Siqura HSD820H3EXP User manual

HSD820H3EXP
Explosion-protected high-speed 1080p IP PTZ dome camera
Installation Manual

Note: To ensure proper operation, please read this manual thoroughly before using the
product and retain the information for future reference.
Copyright © 2016 Siqura B.V.
All rights reserved.
HSD820H3EXP
Installation Manual v2 (150909-2)
AIT55
Nothing from this publication may be copied, translated, reproduced, and/or published by
means of printing, photocopying, or by any other means without the prior written permission
of Siqura.
Siqura reserves the right to modify specifications stated in this manual.
Brand names
Any brand names mentioned in this manual are registered trademarks of their respective
owners.
Liability
Siqura accepts no liability for claims from third parties arising from improper use other than
that stated in this manual.
Although considerable care has been taken to ensure a correct and suitably comprehensive
description of all relevant product components, this manual may nonetheless contain errors
and inaccuracies. We invite you to offer your suggestions and comments by email via
[email protected]. Your feedback will help us to further improve our documentation.
How to contact us
If you have any comments or queries concerning any aspect related to the product, do not
hesitate to contact:
Siqura B.V.
Zuidelijk Halfrond 4
2801 DD Gouda
The Netherlands
General : [phone]
Fax : [phone]
E-mail : [email protected]
WWW : www.siqura.com
2

Contents
1 About this manual ..................................................................................... 4
2 Safety information .................................................................................... 5
2.1 Safety ................................................................................................ 5
2.2 Cautions ............................................................................................. 7
3 Product description ................................................................................... 9
3.1 Models ............................................................................................... 9
3.2 Operation requirements ........................................................................ 9
3.3 Package contents ................................................................................. 9
3.4 Dimensions ......................................................................................... 10
4 Camera setup ............................................................................................ 11
4.1 Connector definition ............................................................................. 11
4.2 Connect to power ................................................................................ 12
4.3 Connect to network .............................................................................. 12
4.4 Establish a network connection .............................................................. 13
4.5 Access the webpages ........................................................................... 14
4.6 Connect audio ..................................................................................... 14
4.7 Connect alarm inputs and outputs .......................................................... 15
Index ...................................................................................................... 16
3

1 About this manual
What this manual covers
This manual describes how to install the HSD820H3EXP, Siqura's explosion-protected, high-
speed 1080p IP PTZ dome camera. For configuration and operation instructions, refer to the
User Manual. For the Technical Specifications, refer to the HSD820H3EXP datasheet.
Download the latest version of the datasheet and all related manuals from www.siqura.com.
Who should read this manual
This manual is intended for technicians involved in the installation of HSD820H3EXP cameras.
What you should already know
To be able to install and connect the HSD820H3EXP properly, you should have adequate
knowledge and skills in the following fields.
● CCTV systems and components
● Electrical wiring and low-voltage electrical connections
● Hazardous environments and ATEX regulations
● Ethernet network technologies and Internet Protocol (IP)
● Video, audio, and contact closure transmissions
● Video compression methods
● Windows environments
● Web browsers
Before you start
We advise you to read and observe all instructions and warnings in this manual before you
continue. Keep this manual with the original bill of sale for future reference and warranty
service. When you unpack your product, check for missing or damaged items. If any item is
missing, or if damage is evident, do not install or operate this product. Contact your supplier
for assistance.
Important: The supplied manuals listed below are the governing documents. They must be
followed to the letter by the installer.
- 53-XCC-5_B User Manual TNXCC DNV
- Bartec CE DoC HSD626EXP series TEC-15-ATEX-SIQURA-01-A
- DNV-2004-OSL-ATEX-0115-1
Why specifications may change
At Siqura, we are committed to delivering high-quality products and services. The information
given in this manual was current when published. As we continuously seek to improve our
products and user experience, all features and specifications are subject to change without
notice.
We like to hear from you!
Customer satisfaction is our first priority. We welcome and value your opinion about our
products and services. Should you detect errors or inaccuracies in this manual, we would be
grateful if you would inform us. We invite you to offer your suggestions and comments via
[email protected]. Your feedback helps us to further improve our documentation.
4

2 Safety information
This chapter presents the HSD820H3EXP safety instructions and cautions.
In This Chapter
2.1 Safety................................................................................................................... 5
2.2 Cautions................................................................................................................7
2.1 Safety
The safety information contained in this section, and on other pages of this manual, must be
observed whenever this unit is operated, serviced, or repaired. Failure to comply with any
precaution, warning, or instruction noted in the manual is in violation of the standards of
design, manufacture, and intended use of the module. Siqura assumes no liability for the
customer's failure to comply with any of these safety requirements.
Trained personnel
Installation, adjustment, maintenance, and repair of this equipment should conform to all
local codes and should be performed by trained and qualified personnel with adequate
expertise in hazardous area practice and ATEX requirements. For correct and safe use of the
equipment and in order to keep the equipment in a safe condition, it is essential that both
operating and servicing personnel follow standard safety procedures in addition to the safety
precautions and warnings specified in this manual, and that this unit be installed in locations
accessible to trained service personnel only.
Safety requirements
The equipment described in this manual has been designed and tested according to the
UL/IEC/EN 60950-1 safety requirements.
Warning: If there is any doubt regarding the safety of the equipment, do not put it into
operation.
This might be the case when the equipment shows physical damage or is stressed beyond
tolerable limits (for example, during storage and transportation).
Important: Before opening the equipment, disconnect it from all power sources.
The equipment must be powered by a SELV1 power supply. This is equivalent to a Limited
Power source (LPS, see UL/IEC/EN 60950-1 clause 2.5) or a "NEC Class 2" power supply.
When this module is operated in extremely elevated temperature conditions, it is possible for
internal and external metal surfaces to become extremely hot.
1. SELV: conforming to IEC 60950-1, <60 Vdc output, output voltage galvanically isolated
from mains. All power supplies or power supply cabinets available from Siqura comply with
these SELV requirements.
5

Do not exceed the ratings given in the Technical Specifications
Make sure that the power source is appropriate before you plug in and operate the unit. Use
the unit under conditions where the temperature remains within the range given in the
Technical Specifications of this product. You can download the HSD820H3EXP datasheet at
www.siqura.com.
Optical safety
The following optical safety information applies to HSD820H3EXP models with SFP interface.
This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to
Laser Notice No. 50, dated June 24, 2007. This optical equipment contains Class 1M lasers or
LEDs and has been designed and tested to meet IEC 60825-1:1993+A1+A2 and IEC
60825-2:2004 safety class 1M requirements.
Warning: Optical equipment presents potential hazards to testing and servicing personnel,
owing to high levels of optical radiation.
When using magnifying optical instruments, avoid looking directly into the output of an
operating transmitter or into the end of a fiber connected to an operating transmitter, or there
will be a risk of permanent eye damage. Precautions should be taken to prevent exposure to
optical radiation when the unit is removed from its enclosure or when the fiber is disconnected
from the unit. The optical radiation is invisible to the eye.
Use of controls or adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
The installer is responsible for ensuring that the label depicted below (background: yellow;
border and text: black) is present in the restricted locations where this equipment is installed.
EMC
This device has been tested and found to meet the CE regulations relating to EMC and
complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation. These limits
are designed to provide reasonable protection against interference to radio communications in
any installation. The equipment generates, uses, and can radiate radio frequency energy;
improper use or special circumstances may cause interference to other equipment or a
performance decrease due to interference radiated by other equipment. In such cases, the
user will have to take appropriate measures to reduce such interactions between this and
other equipment.
Any interruption of the shielding inside or outside the equipment could make the equipment
more prone to fail EMC requirements.
Non-video signal lines must use appropriate shielded Cat 5 cabling (S-FTP), or at least an
equivalent. Ensure that all electrically connected components are carefully earthed and
protected against surges (high voltage transients caused by switching or lightning).
ESD
Electrostatic discharge (ESD) can damage or destroy electronic components. Proper
precautions should be taken against ESD when opening the equipment.
Safety information
6

RoHS statement
Global concerns over the health and environmental risks associated with the
use of certain environmentally-sensitive materials in electronic products have
led the European Union (EU) to enact the Directive on the Restriction of the
use of certain Hazardous Substances (RoHS) (2002/95/EC). Siqura offers
products that comply with the EU’s RoHS Directive. The full version of the
Siqura RoHS statement can be viewed at www.siqura.com.
Product disposal
The unit contains valuable materials which qualify for recycling. In the
interest of protecting the natural environment, properly recycling the unit at
the end of its service life is imperative.
When processing the printed circuit board, dismantling the lithium battery
calls for special attention. This kind of battery, a button cell type, contains so
little lithium, that it will never be classified as reactive hazardous waste. It is
safe for normal disposal, as required for batteries by your local authority.
2.2 Cautions
Handle the camera carefully
Do not abuse the camera. Avoid bumping and shaking. The camera can be damaged by
improper handling or storage.
Do not disassemble the camera
To prevent electric shock, do not remove screws or covers. There are no user serviceable
parts inside. Consult technical support if a camera is suspected of malfunctioning.
Do not use strong or abrasive detergents to clean the camera
Use a mixture of water and Isopropyl alcohol to clean the camera when it is dirty. To clean the
lens, wipe gently with a lens tissue or use a cotton tipped applicator. Do not clean the lens
with strong detergents.
Never face the camera towards the sun
Do not aim the camera at bright objects. Whether the camera is in use or not, never aim it at
the sun or other extremely bright objects, as this can damage the camera.
Reduce the risk of ignition of hazardous atmospheres
To reduce the risk of ignition of hazardous atmospheres, disconnect the equipment from the
supply circuit before opening. Keep assembly tightly closed when operating. Conduit runs
must have a sealing fitting connected within 2 inches of the enclosure.
Warning: TO REDUCE THE RISK OF IGNITION DO NOT OPEN WHEN AN EXPLOSIVE GAS
ATMOSPHERE MAY BE PRESENT.
Safety information
7

Reduce the risk of electric shock
To reduce the risk of electric shock, do not perform any servicing other than contained in the
operating instructions unless you are qualified to do so.
Install electrical wiring carefully
Ask a qualified electrician to perform the wiring for the installation. For power specifications,
refer to the Technical Specifications given in the datasheet of this product. Ground the camera
appropriately to prevent electric shock or damage. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
Safety information
8

3 Product description
The HSD820H3EXP camera is a networked high-speed PTZ dome camera designed to endure
in extremely harsh environments. This chapter introduces the HSD820H3EXP and its features.
In This Chapter
3.1 Models.................................................................................................................. 9
3.2 Operation requirements...........................................................................................9
3.3 Package contents....................................................................................................9
3.4 Dimensions.......................................................................................................... 10
3.1 Models
HSD820H3EXP Ex 316L 1080p PTZ dome camera, 30x zoom
● Explosion-protected for use in onshore,
offshore, marine, and heavy industrial
applications
● Full HD 1080p resolution
● Quad stream H.264/H.264 or H.264/MJPEG
● 30x Optical zoom / 12x Digital zoom
● Day/Night with IR-cut filter / WDR / BLC
● 316L Stainless steel construction
● 360° Continuous rotation
● 400°/s Preset targeting
● 256 Presets / 8 Programmable cruises
● IP66/IP67 Ingress rating
HSD820H3EXP
3.2 Operation requirements
A minimum of one control device is required for operation, such as a control keyboard, a DVR,
or a PC. The HSD820H3EXP contains a built-in receiver that decodes commands originating
from a control device.
Select one of the built-in protocols to provide connectivity to other surveillance systems and
allow the HSD820H3EXP to be integrated with the surveillance system.
3.3 Package contents
Before proceeding, verify that the box contains the items listed here. If any item is missing or
has defects, do not install or operate the product. Contact your supplier for assistance.
9

Printed product documentation:
- 53-XCC-5_B User Manual TNXCC DNV
- Bartec CE DoC HSD820EXP series TEC-15-ATEX-SIQURA-03-A
- DNV-2004-OSL-ATEX-0115-1
- HSD820H3EXP Supplementary Installation Information
- Network connector installation leaflet
- Safety instructions leaflet
Explosion-proof housing with
dome body inside
SFP connector
3.4 Dimensions
Product description
10

4 Camera setup
This chapter gives information about the HSD820H3EXP connector locations and definitions.
Note: Mechanical camera installation is described in these printed documents:
- 53-XCC-5_B User Manual TNXCC DNV
- Supplementary Installation Information
In This Chapter
4.1 Connector definition.............................................................................................. 11
4.2 Connect to power..................................................................................................12
4.3 Connect to network............................................................................................... 12
4.4 Establish a network connection............................................................................... 13
4.5 Access the webpages.............................................................................................14
4.6 Connect audio...................................................................................................... 14
4.7 Connect alarm inputs and outputs........................................................................... 15
4.1 Connector definition
Connectors on the back plate of the HSD820H3EXP
11

Connector Definition
A RJ-45
B Alarm I/O (including BNC output on pins 9 and 10)
C Power
D microSD card slot
E Factory reset button
F Audio I/O
To restore the factory default settings of the camera
● Hold button E until you hear the lens initialise (IR cut filter, zoom, and focus).
This takes about 20 seconds.
The camera's pan/tilt initialisation indicates a successful hardware reset.
Important: Do not perform these steps during camera initialisation. Only restore factory
defaults when the camera is fully operational.
4.2 Connect to power
Refer to the illustration below to connect the power core through the supplied power adapter.
Pin Definition
1 AC 24_1
2 FG
3 AC 24_2
HSD820H3EXP power connector
4.3 Connect to network
Ethernet connection
The use of Cat 5 cable is recommended for Ethernet network connections. To have the best
transmission quality, cable length should not exceed 100 metres. Connect one end of the
Ethernet cable to the RJ-45 connector on the camera and plug the other end of the cable into
the network switch or PC.
Note: For direct connection of the camera to a PC you may need to use an Ethernet
crossover cable.
Verify Ethernet connectivity
Check the status of the link indicator and activity indicator LEDs. Check the LAN connection if
the LEDs are unlit.
Camera setup
12

Ethernet socket LEDs green/yellow
Green on/off : 100/10 Mbit
Yellow on/blink : link OK, active
Yellow off/flash : link down, TX attempt
4.4 Establish a network connection
The webpages of the HSD820H3EXP provide a convenient way of accessing its settings. You
can log on to the web interface of the HSD820H3EXP from a PC which is on the same subnet
as the unit. Follow the steps below to open communication with the HSD820H3EXP and
configure its network settings.
Step 1: Set the network adapter of the PC to the factory-set subnet of the
HSD820H3EXP and then connect the two devices to the network.
Step 2: Access the unit from a web browser or other tool installed on the PC.
Step 3: Set the IP address and subnet mask of the HSD820H3EXP to the subnet
that it is going to be used in and reboot the unit.
To address the unit from the same PC again, configure the network adapter of the PC once
more to assign the PC to the same subnet as the unit.
Step 1: Set the PC to the factory-set subnet of the unit
To configure the network adapter on the PC
1 In Control Panel, open Network and Sharing Center.
2 Select the connection to be configured, and then click Properties.
3 On the items list, select Internet Protocol Version 4 (TCP/IPv4).
4 Click Properties.
5 In the Internet Protocol Version 4 (TCP/IPv4) Properties dialog box, click Use the
following IP address.
6 Enter an IP address which assigns your PC to the same subnet as the HSD820H3EXP -
that is, within the 10.x.x.x range. Use 255.0.0.0 as a subnet mask.
Important: To prevent conflicts, be sure to choose a unique IP address. No two
devices on a network can have the same IP address.
7 To apply the new settings, click OK.
Camera setup
13

Setting the IP settings of the PC to the factory-set IP settings of the unit
At this point, connect your PC to the HSD820H3EXP. You can connect them directly using a
crossover cable, or connect both to a switch.
Step 2: Access the unit
Using a standard web browser you can now log on to the web server of the HSD820H3EXP.
Step 3: Change the network settings of the unit
The Network page enables you to make the network addressing of the unit compatible with
the network it will be added to. You can set a fixed IP address or have the IP address assigned
by a DHCP server. In the latter case, open the Advanced Settings and enable DHCP. Do not
forget to save and reboot the unit after changing the settings.
4.5 Access the webpages
Once you have established a network connection to the HSD820H3EXP, you can log on to the
camera and open its webpages using a standard web browser, Siqura Device Manager
(available for download at www.siqura.com/support-files) or UPnP. For more information, see
the User Manual.
4.6 Connect audio
Use the pin definition below to set up audio.
Camera setup
14

Pin Definition
1 Line Out
2 GND
3 Line In
HSD820H3EXP audio connector
4.7 Connect alarm inputs and outputs
Use the pin definition below for alarm system wiring.
Pin Definition Pin Definition
1 ALARM_OUT_NO_1 7 ALARM_OUT_COM_2
2 ALARM_OUT_NC_1 8 GND
3 ALARM_OUT_COM_1 9 VIDEO_GND
4 GND 10 VIDEO_OUT
5 ALARM_OUT_NO_2 11 ALARM_IN_2
6 ALARM_OUT_NC_2 12 ALARM_IN_1
HSD820H3EXP Alarm I/O connector
Camera setup
15

Index
A
About this manual.................................... 4
Access the webpages.............................. 14
C
Camera setup........................................ 11
Cautions................................................. 7
Connect alarm inputs and outputs.............15
Connect audio........................................ 14
Connect to network.................................12
Connect to power................................... 12
Connector definition................................11
D
Dimensions............................................10
E
Establish a network connection.................13
M
Models.................................................... 9
O
Operation requirements............................ 9
P
Package contents..................................... 9
Product description................................... 9
S
Safety.....................................................5
Safety information....................................5
16
