Siqura hsdpa Series User manual

HSD820 Series
Full HD IP speed dome camera
User Manual

Note: To ensure proper operation, please read this manual thoroughly before using the
product and retain the information for future reference.
Copyright © 2015 Siqura B.V.
All rights reserved.
HSD820
User Manual v2 (142703-2)
AIT55
Nothing from this publication may be copied, translated, reproduced, and/or published by
means of printing, photocopying, or by any other means without the prior written permission
of Siqura.
Siqura reserves the right to modify specifications stated in this manual.
Brand names
Any brand names mentioned in this manual are registered trademarks of their respective
owners.
Liability
Siqura accepts no liability for claims from third parties arising from improper use other than
that stated in this manual.
Although considerable care has been taken to ensure a correct and suitably comprehensive
description of all relevant product components, this manual may nonetheless contain errors
and inaccuracies. We invite you to offer your suggestions and comments by email via
[email protected]. Your feedback will help us to further improve our documentation.
How to contact us
If you have any comments or queries concerning any aspect related to the product, do not
hesitate to contact:
Siqura B.V.
Zuidelijk Halfrond 4
2801 DD Gouda
The Netherlands
General : [phone]
Fax : [phone]
E-mail : [email protected]
WWW : www.siqura.com
2

Contents
1 About this manual ..................................................................................... 6
2 Safety and compliance .............................................................................. 7
2.1 Safety ................................................................................................ 7
2.2 Cautions ............................................................................................. 9
2.3 Compliance ......................................................................................... 10
3 Product overview ...................................................................................... 11
3.1 Models ............................................................................................... 11
3.2 Description ......................................................................................... 12
4 Access the webpages ................................................................................ 14
4.1 System requirements ........................................................................... 14
4.2 Connect via web browser ...................................................................... 14
4.3 Find the unit with Siqura Device Manager ................................................ 15
4.4 Change the network settings with Siqura Device Manager ......................... 16
4.5 Log on to the unit ................................................................................ 17
4.6 Install Siqura Viewer ............................................................................ 18
4.7 The HSD820 web interface .................................................................... 18
5 Home ........................................................................................................ 20
5.1 Overview ............................................................................................ 20
5.2 Features ............................................................................................. 21
5.3 PTZ Panel ........................................................................................... 23
6 System settings ........................................................................................ 24
6.1 System .............................................................................................. 25
6.1.1 Host name ...................................................................................... 25
6.1.2 Time zone ....................................................................................... 25
6.1.3 Daylight saving time ........................................................................ 25
6.1.4 Time format .................................................................................... 26
6.1.5 Time synchronisation ....................................................................... 26
6.2 Security ............................................................................................. 26
6.2.1 User ............................................................................................... 27
6.2.1.1 Admin password ....................................................................... 27
6.2.1.2 Adding and managing user accounts ............................................ 27
6.2.1.3 Streaming Authentication Setting ................................................ 28
6.2.2 HTTPS ............................................................................................ 29
6.2.2.1 Create a self-signed certificate .................................................... 30
6.2.2.2 Create and install a signed certificate ........................................... 30
6.2.3 IP filter ........................................................................................... 31
6.2.4 IEEE 802.1X .................................................................................... 32
6.2.4.1 CA certificate ............................................................................ 32
6.2.4.2 Client certificate and private key ................................................. 32
6.3 Network ............................................................................................. 33
6.3.1 Basic .............................................................................................. 33
6.3.1.1 Acquiring an IP address automatically .......................................... 33
6.3.1.2 Modify the fixed IP address ........................................................ 34
6.3.1.3 Use PPPoE ................................................................................ 35
6.3.1.4 Advanced settings ..................................................................... 35
6.3.1.5 IPv6 address configuration ......................................................... 35
6.3.2 QoS ............................................................................................... 36
3

6.3.3 SNMP ............................................................................................. 37
6.3.4 UPnP .............................................................................................. 39
6.4 DDNS ................................................................................................. 40
6.5 Mail ................................................................................................... 41
6.6 FTP .................................................................................................... 42
6.7 HTTP .................................................................................................. 43
6.8 Events ............................................................................................... 43
6.8.1 Application ...................................................................................... 44
6.8.1.1 Alarm trigger actions ................................................................. 45
6.8.1.2 Specifying file name conventions ................................................. 47
6.8.2 Motion Detection ............................................................................. 48
6.8.2.1 Motion detection area ................................................................ 50
6.8.2.2 Motion detection window ............................................................ 50
6.8.3 Network Failure Detection ................................................................. 51
6.8.4 Periodical event ............................................................................... 52
6.8.5 Manual trigger ................................................................................. 53
6.8.6 Audio detection ............................................................................... 54
6.9 Storage management ........................................................................... 55
6.9.1 SD Card ......................................................................................... 55
6.9.2 Network Share ................................................................................ 57
6.10 Recording ........................................................................................... 59
6.11 Schedule ............................................................................................ 60
6.12 File location ........................................................................................ 61
6.13 View information ................................................................................. 61
6.13.1 Log file ........................................................................................... 62
6.13.2 User Information ............................................................................. 63
6.13.3 Parameters ..................................................................................... 64
6.14 Factory default .................................................................................... 65
6.15 Software version ................................................................................. 66
6.16 Software upgrade ................................................................................ 66
6.17 Maintenance ....................................................................................... 67
7 Video and Audio Streaming ....................................................................... 69
7.1 Video format ....................................................................................... 69
7.1.1 Video resolution ............................................................................... 70
7.1.2 Video rotate type ............................................................................. 70
7.1.3 GOV Settings .................................................................................. 70
7.1.4 H.264 Profile ................................................................................... 71
7.2 Video compression ............................................................................... 71
7.3 Video text overlay ................................................................................ 72
7.4 Video stream protocol .......................................................................... 74
7.5 Video frame rate ................................................................................. 75
7.6 Audio ................................................................................................. 75
8 PTZ&IMAGE ............................................................................................... 77
8.1 Preset ................................................................................................ 77
8.2 Cruise ................................................................................................ 79
8.3 Autopan ............................................................................................. 80
8.4 Sequence ........................................................................................... 81
8.5 Home ................................................................................................. 83
8.6 Tilt Range ........................................................................................... 84
8.7 Privacy Mask ....................................................................................... 85
8.8 Camera - Exposure .............................................................................. 86
8.9 Camera - WB ...................................................................................... 87
8.10 Camera - Misc 1 .................................................................................. 89
8.11 Camera - Misc 2 .................................................................................. 90
Contents
4

8.12 Camera - Profile .................................................................................. 92
8.13 Camera - Default ................................................................................. 93
Appendix: Enable UPnP ............................................................................. 94
Appendix: Delete the existing Siqura Viewer software .............................. 95
Appendix: Set Up Internet Security ........................................................... 96
Appendix: NTCIP Configuration ................................................................. 97
Supported conformance groups ............................................................. 97
Configuration .................................................................................. 97
CCTV configuration .......................................................................... 98
Motion control ................................................................................. 98
SNMP MIB .......................................................................................... 99
Index ...................................................................................................... 100
Contents
5

1 About this manual
What this manual covers
This manual applies to the HSD820 series, Siqura's full HD IP speed dome cameras.
It explains:
● How to communicate with the unit
● How to operate the unit
● How to adjust the unit's settings
For instructions on camera installation and establishing connections, see the separate Quick
Start Guide and Installation Manual provided with each HSD820 series model.
Who should read this manual
This manual is intended for technicians and operators involved in the configuration and
operation of HSD820 cameras.
What you should already know
Adequate knowledge and skills in the following fields are recommended when working with
this product:
● Basic understanding of camera technologies
● CCTV systems and components
● Ethernet network technologies and Internet Protocol (IP)
● Windows environments
● Web browsers
● Video, audio, data, and contact closure transmissions
● Video compression methods
Before you continue
Before you continue, read and obey all instructions and warnings in this manual. Keep this
manual with the original bill of sale for future reference and, if necessary, warranty service.
When you unpack your product, make sure there are no missing or damaged items. If any
item is missing, or if you find damage, do not install or operate this product. Contact your
supplier for assistance.
Why specifications may change
At Siqura, we are committed to delivering high-quality products and services. The information
given in this manual was current when published. As we continuously seek to improve our
products and user experience, all features and specifications are subject to change without
notice.
We like to hear from you!
Customer satisfaction is our first priority. We welcome and value your opinion about our
products and services. Should you detect errors or inaccuracies in this manual, we would be
grateful if you would inform us. We invite you to offer your suggestions and comments via
[email protected]. Your feedback helps us to further improve our documentation.
6

2 Safety and compliance
This chapter provides cautions on what to do and what not to do when working with or
handling your HSD820 unit. It also offers information on product compliance with
environmental regulations and explains how to dispose of the product at the end of its service
life.
In This Chapter
2.1 Safety................................................................................................................... 7
2.2 Cautions................................................................................................................9
2.3 Compliance.......................................................................................................... 10
2.1 Safety
The safety information contained in this section, and on other pages of this manual, must be
observed whenever this unit is operated, serviced, or repaired. Failure to comply with any
precaution, warning, or instruction noted in the manual is in violation of the standards of
design, manufacture, and intended use of the module. Siqura assumes no liability for the
customer's failure to comply with any of these safety requirements.
Trained personnel
Installation, adjustment, maintenance, and repair of this equipment are to be performed by
trained personnel aware of the hazards involved. For correct and safe use of the equipment
and in order to keep the equipment in a safe condition, it is essential that both operating and
servicing personnel follow standard safety procedures in addition to the safety precautions
and warnings specified in this manual, and that this unit be installed in locations accessible to
trained service personnel only.
Safety requirements
The equipment described in this manual has been designed and tested according to the
UL/IEC/EN 60950-1 safety requirements. See the CE Declaration of Conformity for
compliance information.
Warning: If there is any doubt regarding the safety of the equipment, do not put it into
operation.
This might be the case when the equipment shows physical damage or is stressed beyond
tolerable limits (for example, during storage and transportation).
Important: Before opening the equipment, disconnect it from all power sources.
The equipment must be powered by a SELV1 power supply. This is equivalent to a Limited
Power source (LPS, see UL/IEC/EN 60950-1 clause 2.5) or a "NEC Class 2" power supply.
When this module is operated in extremely elevated temperature conditions, it is possible for
internal and external metal surfaces to become extremely hot.
1. SELV: conforming to IEC 60950-1, <60 Vdc output, output voltage galvanically isolated
from mains. All power supplies or power supply cabinets available from Siqura comply with
these SELV requirements.
7

Power source and temperature ratings
Verify that the power source is appropriate before you plug in and operate the unit. Use the
unit under conditions where the temperature remains within the range given in the Technical
Specifications of this product.
Optical safety
The following optical safety information applies to HSD820 models with SFP interface.
This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to
Laser Notice No. 50, dated June 24, 2007. This optical equipment contains Class 1M lasers or
LEDs and has been designed and tested to meet IEC 60825-1:1993+A1+A2 and IEC
60825-2:2004 safety class 1M requirements.
Warning: Optical equipment presents potential hazards to testing and servicing personnel,
owing to high levels of optical radiation.
When using magnifying optical instruments, avoid looking directly into the output of an
operating transmitter or into the end of a fiber connected to an operating transmitter, or there
will be a risk of permanent eye damage. Precautions should be taken to prevent exposure to
optical radiation when the unit is removed from its enclosure or when the fiber is disconnected
from the unit. The optical radiation is invisible to the eye.
Use of controls or adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
The installer is responsible for ensuring that the label depicted below (background: yellow;
border and text: black) is present in the restricted locations where this equipment is installed.
EMC
This device has been tested and found to meet the CE regulations relating to EMC and
complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause undesired operation. These limits
are designed to provide reasonable protection against interference to radio communications in
any installation. The equipment generates, uses, and can radiate radio frequency energy;
improper use or special circumstances may cause interference to other equipment or a
performance decrease due to interference radiated by other equipment. In such cases, the
user will have to take appropriate measures to reduce such interactions between this and
other equipment.
Any interruption of the shielding inside or outside the equipment could make the equipment
more prone to fail EMC requirements.
Non-video signal lines must use appropriate shielded Cat 5 cabling (S-FTP), or at least an
equivalent. Ensure that all electrically connected components are carefully earthed and
protected against surges (high voltage transients caused by switching or lightning).
ESD
Electrostatic discharge (ESD) can damage or destroy electronic components. Proper
precautions should be taken against ESD when opening the equipment.
Safety and compliance
8

RoHS statement
Global concerns over the health and environmental risks associated with the
use of certain environmentally-sensitive materials in electronic products have
led the European Union (EU) to enact the Directive on the Restriction of the
use of certain Hazardous Substances (RoHS) (2002/95/EC). Siqura offers
products that comply with the EU’s RoHS Directive. The full version of the
Siqura RoHS statement can be viewed at www.siqura.com.
Product disposal
The unit contains valuable materials which qualify for recycling. In the
interest of protecting the natural environment, properly recycling the unit at
the end of its service life is imperative.
When processing the printed circuit board, dismantling the lithium battery
calls for special attention. This kind of battery, a button cell type, contains so
little lithium, that it will never be classified as reactive hazardous waste. It is
safe for normal disposal, as required for batteries by your local authority.
2.2 Cautions
Handle the camera carefully
Do not abuse the camera. Avoid bumping and shaking. The camera can be damaged by
improper handling or storage.
Do not disassemble the camera
To prevent electric shock, do not remove screws or covers. There are no user serviceable
parts inside. Consult technical support if a camera is suspected of malfunctioning.
Do not block the cooling vent
This camera has a cooling fan inside. Blocking the cooling holes may lead to overheating and
cause malfunction. Overheating is not covered by warranty.
Never face the camera towards the sun
Do not aim the camera at bright objects. Whether the camera is in use or not, never aim it at
the sun or other extremely bright objects, as this can damage the camera.
Do not expose indoor models to moisture
The indoor camera model is designed for indoor use or use in locations where it is protected
from rain and moisture. Turn the power off immediately if the camera is wet and ask a
qualified technician for servicing. Moisture can damage the camera and also create the danger
of electric shock.
Safety and compliance
9

Do not use strong or abrasive detergents to clean the camera
Use a dry cloth to clean the camera when it is dirty. If the dirt is hard to remove, use a mild
detergent and wipe gently. To clean the lens, use lens tissue or a cotton tipped applicator and
ethanol. Do not clean the lens with strong detergents.
2.3 Compliance
Safety and compliance
10

3 Product overview
This chapter introduces the HSD820 models and their features.
In This Chapter
3.1 Models.................................................................................................................11
3.2 Description...........................................................................................................12
3.1 Models
HSD820H2 full HD IP speed dome camera, 20x zoom
● Full HD 1080p resolution
● Quad stream H.264/H.264 or H.264/MJPEG
● 20x Optical zoom / 8x Digital zoom
● Optical output / Analogue output options
● Day/Night with IR-cut filter / WDR / BLC
● 360° Continuous rotation
● 400°/s Preset targeting
● 256 Presets / 8 Programmable cruises
● Two alarm inputs / Two alarm outputs
● Two-way audio
● 16 Privacy masks
● ONVIF Profile S
HSD820H2-I
(indoor model)
HSD820H2-E
(outdoor model)
HSD820H3 full HD IP speed dome camera, 30x zoom
● Full HD 1080p resolution
● Quad stream H.264/H.264 or H.264/MJPEG
● 30x Optical zoom / 12x Digital zoom
● Optical output / Analogue output options
● Day/Night with IR-cut filter / WDR / BLC
● 360° Continuous rotation
● 400°/s Preset targeting
● 256 Presets / 8 Programmable cruises
● Two alarm inputs / Two alarm outputs
● Electronic Image Stabilisation
● Two-way audio
● 16 Privacy masks
● ONVIF Profile S
● NTCIP protocol support
HSD820H3-E
(outdoor model)
11

HSD820H3EXP explosion-protected full HD IP PTZ dome camera
● Explosion-protected for use in onshore,
offshore, marine, and heavy industrial
applications
● Full HD 1080p resolution
● Quad stream H.264/H.264 or H.264/MJPEG
● 30x Optical zoom / 12x Digital zoom
● Day/Night with IR-cut filter / WDR / BLC
● 360° Continuous rotation
● 400°/s Preset targeting
● 256 Presets / 8 Programmable cruises
● Two alarm inputs / Two alarm outputs
● IP66/IP67 Ingress rating
● Electronic Image Stabilisation
● Two-way audio
● 16 Privacy masks
● ONVIF Profile S
● NTCIP protocol support
HSD820H3EXP
3.2 Description
Multistream high definition
The HSD820 series cameras have quad-stream capability for simultaneous streaming of H.
264/H.264 or H.264/MJPEG. Full HD 1080p streaming with a D1 second stream or dual 720p
streaming is possible. Multiple combinations of resolution and frame rate can be configured to
satisfy different live viewing and recording scenarios.
Open standards
Siqura provides multiple options to easily integrate the HSD820 series cameras with a video
management system (VMS). In support of open standards, the HSD820 cameras are
compliant with the ONVIF Profile S specification as well as the Siqura Open Streaming
Architecture (OSA) HTTP API.
High-speed dome
The HSD820 series cameras have a 20x (H2 model) or 30x (H3 model) auto focus zoom lens.
Precision 400° per second pan and tilt drive technology offers almost instant preset
positioning. Support for many presets, cruises, and sequences provides for highly flexible
manual or automatic operation.
Day/Night, Backlight Compensation, and Wide Dynamic Range
The HSD820 series cameras provide automatic day/night functionality, for use in low light
situations. Backlight compensation enhances image visibility in difficult lighting conditions.
Wide dynamic range solves the problem of overlit images by combining the best of two
pictures with different exposure settings.
Image stabiliser
The HSD820H3 has a built-in image stabiliser to prevent vibrations from disrupting a camera
view or footage, such as those caused by wind in pole-mount installations.
Product overview
12

Privacy masks
Through the camera's web interface, administrators can configure privacy masks to conceal
sensitive areas, such as point-of-sale keypads in retail or ATM applications as well as windows
or other exposed areas appearing in city centre surveillance situations.
Audio and I/O contacts
The HSD820 series cameras combine streaming video with duplex audio, balanced audio
inputs/outputs suitable for all industrial audio systems, and I/O contacts over IP.
Fiber option
A fiber option is available for direct connection of fiber to the camera via a flexible SFP
interface. The XSNet™ range of SFP modules, with options for both single mode and
multimode is available. The SFP interface is built into the camera itself so a wide range of
mounting options is available.
NEMA TS 2
The HSD820H3 has been tested and approved according to the NEMA TS 2 standard.
Product overview
13

4 Access the webpages
The webpages of the HSD820 offer a user-friendly interface for configuring the settings of the
unit and viewing live video images over the network. This chapter explains how to connect to
the built-in web server.
In This Chapter
4.1 System requirements............................................................................................ 14
4.2 Connect via web browser....................................................................................... 14
4.3 Find the unit with Siqura Device Manager.................................................................15
4.4 Change the network settings with Siqura Device Manager...........................................16
4.5 Log on to the unit................................................................................................. 17
4.6 Install Siqura Viewer............................................................................................. 18
4.7 The HSD820 web interface..................................................................................... 18
4.1 System requirements
To connect to the HSD820, access its webpages, and view live video over the network, make
sure that your PC meets the following requirements.
Component Minimum requirement
Personal computer ● Intel® Pentium® IV, 3 GHz or higher, Intel® Core2 Duo, 2 GHz
or higher
● 1 GB RAM or more
● AGP graphics card 64 MB RAM, DirectDraw
Operating system Windows 7
Web browser Internet Explorer 6.0 or later, Firefox, Chrome, Safari
Network interface
card
10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer ActiveX control plug-in for Microsoft IE
4.2 Connect via web browser
To connect to the unit via your web browser
1 Open your web browser.
2 Type the IP address of the HSD820 in the address bar, and then press ENTER.
The factory-set IP address of the HSD820 is in the 10.x.x.x range. You will find it printed
on a sticker on the unit.
If your network configuration is correct you are directed to the login page of the unit.
14

Type the IP address of the HSD820 in the address bar of the browser
Note: A hard reset sets the IP address of the camera to its factory-default setting (see
above).
4.3 Find the unit with Siqura Device Manager
With Siqura Device Manager - a tool included on the supplied Siqura Product CD - you can
locate, manage, and configure Siqura IP cameras and video encoders.
Note: Siqura Device Manager is also available for download at www.siqura.com.
To install Siqura Device Manager
1 Insert the supplied Siqura Product CD into your CD drive.
2 Browse to the Siqura Device Manager folder.
3 Double-click the setup file.
4 Follow the installation steps to install Siqura Device Manager.
Install Siqura Device Manager from the supplied CD
To connect to the unit via Siqura Device Manager
1 Start Siqura Device Manager
The network is scanned.
Detected devices appear in the List View pane.
2 If multiple network adapters exist, select the appropriate adapter to scan the network
that you wish to connect to.
3 To perform a manual search, click the Rescan button.
4 Use the tabs in the Tree View pane to define the scope of your search.
5 Click the column headings in the List View pane to sort devices by type, IP address, or
name.
6 To connect to the webpages of the HSD820, double-click its entry in the device list,
Access the webpages
15

- or -
Right-click the entry, and then click Open Web Page.
The login page of the HSD820 is opened in your web browser.
Connect to a device via Siqura Device Manager
4.4 Change the network settings with Siqura Device
Manager
With Siqura Device Manager, you can directly change the network settings of the HSD820.
To assign a static IP address
1 Go to the list of detected devices, and then right-click the entry for the HSD820.
2 Click Change Network Settings.
3 In Change Network Settings, click Static IP.
4 Provide the camera with an appropriate IP address, netmask, and gateway address for
the desired network configuration, and then click OK.
5 In the pop-up window indicating that you have successfully changed the settings, click
OK.
6 Wait one minute, and then rescan the network.
7 To access the webpages of the HSD820, double-click its entry in the list of found
devices.
Access the webpages
16

Assign a static IP address
To assign a DHCP server
1 Record the HSD820's MAC address (see the Serial no. column in Siqura Device Manager)
for future identification
2 In the list of detected devices, right-click the device with the network property that you
would like to change.
3 Click Change Network Settings.
4 In Change Network Settings, click Enable DHCP, and then click OK.
5 In the pop-up window indicating that you have successfully changed the settings, click
OK.
6 Wait one minute, and then rescan the network.
You can identify the device by its MAC address.
7 To access the webpages of the HSD820, double-click its entry in the list of found
devices.
Note: A DHCP server must be installed on the network in order to provide DHCP network
support.
4.5 Log on to the unit
Users with a valid account for the HSD820 can log on to the unit.
To log on
1 In the Authentication box, log on with the account that was created for you.
User name and password are case sensitive.
The default user name set at the factory for the HSD820 is "Admin" with password
"1234".
2 Click Log In.
Note: To prevent unauthorised access from people using the default account, we
recommend that the administrator changes the default password after first login and creates
separate user accounts as needed.
Access the webpages
17

4.6 Install Siqura Viewer
The first time you access the webpages of the camera, you may be prompted about the
installation of Siqura Viewer. This add-on is required to view camera images in the webpages.
The Siqura Viewer installation file is named install.cab. It does not give rise to any security
risks. You can install it safely.
Important: You are strongly advised to remove a previous installation of Siqura Viewer
from your computer before you initially access the camera over the network or when you
encounter an "A new version is available" message. For more information, see Appendix:
Delete the existing Siqura Viewer software.
Note: Make sure that the security settings of your web browser permit the use of ActiveX
controls. For more information on how to modify these settings, see Appendix: Set up
Internet Security.
To install the Siqura Viewer software
1 When prompted about the ActiveX control installation, allow the Siqura Viewer
installation wizard to make changes to your computer.
2 In the initial screen of the installation wizard, click Next.
A progress bar is displayed while the application is being installed.
3 When installation is complete, click Finish.
The camera’s web interface is displayed.
Siqura Viewer installation wizard
4.7 The HSD820 web interface
On successful login, the home page of the HSD820 is displayed. Camera settings and
functions are organised on five tabs found across the top of this page: Home, System,
Streaming, PTZ&IMAGE, and Logout.
Access the webpages
18

Home
On the Home page (see "Home" on page 20), you can watch a live video stream from the
camera and see stream details.
System
From the System tab (see "System" on page 25), administrators can view and configure
system, security, and network related settings, and upgrade the embedded software.
Streaming
From the Streaming tab (see "Video and Audio Streaming" on page 69), administrators can
set video and audio formats and compression parameters.
PTZ&IMAGE
From the PTZ&IMAGE tab (see "PTZ&IMAGE" on page 77), users can program preset points,
cruise lines, autopan paths, and sequence lines via PTZ controls, and adjust various camera
parameters such as Auto Exposure (AE), White Balance (WB), Back Light Compensation
(BLC), Sharpness, and Exposure Compensation.
Logout
The Logout option logs the user off of the camera webpages and reopens the logon page.
Access the webpages
19

5 Home
This chapter gives an overview of the actions that you can perform from the home page of the
camera:
● View live video
● Control PTZ functions
● Record live view images
● Save snapshots of live view images
● Adjust the video display size
● Select the video format
● Communicate with a remote site
● See details about the current video and audio
● Select a display language for the webpages
In This Chapter
5.1 Overview............................................................................................................. 20
5.2 Features.............................................................................................................. 21
5.3 PTZ Panel............................................................................................................ 23
5.1 Overview
HSD820 home page
20
