SimpliFire SF-ALLP50-BK User manual

1
SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/19
SERVICE MANUAL
Glass Front, Media, Trim, LED Light Boards (Fuelbed and Flame), Touch Buttons, Receiver
Board, Control Board, Heater, Flame Screen,Rotisseire, Motor & Power Cord
Model: SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK
- Instructions -
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
Leave this manual with party responsible for use
and operation.
NOTICE! DO NOT discard this manual. Important service
and maintenance instructions included.
NOTICE! DO NOT discard any hardware while
servicing. It may be reused.
WARNING! Risk of Shock! Always unplug the cord or
turn off the circuit breaker before moving or servicing.
Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Tape measure
Needle-nose pliers
Hammer
Gloves
Level
Magnetic Phillips screwdriver
Safety glasses
Drill
Flathead screwdriver
Phillips Tip-Bit socket and ratchet (for Blower/Heater)
5/16 drill bit for 3/16 diameter toggle bolts
(applicable if installing on drywall-sheathed walls)
Masonry drill bit 5/16 in. (applicable if installing on
masonry walls)
Glass Front Replacement
Remove Glass Front
1. Remove the two (2) glass bracket cover (if installed).
See Figure 1.
2. Remove the two (2) ST4X8 screws located on the
glass panel. See Figure 1.
Note: Do not discard screws, screws will be reused.
3. Tilt glass forward and pull up to remove from appliance.
CAUTION! Two adults recommended for the removal
or installation of glass front. Use caution when han-
dling glass. Failure to do so could result in personal injury
or property damage.
Figure 1 Remove Glass Front
WARNING! Risk of Personal Injury or Property Dam-
age! Failure to follow instructions below may result in
damage to the equipment and or may expose the user to
the risk of re, serious injury, illness or death.
GLASS BRACKET
COVER
ST4X8 SCREWS

SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/192
Stone/Media/Log Installation
1. Remove Glass.
2. Arrange the stone/media/log along the inset window
ledge at the front of the appliance.
Note: Extra media is provided and may be
distributed based on consumer preference.
Not all media needs to be used.
Glass Replacement (Continued)
Installing Glass
3. Place the bottom edge of the glass in the channel on
the appliance.
4. Place the top edge of the glass against the appliance
and secure with two (2) ST4X8 screws removed in
step 1.
Figure 2 Glass Front Removal/Installation
1. Disconnect electrical service to the appliance. For
recessed electrical installations that are hardwired,
nd and shut-off service at the breaker. For wall-
mounted installations that use a corded plug,
disconnect the cord from the receptacle.
2. Remove the glass front from the appliance. Use of
two people recommended.
3. Follow specic instructions from page 1 and 2 for
removal of the front glass.
CAUTION! Two adults recommended for the removal
or installation of glass front. Use caution when han-
dling glass. Failure to do so could result in personal injury
or property damage.
Preparation for Component Installation
ST4X8 SCREWS
Trim Removal
Trim is shipped attached to the appliance.
Note: Trim must be installed before the appliance is
recessed in wall cavity.
1. Remove by removing the ST4X8 phillip screws
on the top, bottom and sides of the appliance See
Figure 3.
2. Pull Trim off from the front of the appliance. See
Figure 4.
SCREWS
TOP AND BOTTOM SCREW LOCATION
SIDE VIEW
SCREW LOCATION
SCREWS
Figure 3 Remove Trim Screws
Figure 4 Remove Trim
3. Install new Trim by following the removal steps in
reverse order.
Note: Replacement trim will require removal of corner
shipping brackets prior to installation.

3
SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/19
REMOVE TWO (2) SCREWS
ON EACH SIDE
Figure 5 Remove two (2) Screws on Each Side and Remove Panels
5. Using a athead screwdriver, pry open the tabs as shown in Figure 6.
Pry the tabs upward at a 30 degree angle. During this step, take care not to
scratch or damage the glass panel behind the tabs.
FUELBED PLASTIC COVER
Figure 6 Remove Plastic Cover
6. Remove the fuelbed plastic cover that covers the
fuelbed LED light strips. See Figure 6.
4. Remove right and left side panels by removing two
(2) screws from each side. Remove panels.See Figure 5.
SIDE PANELS

SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/194
LED Light Board Installation
The LED Service Kit includes LED Light Boards for both
the Fuelbed and the Flame effect.
Determine which LED light set to be installed. See
Figure 7.
Figure 7 LED Light Board Identication
LED FOR
FUELBED
1. Complete Steps 1-6 in Preparation for Component
Installation instructions.
2. Locate the Fuelbed LED Light Board cable. See
Figure 8.
LED LIGHT BOARD CABLE
3. Unplug the LED Light Board cable. See Figure 9.
LED LIGHT BOARD CABLE
Figure 8 LED Light Board Cable
Figure 9 Unplug LED Light Board Cable
4. Remove the LED light board from the bottom isolation
columns. Starting at one end of the board use a
needle-nose pliers to compress the plastic barbs from
each isolation column as each plastic barb is
compressed, disengage the LED light board from
each barb. See Figure 10.
ISOLATION COLUMNS
Figure 10 Isolation Columns
5. Remove and discard LED light board, replace with
new LED light board. Install new LED light board
by engaging the holes in the light board with the
plastic barbs, and pressing into position. Reconnect
the cables. See Figure 9.
Fuelbed LED Light Board Installation
LED FOR
FLAME
(APPLIANCE MAY VARY)

5
SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/19
Touch Button Installation
1. Complete Steps 1-6 in Preparation for Component
Installation instructions.
ST3X8 SCREWS
(STEPS 2 & 7)
2. Remove the front two (2) ST3X8 screws on the
Touch Button Assembly..
Figure 11 Touch Button Assembly
3. Unplug the touch button wire connector and remove
the Touch Button Assembly. See Figure 11.
4. Remove the two (2) screws holding the touch button
assembly to the plastic housing. See Figure 12.
SCREWS
(STEPS 4 & 6)
Figure 12 Touch Button board - Plastic Housing
5. Remove the Touch Button board from the plastic
housing.
6. Replace the Touch Button Assembly by installing the
new Touch Button Board in the plastic housing with
button cover. Fasten with two (2) screws.
7 Reinstall the Touch Button Assembly and housing by
reconnecting the wire connector and refastening in
place with two (2) screws.
Glass Screen Panel, Receiver Board, Control
Board, Heater, Rotisserie, Motor, Flame LED
Light Board Installation
1. Complete Steps 1-6 in Preparation for Component
Installation instructions.
REMOVE SCREWS
2. Remove screws holding the screen xing bracket.
See Figure 13.
Figure 14 Glass Screen Panel Removal
4. After these steps, the heater assembly, control board
assembly and reciever board may be replaced.
3. Carefully remove the Glass Screen Panel. Rotate
the top edge of the glass panel towards the opening,
then lift out the the glass panel from the appliance.
Set glass panel aside in a safe location, preferably a
soft surface such as carpet or cardboard. See
Figure 14.
Figure 13 Remove Fixing Bracket Screws

SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/196
Receiver Board Installation
ISOLATION
COLUMNS
1. Locate the Receiver Board in the upper right side of
appliance. See Figure 15.
Figure 15 Reciever Board Location
ISOLATION
COLUMN
ISOLATION
COLUMN
CABLE
Figure 16 Receiver Board Cable
2. Remove the Receiver Board from the isolation
columns. Use a needle-nose pliers to compress the
barbs on each isolation column.
3. Unplug the cable, remove the Receiver Board and
install with replacement board. See Figure 16.
4. Reverse steps to complete installation.
NOTE: Follow the appliacable installation instruc-
tions based on component being replaced. Control Board Installation
SCREWS
ISOLATION COLUMNS
2. Unplug ve (5) wire connectors from the board and
three (3) wire assemblies. See Figure 17.
Figure 17 Control Board Installation
3. Remove screws securing the board.
5. Install new Control Board by following the
removal steps in reverse order.
1. Locate the Control Board. See Figure 17.
4. Remove Control Board from isolation columns by
using needle nose to compress the barbs on each
isolation column.

7
SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/19
Note: Flame Screen must be removed before Rotisserie
replacement can be completed.
1. Remove one (1) ST3X8 screw on the Rotisserie
support bracket. See Figure 21.
2. Remove Rotisserie from the rubber sleeve
connecting it to the motor.
Rotisserie Installation
Heater Assembly Installation
SIX (6) ST4X8 SCREWS
Figure 18 Heater Assembly Screw Location (bottom view)
4. Install new Heater Assembly by following the
removal steps in reverse order.
1. Remove six (6) ST4X8 screws on the heater top
securing to the bottom of the appliance. See Figure
18.
2. Unplug the wire connector. See Figure 19.
3. Remove the Heater Assembly.
WIRE CONNECTION
Figure 19 Unplug / Remove Heater Assembly
Flame Screen Installation
REMOVE ST4X8 SCREWS
Figure 20 Flame Screen Removal
2. Remove the Flame Screen.
3. After removal of the Flame Screen, the Rotisserie
Assembly, Flame LED Assembly and the Motor may
be replaced.
4. Install Flame Screen by following the removal steps in
reverse order.
1. Remove ST4X8 screws holding the Flame Screen in
place. See Figure 20.
ST3X8 SCREW
RUBBER SLEEVE
Figure 21 Rotissserie Removal
3. Install new Rotisserie by following the removal steps
in reverse order.

SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/198
Note: Flame Screen and Rotisserie must be removed
before Motor replacement can be completed.
1. Remove three (3) ST4X8 screws on the Motor
Bracket. See Figure 22.
2. Unplug the wire connector.
Motor Installation
(3) ST4X8
SCREWS
WIRE
CONNECTOR
Figure 22 Motor Removal
3. Install new Motor by following the removal steps
in reverse order.
Flame LED Light Board Installation
1. Remove screws used to attach the ame screen
bracket. See Figure 22.
FLAME SCREEN
BRACKET SCREWS
Figure 23 Remove Flame Screen Bracket Screws.
2. Remove ame screen bracket.
3. Unplug cable connection on each end of the LED
Board. See Figure 23.
4. Release the LED boards from plastic retainers. See
Figure 24.
Note: Some retainers may require releasing an adhesive
prior to removal.
Figure 24 Unplug LED Board Cable Connections
CABLE CONNECTION LOCATION
5. To install replacement part reverse the installation
steps.
Note: Flame Screen and Rotisserie must be removed
before LED Light Board replacement can be
completed.
LED BOARD RETAINERS

9
SimpliFire • SF-ALLP50-BK, SF-ALLP60-BK, SF-ALLP72-BK Service Manual • 2044-960 Rev. C • 10/19
SimpliFire, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
WARNING! Risk of Fire, Electrical Shock and Injury!
Ensure the power cord is not installed so that it is pinched
or against a sharp edge and ensure that the power cord is
stored or secure to avoid tripping and snagging.
Power Cord Kit Installation
The appliance power cord has a three pin NEMA-5-15P
plug. The power cord should not be used unless a
grounded receptacle is available.
1. Remove the terminal block cover plate located on
the right end of the appliance.
2. Disconnect the terminal block from the three wires
inside the appliance. Discard the terminal block
cover plate.
3. Connect the three appliance wires to the terminal
block supplied with the power cord kit. See Figure
25.
4. Replace cord kit terminal block cover plate and
retaining screws. Plug cord into nearest outlet.
Figure 25 Optional Power Cord Assembly (Only for Direct Wall Mount Installation)
LN
RED
YELLOW / GREEN
BLUE
Wire Diagram
