SimpliFire • SF-PP23, SF-PP26 Service Manual • 2040-909 • 8/13
SERVICE MANUAL
(Door Frame Glass Removal /Replacement)
Model: SF-PP23, SF-PP26
- Instructions -
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during
installation and service. Sheet metal edges are sharp.
Leave this manual with party responsible for use
and operation.
WARNING: If theinformation inthese
instructions is notfollowed exactly it may
result in personal injury and/or property
damage.
NOTICE! DO NOT discard this manual. Important service
and maintenance instructions included.
Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Pliers
Phillips screwdriver
Electric drill and bits (1/4 in.)
Safety glasses
Flat blade screwdriver
Door Frame Glass Removal / Replacement:
1. Remove unit from cabinet.
2. Access rear side of front flange of the sides and top
of the unit.
3. Remove 16 screws around top and side flange (4 on
top and 6 on each side). See Figure 1.
4. Remove damaged glass frame assembly. See Figure
2.
5. Align new glass frame assembly on the face of the
unit.
6. Attach the new glass frame by installing 16 screws
through the side and top flange.
7. Install unit into cabinet.
TOP - 4 SCREWS
BOTH SIDES
6 SCREWS
Figure 1
Figure 2
NOTICE! DO NOT discard any hardware while
servicing. It must be reused.
WARNING! Risk of Shock! Always unplug the cord
before moving or servicing.

SimpliFire • SF-PP23, SF-PP26 Service Manual • 2040-909 • 8/132
SimpliFire, a brand of Hearth & Home Technologies
7571 215th Street West, Lakeville, MN 55044
www.hearthnhome.com
Installation into Cabinet (Mounting Brackets)
1. Locate the securing hardware and mounting brackets.
See Figure 3.
2. Liftfireplaceintothe rearofthe finishedmantel andslide
forward into opening. See Figure 4
Figure 4 Installing Fireplace
3. Secure the fireplace into finished mantel by installing
brackets. Line up holes in brackets with holes in
mantel and secure each side with two screws.
See Figure 5.
Figure 5 Securing Fireplace
WARNING! Risk of Fire! Do not store or use gasoline
or other flammable vapors and liquids in the vicinity of the
heater.
Figure 3 Mounting Hardware
2 - Mounting Brackets
4 - Securing Screws
Please contact the SimpliFire customer/technical
support hotline at 877-320-0730 with any questions
or concerns.
