SIP CW2000 User manual

•
Technical data plate
HIGH PRESSURE CLEANER
WARNING: read the instructions carefully before use.
SIP CW2000

1 Handle
2 ON/OFF switch
3Detergent tank
4
Water outlet
5 High pressure hose
6 Gun
7 Lance
8a Nozzle
8b Turbo nozzle
8c Detergent nozzle
9 Electric cable
10 Water inlet + filter+ Quick hose fitting
DESCRIPTION OF THE MACHINE
2
1
10
67 5
8a
8b
8c
3
4
9
click
X1
X4
1. 2. 3. 6. 7.
4. 5.
OPTIONAL
click
click
click
click
X2
2

click
X1
X4
1. 2. 3. 6. 7.
4. 5.
OPTIONAL
click
click
click
click
X2
ASSEMBLY INSTRUCTIONS
Depending on the model, there are dierences in the scopes of delivery.
3

A
B
C
D
E
G
F
Optional
IN
OUT
1.
4.2. 3.
ON I
5.
2.
5÷40°C
Optional
1/2 inch 13 mm
CLICK!
15
30
45
60
1.
1. 2.
3.
IN
1 min
click
click
click
4

A
B
C
D
E
G
F
Optional
IN
OUT
1.
4.2. 3.
ON I
5.
2.
5÷40°C
Optional
1/2 inch 13 mm
CLICK!
15
30
45
60
1.
1. 2.
3.
IN
1 min
click
click
click
5

Click!
Click!
D
6
spread pattern/pencil jet
H
turbo lance
1.
2.
3.
L
Optional
2.1.
Optional
I
K
2.
3.
CLICK!
4C.3C.
N
OFF
1. 2. 3. 4.
M
4.
Optional

Use the hydrocleaner only if the hose is completely uncoiled and extended.
7
spread pattern/pencil jet
1.
2.
3.
L
Optional
2.1.
Optional
I
K
2.
3.
CLICK!
4C.3C.
N
OFF
1. 2. 3. 4.
M
4.
Optional
1.
2.
3.
L
Optional
2.1.
Optional
I
K
2.
3.
CLICK!
4C.3C.
N
OFF
1. 2. 3. 4.
M
4.
Optional
OPTIONALOPTIONAL
HIGH PRESSURE HOSE

Translation of the original instructions
EN
8
SAFETY PRECAUTIONS
> WARNINGS
• 01WARNING: This appliance is for outdoor use
only.
•02WARNING: Always disconnect the electricity
and water supplies on completion of every job.
•03WARNING: Do not use the machine if a supply
cord or important parts of the machine are dam-
aged, e.g. safety devices, high pressure hoses,
trigger gun.
•04WARNING: This appliance has been designed
for use with the detergent provided or the de-
tergent specied by the manufacturer, such as a
neutral shampoo based on biodegradable ani-
onic surface active detergents. The use of other
detergents or chemicals may put the appliance’s
safety at risk.
•05a WARNING: Do not use the machine within
range of persons unless they wear protective
clothing.
05b - Do not allow other people or animals within
a range of 5m when operating the machine.
05c - Always wear suitable protective clothing
in order to protect yourself against ricocheting
parts.
05d - Do not touch the plug and the appliance
with wet hands or when barefoot.
05e - Wear safety goggles and non-slip rubber
footwear.
•06WARNING: Do not direct the nozzle toward
mechanical parts containing lubricant grease, as
the grease will dissolve and spread over the sur-
rounding ground. Vehicle tyres/tyre valves may
only be cleaned from a minimum distance of 30
cm, otherwise the vehicle tyre/tyre valve could
be damaged by the high-pressure jet. The rst
indication of this is a discoloration of the tyre.
Damaged vehicle tyres/tyre valves can be deadly
dangerous.
•07WARNING: High pressure jets
can be dangerous if subject to mis-
use. The jet must not be directed at
persons, animal, live electrical equipment or the
machine itself.
•08WARNING: High pressure hoses, ttings
and couplings are important for the safety
of the machine. Use only hoses, ttings and
couplings recommended by the manufacturer.
GENERAL INFORMATION
>INTENDED USE
-The appliance can be used for washing surfaces
outdoors, whenever pressurised water is required
to remove dirt.
-With special optional accessories, it can be used
for foaming and sandingblasting, and for washing
with a rotary brush for application to the gun.
-This appliance’s performance and userfriendliness
make it suitable for NON PROFESSIONAL use.
> TECHNICAL DATA
(see technical data plate)
SYMBOLS
CAUTION! It is important to be careful of
the following items.
IMPORTANT
LOCKED
OPEN
IF PRESENT
Double insulated (IF PRESENT):
supplementary insulation is applied to
the basic insulation to protect against
electric shock in the event of failure of the
basic insulation.
INDEX ......................................................................... PAG.
PICTURES...................................................................... 17
GENERAL INFORMATION............................................... 8
SYMBOLS ......................................................................... 8
SAFETY PRECAUTIONS .................................................. 8
USAGE .............................................................................. 9
PUT INTO SERVICE / STARTING UP ............................. 11
CARE AND MAINTENANCE .......................................... 12
TROUBLESHOOTING .................................................... 12
DISPOSAL WEEE ........................................................ 12
WARRANTY CONDITIONS............................................ 13

EN
9
(it is extremely important to protect these
components against damage by avoiding their
improper use and protecting them against
bending, knocks and scratches).
•09WARNING: Appliances not equipped with
T.S. – Total Stop : must not be left in operation for
more than 2 minutes with the gun released. The
recycled water heats up considerably, seriously
damaging the pump.
•10WARNING: Appliances equipped with T.S.–
Total Stop : these appliances should not be left in
standby for more than 5 minutes.
•11WARNING: Switch the appliance o complete-
ly (master switch on (0)OFF) whenever it is left un-
attended.
•12WARNING: Every machine is tested in its oper-
ating conditions, so it is normal for a few drops of
water to be left inside it.
•13WARNING: Take care not damage the electric
cable. If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a haz-
ard
•13b WARNING: The power cord should not be
used to pull or lift the machine.
•14WARNING: Appliance with uid under pres-
sure. Keep a rm hold on the gun and be prepared
to take the kickback pressure. Only use the high
pressure nozzle provided with the appliance.
•16WARNING: This appliance is not intended for
use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge.
•17WARNING: Children should be supervised to
ensure that they do not play with the appliance.
•18WARNING: Never start the high-pressure
cleaner without rst completely unwinding the
high-pressure hose.
•19WARNING: When winding and unwinding the
pipe take care not to cause the high-pressure
cleaner to overturn.
•20WARNING: Before unwinding or winding the
hose, switch the machine o and release the pres-
sure in the hose itself (switching o).
•21WARNING: Risk of explosion — Do not spray
ammable liquids.
•22WARNING: To ensure machine safety, use only
original spare parts from the manufacturer or ap-
proved by the manufacturer.
•23WARNING: Do not direct the jet against your-
self or others in order to clean clothes or foot-
wear.
•WARNING:Water that has own through back-
ow preventers is considered to be non-potable.
• XX WARNING: the machine shall be disconnect-
ed from its power source, by removing the plug
from the socket-outlet, during cleaning or main-
tenance and when replacing spare parts
• XJ WARNING: If an extension cord is used, the
plug and socket must be of watertight construc-
tion.
• XY WARNING: Inadequate extension cords can
be dangerous.
> SAFETY DEVICE
•WARNING: the gun is tted with a safety catch.
Whenever use of the machine is interrupted it is
important to operate the safety catch to prevent
accidental activation of the jet.
- Safety features: gun equipped with safety locking
device, appliance equipped with (Class I) over-
load cutout, pump equipped with by-pass valve
or shutdown device.
- The safety button on the gun is not there to lock
the lever during operation, but to prevent its ac-
cidental operation.
•WARNING: The appliance is equipped with a mo-
tor protection device: in case of device interven-
tion, wait some minutes or, in alternative, discon-
nect and re-connect the product to the electric
system. In case this problem repeats again or if
the product does not start again, take the product
to the nearest After Sales Service Point
> STABILITY
•WARNING: The machine must be always kept on hori-
zontal bases, in a safe and stable way.
USAGE
> DESCRIPTION OF THE MACHINE
See the specic instructions manual provided.
> ASSEMBLY INSTRUCTIONS
See the specic instructions manual provided.
> WATER SUPPLY
Water supply collection
Water supply from the water main
-Connect a supply hose (not included) to the water
inlet of the unit and to the water supply.
-Open the water supply.
WARNING: (symbol) machine not suitable for
connection to the potable water mains.

EN
10
The cleaner can only be connected to the water
mains if the water mains is separated by a back-
ow preventer. Make sure that the hose is at least Ø
13mm-1/2 inch and that it is reinforced.
•WARNING: Water that has own through
backow preventers is considered to be
nonpotable.
IMPORTANT: Only clean or ltered water should
be used for intake. The delivery of the water
intake tap should be equal to the double of the
maximum pump range.
- Minimum delivery rate: 15 l/ min.
- Maximum intake water temperature: 40°C
- Max inlet water pressure: 1Mpa
Place the cleaner as close to the water supply system
as possible.
Water supply from an open container
-Unscrew the coupling part for the water inlet.
-Screw the suction hose with lter (not included)
onto the water connection of the unit.
-Hang the lter in the container.
-Vent the unit before operation.
-Unscrew the high-pressure line at the high-
pressure outlet of the unit.
-Switch on the unit and let it run until water free of
bubbles emerges at the high-pressure outlet.
-Switch o the unit and screw on the high-pressure
hose again.
Failure to comply with the above conditions causes
serious mechanical damage to the pump and the
loss of warranty cover.
> ELECTRICITY SUPPLY
- The appliance’s electrical connection must
comply with the IEC 60364-1 standard.
IMPORTANT: Before connecting the
appliance, make sure that the nameplate data are
the same as those of the electrical mains and that
the socket is protected by a dierential security
breaker with tripping sensitivity below 0.03 A - 30
ms.
- If the appliance’s plug is not compatible with the
socket, have the socket replaced with another of
suitable type by professionally qualied sta.
- Never use the appliance in ambient temperatures
below 0° C if it is equipped with a PVC (H VV-F)
cable.
•XY WARNING: Inadequate extension cords can
be dangerous.
•XJ WARNING: If an extension cord is used,
the plug and socket must be of watertight
construction.
Information for supply may also be obtained
from the plug manufacturer.
<16 A <25 A
<20 m ø 1,5 mm
2
- 14 AWG ø 2,5 mm
2
- 12 AWG
20 m - 50 m ø 2,5 mm
2
- 12 AWG ø 4,0 mm
2
- 10 AWG
> PLUG
HOW TO CONNECT THE CORD TO A U.K. PLUG:
IMPORTANT The wires in the mains lead are
coloured in accordance with the following code:
Blue Neutral
Brown Live
Yellow/Green Earth
Please read the instructions given below before con-
necting the cord to a plug. If in doubt please consult
a qualied electrician. As the colours of the wires in
the mains lead of this appliance may not correspond
with the coloured markings identifying the termi-
nals in your plug, proceed as follows:
The wires that is coloured Brown must be connected
to the terminal which is marked with the letter L or
coloured Red. The wire that is coloured Blue must be
connected to the terminal which is marked with the
letter N or coloured Black.
Safety points for rewireable or moulded plug:
The mains lead of this appliance may be already
tted with a BS1363 13A plug.
- If your socket outlet is not suitable for the plug,
then the plug must be removed (cut o if it is a
moulded on plug), the exible cord insulation
should be stripped back as appropriate and a
suitable 3 pin plug tted.
•
WARNING: Dispose of
a plug that has been
cut from the power
supply cord, as such
a plug is hazardous
if inserted in a live
13A socket outlet
elsewhere in the
house.
- Should the fuse
need to be replaced
an ASTA marked fuse,
approved to BS1362, of the same rating must be
used.
- Always replace the fuse cover after tting a fuse.

EN
11
The plug must NOT be used if the cover is omitted
or lost until a replacement is obtained.
- Make certain that only the correct fuse cover is
used and tted.
- For plugs with detachable fuse cover the
replacement must be the same as the colour
insert in the base of the plug, or as directed by the
embossed wording on the base of the plug.
- If the detachable fuse cover is lost a replacement
may be purchased from a Service Centre.
PUT INTO SERVICE / STARTING
UP
See g. A
- Connect the high pressure hose to the trigger gun.
- Push the high pressure hose into the trigger gun.
Note: Make sure the connection nipple is aligned
correctly.
- Check the secure connection by pulling on the
high pressure hose.
See g. B
- Insert the high pressure hose tightly into the quick
coupling on the appliance
See g. C
- Screw the coupling element to the water
connection on the appliance.
- Attach the water supply hose to the coupling on
the water connection.
NOTE: The supply hose is not included.
- Connect the water supply hose to the water
supply.
- Completely open the water tap.
- Insert the mains plug into the socket.
- Turn on the appliance “I/ON”.
See g. D
- Unlock the lever on the trigger gun.
- Pull on the lever of the trigger gun; the device will
switch on.
- Switch the appliance on for a (max. of 1 minute)
and wait until the water exits at the hand spray
gun without bubbles.
- Release the lever on the trigger gun.
NOTE: Release the lever of the trigger gun; the
device will switch o again.
- High pressure remains in the system.
See g. E
- Lock the lever on the trigger gun.
Operation
See g. F
- Push the spray lance into the trigger gun and fasten
it by turning it through 90°.
- Unlock the lever on the trigger gun.
See g. G
- Pull on the lever of the trigger gun; the device will
switch on.
•14WARNING: Appliance with uid under pres-
sure. Keep a rm hold on the gun and be prepared
to take the kickback pressure.
See g.H
> HIGH PRESSURE LANCE
See g.I
> DETERGENT SUCTION
See g.L
> HIGH PRESSURE HOSE
Use the hydrocleaner only if the hose is completely
uncoiled and extended.
See g. M
> SWITCHING OFF
T.S. Total Stop ( if tted)
NOTE: Total Stop, which stops the machine
during the bypass phase. To start the water
cleaner, it is therefore necessary to set the switch
on position (I)“ON”; after that press the pistol
trigger: the Total Stop will start the machine
and will stop it automatically when the trigger is
released. It is advisable to put on the safety of the
pistol trigger whenever the machine is stopped,
in order to avoid unintentional starting.
-Any automatic start of the machine without
pressing the gun trigger is attributable to air
bubbles in the water or other similar phenomena
which do not imply the existence of any defects in
the machine.
-Do not leave the appliance unattended during
the standby for more than 5 minutes. Contrarily,
for the safety of the appliance it is necessary to
re-turn the switch into the (0) OFF position.

EN
12
-Please check that the coupling of the high
pressure hose with the appliance and the gun
supplied as standard equipment made correctly,
that is to say without any water leak.
CARE AND MAINTENANCE
See g. N
The unit is maintenance-free.
• XX WARNING: the machine shall be discon-
nected from its power source, by removing the
plug from the socket-outlet, during cleaning or
maintenance
• WARNING: Do not spray the appliance with water
and do not use detergents or aggressive solvents.
Machine could be damaged.
-Clean the exterior part of the machine with a dry cloth.
> STORAGE
See g. N
- Move the machine only by grasping the carrying
handle
- Store the appliance and the accessories in a frost-
safe room.
TROUBLESHOOTING
Appliance does not work
-Check whether the voltage shown on the rating
plate corresponds to that of the power source.
-Check the connector cable for damage.
Appliance does not reach operational pressure
-Vent the appliance: allow the pump to operate
without the high-pressure hose until water
appears at the high-pressure outlet without any
more bubbles. Then reattach the high-pressure
hose.
-Clean the strainer in the water connection.
-Clean the lter placed inside the hose coupling (if
set)
-Check the inlet water ow rate.
-Check all inlet pipes to the pump for leaks or
blockage.
Strong pressure uctuations
-Clean the high-pressure nozzle. Remove dirt from
the nozzle hole with a needle and then rinse out
with water from the front.
Pump leaks
-10 drops per minute are permissible. In the case
of more serious leakage, you should contact the
authorized customer service.
Replacement parts
-Use only original spare parts or spare parts
suggested by the manufacturer.
DISPOSAL WEEE
As the owner of electrical or electronic
equipment, the law (in accordance with
the EU Directive 2012/19/EU on waste from
electrical and electronic equipment and
the national laws of the EU Member States
that have implemented this Directive) prohibits
you from disposing of this product or its electrical /
electronic accessories as municipal solid waste and
obliges you to make use of the appropriate waste
collection facilities.The product can be disposed of
by returning it to the distributor when a new prod-
uct is purchased. The new product must be equiva-
lent to that being disposed of. Disposing of the
product in the environment can cause great harm to
the environment itself and human health.
The symbol in the gure indicates the urban waste
containers and it is strictly prohibited to dispose of
the equipment in these containers. Non-compliance
with the regulations stipulated in the Directive
2012/19/EU and the decrees implemented in the
various EU Member States is administratively pun-
ishable.

1,5 m/s2
K (uncertainty)
0,5 m/s2
• SIP warrants its products for 12 months
from the date of purchase.
• In accordance with the above-mentio-
ned terms, SIP agrees to furnish free of
charge any replacement parts for such
parts as, in the Manufacturer's opinion
or that of their authorized representa-
tive, are defective either in material or
manufacture. In any case transport and
labour costs shall be charged to the cu-
stomer.
• The product returned to SIP or au-
thorized representative for warranty
inspection or repair must be sent back
together with each single part the unit
is complete with and must not have
been improperly damaged. SIP will
otherwise decline all responsibility for
any warranty claims.
• The warranty does not include any
payment for faults due to incorrect usa-
ge by the operator and for parts falling
within the usual maintenance, such as:
Gaskets, diaphragms sealing rings, oil
and so on.
• The Manufacturer shall not be held re-
sponsible for accidents to the operator
or third parties while the equipment is
in use.
• This warranty shall not be valid if:
a) previous service or repairs were per-
formed by unauthorized
individuals or companies.
b) the equipment was previously re-
paired with non-original parts.
• Breakdowns and failures in our ma-
chines during or after the warranty
period, do not grant any right to su-
spend payments for the goods delive-
red which have already been agreed
to. Nor can such breakdowns and fai-
lures be used to excuse further delay
in such payments.
• The Manufacturer reserves the right
at any time to carry out any and all
changes to improve his products. Nor
shall he be obliged by this to add such
improvements to units previously ma-
nufactured, already consigned or in
the process of installation.
• These general conditions of warran-
ty hereby substitute and nullify every
previous condition expressed or impli-
cit.
WARRANTY CONDITIONS
Arm vibrations
13

EU - DECLARATION OF CONFORMITY
We
SIP (Machinery Europe) Ltd
ASM Chartered Accountants
First Floor, Block One,
Quayside Business Park
Dundalk
County Louth
Republic of Ireland
As The Manufacturer's Authorised
Representative Declare that the
Conforms to the requirements of the following Directive/s, as indicated.
And the relevant harmonised standard/s, including:
EN 55014-1:2006+A1:2009+A2:2011
EN 61000-3-2:2014
61000-3-3:
EN 61000-3-3:2013
EN 60335-2-79
EN 60335-1
Tigren Hot Wash 6000 Compact pressure
washer
Part No. 08980
Name: Mr Paul Ippaso
Position: Director
Suppliers Model Type: P86.0197
Max Flow: 9,5 l/min
Net Installed Power: 3000 W
(02/2019) 7.700.0535-00
EN 60335-1
EN 60335-2-79
EN 62233:2008
EN 50581
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:2015
EN 61000-3-3:2014.
EN 61000-3-3:2013.
2006/42/EC Machinery Direcve
2009/127/EC
EMC Direcve2014/30/EU
2011/65/EU RoHS Direcve
2014/14/EC Outdoor Noise Direcve
2005/88/EC
The appliance is dened at no.27 of the annex I. Conformity evaluaon procedure
according to annex V.
Measured Sound Pressure Measured Sound Power
87dB(A) 100.8dB(A)
Uncertainty Granted Sound Power
0.7dB(A) 102dB(A)
The technical file is kept at:
SIP Industrial Products Ltd Loughborough Leicestershire LE12 9NH UK
SIP CW2000 Pressure Washer
Part No. 08970
Suppliers Model type: P80.0613
Max Flow: 6 l/min
Net Installed Power: 2000 W
Measured Sound Pressure Measure Sound Power
74 dB(A) 86,7 dB(A)
Uncertainty Granted Sound Power
2,54 dB(A) 90 dB(A)
14

EU - DECLARATION OF CONFORMITY
We
SIP (Machinery Europe) Ltd
ASM Chartered Accountants
First Floor, Block One,
Quayside Business Park
Dundalk
County Louth
Republic of Ireland
As The Manufacturer's Authorised
Representative Declare that the
Conforms to the requirements of the following Directive/s, as indicated.
And the relevant harmonised standard/s, including:
EN 55014-1:2006+A1:2009+A2:2011
EN 61000-3-2:2014
61000-3-3:
EN 61000-3-3:2013
EN 60335-2-79
EN 60335-1
Tigren Hot Wash 6000 Compact pressure
washer
Part No. 08980
Name: Mr Paul Ippaso
Position: Director
Suppliers Model Type: P86.0197
Max Flow: 9,5 l/min
Net Installed Power: 3000 W
(02/2019) 7.700.0535-00
EN 60335-1
EN 60335-2-79
EN 62233:2008
EN 50581
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:2015
EN 61000-3-3:2014.
EN 61000-3-3:2013.
2006/42/EC Machinery Direcve
2009/127/EC
EMC Direcve2014/30/EU
2011/65/EU RoHS Direcve
2014/14/EC Outdoor Noise Direcve
2005/88/EC
The appliance is dened at no.27 of the annex I. Conformity evaluaon procedure
according to annex V.
Measured Sound Pressure Measured Sound Power
87dB(A) 100.8dB(A)
Uncertainty Granted Sound Power
0.7dB(A) 102dB(A)
The technical file is kept at:
SIP Industrial Products Ltd Loughborough Leicestershire LE12 9NH UK
UK - DECLARATION OF CONFORMITY
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer within the UK, England,
Scotland & Wales, declare that the
Conforms to the requirements of the following Directive/s, as indicated.
And the relevant harmonised standard/s, including:
Part No. 08980
Suppliers Model Type: P86.0197
Max Flow: 9,5 l/min Net Installed Power: 3000 W
(02/2019) 7.700.0535-00
Supply of Machinery (Safety) Regulations 2008
BS EN 61000-3-3:2013.
Name: Mr Paul Ippaso
Position: Director
BS EN 61000-3-2:2014.
BS EN 55014-2:2015
BS EN 55014-1:2006+A1:2009+A2:2011
BS EN 50581
BS EN 62233:2008
BS EN 60335-2-79
BS EN 60335-1
Electromagnetic Compatibility Regulations 2016
Noise Emission in the Environment by Equipment for use Outdoors Regulations 2001
The Restriction of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment Regulations 2012
Tigren Hot Wash 6000 Compact pressure
washer
Measured Sound Pressure Measured Sound Power
87dB(A) 100.8dB(A)
Uncertainty Granted Sound Power
0.7dB(A) 102dB(A)
The technical file is kept at:
SIP Industrial Products Ltd Loughborough Leicestershire LE12 9NH UK
Measured Sound Pressure Measure Sound Power
74 dB(A) 86,7 dB(A)
Uncertainty Granted Sound Power
2,54 dB(A) 90 dB(A)
SIP CW2000 Pressure Washer
Part No. 08970
Suppliers Model type: P80.0613
Max Flow: 6 l/min
Net Installed Power: 2000 W
15

cod. 7.100. 2261-02 07/2021
16
