Silvercrest SFR 2.4 A1 User manual

6
PERSONAL CARE
Shaver SFR 2.4 A1
Shaver
Operating instructions
KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: SFR2.4A1-06/10-V2
IAN: 38018
CV_38018_SFR24A1_LB6.qxd 03.06.2011 12:01 Uhr Seite 1

1
3
4
5
6
7
8
90
q
w
22
SFR 2.4 A1
CV_38018_SFR24A1_LB6.qxd 03.06.2011 14:25 Uhr Seite 4

- 1 -
Content Page
Intended Usage 2
Safety instructions 2
Items supplied 2
Description of the appliance 3
Technical Data 3
Shaving without the power cable 3
Shaving using the power adapter 4
Intended purpose 4
Shaving..............................................................................................................................................4
Trimming ............................................................................................................................................5
Cleaning and care 5
Dry cleaning .....................................................................................................................................5
Wet cleaning.....................................................................................................................................5
Maintenance.....................................................................................................................................6
Changing the cutter heads ..............................................................................................................6
Storage 6
Disposal 7
Warranty and Service 7
Importer 8
Read the operating instructions carefully before using the device for the first time and preserve this booklet
for later reference. Pass this manual on to whoever might acquire the device at a future date.
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 1

- 2 -
SHAVER
Intended Usage
This appliance is intended exclusively for shaving and
trimming human hair. Do not use it in commercial or
industrial applications.
Safety instructions
• This appliance is not intended for use by individuals
(including children) with restricted physical,
physiological or intellectual abilities or deficiences
in experience and/or knowledge unless they are
supervised by a person responsible for their safety
or receive from this person instruction in how the
appliance is to be used.
• Children should be supervised to ensure that they
do not play with the appliance.
• To avoid unnecessary risks, arrange for damaged
plugs, power cables and adapters to be exchanged
by Customer Services forthwith.
• Should the razor become damaged, to avoid
unnecessary risks arrange for it to be repaired by
an authorised specialist or Customer Services.
NEVER submerse the razor and the power
adapter in water or other liquids. This would
cause irreparable damage to the appliance.
NEVER use the appliance whilst in the bath or
under the shower. Risk of electric shock!
• Do NOT take the appliance into use if there is vi-
sible damage to either the appliance itself or the
power cable. Injury hazard!
To avoid the risks of fire
or injury
:
• Use only the original accessory parts for this ap-
pliance. Other accessories may not meet the safety
requirements.
• Discontinue using the appliance if there is visible
damage to the cutter heads or if the cutter heads
suddenly become hot.
Attention!
ALWAYS disconnect the razor from the power adapter
before cleaning it with water! There is a risk of recei-
ving an electric shock!
Note:
The installation of a residual current circuit breaker
with a rated tripping current of no more than 30 mA
offers further protection. Arrange for the installation
to be carried out ONLY by a qualified electrician.
Items supplied
Electric razor
Mains adapter
Protective cap
Cleaning brush
Storage case
Operating instructions
After the unpacking, remove all wrapping materials
and protective foils from the appliance. Check to en-
sure that all listed items have been supplied.
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 2

- 3 -
Description of the appliance
1Cutter foil retainer
2Release tabs
3Locking button
4On/Off switch
5Charge-LEDs
6Socket
7Storage case
8Brush
9Mains power adapter
0Connection plug
qLong hair trimmer
wProtective cap
Technical Data
Mains adapter
Input voltage: 100 - 240 V ~
50/60Hz
Output Voltage: 4 V 400 mA
Protection class: IPX4
Electric razor
Input voltage: 4 V 400 mA
Batteries : 2 x AAA, Ni-MH
Protection class: IPX4
Shaving without the
power cable
Note:
On to the first usage, there could be production re-
lated oil residues on the cutter foil. Wipe them off with
an absorbant and lint-free cloth.
+
–
Attention! Appliance Damage!
NEVER use the razor in the bathtub or shower. This
could irreparably damage the appliance.
This razor can be used without the power cable. In
this case, you must charge it before the ffiirrssttuse for
about 14 hours.
1. Check to ensure that the appliance is switched off.
2. Insert the connector plug 0into the socket 6
on the razor. Pay heed to the correct polarity:
The guide pillar in the socket 6must grip the guide
rail on the connector plug 0. If it does not, the
connector plug 0cannot be inserted.
3. Connect the plug with a mains power socket. The
batteries are being charged.
Note:
To optimise the life of the batteries, if possible do not
interrupt the charging process until the batteries have
been fully charged.
Furthermore, it can happen that if you interrupt the
charging process, the charge LEDs 5will not indi-
cate the correct load capacity of the battery's!
The charge LEDs 5indicate to what extent the ap-
pliance is charged: The more charge LEDs 5there
are that glow permanently, the higher the current
charge is. When the appliance is fully charged (from
a complete discharge, this will be after about 8
hours), remove the connection plug 0from the
socket 6and disconnect the power adapter 9from
the mains power supply. The razor can now be used
without the power cable.
Note:
The full charging process after complete discharge
of the batteries takes approx. 8 hours. You can then
use the razor for approx. 60 minutes.
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 3

- 4 -
Note:
Do not recharge the battery after every use. Charge
the batteries only when the last charge LED 5is
blinking. This will optimise the performance of the
battery.
Shaving using the
power adapter
Warning
When it is connected to the mains power adapter 9,
NEVER use the appliance in the bath, under the sho-
wer or close to a washbasin! Risk of electric shock!
Note:
On the first usage, there could be production-related
oil residues on the cutter foil. Wipe them off with an
absorbant and lint-free cloth.
Should you wish to use the razor without first charging
the battery, you can do so by using energy directly
from the mains power adapter 9:
1. Insert the connector plug 0into the socket 6on
the razor. Pay heed to the correct polarity:
The guide pillar in the socket 6must grip the
guide rail on the connector plug 0. If it does not,
the connector plug 0cannot be inserted.
2. Connect the plug with a mains power socket.
The razor can then be used.
Intended purpose
Shaving
This razor is suitable for both wet and dry shaving.
However, the best results are obtained with a dry
skin.
Warning regarding appliance
damage!
Do not use a shaving gel, as this can clog the cutter
foil and the cutter heads.
Note:
The appliance may not be used if you have skin
wounds, sunburn, pimples or blisters.
Note:
In the first 2 to 3 weeks you could suffer some light
skin irritation, until your skin has got used to the cutter
heads. Should the skin irritation continue beyond
this time, consult your doctor.
1. Remove the protective cap w.
2. Press the locking button 3and, at the same
time, slide the On/Off switch 4upwards. The
cutter heads rotate.
Warning regarding appliance
damage!
Avoid using too high pressure on the cutting foil, so
as to avoid breaking the foil. Further, too much pres-
sure on the skin can reduce the effectiveness of the
cutters and also lead to skin irritation.
3. Guide the razor upright and with light pressure
over the skin surface and against the direction of
hair growth. At the same time tense your facial
skin with your free hand, so that the whiskers stick
out. The razor should always be at a right angle
to the skin. A light circular motion of the cutter he-
ads helps ensure the capture of individual whiskers.
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 4

- 5 -
4. When you have finished shaving, slide the
On/Off switch 4downwards.
5. Clean the appliance as described in the chapter
"Cleaning and Care".
Trimming
The long-hair trimmer qintegrated onto the razor is
suitable for trimming sideboards and moustaches.
1. Always use the long-hair trimmer qin the top
rest position. Slide it over the first rest position
out to the top.
2. Press the locking button 3and, at the same time,
slide the On/Off switch 4upwards. The long-hair
trimmer qis running.
You can now trim the hairs as required.
3. When you have finished trimming, slide the
On/Off switch 4downwards.
4. Remove any loose hairs on the long-hair trimmer q
with the brush 8.
5. Slide the long-hair trimmer qdownwards.
Cleaning and care
Risk of electric shock!
Always withdraw the plug from the mains power
socket before cleaning! Otherwise, there is the great
risk of receiving an electric shock!
Clean the razor after every use.
Dry cleaning
• Press the lateral release tabs 2and pull the cut-
ter foil retainer 1upwards.
• Carefully tap the cutter foil retainer 1on a flat
surface.
• Clean the cutter heads with the brush 8.
Wet cleaning
The cutter heads under the cutter foil retainer
1are suitable for cleaning under running
water.
Attention!
Ensure that you hold ONLY the cutter heads under
the flow of water! The hand element of this razor is
protected only against spray water, it could be irre-
parably damaged if it is held under running water.
• Press the lateral release tabls 2and pull the cut-
ter foil retainer 1upwards.
• Hold the cutter heads under warm flowing water.
If necessary, add some liquid soap.
• To achieve a more intense cleaning, switch the
razor on while it is being rinsed.
• Rinse the cutter foil retainer 1under warm flowing
water.
• Wipe the housing with a soft, moist and lint-free
cloth.
• Allow the appliance and all parts to dry well be-
fore reassembling it.
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 5

- 6 -
Risk of personal injury!
When replacing the cutter foil retainer 1do not use
force and do not press on the cutter foil!
• Take hold of the cutter foil retainer 1on the sides
and press it down until the securing tabs engage.
• Replace the protective cap w.
• Clean the housing and the power adapter 9with
a moist cloth.
• Clean the long-hair trimmer qafter every use with
the brush 8.
Lubricate the long-hair trimmer qapprox. every 6
months with a drop of sewing machine oil.
Maintenance
Shaving quality is mostly determined by the condition
of the cutter parts. As these are subject to wear and
tear, an opportune exchange is necessary.
We recommend replacing the cutter foil retainer 1
and the cutter heads annually. Always replace the
cutter foil retainer 1and the cutter heads at the
same time.
If...
- ... the shave is noticeably unsatisfactory,...
- ... you must run the razor over the same spot seve-
ral times to obtain an acceptable result,...
- ... shaving takes noticeably longer,...
- ... damage is visible on the cutter blades,...
.... the cutter foil retainer 1and the cutter heads
must be exchanged.
Replacement cutter foil retainers and cutter heads
can be ordered with the enclosed order form.
Changing the cutter heads
• Remove the cutter foil retainer 1, as described
in "Wet cleaning".
• Grasp the ssiiddeessof a cutter head and carefully pull
it upwards.
• Repeat this procedure with the second cutter head.
• Attach the new cutter heads onto the mountings.
Ensure that they engage and are seated firmly.
• Take hold of the cutter foil retainer 1on the sides
and press it down until the securing tabs engage.
Storage
Attention!
Never keep the razor in its storage case 7when the
battery is being charged! Risk of overheating!
If you do not intend to use the razor for an extended
period, or you are transporting it, place it in its storage
case 7.
Ensure that the razor is clean and completely dry.
Store the razor at a clean and dry location.
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 6

- 7 -
Disposal
Do not dispose of this appliance in your
normal domestic waste. This product is
subject to the provisions of European
Directive 2002/96/EC.
Dispose of the appliance through an approved dispo-
sal centre or at your community waste facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal
centre.
Disposal of batteries
Used batteries may not be disposed of in household
waste. Every consumer is statutorily obliged to dispose
of batteries at a collection site of his community/city
district or at a retail store.
The purpose of this obligation is to ensure that batte-
ries are disposed of in a non-polluting manner. Only
dispose of batteries when they are fully discharged.
Dispose of all packaging materials in an
environmentally friendly manner.
Warranty and Service
The warranty for this appliance is for 3 years from
the date of purchase. The appliance has been ma-
nufactured with care and meticulously examined be-
fore delivery. Please retain your receipt as proof of
purchase. In the event of a warranty claim, please
make contact by telephone with our Service Depart-
ment. Only in this way can a post-free despatch for
your goods be assured.
The warranty covers only claims for material and
manufacturing defects, but not for transport dama-
ge, for wearing parts or for damage to fragile com-
ponents, e.g. buttons or batteries. This product is for
private use only and is not intended for commercial
use. The warranty is void in the case of abusive and
improper handling, use of force and internal tampe-
ring not carried out by our authorized service
branch. Your statutory rights are not restricted in
any way by this warranty.
The warranty period will not be extended by repairs
made under warranty. This applies also to replaced
and repaired parts. Any damage and defects extant
on purchase must be reported immediately after un-
packing the appliance, at the latest, two days after
the purchase date. Repairs made after the expira-
tion of the warranty period are subject to payment.
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: k[email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: k[email protected]
IAN 38018
IAN 38018
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 7

- 8 -
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 8

Order card SFR 2.4 A1
www.kompernass.com
£
(Location, Date) (Signature)
Payment method
Add. £ 3,50 p&p.
Quantity ordered
(max. 3 sets per order) Name of article Cost p. Unit Total sum
Cutter foil holder
including cutter
foils and long hair
trimmer as well as
two cutter heads
for razor
SFR 2.4 A1.
£ 7,00 £
Bank Transfer
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 9

2. Bank Transfer (BACS): Please transfer
the complete amount to our account below:
Natwest Bank Plc Hammersmith Branch Sort Code: 60-50-06 Account No: 37758829 Account Name: Domestic Electrical Solutions UK Limited On your transfer, please provide the article(s) you ordered as well as your complete name and address. Then post your completed order card to our postal address.
Our postal address: DES UK LTD Unit B7 Oxford Street Industrial Park Vulcan Road Bilston/ West Midlands WV14 7LF Important: • Please affix sufficient postage to the letter. • Write your name as the sender on the envelope.
www.kompernass.com
Order Card - How toorder:
1. Enter under “Sender/orderer” your name, address and telephone number (for possible queries)
in block capitals.
Sender /Orderer (please complete in block captals) (Surname, first name)
(Street)
(Post code, town)
(Telephone)
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 10

Order card SFR 2.4 A1
www.kompernass.com
€
(Location, Date) (Signature)
Payment method
Add. 3 € p&p.
Bank Credit Transfer
Quantity ordered
(max. 3 sets per order) Name of article Cost p. Unit Total sum
Cutter foil holder
including cutter
foils and long hair
trimmer as well as
two cutter heads
for razor
SFR 2.4 A1.
8 € €
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 11

2. Bank Credit Transfer: Transfer the
whole amount in advance to our account:
Kompernaß Handelsgesellschaft mbH IBAN: DE03440100460799566462 SWIFT (BIC): PBNKDEFF 440 Bank: Postbank Dortmund AG If you pay by bank credit transfer, on the remit- tance form please tick „shared“ (shared costs) in the box under the item `Costs´. Otherwise, we can not process your order.
Our postal address: Kompernaß Handelsgesellschaft mbH Burgstraße 21 44867 Bochum Germany Important: • Please affix sufficient postage to the
letter.
• Write your name as the sender on the envelope.
www.kompernass.com
Order Card - How toorder:
1. Enter under “Sender/orderer”your name, address and telephone number
(for possible queries) in block capitals.
Sender /Orderer (please complete in block captals) (Surname, first name)
(Street)
(Post code, town)
(Country)
(Telephone)
IB_38018_SFR24A1_LB6 24.08.2011 12:16 Uhr Seite 12
