SkyLink WIRELESS SWITCH SW-18 User manual

1. INTRODUCTION
Skylink®Wireless Switch Model SW-18
In this package, you will find a keychain transmitter with 12V alkaline
battery and a wireless switch receiver.
4. REMOVE TRANSMITTER FROM THE RECEIVER
6. BATTERY
There are 2 buttons on your transmitter, the other
button can be used to control another Skylink®Garage
Door Receiver Model 18R (sold separately) or Skylink®
Wireless Switch Receiver Model SW-18R (sold
separately).
7. ADDITIONAL RECEIVER
You can add up to 15 transmitters as you want to control
the same receiver. Simply program the transmitters to the
receiver. Skylink®offers Keychain Transmitter Model 18T4
tow ork with your receiver. For more information, please visit
our website at www.skylinkhome.com or contact us.
8. ADDITIONAL TRANSMITTER
12 volt alkaline battery (size 23A)
(included).
It is time to change the battery
when the red LED on the
transmitter does not turn on when
either button is pressed.
If, within one year from date of purchase, this product should become defective
(except battery), due to faulty workmanship or materials, it will be repaired or
replaced, without charge. Proof of purchase and a Return Authorization are required.
11. WARRANTY
12. CUSTOMER SERVICE
9. CAUTION
10. FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However,thereis noguaranteethat interference will not occur in a particular installation. If this equipment does
causeharmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
RISK OF ELECTRICAL SHOCK. FOR INDOOR USE ONLY.
CAUTION : NOT FOR USE WITH DIMMER. DISCONNECT POWER BEFORE
SERVICING.
Maximum Rating :
Input : 120VAC 60Hz
Resistive : 8A (960W)
Incandescent : 300 watts
Motor Load : 1/3 HP
If you would like to order Skylink’s products or have difficulty getting them to work,
please :
1. visit our FAQ section at www.skylinkhome.com , or
2. email us at [email protected], or
3. call our toll free at 1-800-304-1187 from Monday to Friday, 9 am to 5 pm
EST. Fax [phone]
CUSTOMER SERVICE
17 Sheard Avenue, Brampton, Ontario, Canada L6Y 1J3
Email:[email protected]
http://www.skylinkhome.com
P/N. 101A289-001 Rev.1
US Patent. D380895
©2005 SKYLINK GROUP
Wireless Switch
Receiver
Keychain Transmitter
(Battery inside)
The transmitter in this kit has been programmed to the receiver in the
factory. You need to do the programming only if you add additional
transmitters to the receiver.
Plug the receiver into an electrical socket.
Press and hold the learn button on the left hand side of the receiver.
The red LED on the receiver will flash.
Simultaneously, press your assigned button (either button A or B) of
the transmitter you want to program to the receiver.
Thereceiver redLED will go
off indicates the programming
is completed.
To program the transmitter
to control another receiver,
repeat process (1) to (4)
but pressing another button
(A or B).
3. PROGRAM A TRANSMITTER TO THE RECEIVER
5. OPERATION
To activate the receiver, simply press the appropriate button on the
transmitter, it will activate the plugged in device. Pressing it again will turn
off the plugged in device.
2
1
3
4
5
Plug the receiver into a powered, 120VAC electrical outlet inside your
house. (Note: This receiver is designed to be used indoor only. Do not
use this receiver in an outdoor environment.)
Once the receiver is plugged into an electrical
outlet, the red LED on the front of the unit will
be “on” indicating the unit is in standby mode.
Plug in the light fixture or small appliance
that you would like to control into the
receiver, as shown.
If there is a power switch on the plugged
in light fixture or small appliance, please
turn it on. The receiver is ready to be
activated.
Pressing the appropriate button will
turn on the plugged in device and the
red LED on the front will flash.
(Caution: When the red LED on the
unit is flashing, that means output
outlet is powered. Do not disconnect /
connect devices from / to the receiver’s
outlet when the red LED is flashing.)
1
2
3
4
5
2. INSTALLATION
Button A
Button B
Learn Button
You can delete the transmitter from a receiver.
Unplug the receiver from the electrical socket.
Press and hold the learn button on the left hand side of the receiver
when plugging the receiver into an electrical socket, the red LED on the
receiver will flash rapidly. All the transmitters are deleted.
