OIL-FILLED RADIATOR SOR 1500 D3
IAN 304408
OIL-FILLED RADIATOR
Operation and safety notes
This product is only suitable for well insulated
spaces or occasional use.

GB/IE/NI Operation and safety notes Page 5

A
1
2
3
5
4

B
76
8

5GB/IE/NI
List of pictograms used ................................................Page 6
Introduction ...........................................................Page 6
Intended use..........................................................Page 6
Part description .......................................................Page 6
Technical data ........................................................Page 6
Scope of delivery ......................................................Page 6
Safety notices .........................................................Page 7
Installation (see fig. A–C) ..............................................Page 10
Operation .............................................................Page 10
Reaching the decided room temperature....................................Page 11
Switch off the product ..................................................Page 11
Frost protection function .................................................Page 11
Care and cleaning .....................................................Page 11
Storage ...............................................................Page 11
Disposal...............................................................Page 12
Warranty .............................................................Page 12

6 GB/IE/NI
List of pictograms used
Observe caution and safety notes! Danger - Risk of electric shock!
Voltage (alternating current) Risk of fire!
Watts (effective power) Do not cover!
Hertz (mains frequency) Indoor use only.
Do not touch
OIL-FILLED RADIATOR
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product.
They contain important information concerning
safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety
information and instructions for use. Only use
the product as described and for the specified
applications. If you pass the product on to anyone
else, please ensure that you also pass on all the
documentation with it.
Intended use
The product is only designed for heating rooms
in private households. It is only intended for
indoor use in dry locations. It is not suitable
for commercial use. The manufacturer is not
liable for damage caused by improper use. This
product is only suitable for well insulated spaces
or occasional use.
Part description
1Heat level switch
2Temperature control
3Power indicator
4Ventilation slots
5Power cord retainer
6Wing nut
7Castor assembly
8U shape bolt
Technical data
Operating voltage: 220–240 V∼, 50 Hz
Nominal power: 1500 W
Heat level: “1” – 600 W
“2” – 900 W
“3” – 1500W
Temperature control: Continuously variable
Number of heating fins: 7
Scope of delivery
Immediately after unpacking, please check the
package contents for completeness and if the
product and all parts are in good condition.
Remove all packaging materials from the
product.
1 Oil filled radiator
2 Castor assemblies
1 U shape bolt
4 Wing nuts
1 Instruction manual

7GB/IE/NI
Safety notices
Read all safety advices and
instructions. Non-observance
of the safety advices and
instructions may cause electric
shock, fire and/ or bad injuries.
KEEP ALL SAFETY NOTICES
AND INSTRUCTIONS FOR
FUTURE REFERENCE!
WARNING!
DANGER TO LIFE
AND RISK OF
ACCIDENTS FOR
INFANTS AND
CHILDREN! Never leave
children unsupervised with the
packaging materials. The
packaging material poses a
suffocation hazard. Children
frequently underestimate the
dangers. Always keep
children away from the
packaging material.
mCAUTION! This product
is not a toy for children!
Children are not aware of
the dangers associated with
handling electrical products.
This product can be used by
children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the product
in a safe way and understand
the hazards involved.
Children shall not play with
the product.
Cleaning and user
maintenance shall not be
made by children without
supervision.
Children of less than 3 years
should be kept away unless
continuously supervised.
Children aged from 3 years
and less than 8 years shall
only switch on/ off the
product provided that it has
been placed or installed in its
intended normal operating
position and they have
been given supervision or
instruction concerning use of
the product in a safe way and
understanding the hazards
involved.

8 GB/IE/NI
Children aged from 3 years
and less than 8 years shall
not plug in, regulate and
clean the product or perform
user maintenance.
mCAUTION! Some parts of
this product can become very
hot and cause burns. Particular
attention has to be given
where children and vulnerable
people are present.
WARNING! In
order to avoid
overheating, do not
cover the product.
The product must not be
located immediately below a
socket-outlet.
Do not use the product
without feet properly
installed; follow the assembly
instructions within this
instruction manual.
If the supply cord is
damaged, it must be replaced
by the manufacturer, its
service agent or similarly
qualified persons in order to
avoid a hazard.
This product is filled with a
precise quantity of special oil.
Repairs requiring opening of
the oil container are only to
be made by the manufacturer
or his service agent. Contact
them, if there is an oil leak.
When scrapping the product,
follow the regulations
concerning the disposal of oil.
mCAUTION! Avoid the hazard
of life by electric shock:
Never use a damaged or oil
leaking product.
Never immerse the product
into water or any liquid.
Never touch the product, the
power cord or the mains plug
with wet hand or use it in very
humid environments.

9GB/IE/NI
Never place containers filled
with liquid, such as drinking
glasses, vases etc. on the
product. If liquid should enter
the product, unplug the mains
plug immediately and have
the product repaired by a
qualified technician.
Make sure that the details
on the rating label are in
conformity with your mains
voltage. Only connect the
product to alternating current
with an earthing contact
as otherwise a protection
against electric shock is not
provided.
In the event of malfunctions,
remove the mains plug from
the mains socket.
Do not open the product or
attempt to repair it yourself.
Defective products should
only be repaired by qualified
personal.
Check the power cord
regularly for damage or
deterioration.
Always remove the mains
plug from the mains socket
after each use and before
cleaning the product.
Do not pull the power cord
for unplugging the product.
Unplug the product by pulling
out the mains plug.
Keep the power cord away
from hot surfaces, sharp
edges and mechanical forces.
Never let the power cord
becomes a trip hazard, that
no one can get tangled in it
or tread on it.
Allow the product to cool
down before moving it to a
different location.
ATTENTION!
HAZARD OF FIRE!
Do not operate the
product close to or below
curtains, wall cupboards or
other inflammable materials.
Always operate the product
in an upright position (both
castor assemblies 7on the
bottom). Any other position
could cause a hazardous
situation.

10 GB/IE/NI
Place the product on a level,
stable and heat resistant floor.
Do not place any open fire
sources, such as candles, on
the product.
Never block the ventilation
slots 4.
Do not use this product with a
programmer, timer, separate
remote-control system or any
other device that switches
the product on automatically,
since a fire risk exists if
the product is covered or
positioned incorrectly.
Do not use an extension cord.
Do not use this product in
rooms with a room volume of
less than 4 m3.
Only use accessories and
additional equipment
stated in the instruction
manual. The use of other
products or accessories
than recommended in the
instruction manual may
present a risk of injuries for
you.
Do not use this product
near a bathtub, shower or
swimming pool.
Installation
Place the product upside down on a
soft underlay to avoid scratches on the
surface (see fig. B).
Place a caster assembly 7over both bolts
fixed on the front cover with both wheels
pointing upwards (see fig. B).
Ensure both threaded ends of fixed bolts
are passing through both holes of the castor
assembly 7.
Fasten wing nut 6securely onto each
threaded end of fixed bolts.
Attach the U shape bolt 8to the product
between the last 2 fins with the threaded
ends pointing upwards (see fig. B).
Place the castor assembly 7over the U
shape bolt 8with both wheels pointing
upward, see fig. B. Ensure both threaded
ends of U shape bolt 8passing through
both holes on the castor assembly 7.
Fasten the wing nut 6securely onto each
threaded end of U shape bolt 8.
S
et the product back to upright position, whe els
on the floor. It is now ready to use.
Note: The product is equipped with a tilt
protection switch. It will shut down the product
automatically if it falls over or is lying on its side.
Operation
Unwind the power cord completely from the
power cord retainer 5.

11GB/IE/NI
Make sure that both temperature control 2
and heat level switch 1are set to MIN and
“0” respectively.
Connect the product to a grounded mains
socket protected by a residual current circuit
breaker. Ensure that the mains voltage of the
electrical outlet meets the requirement (see
“Technical data” chapter).
Note: Ensure the mains plug is fully inserted
to the mains socket.
Reaching the decided room
temperature
Set the temperature control 2to MAX and
the heat level switch 1to “3”. The power
indicator 3lights up.
When the desired room temperature is
reached, turn the temperature control 2
gently counter-clockwise until the product
shuts off. A “click” sound is heard and the
power indicator 3goes off. Leave the
temperature control 2at the position. The
room temperature is now retained.
The product automatically cycles on and off
to keep the decided room temperature. The
power indicator 3light also cycles on and
off to indicate when the product is heating
up. As long as the heat level switch 1is set
to “1”/”2”/”3”, the product operates even
when the power indicator 3is off.
Use the heat level switch 1to select how
quickly the product shall warm up. To warm
up quickly, set the heat level switch 1
to “3”.
Switch off the product
Turn the heat level switch 1to “0” then turn
the temperature control 2to MIN.
Remove the mains plug from the mains
socket.
Frost protection function
The frost protection function
automatically controls the product to
keep the room temperature above
7°C, steps are as follows:
Connect the product to an earthed socket
protected by a residual current circuit
breaker.
Switch on the product by setting the heat
level switch 1to either “1”, “2” or “3” and
by setting the temperature control 2to
“MIN”. The product switches on when the
room temperature is approx. 7°C. As soon
as the room temperature is above 7°C, the
product automatically switches off again.
Note: The product will switch itself on and off
automatically to maintain a temperature higher
than 7°C.
Care and cleaning
WARNING! Remove the mains plug
from the mains socket and leave the product to
cool completely before cleaning.
WARNING! Never immerse the product,
power cord or mains plug into water.
Use a damp lint-free cloth to clean the
product. Use a mild detergent on the cloth
for stubborn dirt.
Do not use abrasive, aggressive or chemical
cleaning agents. It could damage the surfaces
of the product.
Storage
If the product not to be use for a long period
of time, clean it as described in the section
“Care and cleaning”.

12 GB/IE/NI
Wind the power cord around the power
cord retainer 5clockwise tightly and let
the mains plug being held at the cord clip in
front of the power cord retainer 5.
Store the product at a clean and dry location.
Disposal
The packaging is made entirely of recyclable
materials, which you may dispose of at local
recycling facilities.
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a)
and numbers (b) with following
meaning: 1–7: plastics/ 20–22:
paper and fibreboard/ 80–98:
composite materials.
The product and packaging materials
are recyclable, dispose of it separately
for better waste treatment.
The Triman logo is valid in France
only.
Contact your local refuse disposal
authority for more details of how to
dispose of your worn-out product.
To help protect the environment,
please dispose of the product properly
when it has reached the end of its
useful life and not in the household
waste. Information on collection
points and their opening hours can be
obtained from your local authority.
Observe the current regulations for waste oil
disposal.
Warranty
The product has been manufactured to strict
quality guidelines and meticulously examined
before delivery. In the event of product defects
you have legal rights against the retailer of this
product. Your legal rights are not limited in any
way by our warranty detailed below.
The warranty for this product is 3years from the
date of purchase. Should this product show any
fault in materials or manufacture within 3years
from the date of purchase, we will repair or
replace it –at our choice– free of charge to
you.
The warranty period begins on the date of
purchase. Please keep the original sales receipt
in a safe location. This document is required as
your proof of purchase. This warranty becomes
void if the product has been damaged, or used
or maintained improperly.
The warranty applies to defects in material
or manufacture. This warranty does not
cover product parts subject to normal wear,
thus possibly considered consumables (e.g.
batteries) or for damage to fragile parts, e.g.
switches, rechargeable batteries or glass parts.

13GB/IE/NI
Information requirements for electric local space heaters
Model identifier(s): 304408
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric
storage local space heaters only
(select one)
Nominal
heat out put
Pnom 1.1 kW manual heat charge control,
with integrated thermostat
[yes/no]
Minimum
heat output
(indicative)
Pmin 0.6 kW manual heat charge control
with room and/ or outdoor
temperature feedback
[yes/no]
Maximum
continuous
heat output
Pmax,c1.1 kW electronic heat charge control
with room and/ or outdoor
temperature feedback
[yes/no]
Auxiliary electricity consumption fan assisted heat output [yes/no]
At nominal
heat output
elmax 1.081 kW Type of heat output /room
temperature control (select one)
At minimum
heat output
elmin 0.617 kW single stage heat output and no
room temperature control
[yes/no]
In standby
mode
elSB 0.000 kW Two or more manual stages, no
room temperature control
[yes/no]
with mechanic thermostat room
temperature control
[yes/no]
with electronic room
temperature control
[yes/no]
electronic room temperature
control plus day timer
[yes/no]
electronic room temperature
control plus week timer
[yes/no]
Other control options (multiple
selections possible)
room temperature control, with
presence detection
[yes/no]
room temperature control, with
open window detection
[yes/no]
with distance control option [yes/no]
with adaptive start control [yes/no]
with working time limitation [yes/no]
with black bulb sensor [yes/no]
Contact details see back side of instruction manual

IAN 304408
OWIM GmbH & Co. KG
Stiftsbergstraße 1
DE-74167 Neckarsulm
GERMANY
Model-No.: HG04165-BS
Version: 07 / 2018
