Silvercrest 60113 User manual

FUNKTÜRKLINGEL
Bedienungs- und Sicherheitshinweise
BEŽIČNO ZVONO
Upute za posluživanje i za Vašu sigurnost
SONERIE FĂRĂ FIR
Instrucţiuni de utilizare şi de siguranţă
БЕЗЖИЧЕН ЗВЪНЕЦ
Инструкции за обслужване и безопасност
ΑΣΎΡΜΑΤΟ ΚΟΥΔΟΎΝΙ ΠΌΡΤΑΣ
Υποδείξεις χειρισμού και ασφαλείας
IAN 60113
WIRELESS DOORBELL
Operation and Safety Notes
WIRELESS DOORBELL
60113_silv_Tuerklingel_Cover_HR_RO_BG_GR_CY.indd 2 16.05.14 13:18

GB/CY Operation and Safety Notes Page 7
HR Upute za posluživanje i za Vašu sigurnost Stranica 20
RO Instrucţiuni de utilizare şi de siguranţă Pagina 33
BG Инструкции за обслужване и безопасност Страница 47
GR/CY Υποδείξεις χειρισμού και ασφαλείας Σελίδα 61
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 75
60113_silv_Tuerklingel_Cover_HR_RO_BG_GR_CY.indd 3 16.05.14 13:18

3
You need
Potrebno Vam je
Aveţi nevoie de
următoarele
Необходими са Ви
Χρειάζεστε
Sie benötigen:
ø 6mm
A
1
2
3
4
5
6
7
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 3 16.05.14 13:21

4
B
8
9
10
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 4 16.05.14 13:21

5
D
C
12
11
13
14
15
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 5 16.05.14 13:21

6
F
18
17
16
E
17
16
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 6 16.05.14 13:21

GB/CY 7
Introduction
Intended use........................................................................................... Page 8
Technical data........................................................................................ Page 8
Included items ........................................................................................ Page 9
Parts and features.................................................................................. Page 9
Safety.................................................................................................... Page 10
General safety information................................................................... Pag e 11
Safety instructions for batteries ............................................................ Page 12
Assembly............................................................................................ Page 13
Preparing for use
Inserting/replacing the batteries......................................................... Page 13
Operation
Synchronising transmitter / receiver ..................................................... Page 15
Setting the signal type........................................................................... Page 15
Setting the volume ................................................................................. Page 16
Selecting the chime................................................................................ Page 16
Troubleshooting...................................................................................... Page 16
Cleaning and maintenance............................................... Page 17
Disposal............................................................................................... Page 17
Information
Declaration of conformity..................................................................... Page 18
Warranty............................................................................................ Page 19
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 7 16.05.14 13:21

GB/CY8
Wireless Doorbell
Introduction
Keep these instructions in a safe place. If you pass the product
on to anyone else, please ensure that you also pass on all
the documentation.
Intended use
This product is intended for the wireless transmission of the doorbell
chime. The product is not intended for commercial use.
Technical data
Range: 100m (unobstructed area)
Transmission frequency: 433MHz
Battery types: Receiver: 2 x 1.5V (type AA/LR6),
Transmitter: 1x 3V (type CR2032)
Receiver: Audible signal volume (at maximum volume
setting): min. 73dB (at a distance of 1m
from the device)
Transmitter: IP rating: IPX4
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 8 16.05.14 13:21

GB/CY 9
Included items
1 Transmitter
1 Receiver
1 Stand (for the receiver)
2 Batteries 1.5V , type AA (receiver)
1 Batteries 3V , type CR2032 (transmitter)
3 Screws (for transmitter and for mounting the receiver on a wall)
3 Dowels
5 Exchangeable name plates (for the doorbell)
1 Doorbell cover
1 Operating instructions
Parts and features
Receiver (Figs. A/B):
1Signal indicator
2Synchronisation button
3Volume button
4Melody selection button
5Signal type selector button (optical, acoustic, optical and acoustic
signal)
6Speaker
7Stand
8Hanger
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 9 16.05.14 13:21

GB/CY10
9Battery compartment cover
10 Battery compartment
Transmitter (Figs. C/D):
11 Signal indicator
12 Name plate
13 Chime button
14 Battery compartment
15 Holder (for wall mounting)
Mounting (Figs. E/F):
16 Screw
17 Dowel
18 Screw (for transmitter)
Safety
Read all safety information and instructions. Failure
to comply with the safety information and instructions may cause fire
and/or serious injury.
YOU SHOULD STORE ALL SAFETY INFORMATION AND INSTRUC-
TIONS IN A SAFE PLACE IN CASE YOU NEED TO REFER TO THEM
AGAIN IN THE FUTURE!
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 10 16.05.14 13:21

GB/CY 11
General safety information
DANGEROUS TO LIFE AND RISK
OF ACCIDENTS FOR TODDLERS AND CHILDREN!
Never leave children alone and unsupervised with the
packaging material. There is a risk of suffocation from the packaging
material. Children often underestimate risks. Always keep children
away from the product. This is not a toy.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given super-
vision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
Check that all parts are in sound condition. If you use damaged
parts when assembling the device, you risk injury.
Check that all parts have been assembled correctly. There is a risk
of injury if the device is not properly assembled.
Keep the device away from open flames or sources of heat (e.g.
burning candles).
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 11 16.05.14 13:21

GB/CY12
Safety instructions for batteries
DANGER TO LIFE! Batteries can be swallowed,
which can prove fatal. Consult a doctor immediately if anyone
swallows a battery.
EXPLOSION HAZARD! Never recharge nonrecharge-
able batteries, short-circuit and/or open batteries. This can
cause them to overheat, burn or burst.
Never throw batteries into fire or water. The batteries may explode.
Immediately remove depleted batteries from the device; otherwise
there will be an increased risk of leakage!
Always replace all the batteries at the same time and insert batteries
of the same type.
Do not use different types of batteries or mix used and new batter-
ies together.
Batteries do not belong in household refuse. Dispose of used batteries
in an environmentally friendly manner.
Consumers are under a legal obligation to dispose of batteries in
the proper way.
Keep the battery out of the reach of children, do not dispose of the
battery in fire, do not short-circuit it, and do not take it apart.
Failure to observe these instructions may result in the battery discharging
beyond its end voltage, which poses a risk of leakage. If the battery
in your instrument has leaked, have it removed immediately to prevent
damage to the instrument.
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 12 16.05.14 13:21

GB/CY 13
Avoid contact with skin, eyes and mucous membrane. In the event of
contact with battery acid, rinse the affected area with plenty of water
and/or consult a doctor.
Never use rechargeable batteries.
The supply terminals are not to be short-circuited.
Do not mix old batteries with new ones.
Remove the batteries from the device if they have not been used for
a long period.
Make sure you insert the batteries the right way round (polarity).
Assembly
Note: You will need a screwdriver and a drill to assemble the doorbell.
Note: Only use the screws and dowels supplied for the assembly of
the device.
Mount the receiver (see Fig. E)
Mount the transmitter (see Fig. F)
Preparing for use
Inserting/replacing the batteries
Insert the batteries to provide power to the device before preparing
it for use.
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 13 16.05.14 13:21

GB/CY14
CAUTION! Use the above-indicated battery types only. Failure to
observe this advice may result in damage to the product.
Receiver:
Remove the battery compartment cover 9from the back of the
device.
Remove the used batteries, if present.
Insert 2 batteries (1.5 V , type AA).
Note: Ensure correct polarity. This is indicated in the battery
compartment 10 .
Close the battery compartment 10 .
Transmitter:
Remove the holder 15 from the back of the transmitter.
Open the battery compartment 14 by turning the battery compartment
cover anticlockwise.
Insert a battery (3 V , type CR 2032). The side marked “+” must
face upwards.
Place the battery compartment cover on the battery compartment 14
and tighten it by turning it clockwise.
Fasten the holder 15 of the receiver back on to the back of the device.
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 14 16.05.14 13:21

GB/CY 15
Operation
Synchronising transmitter/receiver
Synchronise the transmitter and receiver as follows:
Press the synchronisation button 2.
Press the chime button 13 ; the signal indicator 1flashes red. The
programmed audible signal sounds and the signal indicator 1
ceases to illuminate.
If the receiver does not react as described, press the synchronisation
button 2again to switch off the synchronisation function and repeat
the synchronisation process.
The transmitter indicates the transmission of the signal to the receiver by
the signal indicator 11 flashing briefly.
Setting the signal type
The receiver can indicate the reception of a door signal either optically
or acoustically or both optically and acoustically.
Using the signal type selector button 5, select whether the signal
is to be indicated optically or acoustically or both optically and
acoustically.
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 15 16.05.14 13:21

GB/CY16
Setting the volume
Press the volume button 3until the desired volume is reached. There
are a total of 5 possible volume settings: very loud, loud, medium,
soft, very soft.
Selecting the chime
Note: The doorbell has 36 different chimes.
Press the melody selection button 4. The first audible signal sounds.
Press the melody selection button 4again to move on to the next
audible signal.
Repeat this process until you have selected your desired audible signal.
The last-selected audible signal is automatically stored.
Troubleshooting
After the influence of extraordinary environmental conditions (e.g. a strong
electromagnetical field) the function of the item may be affected. In this
case, please take off the batteries of both appliances for approximately
2 minutes. Then proceed again as described in the section “Synchronising
the transmitter/receiver”.
Electrostatic discharges may lead to malfunctions. If such malfunctions
do occur, remove the battery for a short time and then replace it again.
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 16 16.05.14 13:21

GB/CY 17
Then proceed again as described in the section “Synchronising the
transmitter/receiver”.
Cleaning and maintenance
Under no circumstances should you use liquids or detergents, as
these will damage the device.
The device should only be cleaned on the outside with a soft dry cloth.
Disposal
The packaging is made entirely of recyclable materials,
which you may dispose of at local recycling facilities.
Contact your local refuse disposal authority for more details of how to
dispose of your worn-out product.
To help protect the environment, please dispose of the product
properly when it has reached the end of its useful life and not
in the household waste. Information on collection points and
their opening hours can be obtained from your local authority.
Faulty or used batteries must be recycled in accordance with Directive
2006/66 /EC. Please return the batteries and/ or the device to the
available collection points.
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 17 16.05.14 13:21

GB/CY18
Pb Hg
Environmental damage through
incorrect disposal of the batteries!
Batteries may not be disposed of with the usual domestic waste. They
may contain toxic heavy metals and are subject to hazardous waste
treatment rules and regulations. The chemical symbols for heavy metals
are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why
you should dispose of used batteries at a local collection point.
Information
Declaration of conformity
We, OWIM GmbH & Co. KG, Stiftsbergstraße 1, D-74167 Neckarsulm,
hereby declare under our sole responsibility that the product: Wireless
Doorbell, Model No.: Z32155, Version: 06/2014, to which this decla-
ration refers, complies with the standards/normative documents of
1999/5 /EC.
The complete declaration of conformity can be viewed at:
www.owim.com.
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 18 16.05.14 13:21

GB/CY 19
Warranty
The device has been manufactured to strict quality guidelines and metic-
ulously examined before delivery. In the event of product defects you
have legal rights against the retailer of this product. Your legal rights are
not limited in any way by our warranty detailed below.
The warranty for this device is 3 years from the date of purchase. Should
this device show any fault in materials or manufacture within 3 years from
the
date of purchase, we will repair or replace it – at our choice – free of
charge to you.
The warranty period begins on the date of pur chase. Please keep the
original sales receipt in a safe location.
This document is required as your
proof of purchase. This warranty becomes void if the device has been
damaged or improperly used or maintained.
The warranty applies to faults in material or manufacture. This warranty
does not cover product parts subject to normal wear, thus possibly con-
sidered con
sumables (e.g. batteries) or for damage to fragile parts, e.g.
switches, rechargeable batteries or glass parts.
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 19 16.05.14 13:21

HR20
Uvod
Namjena proizvoda........................................................................Stranica 21
Tehnički podaci................................................................................Stranica 21
Opseg pošiljke.................................................................................Stranica 22
Pregled dijelova...............................................................................Stranica 22
Sigurnost.......................................................................................Stranica 23
Opće sigurnosne upute...................................................................Stranica 24
Sigurnosne napomene za baterije.................................................Stranica 24
Postavljanje...............................................................................Stranica 26
Stavljanje u pogon
Postavljanje/zamjena baterija ......................................................Stranica 26
Opsluživanje
Sinkroniziranje odašiljača/prijemnika..........................................Stranica 27
Namještanje vrste signala...............................................................Stranica 28
Namještanje jačine zvuka ..............................................................Stranica 28
Odabir zvuka signala .....................................................................Stranica 28
Uklanjanje smetnji............................................................................Stranica 29
Čišćenje i njega.......................................................................Stranica 29
Zbrinjavanje otpada.........................................................Stranica 29
Informacije
Izjava o sukladnosti.........................................................................Stranica 30
Jamstvo .........................................................................................Stranica 31
60113_silv_Tuerklingel_content_HR_RO_BG_GR_CY.indd 20 16.05.14 13:21
