SimpliFire SF-INS30-BK User manual

1SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
Model(s):
WARNING: To reduce risk of re, electrical shock, or personal injury, read all instructions
before using appliance.
Owner’s Manual
Installation and Operation
DO NOT DISCARD THIS MANUAL
NOTICE
• Leave this manual with
party responsible for use
and operation.
DO NOT
DISCARD
• Important operating
and maintenance
instructions included.
• Read, understand and follow
these instructions for safe
installation and operation.
SF-INS30-BK
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN
THIS PRODUCT.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE
TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR
PROPERTY DAMAGE.
INSTALLER: DO NOT DISCARD THIS MANUAL -
LEAVE FOR HOMEOWNER - SAVE THESE INSTRUCTIONS
Congratulations!
Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood and gas burning
replaces. The SimpliFire electric replace you have selected is designed to provide the utmost in safety, reliability, and
efciency.

SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
2
1IMPORTANT INSTRUCTIONS
WARNING! Risk of Fire! Risk of Burns!
Risk of Electrical Shock!
DO NOT:
• Install or operate damaged heater
• Modify heater
• Operate the heater without fully assembling all
components
Hearth & Home Technologies Inc. disclaims any
responsibility for, and the warranty and agency listing will
be voided by the above actions.
WARNING! DO NOT operate replace before reading
and understanding operating instructions. Failure to
operate appliance according to operating instructions
could cause re or injury.
WARNING! Improper installation, adjustment, al-
teration, service or maintenance can cause injury or
property damage. Failure to install appliance accord-
ing to Owner’s Manual could cause property damage or
injury.
NOTICE! This appliance is not intended for use as a pri-
mary heat source and should not be factored as such in
residential heating calculations.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
When using electrical appliances, basic precautions
should always be followed to reduce the risk of re,
electric shock, and injury to persons, including the
following:
• Read all instructions before installing this appliance.
• This appliance is hot when in use. To avoid burns, do not let
bare skin touch hot surfaces. Keep combustible materials
such as furniture, pillows, bedding, papers, clothes, etc., and
curtains at least 3 ft. (0.9 m) from the front of the appliance
and keep them away from the sides and rear.
• Extreme caution is necessary when any appliance is used by
or near children or or other at risk individuals and whenever
the appliance is left operating and unattended.
• Do not operate any appliance if it malfunctions. Disconnect
power at service panel and have appliance inspected by a
certied electrician before reusing.
• To prevent a possible re, do not block appliance fan air
intakes or exhaust in any manner.
• A heater has hot and sparking parts inside. Do not use it in
areas where gasoline, paint, or ammable vapors or liquids
are used or stored.
• Use this appliance only as described in this manual. Any
other use not recommended by the manufacturer may cause
re, electric shock, or injury to persons.
• Do not operate any appliance with a damaged cord or plug
or after the appliance malfunctions, has been dropped or
damaged in any manner. Contact authorized dealer.
• Do not use outdoors.
• Never locate appliance where it may fall into a bathtub or
water container.
• Do not run cord under carpeting. Do not cover cord with
throw rugs, runners, or the like. Arrange cord away from
trafc areas and where it will not be tripped over. Do not
tightly coil cord.
• Always use ground fault protection where required by
electrical code.
• To disconnect appliance, turn controls to “OFF” then remove
plug from outlet.
• Always disconnect power before performing any cleaning,
maintenance or relocation of the appliance.
• To prevent electrical shock or re, always use a certied
electrician should new circuits be required.
• When transporting or storing the appliance, keep in a dry
place free from excess vibration to avoid damage.
• Avoid use of an extension cord because an extension
cord may overheat and cause a fire. However if you
have to use an extension cord, the cord should be No.
14 AWG minimum size and rated to not less than 1875
watts.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not
play with the appliance.
• Do not insert or allow ngers or foreign objects to enter any
ventilation or exhaust opening as it may cause an electric
shock or re or damage the heater. Do not block or tamper
with the heater in any manner while it is in operation
• Always use properly grounded, fused and polarized outlets.

3SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
Safety Alert Key:
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
Table of Contents
Congratulations! ...................................1
1IMPORTANT INSTRUCTIONS
A. Warranty.......................................4
2 GENERAL INFORMATION
A. Appliance Certication ............................5
B. Unpacking and Inspecting Appliance ................5
C. Model and Serial Number Information ..............5
3 GETTING STARTED
A. Parts and Hardware .............................6
B. Appliance Dimensions ............................6
C. Tools and Supplies Needed . . . . . . . . . . . . . . . . . . . . . . . . 6
D. Location ....................................... 7
E. Clearance to Combustibles ........................7
F. Electrical Connection .............................7
4 INSTALLATION
A. Minimum Fireplace Opening .......................8
B. Installation into Existing Fireplace ................... 8
C. Appliance Preparation ............................ 9
D. Install Surround ................................10
E. Installing Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
F. Finishing...................................... 11
5 OPERATING INSTRUCTIONS
A. Manual Switch Function: .........................12
B. Operating by Remote Control. . . . . . . . . . . . . . . . . . . . . . 13
C. Resetting Temperature Cutoff Switch................13
6 MAINTENANCE
A. Maintenance ..................................14
B. Cleaning ......................................14
C. Servicing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
D. Service Parts List ..............................15
E. Contact Information .............................16

SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
4
SimpliFire™ WARRANTY
Hearth & Home Technologies, on behalf of its brand SimpliFire (”SimpliFire”), extends the following warranty
for electric fireplaces that were purchased from a SimpliFire authorized dealer.
WARRANTY COVERAGE:
SimpliFire warrants to the original owner of the SimpliFire fireplace, and to any transferee taking ownership of the Simpli-
Fire fireplace within one year following the date of original purchase, that the SimpliFire fireplace will be free from defects
in materials and workmanship at the time of manufacture. If a SimpliFire fireplace is found to be defective in materials or
workmanship during the applicable warranty period, HHT will, at its option, repair or replace the SimpliFire fireplace.
SimpliFire, at its own discretion, may fully discharge all of its obligations under such warranties by replacing the product
itself or refunding the verified purchase price of the product itself. The maximum amount recoverable under this warranty
is limited to the purchase price of the product. This warranty is subject to conditions, exclusions and limitations as
described below.
WARRANTY PERIOD:
Warranty coverage begins on the date of original purchase. In the case of new home construction, warranty coverage
begins on the date of first occupancy of the dwelling or six months after the sale of the product by an independent,
authorized SimpliFire dealer/ distributor, whichever occurs earlier. The warranty shall commence no later than 24 months
following the date of product shipment from HHT, regardless of the installation or occupancy date.
WARRANTY CONDITIONS:
This warranty only covers SimpliFire fireplaces that are purchased through a SimpliFire authorized dealer or distributor. A
list of SimpliFire authorized dealers is available on the SimpliFire websites.
WARRANTY EXCLUSIONS:
This warranty does not cover the following:
• Changes in surface finishes as a result of normal use. As a heating appliance, some changes in color of interior and
exterior surface finishes may occur. This is not a flaw and is not covered under warranty.
• Damage to printed, plated, or enameled surfaces caused by fingerprints, accidents, misuse, scratches, melted items,
or other external sources and residues left on the plated surfaces from the use of abrasive cleaners or polishes.
• Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts
include: paint, batteries and the discoloration of glass.
• Damages resulting from: (1) failure to install, operate, or maintain the appliance in accordance with the installation
instructions, operating instructions, and listing agent identification label furnished with the appliance; (2) shipping or
improper handling; (3) improper operation, abuse, misuse, continued operation with damaged, corroded or failed
components, accident, or improperly/ incorrectly performed repairs; (4) environmental conditions (5) installation or use
of components not supplied with the appliance or any other components not expressly authorized and approved by
HHT; (6) modification of the appliance not expressly authorized and approved by HHT in writing; and/or (7) interrup-
tions or fluctuations of electrical power supply to the appliance.
• Our obligation under this warranty does not extend to the SimpliFire fireplace’s capability to heat the desired space.
This warranty is void if:
• The fireplace is subject to or operated in atmospheres contaminated by chlorine, fluorine, or other damaging chemi-
cals.
• The fireplace is subjected to or operated in places with prolonged periods of dampness or condensation or weather.
Examples include but are not limited to outdoors, porches, and laundry rooms.
• There is any damage to the fireplace or other components due to water or weather damage.
LIMITATIONS OF LIABILITY:
• The owner’s exclusive remedy and SimpliFire’s sole obligation under this warranty, under any other warranty, express
or implied, or in contract, tort or otherwise, shall be limited to replacement, repair, or refund, as specified above. In no
event will SimpliFire be liable for any incidental or consequential damages caused by defects in the appliance. Some
states do not allow exclusions or limitation of incidental or consequential damages, so these limitations may not apply
to you. This warranty gives you specific rights; you may also have other rights, which vary from state to state.
EXCEPT TO THE EXTENT PROVIDED BY LAW, SIMPLIFIRE MAKES NO EXPRESS WARRANTIES OTHER THAN
THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION
OF THE EXPRESSED WARRANTY SPECIFIED ABOVE.
A. Warranty

5SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
Note: The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
MODELS: SF-INS30-BK
LABORATORY: CSA International
TYPE: Electric Air-Heaters; Fixed and Location-Dedicated
Electric Room Heaters
STANDARD: CSA C22.2 No 46-13; UL 2021 (4th Edition)
A. Appliance Certication
NOT INTENDED FOR USE AS A PRIMARY HEAT SOURCE.
This appliance is tested and approved as either supplemen-
tal room heat or as a decorative appliance. It should not be
factored as primary heat in residential heating calculations.
NOTICE: This installation must conform with local codes.
2 GENERAL INFORMATION
B. Unpacking and Inspecting Appliance
WARNING! DO NOT use this Electric Fireplace if any
part has been under water. Immediately call a qualied
service technician to inspect and to replace any part of
the electrical system if necessary. Keep plastic wrapping
away from children.
• Carefully remove the appliance and components from
the packaging. Discard packaging.
• Carefully inspect components for any damage.
• Reference parts and hardware list to verify all parts have
been received.
• Report to your dealer any missing or damaged parts.
• Read all the instructions before starting the installation.
Follow these instructions carefully during the installation
to ensure maximum safety and benet.
C. Model and Serial Number Information
The model and serial number information is located on
the rating plate. The rating plate is located on the upper
wall of the replace behind glass front.
SF-INS30-BK
Model Name: ___________________________________________ Date purchased/installed:__________________
Serial Number:__________________________________________ Location on replace: _____________________
Dealership purchased from: _______________________________ Dealer Phone: __________________________
Notes: _______________________________________________________________________________________
_____________________________________________________________________________________________
We recommend that you record the following pertinent
information about your replace.
Homeowner Reference Information
WARNING: This product can expose you to Di-
(2-ethylhexyl) phthalate, which is known to the
State of California to cause cancer and reproductive
harm. For more information go to: www.P65Warnings.
ca.gov.

SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
6
3 GETTING STARTED
Before beginning the installation be sure that the following
tools and building supplies are available.
Tape measure
Gloves
Phillips screwdriver
Level
B. Appliance Dimensions
C. Tools and Supplies Needed
Parts and Hardware List
Part Quantity
Appliance 1
Front 1
Instruction Manual 1
Remote Control 1
AAA Battery 2
Front/Rear Leveling Bracket 4
Screw ST4x8 8
A. Parts and Hardware
W3
H2
W4
H3
H1
D1
W2
D1
W1
MODEL
SHELL SIZE FRONT SIZE VIEWING AREA
D1 H1 W1 W2 W3 H2 W4 H3
SF-INS30-BK in. 11-7/8 20-1/2 29-7/8 22-7/8 33-1/8 21-7/8 27 18-1/8
mm 302 521 759 581 841 556 686 460
Figure 3.1 Appliance Dimensions

7SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
D. Location
Note: If this unit is installed in a bathroom, it must be
protected by GFI receptacle or circuit. If receptacle is
used it must be readily accessible. This electrical ap-
pliance is not water tight. To prevent electrical shock, it
must be installed as to prevent water from entering unit. It
must be installed away from showers, tubs, or other water
sources. Never locate the appliance where it may fall into
a bathtub or other water container.
When choosing a location for your replace ensure that
the general rules are followed:
• For best results, install out of direct sunlight.
• Power supply service must be installed within
proximity of electric replace prior to nishing to
avoid reconstruction.
• See Figure 3.1 for appliance dimensions and to
determine location of appliance installation.
E. Clearance to Combustibles
Reference Figure 4.1 for minimum chase dimensions
and clearance to combustibles.
Minimum Clearance to Combustibles
Sides.......................1/2 in
Floor...........................0 in
Top.......................1-1/8 in
Back...........................0 in
Front........................36 in
Mantels..........See Figure 3.2
WARNING! Risk of Fire! Keep electrical cords, drapery,
furnishings or other combustibles at least 3 ft. (0.9 m)
from the front of the electric replace.
NOTE: Do not pack insulation around the replace
blocking louvers.
F. Electrical Connection
WARNING! Risk of Fire, Electrical Shock and Injury!
Electrical wiring must comply with local building codes
and other applicable regulations to reduce the risk of
re, electrical shock and injury.
A 15 AMP, 120 Volt, 60 Hz circuit with a properly ground-
ed outlet is required.
The appliance is supplied with a power cord equipped
with NEMA-5-15P plug. An adapter must be used for
connecting to a two-slot receptacle (Figure 3.3). The
green grounding wire extending from the adapter must
be connected to a permanent ground such as a properly
grounded outlet box. The adapter should not be used if
a three slot grounded receptacle is available.
Grounding
Pin
Metal Screw
Cover of Grounded
Outlet Box
Grounding
Head
CBA
Figure 3.3 Cord Electrical Connection
WARNING! Risk of Fire, Electrical Shock and Injury!
Ensure the power cord is not installed so that it is pinched
or against a sharp edge and ensure that the power cord is
stored or secure to avoid tripping and snagging.
∞
NOTE: DO NOT OVERLAP SURROUND
WITH PERMANENT MANTEL OR OTHER
FINISHING MATERIALS. SURROUND AND
APPLIANCE MUST BE REMOVABLE IN
CASE FUTURE SERVICE IS REQUIRED.
MINIMUM VERTICAL = 0 in. from top
of surround. No limit to maximium
horizontal projection.
Figure 3.2 Mantel - Surround
Electrical Outlet Box
An outlet box may be installed in the existing solid fuel
masonry or factory built replace. The minimum chase
dimensions may need to be adjusted when planning this
installation. Alternatively, the supplied power cord may
be routed out through the bottom corner of the surround
to a nearby outlet.

SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
8
4 INSTALLATION
A. Minimum Fireplace Opening
When selecting a location for the appliance it is important to
consider the required clearances to walls (see Figure 4.1).
WARNING! Risk of Fire or Burns! Provide adequate
clearance around air openings and for service access.
Due to high temperatures, the appliance should be locat-
ed out of trafc and away from furniture and draperies.
NOTICE: Illustrations reect typical installations and are
FOR DESIGN PURPOSES ONLY. Illustrations/diagrams
are not drawn to scale. Actual installation may vary due to
individual design preference.
Height
Rear Width
Depth
Front Width
Figure 4.1 Clearance Requirements
MINIMUM CHASE DIMENSION
Location Inches Millimeters
A Rear Width 24 610
B Front Width 31 787
C Height 21-3/8 543
E Depth 11-1/2 292
B. Installation into Existing Fireplace
1. Seal all drafts with non-berous insulation materials to
prevent debris or water from falling from the chimney
to electric replace.
2. Close or seal off the chimney ue and close damper
(if applicable) to prevent rain inltration.
3. Do not install in an existing replace that is prone to
dampness.
4. A provision must be made for the appliance to be
connected to power within an existing rebox, or on
an adjacent wall.
Note: Minimum dimensions apply to both combustible and non-combustible construction.

9SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
C. Appliance Preparation
Install leveling brackets (4) by aligning them to the preset
holes at the base of the appliance. Use two (2) screws (ST4
x 8) per bracket to secure the appliance. See Figure 4.2.
Figure 4.2 Pre-drilled Hole Locations
PRE-DRILLED HOLES
LEVELING BRACKETS

SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
10
Figure 4.4 Surround Dimensions & Installation
D. Install Surround
The surround is required for the installation of this prod-
uct. The surround is designed to overlap the opening of
the existing replace or constructed chase.
1. Remove the surround and hardware from the packag-
ing.
2. Remove protective bag from the surround.
3. Remove the shipping bracket by removing the four
screws that attach the bracket to the surround. Keep
the four screws to use later to attach surround to
appliance. Discard the bracket. See Figure 4.3.
SCREW
(x4)
Lorem
31-1/8 in.
40 in.
20-3/4 in.
27 in.
7/8 in.
32 in.
31-1/8 in.
44 in.
20-3/4 in.
7/8 in.
4. Locate the surround on the appliance as shown in
Figure 4.4 and attach it to the appliance with four
screws removed in step 3.
Verify that the surround is securely attached to the
appliance. See Figure 4.4.
Height Width Depth
SF-S14027-BK in. 27 40 7/8
mm 686 1016 22
SF-S14432-BK in. 32 44 7/8
mm 813 1118 22
SHIPPING BRACKET
REMOVE AND RETAIN SCREWS
Figure 4.3 Shipping Bracket

11SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
F. Finishing
The surround is required for installation. The surround
can overlap both combustible and non-combustible wall
facing materials. Wall nishing materials, such as wood
or stone, can be installed up to the outer edge of the sur-
round. Wall or oor nishing materials cannot overlap
the front face of the surround. See Figure 4.4 for mantel
clearances.
∞
NOTE: DO NOT OVERLAP SURROUND
WITH PERMANENT MANTEL OR OTHER
FINISHING MATERIALS. SURROUND AND
APPLIANCE MUST BE REMOVABLE IN
CASE FUTURE SERVICE IS REQUIRED.
MINIMUM VERTICAL = 0 in. from top
of surround. No limit to maximium
horizontal projection.
Figure 4.4 Mantel - Surround
E. Installing Appliance
Once the leveling brackets and surround are securely
attached to the appliance, it can be t into the existing
replace or constructed chase.
1. Place a protective cover over the nished ooring in
front of the replace or wall opening.
2. Locate the appliance in front of the replace or wall
opening.
3. Connect the power cord to the receptacle if the
electrical service is located inside the existing replace
or constructed chase. The cord will need to be loosely
coiled inside the cavity along the right side of the
appliance.
4. If necessary, adjust leveling brackets to achieve
desired height.
5. Slide the appliance into the opening until the surround
contacts the wall.
6. Note any gaps between the surround and the wall.
Check for level. If necessary, adjust leveling brackets.
7. Slide the appliance from the opening and make
adjustments to the leveling brackets.
8. Repeat steps 5-7 until the appliance and surround
are ush and level, and cord is securely routed and
terminated to the receptacle.
Note: If the power supply is located outside the replace
or chase, the cord can be routed through the bottom cor-
ner of the surround to a nearby outlet.

SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
12
WARNING! Do not operate the unit if it is damaged or has
malfunctioned. If you suspect the unit is damaged, call
a qualied service technician to inspect and replace any
part of the electrical system if necessary.
Note: A harmless slight brief odor may occur during rst
use or after prolonged period of storage.
A. Manual Switch Function:
The appliance can be operated by both remote control
and manual button. Once the unit has been properly
connected to a grounded electrical circuit, the unit can
be turned ON by pressing the Flame button. In any ac-
tive Flame mode, the Heater button function is available.
If the Flame effect is OFF, there is no Heater button
function. See Figure 5.1.
Flame Button
By pressing the FLAME button, the unit will cycle
through four ame brightness levels.
Heater Button
- Press the heater button to turn ON. The appliance
will beep, illuminate one LED, and turn the heater on
LOW heat setting.
- Pressing a second time. The appliance will beep,
illuminate two LEDs, and turn the heater on HIGH heat
setting.
- Press a third time. The appliance will beep, no LED
will illluminate, and heater will turn OFF.
NOTE:
There is a brief delay between the heater command and
the heat turning ON. When the appliance receives a
heater ON command, the appliance blower will turn ON
for 10 seconds before the heater turns ON. There is
also an 10 second delay between heater off and blower
shutdown.
5 OPERATING INSTRUCTIONS
Red
Indication
Heater Button
Flame Button
Figure 5.1 Manual Switch and Indicator Light
NOTE: Two Red Indicator Lights
will display when on HIGH heat.

13SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
ICON TITLE FUNCTION REMOTE LCD
DISPLAY
FIREPLACE RESPONSE
POWER
The POWER button will turn the
replace on. It will also put the
replace in a standby mode.
This will turn off all functions at
once but will hold the settings in
memory except Heater function.
The unit will turn on at the same
settings by pressing the power
button again.
LED illuminates and
displays ame status
Icon and temperature
set point.
Fireplace emits single audible beep
to conrm command to transition to
ON or STANDBY state
FLAME
By pressing the FLAME button,
the unit will cycle through four
ame effects.
LED illuminates and
displays ame status
icon.
Fireplace emits single audible beep
to conrm command to transition
between four FLAME states.
HEATER
Press Heater button once heater
turns on heat setting 1. (LOW) One LED illuminates. Fireplace emits single audible beep to conrm command.
Press Heater button twice turns
heater on heat setting 2. (HIGH) Two LED’s illuminates. Fireplace emits single audible beep to conrm command.
Press Heater button again turns
heater OFF. No LED’s illuminate. Fireplace does not make audible beep.
THERMOSTAT
Pressing the Temperature button
adjusts the heater’s response
to the ambient temperature
conditions in the room.
Temperature adjusts from 16 °C
- 28 °C (60 °F - 82 °F). Power
button must be on to set from °C
to °F. Hold for 3 seconds and the
LED display from °C to °F.
Remote displays
the temperature. If
in Stand-by mode,
temperature displays
but cannot be
adjusted.
Fireplace emits single audible beep
to conrm command to change
desired temperature set point.
TIMER
Pressing the Timer button sets
the time desired for the replace
to run. The Timer can be set from
.5 hour up to 9 hours in 1 hour
increments.
Remote will display
the time setting
selected. If no timer
is set, there will be no
indicator.
Fireplace will emit single audible
beep to conrm command to
desired timer setting.
B. Operating by Remote Control
• Make sure batteries are properly installed in Remote
Control.
- Battery requirements 2 x AAA batteries
(included)
• The effective range of the remote is up to 13 ft.
• The remote control must be within the 13 ft. range and
also be pointed directly at the face of the appliance.
For best results, position the remote control within 45
degrees of the face of the appliance
C. Resetting Temperature Cutoff Switch
The heater is protected with a safety device to prevent
overheating. Should the heater overheat, an auto-
matic cutoff will turn the heater OFF. It will not turn ON
automatically without being reset. If it overheats for any
reason, it can be reset by:
1. Turn appliance to off
2. Unplug unit and wait 30 minutes
3. Plug in and turn on.
CAUTION: If appliance overheats repeatedly, discon-
tinue use and call customer / technical support.
CAUTION: If you need to continuously reset the heater,
unplug the appliance and call your customer/technical
support.

SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
14
A. Maintenance
WARNING! Risk of Shock! Always unplug the cord be-
fore moving or servicing. Do not immerse appliance in
water.
• Always turn OFF the appliance and disconnect the
cord from the electrical outlet before cleaning your
appliance.
• Light accumulated dust may be removed from the ap-
pliance with a soft cloth or vacuum cleaner.
• Wipe the exterior surfaces of the appliance occasion-
ally with a slightly damp cloth using a solution of mild
detergent and water. Dry thoroughly before operating
the appliance.
CAUTION! Do not allow water to run into the interior of
the appliance as this could create a re or electric shock.
Always disconnect electrical service before serving ap-
pliance.
• The fan motor is factory lubricated for life and will not
require further lubrication.
• Store appliance in a clean dry place when not in use.
WARNING! Risk of Fire! To reduce risk of re, do not
store or use gasoline or any other ammable vapors or
liquids in the vicinity of the appliance.
WARNING! Risk of Electrical Shock! Any other servic-
ing needed must be performed by an authorized service
technician. Do not attempt to service the unit yourself.
B. Cleaning
Cleaning Glass
Dust particles can be removed by bufng lightly with a
clean dry cloth. Fingerprints and other marks can be
cleaned with a cloth dampened with a quality household
glass cleaner. The glass should be completely dried with
a lint free cloth or paper towel. Do not use abrasive clean-
ers on glass surface. Do not spray liquids directly onto
any surface.
Metal Surface
Dust particles can be removed by bufng lightly with a
clean dry cloth. A damp cloth can be used to clean paint-
ed surfaces. Do not use abrasive cleaners. Do not spray
liquids directly on to any surface,
6 MAINTENANCE
C. Servicing
Except for installation and cleaning described in this man-
ual, an authorized service technician should perform any
other servicing.
WARNING! Risk of Electrical Shock! Any other servic-
ing needed must be performed by an authorized service
technician. Do not attempt to service the unit yourself.

15SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
Service Parts SF-INS30-BK
Beginning Manufacturing Date: Dec 2018
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer
or distributor. Hearth and Home Technologies does not sell directly to consumers.
Provide model number and serial number when requesting service parts from your dealer
or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Front FRONT-INS30
2 Front Glass GLA-INS30 Y
3 Log/Grate Assembly LOGS-INS30 Y
4 Remote REMOTE-INS30 Y
5 Heater Tray Assembly Control Board, Heater &
Fan Included HEATER-INS30 Y
6 Rotisserie (Rod, Motor, & Screws) ROTISS-INS30 Y
7 Flame Screen FLAME-INS30
8 LED Assembly Includes all LEDs LED-INS30 Y
Receiver RECEIVER-ELECT Y
Hardware Bag (Includes 2 leveling legs w/fasteners) HRDW-BI Y
12/18
30” Electric Insert Fireplace
#1 Front #2 Front Glass #3 Log/Grate
#4 Remote #5 Heater #6 Rotisserie
#7 Flame Screen #8 LED #9 Receiver
D. Service Parts List

SimpliFire • SF-INS30-BK • 2042-980 Rev. B • 12/18
16
SimpliFire, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
E. Contact Information
- NOTES -
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
________________________________________________________________________________
Printed in China - Copyright 2018
DO NOT DISCARD THIS MANUAL
NOTICE
• Leave this manual with
party responsible for use
and operation.
• Important operating
and maintenance
instructions included.
• Read, understand and follow
these instructions for safe
installation and operation.
Please contact your SimpliFire dealer or customer / technical support
(877-320-0730) with any questions or concerns.
For the location of your nearest SimpliFire dealer,
please visit www.hearthnhome.com.
