SMART enigma X5 User manual

1
Content
Safety Precaution .............................................................................................2
1. Reference
1.1 General Features ..............................................................................3
1.2 Accessories ........................................................................................4
2. Basic Function
2.1 Front Panel .......................................................................................5
2.2 Rear Panel ........................................................................................6
2.3 Remote Control Unit ..........................................................................7
3. Installation and Connection
3.1 Connecting to TV & VCR ...................................................................9
3.2 Connecting to Dish LNB ...................................................................10
4. Installation and Operation
4.1 Menu Guide .................................................................................... 12
4.2 Other Useful Information ...................................................................21
5. Additional Information
5.1 Problem Solving ..............................................................................26
5.2 Technical Specification ................................................................... .27
5.3 Menu Screen Structure......................................................................28
5.4 Glossary ............................................................................ ……... ..29

Safety Precaution
This STB has been designed and manufactured to satisfy the international
safety standards. Please read the following safety precautions carefully
before operating this receiver.
Main Supply:
Before operating, please check the units operating voltage is 90~240V AC
50/60Hz.
Overload:
Do not overload a wall outlet, extension cord or adapter, neither use damaged
power cord or touch it with wet hand as this may result in electric shock.
Liquid:
The receiver shall not be exposed to dripping or splashing water, and that no
objects filled with liquids, such as base, shall be placed on the apparatus.
Ventilation:
Keep the slots on top of the receiver uncover to allow sufficient airflow to the
unit. Do not put the receiver on soft furnishings or carpets.Do not expose the
receiver to direct light or do not place it near a heater or in humid conditions.
Do not stack other electronic equipments on top of the receiver.
Cleaning:
Plug out the receiver from the wall outlet before cleaning. Clean the receiver
by a soft cloth or mild solution of washing-up liquid (no solvents).
Connection:
Disconnect the receiver from the mains when you connect it to satellite LNB or
disconnect it from LNB. Failure would possibily cause damage to the LNB
Location:
Put the receiver indoor in order to avoid lightening, raining or sunlight.
Uncover:
Do not remove the cover, to reduce the risk of electric shock.Contact qualified
and licensed service personnel to repair the receiver, or contact your dealer.

3
1. Reference
1.1 General Features
MPEG-2 & Fully DVB Compliant
MPEG-2 Video (MP@ML), MPEG-1 Audio Layer1, Layer2
PLL RF-Modulator UHF 21~69 with PAL B/G,I,D/K
Multi LNB Control by DiSEqC 1.0,1.2,1.3
LNB Power 13/18V Max 500mA
SCPC/MCPC Receivable from C / Ku-Band Satellites
Digital Tuner with Loop-Through
2 Scarts for TV and VCR
PAL/NTSC Conversion
Variable Aspect Ratio (4:3,16:9) for TV
4-digi 7-segment LED Display
RS232 Port for Updating software and Additional Information
User Friendly OSD Menu with Full Function
256 Colors Graphic User Interface
Multi Language Menu (English / Italian / French / Spanish / Germany / Turkish
/ Arabic / Russian / Persian)
7-Days EPG (Electronic Program Guide) for On-Screen Channel Information
MP,multi picture. PIP,picture in picture. REC,short record(10 seconds)
Super fast 800 pages OSDTeletext Supported and VBI Teletext Inserted
Favorite Channel and Parent Lock Function
Storing 6000 Channels.
ZOOM function

1.2 Accessories
User manual
Remote Control Unit
A/V Cable
Batteries
Figure 1. Accessories

2. Basic Function
2.1 Front Panel
1. Power Button
The POWER button is used to turn the power on or to make it on Standby
Mode.
2. Up/Down Button /
Change channel in viewing mode and move the cursor up/down in menu
mode.
3. Left/Right Buttont /
Increase / decrease the volume in viewing mode and change settings in menu
mode
4. OK Button
Activate the highlighted sub menu in menu mode and activate the channel list
in viewing mode.
5. MENU Button
Activate the main menu in viewing mode, or exit all menu.
6. Display (4-digi 7-segment)
4-digi displays channel information. In Standby mode the 7-segment displays
local time.
7. Power LED
5

Power indicator
8. Signal LED
Signal Indicator

2.2 Rear Panel
Figure 3. Rear Panel
1. LNB IN 13/18V 500mA Max
Connect the Satellite Dish LNB.
2. LOOP OUT
Output the Dish LNB IN signal.
3. RF IN
Connect to the antenna of TV to Aerial IN.
4. RF OUT
Connect to conventional TV.
5. AUDIO, VIDEO
Connect to Audio/Video of TV.
6. 0/12V
Supply 12V DC to other apparatus.
7. RS232
Connect to serial port of PC for software upgrade.
8. Electric Inlet Lead
Mains 90~240V AC (Auto selectable), 50~60Hz, Make sure to check the power spec.
9. Power
AC Power Switch.
10.S/PDIF
Output for connection to a digital amplifier.
11.TV SCART/VCR SCART
Connect to TV set or VCR with Scart cables.
7

2.3 Remote Control Unit(RCU)
You can control this receiver by this remote controller with full function.
1. POWER :
Switch the receiver on or set it to standby mode.
2. MUTE:
Turn the sound On/Off.
3.NUMERIC KEY (0~9):
Change program or input number.
4. RECALL:
Move to the previous viewed channel.
5.INFO:
Show the information of the current channel.
press EXIT button to exit this menu.
6. MENU:
Activate main menu or exit to live channel.
7. EXIT:
Exit current menu step by step.
8. CH/:
Change program.
9.VOL/:
Change volume in viewing mode.
10.OK:
Confirm the highlighted menu item. Open the
program list.
11.SAT:
Show the scanned satellite list. 12.FAV: Display
favorite channel list.
13.TV/RADIO
Switch between TV and RADIO.
14.PGUP, PGDN:
Page up/down on menu.
15.EPG (Electronic Program Guide):
Show the TV/Radio program guide.
16.ZOOM:
Picture Zooming function.
17.AUDIO:
Select or change the Audio.
18.TXT:

9
Show the teletext content if teletext is transmitted.
19.PAUSE:
Freeze the picture.
20.SLEEP:
Sleep timer function
21.SUB:
Subtitle.
22.FIND:
Find Channel by channel name.
23.PIP:
Picture in Picture.
24. REC:
Record and playback 10 seconds.
25.M.P.
Multi picture.

3. Installation and Connection
The following diagram shows you the connections among receiver, TV, VCR,
LNB and other equipment, please read this first if you are not sure about the
connection, and it will guide you to the correct connection.
3.1 Connecting to TV & VCR
1. Connect the TV antenna toAERIALIN.
2. Connect the RF-IN of TV to RF-OUT.
3. Connect the Video andAudio of TV to the Video and Audio. Connect Red
and White connector toAudio R and Audio L, and Yellow into Video port
respectively.
4. Go to section 3.2 Connecting to Dish, then connect your dish.
TV
Figure 5. Connecting to TV & VCR

3.2 Connecting to Dish LNB
You can connect one fixed dish LNB directly to the LNB IN, or connect at least
two dish LNB by DiSEqC Switch, you can also connect to HH mount dish LNB.
1. Connect the TV antenna toAERIAL IN.
2. Connect the RF-IN of VCR to RF-OUT with RF cable.
3. Connect the RF-OUT of VCR to the RF-IN of TV.
4. Connect the Video andAudio of TV to the Video and Audio. Connect Red
and White connector toAudio R and Audio L, and Yellow into Video port
respectively.
11
COMPUTER
Figure 6. Connecting to Dish LNB

Figure 7. Connecting to Dish LNB

4. Installation and Operation
Ater connecting the receiver to other required equipment, turn on the receiver,
there should be no channel information available at the first startup, you need
to follow the procedure to setup your receiver to search the channel.
4.1 Menu Guide
During the installation there is a short information showed at the bottom of the
menu screen which will guide you to set up, after finishing installation, you can
enjoy watching TV or listening Radio.
--Main Menu--
Press MENU button to activate main menu which consists of
13
 Use RIGHT/LEFT /button to select
your subject and press OK to confirm your selection and enter that sub menu,
press EXIT button you can return to the previous menu.

Here you can setup System
Configuration, TV Output , Parental
Control , System information , Time
Setup and Timer .

A: System Configuration
Select System Configuration and press OK,
you will get this window. Here you can change
Menu Language, Audio Language, OSD
Time Out ,Transparency ,Channel Option
and Auto Power
B: TV Output
You can setup TV Type as PAL or NTSC,
Screen Type as 4:3 or 16:9 or other format
and RF.
C: Parental Control
You can select if need the password
or not for Installation, Edit Channel, System,
also you can change the password, the default
password is 0000.
D: System information
This menu show some information about the
product, such as Product Name, Software Ver,
Loader Ver and so on.

E: Time Setup
When you Enable this option, and press
OK, you will get this window to setup time,
at GMT on item, if select on, you can go to
the second item to change GMT offset which
you want. Or you select off GMT. You can go to
the third item to input your local time.
F: Timer
Here you can set your favorite channel to
begin broadcasting at future time you set,
including both TV and Radio, you can add,
edit and delete the event you set.
In this menu, you can setupAntenna,
and Search channels. And Reset the system.
A: Antenna Setup
Press right button on RCU and move to the
antenna setting, here to setup the correct LNB
frequency, switch Type (None, port 1...port 4,
burst A, burst B, Auto).
15

 Motor
If you connect receiver to DiSEqC1.2 or
DiSEqC1.3 antenna, set motorized system to
DiSEqC1.2 or USALS, Here press OK button to
enter motor system.
Position Auto [W/E]
Press/button, the dish will be
motorized to East/West continuously,
it will stop until it find the best signal.
Move Dish
Push/button, the dish will be motorized
to East/West step by step
until you find the best signal showed on the
signal bar.
Fine Tuning
Set the moving step.
Move Step
Move East or West step by step.
Limit Set
Disable or enable West limit or East limit
Store Position
Save the current position you searched.
Go to Position
Press OK button to move the dish to the
stored position.
Go to Reference
PressOK button to move the dish to
0 position.
Press EXIT after setup, and you can search
channel now.
17

 USALS Setup
If you use USALS, Press RED key to setup
you Local parameters.
A-1 :Delete
Press RED key to delete the selected
sat, then will show a window ask you to
confirm. Select OK confirm and EXIT to
abort this action.
A-2 : Add
Press Yellow key to add new satellite.
A-3 :Rename
Press BLUE key to rename current satellite
name.
19

A-4 :Start Scan
Press GREEN key to go to Satellite Scan
menu to search channels.
B: Satellite Scan
In this menu you can set scan mode
and which type of channels you want
to search by RIGHT/LEFT /
UP/DOWN/. Then Press OK to
start search.
B-1: Search Channel
In this menu you can see the search
Result. During searching the TV channel
and Radio channel will be listed separately.
C: Tp Edit/Scan
Here you can Edit the transponder and
scan channel.
