Silvan Selecta Utepak 100L User manual

Instruction Manual
MANUP-1 REV G 2/02/17
VICTORIA (HEAD OFFICE)
244- 264 Greens Rd,
Dandenong South, 3175 Australia
Telephone: [phone]
Facsimile: [phone]
www.silvan.com.au
NEW ZEALAND
22 Sunshine Avenue
Te Rapa, Hamilton, 2001 New Zealand
Telephone: [phone]
Fax: [phone]
www.silvannz.co.nz
SILVAN AUSTRALIA PTY. LTD.
ABN 48 099 851 144
Utepak 100L
Trukpak 200L
Squatpak 300L
Squatpak 400L

SilvanWarranty
OurgoodscomewithguaranteesthatcannotbeexcludedundertheAustralianConsumerLaw.Youare
entitledtoareplacementorrefundforamajorfailureandforcompensationforanyotherreasonably
foreseeablelossordamage.Youarealsoentitledtohavethegoodsrepairedorreplacedifthegoodsfailtobe
ofacceptablequalityandthefailuredoesnotamounttoamajorfailure.
Wewarrantourgoodstobefreefromdefectsinmaterialsandworkmanshipforthewarrantyperiodof12
monthsfromthedatetheproductisdeliveredtotheconsumer.
SilvanwarrantsitsauthorisedDealer,whointurnwarrantstheoriginalpurchaser(consumer)ofeachnewSilvan
productthatitwillrepairorreplacetheproduct,or,paythecostofrepairorreplacement,asdeterminedby
Silvanwithoutchargeforlabouroranydefectiveormalfunctioningpartsinaccordancewiththewarranty
limitationsbelow.
ThisWarrantyisinadditiontoanyotherrightsandremediesavailabletoconsumersunderthelaw
ThisWarrantyCovers
Onlyconditionsresultingdirectlyfromdefectsinworkmanshipormaterialundernormaluseandservice.
WarrantyExclusions
TheWarrantydoesnotcover:

•Conditionsresultingfrommisuse,useofincompatiblechemicals,exceedingmachinespecifications
includingoverloading,impactdamage,negligence,accidentaldamageorfailuretoperformrecommended
maintenanceservicesasspecifiedintheOwner/OperatorManualapplicabletotheproduct.
•Damagecausedbycontinueduseofaproductafterinitialfailure
•AnyproductwhichhasbeenrepairedbyotherthananauthorisedSilvanserviceoutletinawaywhich,in
thesoleandabsolutejudgmentofSilvan,adverselyaffectitsperformanceorreliability.
•Thereplacementofmaintenanceitemssuchasdiaphragms,batteries,Vbeltsandgroundengaging
components,etc.

HowtoclaimWarranty

Returnthegoodstotheplaceofpurchaseatyourcostandwithinthewarrantyperiodalongwithevidenceofthe
purchasedate.IftheoriginalsuppliercannotbecontactedthencontactSilvanasbelowandwecandirectyouon
howtoproceedwithyourwarrantyclaim.

Howyourclaimwillbemanaged

TherepairofadefectiveproductqualifyingunderthiswarrantywillbeperformedbyanyauthorisedSilvanservice
outletwithinareasonabletimefollowingthedeliveryoftheproduct,atthecostoftheowner,totheservice
outlet’splaceofbusiness.Theproductwillberepairedorreplaceddependingontheextentoftheproblematthe
discretionofSilvanandtheSilvandealer.

Warrant
y

Before attempting to operate or install the sprayer carefully read and take note of the following
safety warnings.
Failure to comply with these warnings may result in serious injury or death.
You need to read carefully and take note of the following warnings before attempting to operate or install this sprayer. Failure to
comply with these warnings may result in serious injury or death.
Warning ! This sprayer is designed and manufactured solely for the purpose of applying agricultural chemicals to plants. Under
no circumstances may it be used for any other purposes.
Warning ! Prior to sprayer usage all users and operators must have read and fully understand the contents of this manual
Warning ! Do not exceed the the vehicle manufacturer’s specified safe load and carrying capacity.
Warning ! Exercise extreme care when operating in hilly or uneven terrain to ensure proper stability. Refer also to the vehicle
manufacturer’s operating and safety instructions
Warning ! Refer to the chemical manufacturer’s label for correct use and safe handling instructions of chemicals before use
Warning ! Never allow inadequately trained personnel to attach or operate the implement
Warning ! Before carrying out maintenance work, wash the sprayer thoroughly to remove all toxic chemicals that may
contaminate the sprayer.
Warning ! Do not point spray gun at any part of the human body.
Warning ! Do not pump flamable liquids or operate the pump in an explosive environment.
Warning ! Ensure the operators power supply and cabling is suitable to support the pumps maximum current draw and voltage
requirements. Inappropriate power supplies
Warning ! Do not over extend power cables and or use cables of insufficent current capacity as this can cause voltage
restrictions and excessive currents that can damage equipment.
The following “Safety” decal should be fitted to the machine at all times in the location shown in the diagram. If the decal is
missing or unreadable it should be replaced byordering a new decal from your Silvan dealer by the part number shown.
P/No DEC90
Safet
y
Instructions

GENERAL
The Silvan Utepak, Trukpak and Squatpak are portable sprayer’s.
Whether you are a commercial grower, or a home gardener you will find many uses for this unit. The tank pump and wand fittings
are corrosion resistant and are suitable for applying weedicides, herbicides, insecticides, fungicides, miticides, organic and green
formulations.
A variety of models are available configured with different tank capacities, pumps and sprayguns all suited for spot spraying but
may be used in conjunction with a boom for boom spraying. Some models also include additional features such as hose reels,
regulators or included boomless nozzles.
Your Product code indicates the configuration detailing the tank style, tank capacity, pump type and if a hose reel is fitted,
for example. SQ400-S8-1
Other product features may vary that are not covered in the product code suck as the filtration, spraygun used and if a regulator is
fitted.
PUMP (The fitted pump is dependent which model spray unit was purchased and is indicated by the product code as described
above).
•361-8000 Shurflo pump, 12 volt DC electric, max current 7.3 amps, 6.8 litres/minute open flow, Max 60psi on demand electric
pressure switch, On/Off switch.
•361-2088 Shurflo, 12 volt DC electric, max current 8 amps, 11.3 litres/minute open flow, Max 45psi on demand electric
pressure switch, On/Off switch.
•DDP-552A Aquatec Smoothflo, 12 volt DC electric, max current 9 amps, 7 litres/minute open flow, Max 120psi on demand
electric pressure switch, On/Off switch. Special Feature includes adaptive pressure sensing technology to auto bypass flow to
prevent pressure spikes while maintaining higher pressures and flows
•DDP-550 Aquatech High Capacity, 12 volt DC electric, max current 18 amps, 20 litres/minute open flow, Max 60psi on
demand electric pressure switch, On/Off switch.
•DDP-554 Aquatec High Pressure Smoothflo, 12 volt DC electric, max current 16 amps, 5 litres/minute open flow, Max 200psi
on demand electric pressure switch, On/Off switch. Special Feature includes adaptive pressure sensing technology to auto
bypass flow to prevent pressure spikes while maintaining higher pressures and flows
•DDP-555 Aquatec Medium Capacity, 12 volt DC electric, 12 litres/minute open flow, Max 45psi on demand electric pressure
switch, On/Off switch.
HOSE
•6 metres of 10mm I.D delivery hose standard (applicable for models that do not include hose reels)
TANK
100, 200, 300 and 400 litre moulded translucent tank with calibrated litre graduations. Material is U.V. stabilized and impact
resistant polyethylene with screw on lid has anti-spill breather.
100L Utepak and 200L Trukpak feature inmoulded inserts in the tank base allowing the tank to be bolted down to a tray or skid
300L and 400L Squatpak tank feature a large internal baffle for reduction of fluid surge in transit to help improve handling, the
tank tops feature deep grooves for tie-downs and 2 accessory mounting points (only 1 available when hose reel is fitted)
FILTRATION
In line suction filter fitted to pump and basket strainer beneath the tank lid to eliminate coarse debris .
Squatpak style tank, 400L capacity fitted with
DDP-550
p
um
p
and 30m Eco Hosereel
S
p
ecifications
Tank Style
UP Utepak
TK Trukpak
SQ Squatpak
Tank Capacity
(Liters)
100
200
300
400
Pump Type
S1 361-8000
S3 361-2088
S7 DDP-552A
S8 DDP-550
S9 DDP-554
S10 DDP-555
Hose Reel
-1 30m Eco Reel (manual action)
-2 15m Spring Retractable reel

CONTROLS
On/Off power switch. The pump is fitted with an automatic electric pressure sensing switch which automatically starts the pump
when the pressure falls below a preset pressure, and stops the pump when the pressure reaches a maximum preset pressure. (Some
models are fitted with an adjustable pressure regulator).
DIMENSIONS
100 LITRE 200 LITRE 300 LITRE 400 LITRE
Length 660 mm 1050 mm 1010mm 1010mm
Width 590 mm 590 mm 940mm 940mm
Height 580 mm 535 mm 500mm 670mm
Weight (dry) 13 kg 18 kg 27kg 31kg
To calculate the weight of the sprayer add 1kg to the dry weight for every litre of water. E.g. The laden weight of the sprayer with
16L of water is 21kg
SETTING UP YOUR SPRAYER
Where using the PA Spray Gun Fit the extension lance to the handgun ensuring the nylon washer is fitted between them. Fit the
hose to the gun, using the hose clip supplied. Fit the white elbow fitting to the other end of the hose and secure it with the hose
clamp provided. Placing the hose in hot water may assist at this stage. Fit the hose to the outlet side of the pump.
CONNECTING TO 12 VOLT DC SUPPLY
The Sprayer requires a 12 volt DC power source. A 3 metre loom is provided with the sprayer to allow the sprayer to be
connected to the 12 volt DC source available. The red wire is positive and the black is negative. If you extend the wire use wire
of the same guage or larger.
An on/off switch is fitted to the sprayer to allow the sprayer to be switched off from the 12 volt DC source to prevent accidental
drain of power. The switch also allows the pump to be shut down when the tank is empty preventing overheating and damage to
the pump.
•Important Note! Ensure that distance from the power supply to pump is minimised.
•Important Note! If extending power cables ensure a cable of equal or preferably greater current capacity is used
as over extended wires may overheat, blow fuses or damage the pump
•Important Note! Consult your vehicle instruction manual for correct electrical connection.
FITTING INSTRUCTIONS
Position the sprayer so as to minimise contamination to the operator. With the pump away from operator the risk of
contamination due to hose failure can be minimised. It is recommended that the sprayer be securely attached to the vehicle
or trailer. Refer to manufacturer’s instructions for appropriate load limits and fitting positions.
Note : 1 litre of water = 1 kg.
Never fill spray tank to a capacity beyond the specified overall weight limits set by your vehicle manufacturer. Recesses in
the top of the tank allow for tie down straps. When fitted these should be firmly secured to approved attachment points on
the ATV or other vehicle.
The sprayer should be mounted centrally and as near to the vehicle centre of gravity, as possible. It should not protrude so
as to cause an obstruction.
Installation
S
p
ecifications
SPRAY GUN
A variety of spray guns are fitted and matched to the pump for optimal spraying
•The PA spray gun is fitted with 500mm extension and fan nozzle is a
professional choice and popular for spot spraying.
•The Triam 49 Spray Gun is ideal for atomised spraying and is only fitted
to spray units with pumps capable of more than 150psi
•The Spotjet spray Gun is for general duties spraying suited, with 600mm
extension and adjustable nozzle

FILLING THE TANK AND ADDING CHEMICAL
Warning : Before using the sprayer for the first time or adding chemical check the operation and function of the
sprayer with clean water
Check that the battery power supply is charged, the filters are clean and all fittings, hoses and gun connections are tight.
Partly fill the sprayer before adding chemical. Always use clean water to prevent blockages and ensure chemical function is
not inhibited.
Connect pump and ensure it primes correctly, holding the spray lance trigger on until it sprays steadily.
Check all pipes, hoses, hose clamps and connections for leaks or damage.
Be sure to wear safety equipment as recommended by the chemical manufacturer before adding chemical to the
sprayer.
Once satisfied that all hoses and connections are working and there is no leaks or damage.
Add the chemical according to the directions on the chemical container following all safety and protective equipment
recommendations.
Do not use wet powders or chemicals that must remain suspended in solution and require agitation. Only use chemicals or
dyes that fully dissolve.
Do not use a sprayer that has been used to spray herbicides for insecticides or nutrients unless the sprayer has been
thoroughly cleaned including neutralizing the herbicide according to the manufactured directions if required.
PUMP HOSE ANCHOR
We have supplied a Plastic Hose Tie to protect the pump housing or
hose fitting from possible damage caused when the hose is pulled
tight or over stretched.
The hose can be tied against the switch
bracket as shown in the diagram below,
do not over tighten or kink the hose as
this may restrict the flow.
Maintenance
Dispose of unused chemical and water used for rinsing in a manner that will not endanger
people animals or the environment.
After spraying rinse out the spray lines and tank with clean water. To avoid chemical contamination wear appropriate
protective equipment including gloves whenever maintenance is carried out; turn off the pump and depress the trigger on
the spray lance to dissipate any pressure. After spraying is completed, drain unused chemicals from the tank. Rinse the
tank with clean water then operate the sprayer with clean water in the tank to clean out the pump, hose and spray lance.
Do not leave chemicals in the tank as they may crystallize or form solids and block in pump, spray lines, nozzle or filters.
A cleaning agent may be required to clean away residues of spray dies or other solutions that leave deposits in the pump
and lines.
The foot filter should be checked and cleaned if necessary each time the tank is filled. Appropriate protective equipment
should be used whenever maintenance is carried out.
If heavy frosts are experienced, run the pump to make sure pump and spray lines are dry. This will prevent water freezing
in the pump or spray lines and damaging sprayer.
Installation

S
p
ecial Installation. Hose Reel kit fitment for
Fitting the Spray Gun
Different model sprayers feature different
spray guns and have different inlets
Method 1. Fit direct to hose.
The PA spray gun can
be directly fitted to the
¼” Fitting on the hose
reel
(Requires old existing
fitting to be removed).
1.
1. Fit the 2 x long brackets to the
tank with 4x M8x16mm Bolts,
Washer & Spring Washers
2. Fit the hose reel with the 4x M10
nuts Bolts, Washer & Spring Washers
3. Loop the Hosereel inlet hose under
as shown and cut to meet the pumps
inlet. Fit the elbow hosetail and hose
clamp then fit to the pump
30m Eco Reel
2.
3.
15m Reel (100L)
1. Fit the 1 x long and 1x angle bracket
to the tank with 3x M8x16mm Bolts,
Washer & Spring Washers
2. Fit the upright bracket as shown with
2x M8X25mm Bolts, Washer & nyloc
nuts
3. Fit Hose reel to the upright bracket
using 2x M8X25mm Bolts, Washer &
nyloc nuts.
4. Loop the inlet hose under the reel
and cut hose to suitable length to
meet the pumps inlet (allow length for
the hose to swivel). Fit elbow hosetail
and hose clamp then fit to pump
4.
1.
2.
3.
15m Reel (200L)
1. Fit the 2 x long brackets to the tank
with 4x M8x16mm Bolts, Washer &
Spring Washers
2. Fit the upright bracket as shown with
2x M8X25mm Bolts, Washer & nyloc
nuts
3. Fit Hose reel to the upright bracket
using 2x M8X25mm Bolts, Washer &
nyloc nuts.
4. Loop the inlet hose under the reel
and cut hose to suitable length to
meet the pumps inlet (allow length for
the hose to swivel). Fit elbow hosetail
and hose clamp then fit to pump
4.
1.
2.
3.
Method 2. Cut the hose.
The Triam and Spotjet spraygun both have
½” Connections which do not directly fit to
the hose reels ¼” fitting.
Remove any existing hose connections to
the spraygun. Cut the swaged fitting from the
hose reel then fit spraygun using the
included hosetail.

FOR SERVICE SUPPORT AUSTRALIA WIDE
PH 1300 745826
[email protected]
VICTORIA (HEAD OFFICE)
244- 264 Greens Rd,
Dandenong South, 3175 Australia
Telephone: [phone]
Facsimile: [phone]
www.silvan.com.au
NEW ZEALAND
22 Sunshine Avenue
Te Rapa, Hamilton, 2001 New Zealand
Telephone: [phone]
Fax: [phone]
www.silvannz.co.nz
SILVAN AUSTRALIA PTY. LTD.
ABN 48 099 851 144
