C.A. Technologies CAT-Xpress Troubleshooting guide

1
HVLP/Pressure reduced air cap and uid nozzle chart
Pressure
reduced
air cap
SCFM @ max
gun inlet
pressure
HVLP air cap
SCFM @ max
gun inlet
pressure for
HVLP
Fluid tip
range Orice size Fluid tip part number
Fluid needle part
number
2403218 9 CFM
@ 29 PSI 2403233 9 CFM @ 26 PSI
0.8 mm
to
1.8 mm
0.8 mm 2404488 2397054
1.0 mm 2404489 2397055
1.2 mm 2404491 2397056
1.3 mm 2412850 2412848
1.4 mm 2397074 2397057
1.5 mm 2404492 2397058
1.8 mm 2404493 2397059
2403224 9 CFM
@ 29 PSI 2403235 9 CFM @ 26 PSI
2.0 mm
2.2 mm
2.0 mm 2404494 2397060
2.2 mm 2404495 2397061
Actual uid nozzle and air cap combinations are determined by application (see application chart page 4)
*Gun inlet pressures may vary as required by application
*Smaller and larger nozzle sizes are available upon request
CAT-Xpress
PRESSURE FEED SPRAY GUN
PRODUCT INFORMATION
The CAT-Xpress spray gun oers both a pressure reduced
air cap (2403218 &2403224) and HVLP air cap (2403233 &
2403235) for areas requiring HVLP compliance.
2403218 & 2403224
- Consumes 9 cfm at 29 psi gun inlet
- Pressure reduced
- 2403218 - can be used with 0.8 mm - 1.8 mm orices
- 2403244 - can be used with 2.0 mm - 2.2 mm orices
2403233 & 2403235
- Consumes 9 cfm at 26 psi gun inlet
- For areas requiring HVLP compliance.
- 2403233 - can be used with 0.8 mm - 1.8 mm orices
- 2403235 - can be used with 2.0 mm - 2.2 mm orices

2
Operation and Maintenance Instructions for CAT-Xpress Spray Guns
Operation
1. Connect air supply hose at handle of gun.
2. Connect a pressurized uid supply to the gun uid inlet.
3. Fluid ow can be controlled using the uid control knob, this restricts ow by limiting needle travel. It is best to control
uid ow by proper selection of uid orice size and use the uid control knob to “ne tune ow rate”.
4. Fan width can be adjusted using the fan control knob. Turning the knob clockwise narrows the fan.
Maintenance
IMPORTANT! Routine cleaning and maintenance is essential to insure proper gun operation. Several states prohibit spraying
solvent into the atmosphere and require the use of covered gun cleaner.
1. If a gun cleaner is being used, connect and clean the gun in the gun cleaner according to the manufactures instructions.
2. If a gun cleaner is not being used:
Remove air cap and clean separately using clean solvent. For pressure setups, connect a pressurized solvent supply to the
uid inlet, trigger the gun allowing solvent to ow thru the gun until clean.
NOTE: Gun head disassembly is not recommended for normal cleaning and maintenance.
Gun head disassembly and reassembly instructions:
Have repair kit # 2411779 available before gun disassembly.
Gun head disassembly
To remove the nozzle carrier (8):
1. Remove the air cap (1 & 4), uid nozzle body (5), bae (6), uid nozzle (7), and needle (26).
2. Remove the needle seal cartridge (10).
3. Loosen the locknut (12) and remove uid inlet (13) using a 5/8”open-end wrench.
4. The nozzle carrier (8) and o-ring (9) will now slide forward from the gun body (40).
Gun head reassembly
1. Install a new o-ring (9) on the uid nozzle body carrier (8).
2. Install the thread locknut (12) onto the uid inlet (13) as far as possible.
3. Install a new uid inlet seal (11) into the recess area on the uid nozzle body carrier (8) inlet port.
4. Slide the uid nozzle body carrier (8) into the gun body (40) as far as possible. Be sure the uid nozzle body carrier (8)
extends into the hole at the back of the gun head. Install the needle seal (10) but do not tighten.
5. Rotate the uid nozzle body carrier (8) until the uid inlet port in the nozzle body carrier (8) is aligned with the threaded
hole in the gun body (40). While in this position, insert the uid inlet (13) and tighten rmly. Locknut (12) should already
be threaded onto the uid inlet (13).
6. Tighten the needle seal (10) to approx. 12 ft.-lb. torque.
7. Tighten the uid inlet (13) to approx. 25 ft.-lb. torque.
8. Tighten the locknut (12) to approx. 33 ft.-lb. torque.
9. Install bae (6) into gun body (40) with the holes facing inward towards the gun body. Make sure to line up to pins.
10. Install uid nozzle (7) into nozzle body (5), then thread and tighten into uid nozzle body carrier (8).
11. Install air cap (4) into the air cap ring (1). Sealing ring (2) and o-ring (3) should already be installed in the air cap ring (1).
then thread onto the gun body’s (40) head assembly.
Fan control disassembly
To remove the fan control (29):
1. Remove the rear uid adjustment knob assembly (36 - 39) along with the
uid needle (28).
2. Make sure the fan adjustment knob (32) is in the open position (turned
counter clockwise when pointed away from you).
3. Please note step 4 and back out the fan control sleeve (35) counter clockwise.
4. As you back out the fan control sleeve (35), the housing (31) will want to
move inward into the body. When this happens, alternate between turning
the adjustment knob (32) counter clockwise and backing out the contol
sleeve (35). Repeat until the fan control assembly fully backs out.

3
Item
no. K Part no. Description Item no. K Part no. Description
1 2400154 Air Cap Ring 22 * 98-5125 O-Ring
2 * V2070005300 Air Cap Sealing Ring 23 * 2396036 Air Valve Stem Cap
3 * V2070005200 O-Ring 24 60-1371 Air Valve Stem
4 ** See Air Cap Chart (Pg1) Air Cap 25 61-1032 Air Valve Poppet
5 2394821 Nozzle Body 26 * 61-1003 Air Valve Spring
6 2394820 Air Bae 27 60-1375 Rear Cap
7 ** See Nozzle Chart (Pg1) Fluid Nozzle 28 ** See Needle Chart (Pg1) Fluid Needle
82396024 Fluid Nozzle Body Carrier 29 2403453 Fan Control Assembly
9 * 98-8014 O-Ring 30 2396032 Fan Control Rod Seal
10 * 2400771 Needle Packing Assembly 31 2403413 Fan Adjustment Housing
11 * 2396026 Fluid Inlet Sealing Ring 32 2403416 Fan Adjustment Knob
12 60-128 Lock Nut 33 2403429 Fan Adjustment Knob Screw
13 2396785 Fluid Inlet 34 2316489 Fan Control Seal
14 60-1319 Air Control Knob 35 2403412 Fan Control Sleeve
15 60-104 Air Inlet 36 2396038 Fluid Adjustment Knob
16 2396021 Trigger 37 2396039 Fluid Adjustment Lock Nut
17 2396019 Trigger Pin 38 * 2396035 Needle Spring Guide
18 V1070111100 Spring washer 39 * 2396050 Needle Spring
19 V1030109000 Trigger Screw 40 2410599 Gun Body
20 2400772 Air Valve (Complete) 41 2412114 1/16” Allen Wrench for #33
21 * 98-8012 O-Ring
*Indicates part included in repair kit # 2411779
**See air cap selection chart on page 1

4
CAT-XPR Includes:
CAT-Xpress
Air Caps
Nozzle/Needle Sets
60-8002 Gun Wrench
98-0113 Gun Cleaning Brush
2412114 Allen Wrench (1/16”)
Fluid nozzle / Air cap selection charts
CAT-Xpress Series - Pressure Feed Guns
CAT-Xpress HVLP/Pressure reduced spray gun
Material type Fluid orice x Air cap Maximum pattern width CFM
Very Thin
0.8 mm x 2403218 or 2403233
1.0 mm x 2403218 or 2403233
2403218 13”
2403233 12”
2403218 9 CFM
2403233 9 CFM
less than 16 sec. Zahn #2
inks , dyes,
solvents, stains
Thin
1.2 mm x 2403218 or 2403233
1.3 mm x 2403218 or 2403233
2403218 13”
2403233 12”
2403218 9 CFM
2403233 9 CFM
16 to 20 sec. Zahn #2
lacquers, enamels,
primers, sealers
Medium
1.2 mm x 2403218 or 2403233
1.3 mm x 2403218 or 2403233
1.5 mm x 2403218 or 2403233
1.8 mm x 2403218 or 2403233
2403218 13”
2403233 12”
2403218 9 CFM
2403233 9 CFM
21 to 30 sec. Zahn #2
automotive base coat
enamels, primers
epoxies, urethanes
automotive clear coat
Heavy
1.8 mm x 2403224 or 2403235
2.0 mm x 2403224 or 2403235
2.2 mm x 2403224 or 2403235
2.5 mm x 2403224 or 2403235
2403224 13”
2403235 12”
2403224 9 CFM
2403235 9 CFM
over 30 sec. Zahn #2
heavy body primers
high solid enamels
high solid automotive coatings
adhesives
Revised 10/30/2019
C.A.Technologies - Division of the Wagner Group
Liquid Division
337 South Arthur Ave
Louisville, CO 80027
T 888.820.4498
F 303.438.5708
www.spraycat.com
Pos. Designation
A Suspension Hook
B Air Cap Ring
C Air Cap
D Fluid Inlet
E Trigger
F Needle Stroke Regulator
G Needle Stroke Regulator Lock
H Fan Air Control
I Air Inlet Connection
J Air Regulation Knob
CAT-XPR-303R2 Includes:
CAT-Xpress
Air Caps
Nozzle/Needle Sets
51-303-R2 1 QT Aluminum Cup
52-5R2 Regulator
60-8002 Gun Wrench
98-0113 Gun Cleaning Brush
2412114 Allen Wrench (1/16”)
CAT-XPR-PPSR2 Includes:
CAT-Xpress
Air Caps
Nozzle/Needle Sets
CA91-560 850 mL PPS™ Pressure Cup
CA91-562 Lids and Liners (Available in 25 Pack)
CA91-575 #18 PPS Adapter
52-5R2 Regulator
60-8002 Gun Wrench
98-0113 Gun Cleaning Brush
2412114 Allen Wrench (1/16”)
