AIR-EAGLE®XLT
900 MHz RF Receiver
MODEL 441AN-5000-4-20O-DC
DESCRIPTION
The AIR-EAGLE XLT, MODEL 441AN-5000-4-20O-DC Is an RF receiver
capable of receiving two 4-20mA or 0-5VDC input signals from a
remote transmitter(s). Two 4-20mA outputs are provided to relay the
information received. This unit can receive signals from up to 2500 feet
away and is user-programmable for up to eight network frequencies to
allow multiple systems to operate simultaneously in the same area
without interference.
INSTALLATION
1. Mount the AIR-EAGLE XLT RECEIVER in a convenient location
2. Install wiring to output terminal strip.
3. Install antenna to TNC connector on side of unit.
4. Connect supplied power input cable to your external power source.
OPTIONS & FREQUENCY SET-UP
This receiver is factory set to operate on frequency #1. If you wish to
change the default setting, follow the instructions using the table below:
1) Remove power from unit and remote topcover/
2) Select desired options and frequency using table below.
3) Reattach cover and apply power. Programming is now complete.
OPTIONS
SEL1
SWITCH
NUMBER
OPEN
CLOSED
SW1
Uses Safety Timer (default)
No Safety Timer
Select whether output holds or clears when signal lost
SW2
4mA Idle (default)
20mA Idle
Select whethersafety timer clears the output low or high
SW3 &4
Reserved for future use
FREQUENCY SET-UP
SEL1
(SW5-7)
Network
Frequency
SW5
SW6
SW7
1 (default)
OPEN
OPEN
OPEN
2
CLOSED
OPEN
OPEN
3
OPEN
CLOSED
OPEN
4
CLOSED
CLOSED
OPEN
5
OPEN
OPEN
CLOSED
6
CLOSED
OPEN
CLOSED
7
OPEN
CLOSED
CLOSED
8
CLOSED
CLOSED
CLOSED
Dimensions (with mounting plate) 6.3” L x 4.8” W x 2.3” H
TERMINAL STRIP WIRING
1
2
3
4
5
6
7
8
9
10
Not Used
Not Used
Not Used
Not Used
Output 1 4-20mA (-)
Output 1 4-20mA(+)
Output 2 4-20mA(-)
Output 2 4-20mA(+)
(-) 9-36VDC Input
(+) 9-36VDC Input
CONTROLS & INDICATORS
OUTPUT
FAULT LEDS
Each Channel has a RED LED that will turn on
when thecurrent output is open

AIR-EAGLE®XLT
900 MHz RF Receiver
MODEL 441AN-5000-4-20O-DC
APPROVALS
United States (FCC)
MCQ-XB900HP
Canada (IC)
1846A-XB900HP
Australia
RCM
Brazil
ANATEL 3727-12-1209
SPECIFICATIONS
Inputs
Not used on this model
Outputs
Two 4-20mA
Safety Timer
15 seconds
Update Time
4 samples / second
DC Power Input
9-36VDC @ 10 Watts
Enclosure
Polycarbonate NEMA 4 (IP66)
Frequency
900MHz Spread Spectrum
8 Independent Networks
Reception Range
Up to 2500 Feet w/Standard Antenna
Note: Max rangefiguresareestimates, based on free-air terrain with limited sources of
interference. Actual range will vary based on transmitting power, orientation of transmitter
and receiver, height of transmitting antenna, height of receiving antenna, weather conditions,
interference sources in the area, and terrain between receiver and transmitter, including, but
not limited to, indoor and outdoor structures such as walls, metal objects, trees, buildings,
hills, and mountains
Operating Temperature
-40oF to +185oF
ACCESSORIES
Standard Antenna (Included):
900MHz TNC “Rubber Duck” Antenna
49-1103
Mobile/Base Antennas –
Used to help achieve max range in both nonline of sight andline of
sight applications. - Contact BWI Eagle for recommendations
900MHz Thru-Hole Mount Mobile Antenna
49-2101
900MHz Magnet Mount Mobile Antenna
49-2102
900MHz Omni Directional Base Antenna
49-3101
900MHz Yagi Directional Base Antenna
49-3102
High Quality Coax Cables –
Used to connect external high gain antennas to control unit
Flex Coax Cable w/Connectors –Available in
5’,15’,25’,30’,40’,60’,80’,100’ Lengths
49-4000-XX
(XX = # of Feet)
Bulkhead Extensions –
Used to provide an external antenna connection whenmounting
control unit inside another enclosure
TNC Male to TNCBulkhead Cable Assembly
- Available in 2’, 4’, 7’ Lengths
49-5004-X-ISO
(X = # of Feet)
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly
used and installed, will be free from defects inmaterial and workmanship
for a period of 1 year after date of purchase. Said warranty to include the
repair or replacement of defective equipment. This warranty does not
cover damage due to external causes, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair,improper installation, or improper
testing. This limited warranty, andany implied warranties that may exist
under state law, apply only to the original purchaser of the equipment, and
last only for as long as such purchaser continues to own the equipment.
This warranty replaces all other warranties, express or implied including,
but not limited to, the implied warranties or merchantability and fitness for
a particular purpose. BWI Eaglemakes noexpress warranties beyond
thosestated here. BWI disclaims without limitation, implied warranties of
merchantability and fitness for a particular purpose. Some jurisdictions do
not allowthe exclusion of implied warranties so this limitation may not
apply to you. To obtain warranty service, contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss duringshipping and is
responsible for the shipping costs incurred.
DOCUMENT DATE: 11/23/2021 / PRODUCT REV. 3
105 Bonnie Drive
Butler, PA 16002
[phone]
Fax [phone]
www.bwieagle.com

441AN-5000-4-20O
4-20mA Installation
The above diagram shows the channel 1 output hooked to a 4-20mA receiver or PLC. The input
resistance of the receiver can be up to 500 ohms. Anything higher and the current will be limited to
below 20 mA since the maximum output voltage of the channel outputs is 10 volts.
