1. Introducon
1.1 Safety
When not properly used this equipment is a potenally dangerous machine. Maintenance,
servicing, cleaning or any other operaon shall be made by trained people. Plug has to be
o outlet during any of these operaons.
Below instrucons shall be respected to avoid accidents :
1.1.1 Read completely these instrucons
1.1.2 To avoid to risk electric shocks and damage to the equipment never use it with wet
clothes or shoes and/or standing on wet oors. Do not plunge it into water nor any other
liquid, do not spray water directly to the equipment.
1.1.3 When the equipment is in operaon the operator shall supervise it, principally when
children might be near
1.1.4 Unplug the equipment when :
It is not in use, before to clean it, before to remove or to place some accessory. before
maintenance or any other service .
1,1,5 Do not operate the equipment if the cord or plug are damaged. Do not lean the cord
on table edges , nor let them lie on hot surfaces.
1.1.6 When the equipment may have fall , have been damaged any way, or simply does not
work, take it to Technical Assistance to check .
1.1.7 The use of accessories not recommended by the manufacturer may cause corporal
injures.
1.1.8 Keep the hands or any other object away from moving parts while the equipment is
in operaon, to avoid injures or damage to the equipment. .
1.1.9 During operaon never wear loose clothes with wide sleeves principally around the
wrists .
1.1.10 Make sure the equipment voltage and the network voltage are the same, and the
equipment has been solidly grounded .
1,1,11 Never adjust the Blade Guide nor the Thickness Guide with the machine running
1.1.12 Use steel gloves during the operaon.

4
IMPORTANT
This equipment must not be used by children or any persons with reduced
physical or mental aptness, lack of experience or knowledge, unless they are
under supervision or have received from the person responsible for safety, proper
instrucons on how to use the equipment.
IMPORTANT
Children shall be watched in order to avoid them to play with the equipment.
IMPORTANT
In case of emergency take o the plug from its socket.
IMPORTANT
Never spray water directly on to the equipment.
IMPORTANT
Make sure the cord is in perfect condions for use. If it is not, change it for a new
one in accordance with the technical specicaons and safety rules .
The substuon shall be made by a qualied professional , and shall respect the
local safety norms .
1.1.13 This equipment has been developed for commercial operaon, it is used for instance
in restaurants, fast foods, hospitals, bakeries, butchers and similar.
It is not recommended to use it
- For connuous industrial producon
- A working ambient having a corrosive or explosive atmosphere, or contaminated with
water vapour, dust or gas.

5
1 – Blade Tension Regulator Handle
2 – ON/OFF Switch
3 - Door
4 – Upper Wheel
5 - Handle
6 – Blade Guide
7 - Blade
8 – Movable Table
9 – Staple
10-Thickness Guide
11- Fixed Table
12 – Lower Wheel
13- Feet
14- Motor Housing
PICTURE 01
01
03
04
10
11
12
05
07
13
14
09
06
08
02
1.2 Main Components
All components are manufactured with carefully chosen raw materials in accordance with
Skymsen experience and tesng standards.

6
TABLE 01
CHARACTERISTICS UNIDAD SFL-218
Voltage V 220
Frequency Hz 50
Power Rang CV 1
Height mm 1580
Width mm 715
Depth mm 805
Net Weight kg 73
Shipping Weight kg 92
Maximum Cung Height mm 240
Maximum Cung Width mm 240
Floor to Table Top Distance (L x P) mm 735 x 805
Table Dimensions mm 895
1.3 Technical Characteriscs

7
2 – Installaon and Pre Operaon
2.1 Installaon
2.1.1 Placing the equipment
The equipment must be installed over a rm and level working surface. See below drawing
the recommended area
805mm
735mm
Installaon
Area
FRONT
2.1.2 Electric Installaon
The equipment has been designed to operate 220 Volts. When you receive the equipment
check the voltage indicated on the cord label
The power plug has 3 pins the middle pin is the ground . All the 3 pins must be properly
connected.
IMPORTANT
Make sure the network voltage is the same as indicated on the Cord label
2.2 Pre Operaon
Before to use the equipment all the parts which could get into contact with the product
to be processed shall be washed with water and neutral soap ( see item 3.3 Cleaning and
Sanizing ).
Make sire the equipment is rm on its working posion.

8
3 . Operaon
3.1 Starng
To start the equipment follow the below instrucons:
1 – Make sure all the protecons and the door are in due place and the door is closed .
2 - Plug the equipment to the electric network,
3 – Press the ON/OFF Switch # 01 ( Pic.02 ) on posion “I” ON the equipment will start
PICTURE 02
01

9
3.2 Operaon Procedure
3.2.1 Make sure the equipment is steady on its working place.
3.2.2 Door
The Door # 03 (Pic. 01) shall be closed as long as the equipment is in use.
3.2.3 Thickness Guide
To obtain several same thickness slices adjust the Thickness Guide # 10 (Pic.01) as desired.
That for turn the thickness guide handle counter clockwise geng the guide free, then
place the Thickness Guide at the desired thickness and ght the Thickness Guide Handle
turning it clockwise.
3.2.4 Blade
The Blade must be installed with the teeth turned towards the front side of the machine
and with the points downwards.
To regulate ( stretch ) the Blade # 07 (Pic.01) turn clockwise the Blade Tension Regulator
Handle # 01 (Pic.01) unl it stops.
3.2.5 Blade Guide
With the equipment switched OFF, turn the handle # 05 (Pic. 01) counter clockwise to get
free the Blade Guide # 06 (Pic.01). Then adjust the Blade Guide to have it no more than
the height of the product to be cut and ght the Handle # 05 (Pic.01).
3.2.6 Lower Wheel
The Lower Wheel # 12 (Pic. 01) is assembled on the lower bearing sha , and xed by
means of the Staple # 09 (Pic. 01), the staple shall always be placed in the sha slot..
The Lower Wheel may be removed to clean aer the Blade has been removed ( see 3.3
Cleaning and Sanizing)
3.2.7 Upper Wheel
The Upper Wheel # 04 (Pic. 01) has in its frame the sha and the bearing.
The Upper Wheel may be removed to clean aer the Blade has been removed ( see 3.3
Cleaning and Sanizing )
Before to start the machine
Push the Movable Table # 08 (Pic, 01) totally to the front side of the machine.
Place the product to be cut on the Movable Table.
Choice the slices thickness and adjust the Thickness Guide # 10 (Pic.01).
Adjust the Blade Guide # 06 (Pic, 01) to no more than the height of the product to be cut.
Stay in front of the machine to have a front sight of the Blade.

10
IMPORTANT
Never remove the slices by the Blade front side.
Start the Machine
To start the machine press the ON/OFF Switch buon “I” (ON).
Catch the Movable Table with the le hand and push against the Blade cung the product
at constant speed.
Aer nishing the whole slice remove it with the right hand . The slice shall ALWAYS be
removed behind the Blade to avoid the hand to contact the Blade
Place the slices upon the Fixed Table # 11 (Pic. 01).
Bring back the Movable Table to the front side of the machine and repeat the above steps
unl to have nished to cut all the product.
Aer the end of the last slice switch the ON/OFF Switch to the posion “O” (OFF) .# 02
(Pic 01)

11
IMPORTANT
Unplug the equipment before to clean
PICTURE 03
01
When the equipment must go through a complete cleaning and sanizaon process:
- Before to be used rst me.
- Aer every day end of operaons
- When the saw is not going to be used for a long period.
- Before to start operaon aer a long period it has not been used.
Some components may be removed to clean :
- Door
- Fixed Table Block
- Blade
- Upper Wheel
- Lower Wheel
- Blade Tension Regulator Handle
- Blade Tension Regulator
Follow below instrucons to remove the above menoned components :
- Door
Turn the two Door handle counterclockwise unl they get free from their screws.
Open the Door # 01 (Pic. 03) grab it strongly and li the Door.
3.3 Cleaning and Sanizaon

12
- Blade
Turn the Blade Tension Regulator Handle # 01 (Pic 05) counter clockwise to get the Blade #
02 (Pic. 05) free to be removed.
PICTURE 04
PICTURE 05
- Fixed Table Block
Remove the Fixed Table Block # -1 (Pic. 04) just liing it , see picture 04.
01
02
01

13
- Lower Wheel
Remove the Staple # 01 (Pic. 06) grab strongly the Lower Wheel and pull it to the front side
of the equipment , see picture 06.
- Upper Wheel
First remove the Blade and grab strongly the Upper Wheel # 01 (Pic. 07) then li it and pull
it to the front side of the machine, see picture 07
PICTURE 06
PICTURE 07
01
01

14
PICTURE 08
PICTURE 09
- Blade Tension Refulator
Turn the Blade Tension Regulator Handle # 01 (Pic.08) counter clockwise unl the Stretcher
# 02 (Pic. 08) is completely removed.
-Blade Tension Regulator Handle
Remove the Blade tension Regulator Handle # 01 (Pic. 09) liing it;
01 02
01
Wash all the components with water and neutral soap.

15
IMPORTANT
Do not spray water directly on the equipment
Use a clean cloth or a so brush to remove residues.
Wash, sanize, rinse and dry all the components.
Assemble back all the components following the inverse path , and make sure all the
components are correctly in place.

16
3.4 Cauons with Stainless Steel:
The Stainless Steel may present rust signs, which ARE ALWAYS CAUSED BY EXTERNAL
AGENTS, especially when the cleaning or sanizaon is not constant and appropriate.
The Stainless Steel resistance towards corrosion is mainly due to the presence of
chrome, which in contact with oxygen allows the formaon of a very thin protecve coat.
This protecve coat is formed through the whole surface of the steel, blocking the acon
of external corrosive agents.
When the protecve coat is broken, the corrosion process begins, being possible to
avoid it by means of constant and adequate cleaning.
Cleaning must always be done immediately aer using the equipment. For such
end, use water, neutral soap or detergent, and clean the equipment with a so cloth or a
nylon sponge. Then rinse it with plain running water, and dry immediately with a so cloth,
this way avoiding humidity on surfaces and especially on gaps.
The rinsing and drying processes are extremely important to prevent stains and
corrosion from arising.
IMPORTANT
Acid soluons, salty soluons, disinfectants and some sterilizing soluons
(hypochlorites, tetravalent ammonia salts, iodine compounds, nitric acid and
others), must be AVOIDED, once it cannot remain for long in contact with the
stainless steel:
These substances aack the stainless steel due to the CHLORINE on its composion, causing
corrosion spots (ping).
Even detergents used in domesc cleaning must not remain in contact with the stainless
steel longer than the necessary, being mandatory to remove it with plain water and then dry
the surface completely.
Use of abrasives:
Sponges or steel wool and carbon steel brushes, besides scratching the surface and
compromising the stainless steel protecon, leave parcles that rust and react contaminang
the stainless steel. That is why such products must not be used for cleaning and sanizaon.
Scrapings made with sharp instruments or similar must also be avoided.
Main substances that cause stainless steel corrosion:
Dust, grease, acid soluons such as vinegar, fruit juices, etc., saltern soluons (brine),
blood, detergents (except for the neutral ones), common steel parcles, residue of sponges or
common steel wool, and also other abrasives.

17
4.1 Basic Operaon Procedures
4.1.1 Dangers
Some areas of the electric device have parts that are connected or have parts connected
to high voltage. These parts when touched may cause severe electrical shocks or even be
lethal.
Never touch manual commands such as switches, buons, turning keys and knobs with
your hands wearing wet clothes and/or wet shoes. By not following these instrucons
operator could be exposed to severe electrical shocks or even to a lethal situaon.
4.1.2 Warnings
* The operator has to be well familiar with the posion of ON/OFF Switch to make sure the
Switch is easy to be reached when necessary.
* Before any kind of maintenance, physically remove plug from the socket.
* Provide space for a comfortable operaon thus avoiding accidents.
* Water or oil spilled on the oor will turn it slippery and dangerous. Make sure the oor
is clean and dry.
* Before using any commands (switch, buons, lever), be sure it is the correct one. In case
of doubt, consult this manual.
* Never touch any manual commands (switch, buons, lever) unadvisedly.
* If any work is to be made by two or more persons, coordinaon signs will have to be
IMPORTANT
If any recommendaon is not applicable to your equipment , please ignore it .
IMPORTANT
Any change in the protecon systems and safety devices will during operaon,
create serious risks to the operator physical integrity
4. GENERAL SAFETY PRACTICES
The following safety instrucons are addressed to both the operator of the machine as
well as the person in charge of maintenance.
The machine has to be delivered only in perfect condions of use by the Distributor to the
user. The user shall operate the machine only aer being well acquainted with the safety
procedures described in the present manual. READ THIS MANUAL WITH ATTENTION.

18
IMPORTANT
Carefully read ALL INSTRUCTIONS of this manual before turning the machine ON.
Be sure to well understand all the informaon contained in this manual. If you
have any queson contact your supervisor or your nearest Dealer.
4.2.1 Danger
An electric cable or electric wire with damaged jacket or bad insulaon might cause
electrical shocks as well as electrical leak. Before use, check the condions of all wires
and cables.
4.2.2 Advices
Be sure to well understand all the informaon contained in this manual. Every operaon
funcon or procedure has to be thoroughly clear.
Before using any commands (switch, buons, lever), be sure it is the correct one. In case
of doubt, consult this manual.
4.2.3 Precauons
The electric cable has to be compable with the power required by the machine.
Cables touching the oor or close to the machine need to be protected against short
circuits.
4.3 Roune Inspecon
4.3.1 Advice
When checking the tension of the belts or chains, DO NOT insert your ngers between the
belts and the pulleys and nor between the chain and the gears.
given for each operaon step. Every step of the operaon shall be taken only if a sign has
been made and responded.
4.1.3 Advices
* In case of power shortage, immediately switch the machine o.* Use recommended or
equivalent lubricants, oils or greases.
* Avoid mechanical shocks, once they may cause damages or bad funconing.
* Avoid water, dirt or dust contact to the mechanical and electrical components of the
machine.
* DO NOT change the standard characteriscs of the machine.
* DO NOT remove, tear o or maculate any safety or idencaon labels stuck on the
machine. If any labels have been removed or are no longer legible, contact your nearest
dealer for replacement.
4.2 Safety Procedures and Notes before Switching the Machine ON

19
4.3.2 Precauons
Check the motor and sliding or turning parts of the machine in case of abnormal noises.
Check the tension of the belts and chains and replace the set when belts or chains show
signs of wearing.
When checking the tension of belts or chains DO NOT insert your ngers between belts
and pulleys, nor between the chains and gears.
Check protecons and safety devices to make sure they are working properly.
4.4 Operaon
4.4.1 Warnings
Do not use the machine with long hair that could touch any part of the machine. This might
lead to a serious accident. Tie your hair up well and/or cover it with a scarf.
Only trained or skilled personnel shall operate this machine.
Never touch turning parts with your hands or any other way ,
NEVER operate the machine without any original safety devices under perfect condions.
4.5 Aer Finishing The Work
4.5.1 Precauons
Always TURN THE MACHINE OFF before cleaning by removing the plug from the socket.
Never clean the machine unless it has come to a complete stop.
Put all the components back to their funconal posions before turning the machine ON
again.
Check the level of liquids.
Do NOT insert your ngers in between belts and pulleys nor chains and gears.
IMPORTANT
Always remove the plug from the socket in any emergency situaon.
4.7 Warning
Electrical or mechanical maintenance has to be undertaken by qualied personnel.
The person in charge of maintenance has to be sure that the machine is under TOTAL
SAFETY condions when working.
4.6 Maintenance
4.6.1 Danger
Any maintenance with the machine in working situaon is dangerous. TURN IT OFF BY
PULLING THE PLUG OFF THE SOCKET DURING MAINTENANCE.

20
5 . Analysis and Problem Solving
5.1 Problems, Causes and Soluons
The equipments have been designed to need minimum maintenance, however, some
performance failures may happen due mainly to natural worn out, caused by the use of
the equipment.
If some problems arise with your equipment check Table - 02 below where there are
detailed some possible soluons.
