SMART M1 Plus User manual

DIGITAL SATELLITE RECEIVER
User's Guide

Note: This equipment has been tested and found to comply with the limit for a Class B digital device,
pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
Installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions. May cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. IF this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encourage
to try to correct the interference by one or the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
-Consult the dealer or an experience radio TV technician for help
Change or modification not expressly approved by the party responsible for Compliance could void
the user’s authority to operate the equipment

1
CONTENTS
FOR YOUR SAFETY ------------------------------------------------------------------------ 2
BEFORE GETTING STARTED ----------------------------------------------------------- 3
CONTROLS AND FUNCTION ------------------------------------------------------------ 4
Front Panel ------------------------------------------------------------------ 4
Rear Panel -------------------------------------------------------------------- 5
Remote Control Unit ------------------------------------------------------ 6-8
CONNECTIONS ------------------------------------------------------------------------------- 9
Connecting to the TV,VCR and Satellite Antenna --------------- 9
Connecting to the TV, HiFi system and 0/12V switch ---------- 10
Connecting DiSEqC switch---------------------------------------------- 11
SETTINGS AND OPERATIONS ---------------------------------------------------------- 12
Basic Setting -----------------------------------------------------------------12
LNB Power -------------------------------------------------- 12
DiSEqC 1.2 Limit Setting ------------------------------- 13
TP Configuration ------------------------------------------ 14-16
Viewing TV (or Radio) ------------------------------------ 16-17
Other Function --------------------------------------------- 17
LOCK ---------------------------------------------------------- 18
Edit Channel Name --------------------------------------- 18
Parental Control ------------------------------------------- 19
System settings ------------------------------------------------------------- 19-22
Application ------------------------------------------------------------------- 23
TROUBLESHOOTING ---------------------------------------------------------------------- 24

2
FOR YOUR SAFETY
GERNERAL INFORMATION FOR YOUR SAFETY
To avoid the risk of fire, shock or other hazards,
●The receiver shall not be exposed to dripping or splashing
and that no objects filled with liquids,such as vases,shall be
placed on the receiver.
●The minimum distances around the receiver for sufficient
ventilation should be 10cm.
●The ventilation should not be impeded by covering the
ventilation openings with items, such as newspapers, table
cloths, curtains, etc.
●No naked flame sources, such as lighted candles, should be
placed on the receiver.
To reduce the risk of electric shock,
●The top cover of the receiver shall not be removed. Please
refer to a qualified technician.
●Do not connect, disconnect or modify cables when the
receiver is connected to the mains power supply.
●Use a soft, dry cloth to clean the receiver and remove dust.
●It is recommended that a responsible person is always
present when young children are viewing programs through this
receiver.
Do not treat it as a toy.

3
BEFORE GETTING STARTED
MAIN FEATURES
?MULTI LANGUAGE EPG INCLUDING ARABIC
?ENGLISH / ARABIC WRITING FUNCTION ?SUBTITLE DISPLAY FUNCTION
?AUTO AUDIO LANGUAGE DETECTION
?CHANNEL VOLUME SAVING FUNCTION
?FULL PARENTAL CONTROL ON ALL MENUS INCLUDING RECEIVER LOCK
?OSD & INFOBAR CHANGING COLOR, TIMER & TRANSPERANCY
?COPY FUNCTIONS (SET TO SET, SET TO PC, PC TO SET) INCLUDING
(SOFTWARE AND CHANNELS)
?LNB SWITCHING LOGIC (22 KHz, DiSEqC 1.0, DiSEqC 1.2 and AUTO DiSEqC
DETECTION)
?ADVANCED SEARCH OPTIONS (CHANNEL, TRANSPONDER, NETWORK,
BLIND, MULTI SATELLITE & FREE TO AIR ONLY)
?USALS AUTO POSITIONING FUNCTION
?PROVIDER NAME DISPLAY
?EDIT CHANNEL MENU (LOCK, MOVE, RENAME, SKIP (HIDE), DELETE, ADD, &
FAVORITE)
?ADVANCED CHANNEL SORTING OPTIONS BY (NAME, FREQUANCY, FREE
TO AIR, PROVIDER)
?EDIT SATELLITE MENU (LOCK, MOVE, RENAME, SKIP (HIDE), DELETE, &
FAVORITE)
?FIVE FAVORITE PROGRAM TIMERS, SLEEP TIMER, 5 VIDEO TIMERS &
FRONT LED STANDBY CLOCK
?PHONE BOOK FOR 100 NAMES ?CALCULATER
?MULTI SCREEN FORMATS (4:3, 16:9) ?PAL-NTSC CONVERSION
?CALENDER ?5 GAMES

4
CONTROLS AND FUNCTION
Front Panel
The 4-digit displays channel information.
In stand by mode, 7-segment displays local time & red LED indicator.
The green LED is the antenna signal indicator.
POWER
Turn the power on/off.
CH ▼ ▲
Change channel,move menu, or input frequency value.

5
Rear Panel
VIDEO
It provides composite video output. Connect the Video on TV to VIDEO with RCA cable.
Audio(R,L)
It provides stereo audio output. Connect the audio on TV to AUDIO with RCA cable.
0/12V
It provides LNB selection for the different satellite.
TV
It provides stereo audio,RGB video & composite video output.
Connect the receiver to TV with SCART cable.
TV OUT
It provides a modulated audio and video from the receiver. Connect the TV/VCR on TV
to TV/VCR with the RF cable.
ANT.IN
The signal supplied to this connector from a TV antenna will be sent to TV antenna
output. Connect a TV antenna to TV ANT.IN.
LOOP
It sends signal to the another receiver.
LNB
It receivers signals from the LNB in the range of 950 ~ 2150MHz. Connect a satellite
dish to DIGITAL.
RS 232
It receivers data by connecting to PC for software upgrading. Connect with RS 232
cable a PC and receiver.

6
Remote Control Unit
Open the controller cover on the back and insert two
batteries(AAA-1.5V).
STAND BY MUTE
Turn the power on/off Deactivate current sound.
Numeric(0~9)
Move menu, change channel or input
TV
Change to TV mode from radio channel.
RADIO
It is for fast change to radio mode from TV channel.
Shows the current Radio program list.
TXT
Change to Teletext mode.
AUDIO
Select Stereo, Main or Sub from multi language channels
available.
FAV.
Add TV or Radio channel to the favorite list on Edit
TV(Radio) Channels, or watch favorite channel from your
favorite list.
LANG
Select the audio language from 2 or more audio language
channels available.
Page UP/DOWN
Move to previous/next page on TV(Radio),Favorite
Channels or Edit TV(Radio) Channels.
Volume ◀ ▶
Control volume, change item on menu or input frequency
value.

7
Channel ▼ ▲
Change channel, move menu, or input frequency value.
OK
Select menu or value on menu item.
MENU
Shows the menu application.
EXIT
Exit from the menu.
SAT LIST
Shows the current captured satellite list
SIZE
Select between standard 4 : 3 and wide 16 : 9 screen sizes.
RECALL
It is to move to previous channel.
PAUSE
Shows the freeze video display.
DEL
Delete input data (Searched Channel & TP list, Phone Book Data etc.)
ZOOM + -
Zoon in & out for the freeze and live picture.
SLEEP
Sleep timer setting.
REN
Change the Satellite & Channel name.
LOCK
Lock the channel and satellite in order to prevent to watching children.
MOVE
After the channel searching, changing the channel order.

8
SKIP
In the channel edit menu, you can skip specific channel. Skipped channel will not
display in the channel list.
SL/ RP
Press one for the slow display for the live picture. Press one more for the repeat the
live picture for certain time.
INFO
Shows the information of current channel. Click the INFO button twice, TELETEXT
mode will be displayed.
GUIDE
Shows the broadcasting information.(Video -Audio -LNB)
SIGNAL
Front LED will shows you the signal strength.
P
Power for the DiSEqC control box.
STORE
Save the satellite position.
EAST/WEST
The function of EAST/WEST button is to move the Position Actuator
westward/eastward.

9
Connections
Connecting to the TV,VCR and Satellite Antenna
It is not necessary to adjust power, as the product is of free-voltage(100-240V)
1.Connect the RF cable from the TV OUTPUT on the satellite receiver to a TV and
connect the RF modulate on the VCR and the TV ANT.IN.
2. Connect an antenna to the LNB socket on the VCR or other receiver and cable of
the satellite dish to the DIGITAL on the satellite receiver.

10
Connecting to the TV, HiFi system and 0/12V switch
1.Connect the RCA cable from the VIDEO INPUT on the TV to the VIDEO on the
satellite receiver.
2. To use 0/12V switch, connect one cable of the 0/12V switch to the 0/12V on the
satellite switch and connect another cable to the DIGITAL on the satellite receiver.
3. Connect a RCA stereo cable from the AUDIO RL on the satellite receiver to the
AUDIO R/L on the HiFi system.

11
Connecting DiSEqC switch
If you have one antenna equipped with many LNBs or two antennas with one LNB on
each, you need a DiSEqC switch.
1. Connect the LNBs to a DiSEqC switch at first.
2. Connect the antenna cable to the OUT connector on the DiSEqC switch and
connect the end of the cable to the DIGITAL on the satellite receiver.

12
Basic Setting
If it is first time using a receiver, you
should set parameters for system
configuration.
Refer to the following section.
1. Turn on your TV and Satellite receiver.
2. Press the MENU button, main menu
screen will appear as shown below.
Settings and Operations
<LNB Power>
1. Select Installation on the Main Menu.
2. Select LNB Power.
3. If LNB Power is independently
supplied from outside source, set the
LNB Power OFF. Otherwise set it ON.
4. After completion of LNB Power setting,
go back to Installation menu by pressing
MENU.

13
Satellite
The Satellite shows current
name of satellite.
Go to Center
If you press OK button dish
position is moved to center
position.
ReCalculate Pos.
You can change the input data
(Satellite Position) in the
DiSEqC box.
Clear E/W Limits
Set dish position's East or
West limit, clear the limit value.
Movement
In User mode this is used to
tune the position of the motor.
In Installer mode this is used to
search for the position of a
satellite manually.
Set East/West Limit
Set dish position's East or
West limit, disable limit value.
<DiSEqC 1.2 Limit Setting>
If you have a DiSEqC 1.2 motorized system to control your satellite antenna you have
to make the following setting. First, you must select ON on DiSEqC 1.2 of LNB Setting
in the TP Configuration.<♣Please refer to the TP Configuration section>
1. Select DiSEqC 1.2 Limit Setting of the installation.
2. You should set the East Limit and West Limit of your satellite antenna. If you use
the satellite receiver at first. Press OK button on the Change Limit item, set the
EAST/WEST Limit.
3. Select satellite you want and DiSEqC 1.2 Positioner will be set automatically.

14
<TP Configuration>
You have to know valid value for
your LNB at first.
1. Select TP Configuration of the
installation.
2. Select correct name of Satellite.
If there is no proper satellite name
in the item, select one from any of
USER1 ~ USER8.
3. To change value of LNB from
each satellite, press OK button
from LNB.
4. For universal type of LNB, select
Universal from LNB Type item and
input the LNB frequency value on
L.O Freq. Low by using
VOL ◀ ▶ or numeric key. For
standard type of LNB, select
Standard from LNB Type and input
correct value on L.O. Freq..
5. While only 1 antenna is in use,
set the 0/12V switch and DiSEqC
mode to Disable. In case of
STANDARD, select OFF from
22KHz. If more then 1 antenna is in
use, select 0V or 12V from 0/12V
switch, or select a proper position
from Mini A, Mini B, DiSEqC 1~
DiSEqC4 by different DiSEqC type
as you are using DiSEqC switch.

15
6. USALS
If you want to set USALS (Universal
Satellite Automatic Location System),
you must enter your longitude value
and you must set USALS menu
to "ON" and enter position value at
LNB menu in the TP configuration.
The DiSEqC code value will be
automatically sended to Motor. If you
also set DiSEqC 1.2 to "ON", the
USALS function will not work.
7. Select Search Channels on the TP
Configuration press OK, all the
available TP will be searched
automatically.
8. Move to desired TP with Channel
▼ ▲on the RCU. If there are no
transponder data which you want,
move to Add New Transponder and
press OK button.
9. Select the desired satellite. And
input correct values of Frequency,
Polarization and Symbol Rate. Select
the Polarization value as Hor or Ver.
If you did not know accurate
polarization value select Auto.

16
10. After all the values are input, select
Search Channels and wait until the
automatic search is completed. If FTA
only is selected as Yes,only free channels
will be searched without scrambled pay
channels. Otherwise all channel with
scrambled pay channels will be searched.
Scrambled pay channels is marked as
$ at the beginning of the channel name.
After successful completion of channel searching, move to TV Channels or Radio
Channels on MAIN MENU to select currently received channels. Then you should select
the TV channel or Radio channel which you want. After then you can watch the TV
program or listen to radio.
To find not only TP information but also all the channels from current satellite, select
Network Search.
11. In case of searching a certain satellite which can not be searched by TP Search,
add channels by PID. Select Add Channel and input proper Channel name and input the
values of Video PID, Audio PID, Audio PID and PCR PID. Then, press OK button from
the Add item.
Viewing TV(or Radio)
1. Press the TV(or Radio) button.
2. If you want see all TV channel list,click
the OK button and then select the TV
Channels(or Radio Channels). TV
Channels(or Radio Channels) window will
appear.

17
Viewing Favorite Channel
1. Press FAV key.
2. Select a CH ▼ ▲. To move to next or previous page, press PAGE
UP/DOWN(Double Arrow) buttons on Favorite TV(or Radio) List.
3. Press FAV key more will bring you to another Favorite TV (or Radio) List.
Other Function
Edit TV Channels/Edit Radio Channels
From these menus you can create and
channel list. Press OK button from Edit TV
Channels and similar screen will be shown
as below.
Arrange channel
To change the channel orders from TV
List,press OK button from your desired
channel. Then you should move to desired
number by pressing CH ▼▲, after then
press OK button. Its orders will be changed.
Delete channel
To delete a certain channel from current TV
List,press DEL button on the channel to be
deleted. To confirm the deletion, press DEL
button once more. This function will delete
the channel completely and you have to
search channel again for the reactivate
channel. Use SKIP button and the skipped
channel will not display in the channel list.
Create favorite channel
You can create favorite channel
list,containing the channel which you want to
watch frequently.
Press FAV button channel you want, and
then selected channel will be moved to
Favorite List box. To delete the desired
channel from from the Favorite List, press
DEL button.

18
Help function
You can see the functions of each button in Edit TV List. Select the HELP button.
Sort
If you want to sort channels in order,select the SORT button in Edit channels.
You can select the order you want.
LOCK
Lock Channels
From here you can lock channels in
any of the lists in order to prevent
your children from watching.
Satellite Lock
When you want to lock all the
channels in the satellite, go to the
Edit Satellite List. You can select the
specific satellite in the Satellite
Favorite List, press LOCK button.
Edit Channel Name
1. Press REN button on Edit TV or
Edit Radio list. Cursor will be moved
by using VOL ◀ ▶ ,CH ▼ ▲.
2. Press OK button on desired
alphabet. To delete pre-selected
alphabet, press DEL button.
3. To change character
set(upper,lower,number),press REN
button. By using MENU button, it will
be automatically stored and moved
to previous menu.
