drain Flange
Tailpiece
Flat Rubber Gasket
Tapered Rubber Gasket
Lock Nut
Plastic Friction Washer

Ballantine Wall-Mount Faucet Installation Instructions 5
4. Insert the drain flange and tailpiece through the top
of your sink’s drain hole.
6. Thread the lock nut onto the drain flange. Hand
tighten until secure, then finish tightening with a basin
wrench once the drain is properly aligned.
Important: Be careful not to overtighten, which could
crack a porcelain sink or stone countertop.
5. From under your counter, slide the tapered rubber
gasket followed by the plastic friction washer onto the
tailpiece until they meet your sink or countertop. Be
sure that the tapered side of the rubber washer is
facing up.
COUNTERTOP COUNTERTOP
COUNTERTOP COUNTERTOP
BALANTINE WALL-MOUNT FAUCET INSTALLATION
COUNTERTOP COUNTERTOP
