Sloan SMOOTH EL-600-A Assembly instructions

Code No. 0816597
Rev. 0b (08/08)
SIDE-MOUNT-OPERATOR-OVER-THE-HANDLE
EL-600-A SMOOTH HARDWIRE ADAPTER KIT
1Slide the unit over the existing
handle up to the flushometer body.
NOTE: Water does not need to be shut off.
IMPORTANT: Install all electrical wiring in accordance with National/Local Codes and Regulations.
2
34Suggested mounting location of
Electrical Supply Flange.
Swing the Mounting Clamp around
the flushometer body and press the
clamp end into the unit until it clicks
into place.
Tighten unit by pushing in on the
spring loaded Mounting Screw and
turning clockwise with a 1/8” hex
wrench. Do Not overtighten.
FLANGE

5
6
To Wall
Flange
To 6 VAC Class 2
Transformer
(Available from Sloan)
Transformer Part Nos.
EL-386 & EL-451
Wiring Diagram
Insert wires into Wire Connectors as
shown. Twist Wire Connectors onto
wires. 120 VAC
6 VAC
SMOOTH
SMOOTH
SMOOTH
One EL-386 Transformer serves one (1) OPTIMA
Closet/Urinal Flushometer. One EL-451
Transformer serves up to eight (8) OPTIMA
Closet/Urinal Flushometers.
Mounting Hole (2)
Center Hole
8Tighten setscrew against armor
sheath, with 1/8” hex wrench.
Drill two (2) mounting holes into wall and
mount flange using the appropriate
fasteners for the particular wall type.
Mounting Fasteners Provided:
• Plastic Wall Anchor - 1/4” (6 mm) hole
• Hollow Wall Anchor - 5/16” (8 mm) hole
• Toggle Nut Anchor - 1/2” (13 mm) hole
Drill 1/2” (13 mm) center hole. Run Cable
through center hole in Flange.
2

3
OPERATION
NORMAL OPERATION
When a user enters the sensor's effective range,
the Red LED light in the sensor window flashes for
eight seconds. After eight seconds of sensing a
user, the light will stop flashing and the unit waits
for the user to step away before initiating a flush
cycle.
LOW VOLTAGE INDICATOR
A manual flush cycle may be initiated by fully
pressing and releasing the Override Handle.
INITIATING A MANUAL FLUSH CYCLE
When a user enters the sensor’s effective range
and the Red LED light in the sensor window
flashes twice as fast as normal, check all
electrical connections and transformer.

Copyright © 2008 SLOAN VALVE COMPANY
SLOAN VALVE COMPANY • 10500 Seymour Avenue • Franklin Park, IL 60131
Phone: 1-800-9-VALVE-9 or 1-847-671-4300 • Fax: [phone] or 1-847-671-4380
www.sloanvalve.com
08-08
ADJUSTMENT PROCEDURES
RESETTING UNIT TO NORMAL RANGE
(Water Closets)
Mode A
The SMOOTH unit may be reset to normal range by
fully pressing and holding in the Override Handle
until the Red LED light in the Sensor Window
illuminates. Then immediately release the Override
Handle.
SETTING UNIT TO REDUCED RANGE
(Typically for Urinals)
Mode C
The SMOOTH unit may be set to reduced range by
pressing and holding in the Override Handle until
the Red LED light in the Sensor Window displays
a rapid on and off blinking light. Then immediately
release the Override Handle.
SETTING UNIT FOR REDUCED RANGE
(Water Closets)
Mode B
The SMOOTH unit may be set to reduced range
for closet applications by pressing and holding in
the Override Handle until the Red LED light in the
Sensor Window flashes a slow long blinking light.
Then immediately release the Override Handle.
The SMOOTH unit is factory set with a Sentinel Flush Feature. This Feature will activate the flushometer once
every 72 hours with no activity, to maintain the water seal in the fixture and conserve water. There should be no
need for further adjustments; however, if an adjustment is required, refer to the following instructions.
Note: To make the adjustments indicated below, power to unit(s) must be turned off for ten (10) seconds.
Mode selection is available within one (1) hour after every power up condition (energizing transformer).
