SKF ATEX RA Series User manual

Version 01
951-180-082-EN
EN
Operating instructions
according to ATEX Directive 2014/34/EU
ATEX multiline pumps of series RA

Jürgen Kreutzkämper
Manager R&D Germany
Stefan Schürmann
Manager R&D Hockenheim/Walldorf
EU Declaration of Conformity pursuant to ATEX Directive 2014/34/EU, Annex X
The manufacturer, SKF Lubrication Systems Germany GmbH, Hockenheim Plant, 2. Industriestr. 4, DE - 68766 Hockenheim hereby de-
clares the conformity of the device:
Designation: Multiline pumps
Type: RA...EEX
Part number: 750-***-*
Year of manufacture: See rating plate
Explosion protection marking:
II 2G Ex h IIC T4 Gb / II 2D Ex h IIIC T135°C Db
with all essential safety and health requirements of ATEX Directive 2014/34/EU as well as the basic safety and health requirements protec-
tion requirements of Machinery Directive 2006/42/EC specified below at the time of placing on the market.
1.1.2 · 1.1.3 · 1.3.2 · 1.3.4 · 1.5.6· 1.5.8 · 1.5.9 · 1.6.1 · 1.7.1 · 1.7.3 · 1.7.4
The technical documentation pursuant to:
ATEX Directive 2014/34/EU Annex VIII No. 2 has been prepared and filed with the conformity assessment body.
- Machinery Directive 2006/42/EC Annex VII Part B.
We undertake to transmit these in electronic form in response to a reasoned request by the national authorities. The Head of Technical
Standards is the authorized representative for the technical documentation. See the manufacturer information for the address.
Furthermore, the following Directives and (harmonized) standards were applied in the applicable areas:
2014/30/EU EMC Directive | Industrie / 2011/65/EU RoHS II
Standard Edition Standard Edition Standard Edition Standard Edition
EN ISO 80079-36 2016 EN 1127-1 2011 DIN EN 809 2012 EN ISO 12100 2010
EN ISO 80079-37 2016 DIN EN 60204-1 2007 DIN EN 60034-1 2011
The device must not be put into service until the machinery into which it is to be incorporated has been declared in conformity with the
provisions of ATEX Directive 2014/34/EU, Machinery Directive 2006/42/EC, and all other applicable Directives.
Hockenheim, September 17, 2018
- 2 -
951-180-082-EN
Version 01
EN EU Declaration of Conformity
