Pro-tec PROGNOST XP User manual

PROTEC GmbH & Co. KG
In den Dorfwiesen 14, 71720 Oberstenfeld, Germany
Telephone: [phone] E-Mail: [email protected]
Version: 1.0
Issued: 2021-05-17
Subject to alterations
PROGNOST XP, XPE & XPE-Akku
Basic diagnos ic X-ray sys em able,
non-powered or powered
Model/ID: 7036-0-17xx
Basic UDI-DI: 426050264X00 ZT
Model/ID: 7037-x-17xx
Basic UDI-DI: 426050264X011ZE
Model/ID: 7038-9-17xx
Basic UDI-DI: 426050264X024ZP
Ins ruc ions for use
ID No. 5038-0-0002
*Figure PROGNOST XPE-Akku

NOTE
All sheets of this document contain proprietary and confidential information of
PROTEC GmbH & Co. KG and is intended for exclusive use by current PROTEC GmbH
& Co. KG customers. Copying, disclosure to others or other use is prohibited without
the express written consent of PROTEC´s law department. Knowledge of violations
of these regulations must be reported immediately to PROTEC GmbH & Co. KG.
© 2021 PROTEC GmbH & Co. KG, Oberstenfeld
Comments and questions about the documentation, please contact:
PROTEC GmbH & Co. KG
In den Dorfwiesen 14 | 71720 Oberstenfeld
Germany
Phone: (+ 4 ) 7062 – 2 55 0
Fax: (+ 4 ) 7062 – 2 55 60
E-Mail: [e-mail]
Internet: www.protec-med.com

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
3 of 51
Table of con en s
Page
Table of con en s ........................................................................................................................... 3
Revision S a us .............................................................................................................................. 6
General No es ................................................................................................................................ 7
Mechanical and Elec ric Warning ............................................................................................... 7
To he User ..................................................................................................................................... 7
1 Device Descrip ion .............................................................................................................. 8
1.1 Introduction ......................................................................................................................................................................................... 8
1.2 Description............................................................................................................................................................................................ 8
1.2.1 Versions ...................................................................................................................................................................................... 8
1.2.1.1 PROGNOST XP .................................................................................................................................................................. 8
1.2.1.2 PROGNOST XPE ............................................................................................................................................................... 8
1.2.1.3 PROGNOST XPE-Akku ..................................................................................................................................................
1.2.2 Hardware and Network System Requirements .................................................................................................
1.2.3 Installation ................................................................................................................................................................................
1.2.3.1 Floor Loading Capacity............................................................................................................................................ 10
1.3 Performance Characteristics ................................................................................................................................................... 10
1.3.1 X-ray System Table PROGNOST XP ......................................................................................................................... 10
1.3.2 X-ray System Table PROGNOST XPE & PROGNOST XPE-Akku ............................................................... 10
1.4 Intended Use .................................................................................................................................................................................... 10
1.5 Clinical Benefit ................................................................................................................................................................................. 11
1.6 Patient Target Group(s) .............................................................................................................................................................. 11
1.7 Medical Conditions to be diagnosed ................................................................................................................................ 11
1.8 Indications and Contraindications ...................................................................................................................................... 11
1. Intended User Group ................................................................................................................................................................... 11
1.10 Declaration of Conformity ........................................................................................................................................................ 11
2 Safe y Ins ruc ions ............................................................................................................ 12
2.1 General Safety Instructions ...................................................................................................................................................... 13
2.1.1 Requirements for operation ....................................................................................................................................... 13
2.1.2 Device Operation .............................................................................................................................................................. 13
2.1.2.1 Operating Type ............................................................................................................................................................ 13
2.1.3 Operating Personnel ....................................................................................................................................................... 13
2.1.4 Crushing and Collision Hazard .................................................................................................................................. 13
2.1.4.1 PROGNOST XP ............................................................................................................................................................... 13
2.1.4.2 PROGNOST XPE & XPE-Akku ................................................................................................................................. 14
2.1.5 Explosion Protection ....................................................................................................................................................... 14
2.1.6 Interaction with Other Devices ................................................................................................................................. 14
2.1.7 Electromagnetic Environment and Influencing of Devices .................................................................... 14
3 Con rol Elemen s and Displays ....................................................................................... 16
3.1 Main Switch of the PROGNOST XP-series ....................................................................................................................... 16
3.2 Emergency Stop Switches of the PROGNOST XP-series ........................................................................................ 16
3.2.1 Emergency Stop Switch PROGNOST XP ............................................................................................................. 16
3.2.2 Emergency Stop Switch PROGNOST XPE & PROGNOST XPE-Akku .................................................... 16
3.3 Control Elements and Displays of the PROGNOST XP-series .............................................................................. 16
3.3.1 Control Elements and Displays PROGNOST XP .............................................................................................. 16
3.3.1.1 Brake Rollers ................................................................................................................................................................... 17
3.3.1.2 Brake Bracket for the Table Top .......................................................................................................................... 17
3.3.1.3 Hand Grips (optional) ............................................................................................................................................... 17
3.3.1.4 Lateral Edge Protection (optional) ................................................................................................................... 17
3.3.1.5 Shock Protection Profile (optional) .................................................................................................................. 17
3.3.1.6 Center Stop (optional) ............................................................................................................................................. 17
3.3.2 Control Elements and Displays PROGNOST XPE & PROGNOST XPE-Akku ..................................... 18
3.3.2.1 Brake Rollers ................................................................................................................................................................... 18

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
4 of 51
3.3.2.2 Brake Bracket for the Table Top .......................................................................................................................... 18
3.3.2.3 Hand Grips (optional) ............................................................................................................................................... 18
3.3.2.4 Fixing Mechanism (optional) ............................................................................................................................... 1
3.3.2.5 Deflector (optional) .................................................................................................................................................... 1
3.3.2.6 Lateral Edge Protection (optional) ................................................................................................................... 1
3.3.2.7 Shock Protection Profile (optional) .................................................................................................................. 1
3.3.2.8 Protection Foil (optional)........................................................................................................................................ 1
3.3.2. Center Stop (optional) ............................................................................................................................................. 1
3.3.3 Emergency Stop Switch and Status Indication ............................................................................................... 20
3.3.3.1 Acoustic Status Indications ................................................................................................................................... 22
3.3.3.2 Acoustic and Visual Status Indications at Column Drive Blockage .............................................. 22
3.3.4 Hand Control ........................................................................................................................................................................ 23
4 Handling ............................................................................................................................. 24
4.1 Requirements before and during Operation ................................................................................................................ 24
4.2 Operation of the PROGNOST XP-Series............................................................................................................................ 24
4.2.1 Operating of the PROGNOST XP .............................................................................................................................. 24
4.2.1.1 Exposures with the PROGNOST XP .................................................................................................................. 24
4.2.2 Operating of the PROGNOST XPE & PROGNOST XPE-Akku ..................................................................... 25
4.2.2.1 Height adjustment of the table top ................................................................................................................ 25
4.2.2.2 Table heights - Zero balance performance ................................................................................................ 25
4.2.2.3 Saving and setting preferred table heights ................................................................................................ 25
4.2.2.4 Exposures with the PROGNOST XPE & PROGNOST XPE-Akku ......................................................... 25
4.2.3 Specifications for PROGNOST XPE-Akku Operation ..................................................................................... 26
4.2.3.1 Energy Saving Mode ................................................................................................................................................. 26
4.2.3.2 Battery Box ...................................................................................................................................................................... 26
4.2.3.3 Battery Charge Level ................................................................................................................................................. 28
4.2.3.4 Battery Box Charging Station ............................................................................................................................... 28
4.2.3.5 Charging the Battery Box ....................................................................................................................................... 2
4.2.3.6 Charging Cycle and Meaning of the Charging Control LED ............................................................ 30
4.3 Functions of the PROGNOST XP-Series ............................................................................................................................ 30
4.3.1 Switching the PROGNOST XP device on and off ........................................................................................... 30
5 Safe y and Main enance ................................................................................................... 31
5.1 Introduction ...................................................................................................................................................................................... 31
5.2 Reusability .......................................................................................................................................................................................... 31
5.3 Cleaning and Disinfection ........................................................................................................................................................ 31
5.3.1 Cleaning .................................................................................................................................................................................. 31
5.3.2 Disinfection ........................................................................................................................................................................... 31
5.4 Inspection and Maintenance .................................................................................................................................................. 32
5.4.1 Daily Monitoring before and during the Examination Operation....................................................... 32
5.4.2 Regular Monitoring .......................................................................................................................................................... 32
5.4.2.1 Quality control by the operator ......................................................................................................................... 32
5.4.2.2 Safety-related Controls ............................................................................................................................................ 32
5.4.3 Maintenance ........................................................................................................................................................................ 33
5.4.4 Warranty .................................................................................................................................................................................. 33
5.4.5 Product Service Life ......................................................................................................................................................... 33
5.4.6 Further Information ......................................................................................................................................................... 33
5.4.7 Applied Parts and Parts Considered as Applied Parts ................................................................................. 33
5.4.8 Disposal Notes .................................................................................................................................................................... 33
6 Power Supply ..................................................................................................................... 34
6.1 PROGNOST XPE ............................................................................................................................................................................... 34
6.2 PROGNOST XPE-Akku .................................................................................................................................................................. 34
6.3 Electromagnetic Compatibility (EMC) according to EN 60601-1-2 ................................................................ 35
6.3.1 Guidelines and Manufacturer’s Declaration – Electromagnetic interference .............................. 35
7 Technical Da a .................................................................................................................... 38
7.1 Dimensions ........................................................................................................................................................................................ 38
7.1.1 Dimensions PROGNOST XP ......................................................................................................................................... 38
7.1.2 Dimensions PROGNOST XPE ...................................................................................................................................... 38

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
5 of 51
7.1.3 Dimensions PROGNOST XPE-Akku ......................................................................................................................... 3
7.2 Attenuation Equivalent .............................................................................................................................................................. 40
7.2.1 Protection Type and Protection Class .................................................................................................................. 40
7.3 Environmental Conditions ....................................................................................................................................................... 40
7.3.1 Environmental Conditions during Operation .................................................................................................. 40
7.3.2 Environmental Conditions for Shipping and Storage ................................................................................ 40
8 Descrip ion of Symbols, Labels and Abbrevia ions ..................................................... 41
8.1 Symbols ............................................................................................................................................................................................... 41
8.2 Type Label .......................................................................................................................................................................................... 43
8.2.1 Type Label PROGNOST XP ........................................................................................................................................... 43
8.2.2 Type Label PROGNOST XPE ........................................................................................................................................ 43
8.2.3 Type Label PROGNOST XPE-Akku ........................................................................................................................... 43
8.3 Labels .................................................................................................................................................................................................... 44
8.3.1 Labels PROGNOST XP ..................................................................................................................................................... 44
8.3.2 Labels PROGNOST XPE ................................................................................................................................................... 45
8.3.3 Labels PROGNOST XPE-Akku ...................................................................................................................................... 46
8.4 Positions of the Signs and Labels......................................................................................................................................... 48
8.4.1 Positions of the Signs and Labels PROGNOST XP ......................................................................................... 48
8.4.2 Positions of the Signs and Labels PROGNOST XPE ....................................................................................... 4
8.4.3 Positions of the Signs and Labels PROGNOST XPE-Akku .......................................................................... 50
8.5 Abbreviations ................................................................................................................................................................................... 51

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
6 of 51
NOTE
The information contained in this document conforms to the configuration of the
equipment as of the date of manufacture. Revisions to the equipment subsequent
to the date of manufacture will be addressed in service updates distributed to the
PROTEC Technical Service Organisation.
Revision S a us
Revision Da e Upda ed pages Commen s Au hor
1.0 2021-05-17 all
Original issue XP-series
(MDR Layout) MB

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
7 of 51
General No es
WARNING!
In order o main ain he se and es ed requiremen s of he 60601 series of
s andards, he ME sys em mus no be modified during i s ac ual opera ing
life.
Mechanical and Elec ric Warning
WARNING!
All of he movable assemblies and par s of his equipmen should be opera ed
wi h care and rou inely inspec ed in accordance wi h he manufac urer's
recommenda ions con ained in he equipmen accompanying documen s.
Main enance and service is only o be performed by cus omers au horized by
PROTEC GmbH & Co. KG.
Live elec rical erminals are deadly.
Do no remove flexible high- ension cables from X-ray ube cover or high-
ension genera or and/or access covers from X-ray genera or.
For all componen s of he equipmen pro ec ive ear hing means mus be
provided in compliance wi h he na ional regula ions.
Failure o comply wi h he foregoing may resul in serious or fa al bodily
injuries o he opera or or hose in he area.
To he User
NOTE
The user of these accompanying documents is required to carefully read through
and carefully consider the instructions, warnings and cautions contained therein
before starting operation.
Even if you have already operated similar systems, changes in the design,
production and functional routine of the system described here may have been
made, which have a significant influence on the operation.
Assembly and service works on the system described here must be carried out by
authorised and qualified personnel from PROTEC GmbH & Co. KG. Assembly
personnel and other persons who are not employees of the technical service
department of PROTEC GmbH & Co. KG are requested to contact the local branch of
PROTEC GmbH & Co. KG before assembly or service work is started.
For assembly and service works, it is necessary to use the "Technical Description” of
the product and to observe the points it contains.
NOTE
The use of the product with add-on or accessory parts not authorized by PROTEC or
other unapproved components is not permitted.
NOTE
According to Regulation (EU) 2017/745 of medical devices, all serious incidents
related to the device must be reported to the manufacturer and the responsible
authority of the Member State where the user and/or the patient is established.

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
8 of 51
1 Device Descrip ion
1.1 In roduc ion
The instructions for use describe the performance characteristics and operation required for efficient
and effective use of the PROGNOST XP-series.
Before you work with a product of the PROGNOST XP-series, the complete instructions for use must be
read, especially the Safety Instructions and the chapter Handling.
1.2 Descrip ion
The PROGNOST XP-series consist of mobile X-ray system tables with floating table top.
The XPE and XPE-Akku variations also have motorized height adjustment of the table.
The table is designated for the installation of an X-ray cassette holder (Bucky or Grid entity), which can
be moved manually in the longitudinal direction, an anti-scatter grid and a 3-field measuring chamber
for operation with an automatic exposure control unit.
The floating table top is locked in horizontal and vertical direction with a mechanical brake and can be
released by a brake bracket.
The wheels of the table can be locked separately by arrester.
1.2.1 Versions
1.2.1.1 PROGNOST XP
Model/ID: 7036-0-17xx
Table frame colour RAL 003
Table op versions:
Model/ID Ma erial L W Table op color
7036-0-1710 composite fibre 200 cm 65,5 cm white
7036-0-1711 composite fibre 200 cm 75,5 cm white
7036-0-1712 composite fibre 226 cm 75,5 cm white
7036-0-1713 carbon fibre 200 cm 75,5 cm white
7036-0-1714 carbon fibre 226 cm 75,5 cm white
1.2.1.2 PROGNOST XPE
Model/ID: 7037-x-17xx
Table frame colour RAL 003
Table op versions:
Model/ID Ma erial L W Table op color
7037-1-1710 composite fibre 200 cm 65,5 cm white
7037-1-1711 composite fibre 200 cm 75,5 cm white
7037-1-1712 composite fibre 226 cm 75,5 cm white
7037-1-1713 carbon fibre 200 cm 75,5 cm white
7037-1-1714 carbon fibre 226 cm 75,5 cm white
*Model/IDs with in the middle (e.g., 7037- -1710) are operated with 115V

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
9 of 51
1.2.1.3 PROGNOST XPE-Akku
Model/ID: 7038- -17xx
Table frame colour RAL 003
Table op versions:
Model/ID Ma erial L W Table op color
7038
-
-
1710
composite fibre
200 cm
6
5,5 cm
white
7038
-
-
1711
composite fibre
200
cm
75,5 cm
white
7038
-
-
1712
composite fibre
226
cm
75,5 cm
white
7038
-
-
1713
carbon fibre
200
cm
75,5 cm
white
7038
-
-
1714
carbon fibre
226
cm
75
,5 cm
white
Op ional Componen s
•X-ray cassette holder (Bucky or Grid entity)
•3- field measuring chamber (ionization or solid state)
•Anti-scatter grid
Op ional Accessories
The PROGNOST XP-series can be equipped or customized with the following accessories:
•Mattress
•Handle long, which is mounted on the back of the table top and facilitates the positioning and
descending of the patient
•Handle short (2 pieces), which is mounted on the front of the table top to facilitate the
displacement of the table or the table top
•Side protection bar for Z-angle, to protect the detector
•Fixing mechanism
•Shock protection profile, for rear table top accessory rail
•Corner protection table top, set of 4
•Center stop, for accurate positioning
1.2.2 Hardware and Ne work Sys em Requiremen s
As a stand-alone product, the PROGNOST XP-series has no hardware or network connection and
therefore no hardware or network requirements.
1.2.3 Ins alla ion
NOTE
The installation of
a PROGNOST XP
-
series
product
must be performed by
PROTEC
service department or a service company authorized by them.
For more information, please see the Installation manual of the corresponding XP-series product.
Contact information of persons qualified to perform installations are available upon request at:
PROTEC GmbH & Co. KG
In den Dorfwiesen 14 | 71720 Oberstenfeld
Germany
Phone: (+ 4 ) 7062 – 2 55 0
Fax: (+ 4 ) 7062 – 2 55 60
E-Mail: [e-mail]
Internet: www.protec-med.com

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
10 of 51
1.2.3.1 Floor Loading Capaci y
NOTE
The products of the PROGNOST XP-series are primarily made of metal pieces. This
has a corresponding effect in the weight of the device.
The PROGNOST XP has a weight of 103kg.
The PROGNOST XPE has a weight of 114kg.
The PROGNOST XPE-Akku has a weight of 12 kg.
All weights with table top size 2260 x 755 mm.
Every technician is obliged to check the floor load. Raised floors and hollow floors
must also be considered.
1.3 Performance Charac eris ics
1.3.1 X-ray Sys em Table PROGNOST XP
•Floating tabletop
•Table top color white
•Mobile, smooth manoeuvrability
•A low optimized distance from the upper edge of the table top to the film (detector) surface
•Large adjustment range of the table top for positioning the patient
•High reliability
•Lateral profile rails of the table top prepared to attach several table accessories
•Suitable for digital Bucky
1.3.2 X-ray Sys em Table PROGNOST XPE & PROGNOST XPE-Akku
•Floating tabletop
•Table top color white
•Motorized height adjustment of the table top
•Mobile, smooth manoeuvrability
•Automatic stop at pre-programmed table top heights
•A low optimized distance from the upper edge of the table top to the film (detector) surface
•Large adjustment range of the table top for positioning the patient
•High reliability
•Lateral profile rails of the table top prepared to attach several table accessories
•Suitable for digital Bucky
•Battery-supplied accumulator operation via two exchangeable battery boxes (only PROGNOST
XPE-Akku)
•Separate battery box charging station (only PROGNOST XPE-Akku)
1.4 In ended Use
The mobile X-ray system table…
-PROGNOST XP as a component
-PROGNOST XPE as an electrically operated component
-PROGNOST XPE-Akku as a battery-powered component
… of a diagnostic X-ray system for patient positioning is intended for various routine applications in
planar X-ray imaging in human medicine.

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
11 of 51
1.5 Clinical Benefi
Considered in isolation, no clinical benefit can be shown for X-ray system tables.
As components of diagnostic X-ray systems in human medicine, they contribute to the clinical benefit
of X-ray systems, which consists of the generation of conventional two-dimensional X-ray images for
creation or specification of findings as a basis for treatment decisions.
1.6 Pa ien Targe Group(s)
The intended patient group includes all people for whom a justifying indication for a medical X-ray has
been given by a physician with the necessary expertise in radiation protection.
There are no general or fundamental restrictions on the patient group regarding age, gender, origin
and patient condition.
1.7 Medical Condi ions o be diagnosed
As standalone products, X-ray system tables, have no function to diagnose, treat and/or monitor
medical conditions.
1.8 Indica ions and Con raindica ions
As standalone products, X-ray system tables have no intended main effect in or on the human body.
Therefore, considered in isolation, no indications or contraindications can be shown for them.
1.9 In ended User Group
As a component of a diagnostic X-ray system, products of the PROGNOST XP-series are intended
exclusively for use by professional users who are trained in the operation of diagnostic X-ray systems in
accordance with the respective national regulations and who are familiar with the proper handling, use
and operation and also have been instructed in the permitted conjunction with other medical
products, objects and accessories.
Appropriate users can be, for example: X-ray technicians, X-ray assistants, medical technical X-ray
assistants, surgeons, casualty surgeons, orthopaedists and other trained medical personnel.
1.10 Declara ion of Conformi y
This product complies with the requirements of Regulation (EU) 2017/745 of the
European Parliament and of the Council of 5 April 2017 on medical devices,
including all applicable corrigenda.
The declaration of conformity is available upon request from PROTEC:
PROTEC GmbH & Co. KG
In den Dorfwiesen 14 | 71720 Oberstenfeld
Germany
Phone: (+ 4 ) 7062 – 2 55 0
Fax: (+ 4 ) 7062 – 2 55 60
E-Mail: [e-mail]
Internet: www.protec-med.com

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
12 of 51
2 Safe y Ins ruc ions
NOTE
Contains information that must be observed during operation.
xxx
CAUTION!
Contains information which, if not observed, can cause property
damage.
xxx
WARNING!
Contains information which, if not followed, can cause personal
injury.
xxx
WARNING!
Warning of radioactive substances or ionizing radiation. Contains
information which, if not observed, can cause personal injury.
xxx
Settings and calibrations that are not described in these instructions for use must be carried out using
the technical description of the device by PROTEC service department or a service company authorized
by them.
NOTE
All instructions supplied with the PROGNOST XP-series must be observed and the
safety instructions contained therein must be carefully read and adhered to.
NOTE
After the initial installation, the commissioning must be recorded with the PROTEC
acceptance protocol FB-04-07A4.
NOTE
The PROGNOST XP product may only be commissioned if all safety measures for
operator protection have been met and checked. These protective measures can
include door contact, designated area, dosimeter, protective clothing, etc.
CAUTION!
The ins ruc ions for use con ain all he informa ion relevan o safe y in order
o generally pu he PROGNOST XP produc in o opera ion. The device may
only be opera ed by appropria ely rained and rained personnel. In his
con ex , opera ion is ensured by clear symbols on he con rol elemen s. All
fur her informa ion and ins ruc ions can be found on he supplied da a carrier
(USB, CD or DVD). This informa ion applies in i s en ire y as an appendix o
hese ins ruc ions for use and mus be observed.
NOTE
All control elements are described again in detail in these operating instructions.

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
13 of 51
2.1 General Safe y Ins ruc ions
2.1.1 Requiremen s for opera ion
WARNING!
The PROGNOST XPE produc s are pro ec ion class I devices (according o EN
60601-1).
To avoid he risk of an elec ric shock, he PROGNOST XPE or PROGNOST XPE-
Akku may only be connec ed o a supply ne work wi h a pro ec ive ear hing
conduc or.
2.1.2 Device Opera ion
In case of a malfunction, do not use the appropriate PROGNOST XP product anymore and notify
PROTEC service department or a service company authorized by them.
2.1.2.1 Opera ing Type
The PROGNOST XPE and PROGNOST XPE-Akku is not intended for continuous operation.
Duty Cycle: S3 15% - maximum continuous operation of 1,5 minutes.
2.1.3 Opera ing Personnel
NOTE
Only trained and authorized personnel are allowed to work on the PROGNOST XP
device.
NOTE
The operating personnel must be familiar with all warning signs attached to the
particular PROGNOST XP product. They are used for your own safety and that of
others and ensure proper operation.
2.1.4 Crushing and Collision Hazard
WARNING!
I mus be ensured ha when opera ing he moving par s of PROGNOST XP-
series, no persons or objec s are in he obvious danger area of he device. If
no observed, i can resul in personal injury or damage o he produc of he
PROGNOST XP-series or o her objec s.
2.1.4.1 PROGNOST XP
Pinching of fingers and hands is possible at the points marked with arrows in the picture below. Please
ensure that neither the patient nor the personnel are in the movement area in an uncontrolled manner
when moving the table or table top.

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
14 of 51
2.1.4.2 PROGNOST XPE & XPE-Akku
Pinching of fingers and hands is possible at the points marked with arrows in the picture below. Please
ensure that neither the patient nor the personnel are in the movement area in an uncontrolled manner
when moving the table or table top.
2.1.5 Explosion Pro ec ion
The PROGNOST XP-series is not designated for use within areas with explosive hazards.
2.1.6 In erac ion wi h O her Devices
Interactions with other devices are not known.
2.1.7 Elec romagne ic Environmen and Influencing of Devices
CAUTION!
The use of o her accessories, o her conver ers and o her cables han hose
specified by PROTEC or provided in he documen a ion of he componen
manufac urer can resul in increased elec romagne ic in erference or reduced
elec romagne ic immuni y of he device and lead o defec ive opera ion.

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
15 of 51
CAUTION!
The use of a device of he PROGNOST XP-series immedia ely nex o o her
devices or wi h o her devices in a s acked form should be avoided, as his
could resul in defec ive opera ion. If use in he manner described above is
never heless necessary, he PROGNOST XP produc and he o her devices
should be observed o ensure ha hey are working properly.
NOTE
The properties of this device, determined by emissions, allow its use in industrial
areas and in hospitals (CISPR 11, class A). When used in residential areas (for which
class B is usually required by CISPR 11), this device may not provide adequate
protection for radio services. The user may need to take remedial measures such as
relocating or realigning the device.
The PROGNOST XP-series is intended for use in an environment in professional health care facilities
(e.g., clinics, surgery centres, physiology practices ...).

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
16 of 51
3 Con rol Elemen s and Displays
3.1 Main Swi ch of he PROGNOST XP-series
All products of the PROGNOST XP-series do not have a main switch.
3.2 Emergency S op Swi ches of he PROGNOST XP-series
3.2.1 Emergency S op Swi ch PROGNOST XP
The PROGNOST XP does not have an emergency stop switch.
3.2.2 Emergency S op Swi ch PROGNOST XPE & PROGNOST XPE-Akku
The PROGNOST XPE and PROGNOST XPE-Akku has the following emergency stop switch, which can be
used to bring the device to an immediate standstill and disconnect it from the power supply.
The switch is located on the right side of the table below the table top.
3.3 Con rol Elemen s and Displays of he PROGNOST XP-series
3.3.1 Con rol Elemen s and Displays PROGNOST XP
8
6
8
7
10
7
5
3
2
1
4

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
17 of 51
1. Arrester for wheels
2. Brake bracket for table top
3. Table top
4. Type Label, UL label, FDA label, Symbols for the brake
5. Rear side long handle (Optional)
6. Front side hand grips (Optional)
7. Lateral edge protection
8. Deflector for easier positioning of the table above detector
. Shock protection profile for rear tabletop accessory rail
10. Protection film for internal covers
3.3.1.1 Brake Rollers
In order to fix the table on the floor in all directions, it has 2 brake rollers on the front side, which must
be locked with the arrester on the left and right side before a patient gets on or off the table.
3.3.1.2 Brake Bracke for he Table op
By operating the brake bracket with the foot, the brakes of the tabletop are released, then the table top
can be moved floating by hand.
3.3.1.3 Hand Grips (op ional)
A long handle for the back of the table top and 2 handles for the front of the table top are available as
options. Both handles can only be removed with tools. The long handle is intended for easier
ascending and descending of the patient. The table as well as the table top can be better shifted with
the short handles.
3.3.1.4 La eral Edge Pro ec ion (op ional)
The lateral edge protection prevents direct contact of the detector housing with the Z-angle bracket.
3.3.1.5 Shock Pro ec ion Profile (op ional)
The shock profile prevents a direct contact of the rear accessory rail of the table top with the tube
column stand or the detector holder.
3.3.1.6 Cen er S op (op ional)
The center stop for the transverse movement of the table top improves the alignment of the table to
the X-ray tube assembly.

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
18 of 51
1
2
3.3.2 Con rol Elemen s and Displays PROGNOST XPE & PROGNOST XPE-Akku
1. Arrester for wheels
2. Brake bracket for table top
3. Table top
4. Emergency stop switch
5. Hand control and holder
6. Type Label, UL label, FDA label, Symbols for the brake
7. Rear side long handle (Optional)
8. Front side hand grips (Optional)
. Indicator lamp
10. Deflector
11. Protection foil
12. Lateral edge protection
13. Shock protection profile for rear table top accessory rail
14. Locking device
3.3.2.1 Brake Rollers
In order to fix the table on the floor in all directions, it has 2 brake rollers on the front side, which must
be locked with the arrester on the left and right side before a patient gets on or off the table.
3.3.2.2 Brake Bracke for he Table Top
By operating the brake bracket with the foot, the brakes of the table top are released, then the table top
can be moved floating by hand.
Movement of the table top (from the middle position):
Transverse direction: ± 100 mm
Longitudinal direction: ± 330 mm (2 m table top)
± 460 mm (2,26 m table top
3.3.2.3 Hand Grips (op ional)
A long handle for the back of the table top and 2 handles for the front of the table top are available as
options. Both handles can only be removed with tools. The long handle is intended for easier
ascending and descending of the patient. The table as well as the table top can be better shifted with
the short handles.
10
11
7
3
13
8
12
6
5
4
14

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
19 of 51
3.3.2.4 Fixing Mechanism (op ional)
The PROGNOST XPE product can be equipped with a locking device (detent) mounted on the right or
left side.
In addition to precise positioning of the PROGNOST XPE or PROGNOST XPE-Akku in the X-ray
examination room, the locking device enables rotation around the corresponding column axis.
The corresponding device is positioned over the floor-fixed detent disc (2) that the springy plunger (3)
engages in the opening of the detent disc by actuating the arrester (1).
The detent is released again by actuating the arrester accordingly.
3.3.2.5 Deflec or (op ional)
The deflectors prevent the U-rail from touching the detector housing and thus facilitate the positioning
of the table top above the image receiver.
3.3.2.6 La eral Edge Pro ec ion (op ional)
The lateral edge protection prevents direct contact of the detector housing with the Z-angle bracket.
3.3.2.7 Shock Pro ec ion Profile (op ional)
The shock profile prevents a direct contact of the rear accessory rail of the table top with the tube
column stand or the detector holder.
3.3.2.8 Pro ec ion Foil (op ional)
The protective foil on the inner cover plates increases the sliding properties when in contact with the
detector housing.
3.3.2.9 Cen er S op (op ional)
The center stop for the transverse movement of the table top improves the alignment of the table to
the X-ray tube assembly.
2
3
2
3
1
1

V1.0_2021-05-17 PROGNOST XP, XPE, XPE-Akku Instructions for use 5038-0-0002
20 of 51
3.3.3 Emergency S op Swi ch and S a us Indica ion
The control unit and the drive for the height adjustment are switched off by actuating the emergency
stop switch.
The emergency stop switch is unlocked by turning it to the right.
Next to the emergency stop there is the three-color signal lamp, which is used to indicate readiness
and status messages.
WARNING!
Even if he emergency s op swi ch has been ac ua ed and he signal lamp is
no illumina ed, he mains vol age may s ill be presen a he device plug. The
able is only safely disconnec ed from he power supply when he power plug
is pulled ou of he supply socke .
The following is an overview of the signal lamps status indication:
Indica or ligh color S a us Produc concerned
slight green
Energy saving mode
oOperational readiness is activated by
pressing the release key
PROGNOST XPE-Akku
green Device is ready for operation PROGNOST XPE &
PROGNOST XPE-Akku
orange Battery almost empty
o
Normal driving function still possible PROGNOST XPE-Akku
red
Battery empty
oOnly showing driving function
possible
oNo restart in energy saving mode
possible
o
Battery must be replaced
PROGNOST XPE-Akku
Error message PROGNOST XPE &
PROGNOST XPE-Akku
Status indications for all XP-series models are given by cyclic flashing of the indicator light in the color
red.
S a e Flashing-Rhy hm red Descrip ion Measure
1 1x
Over temperature of power
amplifier.
Caused by to frequent up and
down moving or too heavy
patient load
Cool down the device in
standby until red blinking
cycle is finished and
indicator lamp is bright
green again.
Reduce the patient load
2 2x
Drive blocked
Check if there is something
between the table top and
the floor, move the table up
and remove the object.
Notify PROTEC authorized
service.
