signia Dry&Clean Charger BTE P User manual

Dry&Clean Charger BTE P/SP
User Guide
Dry-Clean Charger [EN].indd 1 16-12-2020 13:32:04

2
Content
Before you 󰄋art 4
Components 6
Connecting the USB power cable 7
Charging 8
Correct position of the hearing in󰘵ruments 11
Cleaning and Drying 12
Cleaning 󰘵atus LED 13
Charging 󰘵atus LEDs 14
Charging tips 19
Further information 27
Maintenance and care 27
Troubleshooting 28
Dry-Clean Charger [EN].indd 2 16-12-2020 13:32:04

3
Important safety information 31
General warnings 31
Personal safety 33
Product safety 40
Important information 42
Explanation of symbols 42
Operating, transport, and 󰘵orage conditions 44
Technical data of the power supply adapter 46
Disposal information 46
Conformance information 47
Country-speci󰘰c information 49
Dry-Clean Charger [EN].indd 3 16-12-2020 13:32:04

4
Before you 󰄋art
This device is intended to charge our speci󰘰c hearing
in󰘵ruments with built-in power cells (lithium-ion
rechargeable batteries). Your Hearing Care Professional will
advise you on the compatible models.
The charger is only intended for indoor use. Observe
and follow the operating conditions in section
"Operating, transport, and 󰘵orage conditions".
The charger is not intended as a means of 󰘵orage for
transportation of hearing in󰘵ruments.
Dry-Clean Charger [EN].indd 4 16-12-2020 13:32:04

5
CAUTION
Read this user guide thoroughly and completely and
follow the safety information in this document to avoid
damage or injury.
Dry-Clean Charger [EN].indd 5 16-12-2020 13:32:04

6
Components
➏
➊
➊
➋
➌
➎
➍
➊Status LEDs, charging
➋Status LED, UV cleaning
➌Charging slots
➍USB port for power supply
➎USB power cable
➏Power adapter
Dry-Clean Charger [EN].indd 6 16-12-2020 13:32:05

7
Components
➏
➊➊
➋
➌
➎
➍
➊Status LEDs, charging
➋Status LED, UV cleaning
➌Charging slots
➍USB port for power supply
➎USB power cable
➏Power adapter
Connecting the USB power cable
XConnect your USB power cable to the provided power
adapter.
Dry-Clean Charger [EN].indd 7 16-12-2020 13:32:06

8
Charging
NOTICE
Please make sure that the power plug is easily
accessible to remove it from power supply if
necessary.
XConnect the charger to the power supply.
All LEDs for each charging slot turn on successively
indicating that the charger has power and is ready for
use.
Dry-Clean Charger [EN].indd 8 16-12-2020 13:32:06

9
X
Put the hearing
in󰘵ruments in the
charging slots as shown
in the picture. You can
charge both hearing
in󰘵ruments at the same
time.
The hearing in󰘵ruments
are automatically turned
o󰘯 and 󰘵art charging.
The charging 󰘵atus
is indicated, see table
"Charging 󰘵atus" on the
next pages.
Dry-Clean Charger [EN].indd 9 16-12-2020 13:32:09

10
X
When you want to use your hearing in󰘵ruments, take
them out of the charger. They will automatically turn on.
XYou can leave the charger plugged in or remove it from
the power supply.
Dry-Clean Charger [EN].indd 10 16-12-2020 13:32:09

11
Correct position of the hearing in󰄋ruments
XThe left and right hearing
in󰘵ruments can be inserted
into either charging slot. The
slots are not side speci󰘰c.
XMake sure the bottom parts
of the hearing in󰘵ruments are
placed well into the charging
slots. The ear piece of the
hearing in󰘵rument should
always be placed in the
compartment.
Correct placement will be
indicated by the LED.
Dry-Clean Charger [EN].indd 11 16-12-2020 13:32:11

12
Cleaning and Drying
Drying and cleaning focuses on tubes, ear tips and
molds.
● Put the hearing in󰘵ruments into the charging slots and
close the lid.
UVC cleaning 󰘵arts automatically after closing the lid and
la󰘵s 15 min
● Ongoing UVC cleaning process is indicated by LEDs (see
table “Charging and cleaning 󰘵atus”)
● Drying 󰘵arts automatically after closing the lid and la󰘵s
4 hours.
Dry-Clean Charger [EN].indd 12 16-12-2020 13:32:11

13
Cleaning 󰄋atus LED
LED Description
UVC cleaning 󰘵atus LED is slowly blinking
white:
Cleaning for 15 minutes and only with closed
lid.
Dry-Clean Charger [EN].indd 13 16-12-2020 13:32:12

14
Charging 󰄋atus LEDs
Left
LED
Right
LED
Description
No LED light:
The charger is not connected to a
power supply.
No hearing in󰘵rument is inserted or
the hearing in󰘵rument is inserted
incorrectly.
Dry-Clean Charger [EN].indd 14 16-12-2020 13:32:14

15
Left
LED
Right
LED
Description
321
123
LEDs rapidly blinking green in
sequence (1, 2, 3):
The charger is connected to a power
supply and ready to charge.
3x
3x
1 LED rapidly blinking green 3 times:
Charging of the correctly placed
hearing in󰘵rument is initiated.
Dry-Clean Charger [EN].indd 15 16-12-2020 13:32:20

16
Left
LED
Right
LED
Description
1 LED slowly blinking green:
Charging is in progress; battery SOC
(State of Charge)* is < 33 %.
1 LED solid green, 2nd LED slowly
blinking:
Charging is in progress; battery SOC
is 34-66 %.
* Level of battery charge relative to its capacity.
Dry-Clean Charger [EN].indd 16 16-12-2020 13:32:25

17
Left
LED
Right
LED
Description
2 LEDs solid green, 3rd LED slowly
blinking:
Charging is in progress; battery SOC
is 67-99 %.
3 LEDs solid green:
The hearing in󰘵rument is fully
charged.
321
123
LEDs blinking rapidly orange in
sequence (1, 2, 3):
The charger is cooling down.
Dry-Clean Charger [EN].indd 17 16-12-2020 13:32:33

18
Left
LED
Right
LED
Description
3x
3x
All LEDs blinking red 3 times in every
2 sec:
Hearing in󰘵rument error.
212
212
LEDs blinking red in a sequence (1,
2):
Charger error.
Read more in section
"Troubleshooting".
Dry-Clean Charger [EN].indd 18 16-12-2020 13:32:37

19
Charging tips
You may have some que󰘵ions on how to be󰘵 charge your
hearing in󰘵ruments. Read the que󰘵ions and answers
below. If you have more que󰘵ions, your Hearing Care
Professional will help you.
"
How often do I need to charge the hearing
in󰄋ruments?
We recommend charging the hearing in󰘵ruments
daily, even if the power cell is not empty. Charge
them overnight so you can be sure to 󰘵art your day
with fully-charged hearing in󰘵ruments.
Dry-Clean Charger [EN].indd 19 16-12-2020 13:32:38

20
"How long does charging take?
A full charging cycle takes approximately
3 to 4 hours.
After 30 minutes, it is possible to use your hearing
in󰘵ruments for up to 7 hours.
Charging times may vary due to the use of the
hearing in󰘵ruments and the age of the power cell.
"
Can I leave the hearing in󰄋ruments in the
charger?
Even when fully charged, you can leave the hearing
in󰘵ruments in the charger. They automatically 󰘵op
charging when they are fully charged.
