SMC Networks AS Series User manual

Elbow Brass
Electroless
nickel plated
Stainless steel
Universal
Speed Controller with
One-touch Fitting
Unlock Lock
•Easy to lock
øD
Body size øD[mm]
19.4
2
12 (Port size 1/8)
13 (Port size 1/4)
316.6
418.8
Larger handlePush-lock type
Easy
to
use
Insertion force:
30%
(1.8 lbf [8 N]) reduction
Max.
Removal force:
20%
(1.1 lbf [5 N]) reduction
∗
Max.
∗Tube pulling out strength is ensured to be equivalent
to existing model.
Improved tube insertion/removal
AS221F-02-
Made to Order added
· Vaseline/-X12
· Grease-free + Restrictor/-X21
· Restrictor/-X214
· Clean Series/10-
Stainless steel type
G thread
type
Uni thread
type
AS221F-02-SA
Existing model
New
17.1 mm
12.2 mm
More space beneath the tube.
Easier installation/removal of the tube.
New type added!New type added!
Universal type
Reduces labor time!
Series AS
New
New
RoHS
CAT.NAS20-220C
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

WhiteWhite
Series AS
Light blue
Meter-inMeter-out
Series InchMetric
AS-F AS-F-U
AS-FG
Gray
Release button color
Easy identification of product type
Flow rate reproducibility
Improved reproducibility of flow rate
Stopper face
Contact face
stopper
Stable handle position when fully closed (no flow rate) onto the
contact face stopper (rotating stopper). Small variations in flow
rate depending on the number of handle rotations
Fully closed
Gray Light blue
OrangeLight gray
Elbow type Universal type
1
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

Series Variations
Push-lock Series Variations
05 10
1/8" 5/32" 1/4" 5/16" 3/8" 1/2"1612108643.22
Applicable tubing O.D.
M5 x 0.8
10-32UNF
Seal
method
Port
size
Metal
parts
material
Metric size Inch size
1/8
1/4
1/4
3/8
1/2
1/8
1/4
1/4
3/8
1/2
G∗1
Uni
·Brass/
Steel wire
·Brass/
Steel wire
·Stainless
steel
Applicable
tubing
material
Nylon
(Series
T, TIA)
Soft nylon
(Series
TS, TISA)
Polyurethane
(Series
T, TIUB)
Fluororesin
(Series
TLM, TILM)
(Series
TH, TIH)
1
3
4
2
3
4
2
Speed Controller with One-touch Fitting
∗1 Face seal type is applicable only to G thread type.
∗2 “Without sealant” type can be selected as a standard option.
∗3 Universal type is not available.
Body
size
Numerical indication of handle
rotation for flow rate reduces flow
setting time and setting errors!
Speed Controller with Indicator/Series AS-FS
Applicable tubing O.D.
Metric size
ø2 to ø161 to 4 M5 to 1/2
Inch size
ø1/8" to ø1/2"
Port size
Body size
Flow rate
Number of needle rotations
Gasket
seal
Gasket
seal
Face seal
1/8
1/4
1/4
3/8
1/2
R
NPT
3
4
2
Sealant ∗2
Refer to the WEB catalog for details.
∗3
∗3
∗3
∗3
∗3
∗3
∗3
∗3
∗3
∗3
∗3
∗3
Electroless nickel plating type is standardized.
G thread (Face seal) is standardized.
Stainless steel type is standardized.
2
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

Brass
Electroless
nickel plated
Elbow Universal
Note) Use caution at the max. operating pressure when using soft nylon or polyurethane tubing.
(Refer to the WEB catalog or the Best Pneumatics No. 6 for details.)
Flow Direction Symbols on Body
Caution
Note 1) 10-32UNF has the same specification as M5.
Note 2) C and b values are for controlled flow with the needle fully open and free flow with the needle fully closed.
Note 3) The same specifications also apply to the AS-FG series (stainless steel type).
Specifications
Flow Rate and Sonic Conductance
RoHS
Speed Controller with One-touch Fitting
Elbow Type/Universal Type
Series AS
Model
Note 1) “Without sealant” type can be selected as a standard option.
Note 2) Only polyurethane tubing is applicable for ø2.
Note 3) Universal type is not available.
Model
Port size Seal
method
Applicable tubing O.D.
Metric size Inch size
Elbow type Universal type 2
Note 2)
3.2 46810 12 16 1/8" 5/32" 1/4" 5/16" 3/8" 1/2"
AS12 1F-M5 AS13 1F-M5 M5 x 0.8 Gasket
seal
Note 3)
AS12 1F-U10/32 AS13 1F-U10/32
10-32UNF
Note 3)
AS22 1F- 01 AS23 1F- 01
R
NPT
1/8
Note 1)
Sealant
Note 3)
AS22 1F- 02 AS23 1F- 02 1/4
Note 3) Note 3)
AS32 1F- 02 AS33 1F- 02 1/4
AS32 1F- 03 AS33 1F- 03 3/8
AS42 1F- 04 AS43 1F- 04 1/2
Note 3)
AS22 1F-G01 AS23 1F-G01
G
1/8
Face seal
Note 3)
AS22 1F-G02 AS23 1F-G02 1/4
Note 3)
AS32 1F-G02 AS33 1F-G02 1/4
AS32 1F-G03 AS33 1F-G03 3/8
AS42 1F-G04 AS43 1F-G04 1/2
Note 3)
Model
AS12 1F-M5
AS13 1F-M5
AS22 1F- 01Note 3)
AS23 1F- 01Note 3)
AS22 1F- 02
AS23 1F- 02
AS32 1F
AS33 1F
AS42 1F
AS43 1F
Tubing
O.D.
Metric
size ø2
ø3.2
ø4
ø6
ø3.2 ø4
ø6
ø8
ø10
ø3.2 ø4 ø6 ø8
ø10 ø6 ø8 ø10 ø12 ø10 ø12 ø16
Inch
size —
ø1/8"
ø1/4"
ø5/32"
ø1/8" ø5/32"
ø1/4"
ø5/16"
ø1/8" ø5/32" —
ø1/4"
ø5/16"
ø3/8"
ø1/4" ø5/16" ø3/8" ø3/8" ø1/2"
C values:
Sonic
conductance
dm3/(s·bar)
Free
flow 0.2 0.3 0.4 0.6 0.6 0.7 1.0 1.3 1.5 1.6 1.7 2.5 4.4 4.8
Controlled
flow 0.2 0.3 0.4 0.7 0.8 0.6 0.9 1.3 2.1 2.4 3.3 4.4 4.9
b values:
Critical
pressure
ratio
Free
flow 0.3 0.4 0.2 0.3 0.3 0.4 0.4 0.3 0.3
Controlled
flow 0.2 0.2 0.3 0.3 0.3 0.3
Meter-out Meter-in
Symbol
Fluid Air
218 psi (1.5 MPa)
145 psi (1 MPa)
14.5 psi (0.1 MPa)
23 to 140°F [−5 to 60°] (No freezing)
Nylon, Soft nylon, Polyurethane , FEP, PFA
Proof pressure
Max. operating pressure
Min. operating pressure
Ambient and fluid temperature
Applicable tubing material Note)
Be sure to read this before handling.
Refer to the back cover for Safety
Instructions. For Flow Control
Equipment Precautions, refer to
“Handling Precautions for SMC
Products” and the Operation Manual
on SMC website,
http://www.smcworld.com
3
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

ASAS-FGUni-AS
Note 1) For selecting applicable tubing O.D.,
refer to the “Model” on page 3.
Metric size and inch size types can
be visually identified by color of the
release button.
Metric size: Light gray
Inch size: Orange
Note 2) Use ø1/8" tube.
Brass
Electroless
nickel plated
Elbow Universal
How to Order
0 S
E
F A1AS 2 01 06
0
2
2 F A1AS 1 M5 06
Body size
Type
Thread type
Port size
Port size
Seal method
Push-lock type
Applicable tubing O.D. Note 1)
Metric size Inch size Note 3)
Applicable tubing O.D. Note 1)
Metric size Inch size
Body size 2/3/4
Body size 1
Control type Note)
Body size
Made to Order
Refer to page 14 for
details.
Width across flats (H)
E8 mm
Nil 9 mm
2Elbow
3Universal
1M5 x 0.8
10-32UNF
0Meter-out
1Meter-in
21/8, 1/4
33/8
41/2
01 ø1/8"
03 ø5/32"
07 ø1/4"
02 ø2
23 ø3.2 Note 2)
04 ø4
06 ø6
01 ø1/8"
03 ø5/32"
07 ø1/4"
09 ø5/16"
11 ø3/8"
13 ø1/2"
23 ø3.2 Note 2)
04 ø4
06 ø6
08 ø8
10 ø10
12 ø12
16 ø16
Nil Without sealant
SWith sealant
M5 M5 x 0.8
U10/32 10-32UNF
01 1/8
02 1/4
03 3/8
04 1/2
Nil R
NNPT
GG
4
Speed Controller with One-touch Fitting Series AS
Note 1) For selecting applicable tubing O.D.,
refer to the “Model” on page 3.
Note 2) Use ø1/8" tube.
Note 3) Only the metric size is available for the
G thread type.
Note) Face seal method is used for the
G thread type.
Select “Nil/Without sealant.”
Example) AS2201F-G01-06A
Note) Meter-out and meter-in types can
be visually identified by color of
the handle.
Meter-out: Gray
Meter-in: Light blue
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

Series AS
5
Inlet pressure: 73 psi (0.5 MPa)
0
1.8
[50]
3.5
[100]
50 10
Number of needle rotations
Flow rate scfm L/min(ANR)
02
01, 23, 03, 04, 06, 07
Inlet pressure: 73 psi (0.5 MPa)
0
3.5
[100]
7.1
[200]
10.6
[300]
50 10
Number of needle rotations
Flow rate scfm L/min(ANR)
01, 23
03, 04
06, 07, 08, 09, 10
0
3.5
[100]
7.1
[200]
10.6
[300]
14.1
[400]
17.7
[500]
21.2
[600]
50 10
Number of needle rotations
Flow rate scfm L/min(ANR)
Inlet pressure: 73 psi (0.5 MPa)
03, 04
01, 23
06, 07
08, 09, 10, 11
Inlet pressure: 73 psi (0.5 MPa)
0
17.7
[500]
35.3
[1000]
50 10
Number of needle rotations
Flow rate scfm L/min(ANR)
06, 07
10, 11, 12
08, 09
Inlet pressure: 73 psi (0.5 MPa)
0
17.7
[500]
35.3
[1000]
53.0
[1500]
50 10
Number of needle rotations
Flow rate scfm L/min(ANR)
12, 13, 16
10, 11
Needle Valve/Flow-rate Characteristics
AS2201F-01, AS2211F-01
AS2301F-01, AS2311F-01
AS2201F-02, AS2211F-02
AS2301F-02, AS2311F-02
AS3201F, AS3211F
AS3301F, AS3311F
AS4201F, AS4211F
AS4301F, AS4311F
AS1201F-M5 , AS1211F-M5
AS1301F-M5 , AS1311F-M5
Note) -U10/32 has the same specification as M5.
Note) The numbers above the flow-rate characteristic curves in the charts show the applicable tubing outside diameter as defined by the product number.
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

ASAS-FGUni-AS
6
Speed Controller with One-touch Fitting Series AS
e
!0
o
q
t
r
u
i
y
w
!2
e
!0
o
q
t
r
u
i
y
w
e
q
t
r
i
y
w
!1
u
o !0
Meter-in type
Meter-out type
Component Parts
Construction/ Elbow type
Seal method: Gasket seal
For M5, 10-32UNF
Seal method: Sealant
For R, NPT thread
Meter-in type Meter-out type
Meter-in type
Meter-out type
Seal method: Face seal
For G thread
No. Description Material Note
1 Body A PBT
2 Body B Brass Electroless nickel plating
3 Handle POM
4 Needle PBT
5 Needle guide Brass Electroless nickel plating
6 U-seal HNBR
7 O-ring NBR
8 O-ring NBR
9 Cassette —
10 Seal NBR
11 Gasket NBR/Stainless steel
12 Seal NBR
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

Series AS
7
r
q
y
t
i
o
u
e
!1
!2
!0
w
r
q
y
t
i
o
u
e
!5
w
!1
!2
!0
r
q
w
y
t
i
o
u
e
!4
!1
!2
!0
!3
Component Parts
Note) Spacer is included only for the applicable tubing O.D. ø3.2 and ø1/8".
Construction/ Universal type
Seal method: Gasket seal
For M5, 10-32UNF
Seal method: Sealant
For R, NPT thread
Seal method: Face seal
For G thread
Meter-in type
Meter-in type
Meter-in type
Meter-out type
Meter-out type
Meter-out type
No. Description Material Note
1 Body A PBT
2 Elbow body PBT
3 Body B Brass Electroless nickel plating
4 Handle POM
5 Needle PBT
6 Needle guide Brass Electroless nickel plating
7 U-seal HNBR
8 O-ring NBR
9 O-ring NBR
10 O-ring NBR
11 Cassette —
12 Seal NBR
13 Spacer PBT Note)
14 Gasket NBR/Stainless steel
15 Seal NBR
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

ASAS-FGUni-AS
8
Speed Controller with One-touch Fitting
L4
A
L3
øD1
øD3
L2
L1
MT
Applicable tubing O.D. ød
H
(Width across flats)
Dimensions/ Elbow type
Seal method: Gasket seal
For M5, 10-32UNF
Metric Size [mm]
Inch Size
Note 1) Reference dimensions
Note 2) Reference dimensions of threads after installation
[mm]
Note 1) Reference dimensions
Note 2) Reference dimensions of threads after installation
Model d T H D1 D3 L1 L2 L3 L4
Note 1) ANote 2)
MWeight
[g]
Unlocked Locked Unlocked Locked
AS121F-M5E-01A 1/8"
M5 x 0.8
10/32UNF 8
7.2
9.4
17.2 21.7 16.9
26.5 25.4 23.5 22.4 13.3
5
AS121F-U10/32E-01A
AS121F-M5E-03A 5/32" 8.2
AS121F-U10/32E-03A
AS121F-M5E-07A 1/4" 11.2 18.6 23.1 16.5 6
AS121F-U10/32E-07A
Model d T H D1 D3 L1 L2 L3 L4 Note 1) ANote 2)
MWeight
[g]
Unlocked Locked Unlocked Locked
AS121F-M5E-02A 2
M5 x 0.8
10/32UNF 8
5.8
9.4
15.8 20.3
16.9
26.5 25.4 23.5 22.4
11.9
5
AS121F-U10/32E-02A
AS121F-M5E-23A 3.2 7.2
17.2 21.7
13.3
AS121F-U10/32E-23A
AS121F-M5E-04A 4 8.2
AS121F-U10/32E-04A
AS121F-M5E-06A 6 10.4 18.6 23.1 16.5 6
AS121F-U10/32E-06A
For M5, 10-32UNF Series AS
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

Series AS
9
L5
A
L1
øD2
øD1
L4
L3
M
L2
øD3
HT
Applicable tubing O.D. ød
Seal method: Gasket seal
For M5, 10-32UNF
Dimensions/ Universal type
Metric Size [mm]
Inch Size [mm]
Note 1) Reference dimensions
Note 2) Reference dimensions of threads after installation
Note 1) Reference dimensions
Note 2) Reference dimensions of threads after installation
Model d T H D1 D2 D3 L1 L2 L3 L4 L5 Note 1) ANote 2)
MWeight
[g]
Unlocked Locked Unlocked Locked
AS131F-M5E-01A 1/8"
M5 x 0.8
10/32UNF 8
7.2
9.6 9
11.6 19.4
17.5 33.8
26.5 25.4 23.5 22.4 13.3 6
AS131F-U10/32E-01A
AS131F-M5E-03A 5/32" 8.2
11.5
19.8
AS131F-U10/32E-03A
AS131F-M5E-07A 1/4" 11.2 21.3 20.2 36.5
AS131F-U10/32E-07A
Model d T H D1 D2 D3 L1 L2 L3 L4 L5 Note 1) ANote 2)
MWeight
[g]
Unlocked Locked Unlocked Locked
AS131F-M5E-23A 3.2
M5 x 0.8
10/32UNF 8
7.2
9.6 9
11.6 19.4
17.5 33.8
26.5 25.4 23.5 22.4 13.3 6
AS131F-U10/32E-23A
AS131F-M5E-04A 4 8.2
11.5
19.8
AS131F-U10/32E-04A
AS131F-M5E-06A 6 10.4 20.9 20.4 36.6
AS131F-U10/32E-06A
For M5, 10-32UNF
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

ASAS-FGUni-AS
10
Speed Controller with One-touch Fitting
L4
A
L3
L2
L1
MT
øD1
Applicable tubing O.D. ød
øD3
H
(Width across flats)
Seal method: Sealant
For R, NPT thread
Dimensions/ Elbow type
Metric Size
Note 1) Reference dimensions Note 2) Reference dimensions of threads after installation Note 3) ( ) are the dimensions of NPT thread.
[mm]
Inch Size
Note 1) Reference dimensions Note 2) Reference dimensions of threads after installation Note 3) ( ) are the dimensions of NPT thread.
[mm]
Model d T H D1 D3 L1 L2 L3 L4 Note 1) ANote 2) MWeight
[g]
Unlocked Locked Unlocked Locked
AS221F-01-01(S)A 1/8"
1/8 13
(12.7)
7.2
12
19.1 26.2
19.1 30.6 29.2 27.5 26.1 13.3 9 (9)
AS221F-01-03(S)A 5/32" 8.2
AS221F-01-07(S)A 1/4" 11.2 20.8 27.9 10 (9)
AS221F-01-09(S)A 5/16" 13.2 22.4 29.5 14.2 11 (10)
AS221F-02-01(S)A 1/8"
1/4 17
(17.5)
7.2
13
20.9 30.2 (30.3)
22.6 36.6 35 31.1 29.5
13.3 18 (19)
AS221F-02-03(S)A 5/32" 8.2
AS221F-02-07(S)A 1/4" 11.2 23.4 32.7 (32.8) 19 (19)
AS221F-02-09(S)A 5/16" 13.2 23.9 33.2 (33.3) 14.2 19 (20)
AS221F-02-11(S)A 3/8" 15.5 26.4 35.7 (35.8) 15.6 20 (21)
AS321F-02-07(S)A 1/4"
1/4 19
11.2
16.6
21.8 32.1 36.4 50 48.4 44.5 42.9
13.3 40 (40)
AS321F-02-09(S)A 5/16" 13.2 22.7 33 14.2 41 (41)
AS321F-02-11(S)A 3/8" 15.5 26.7 37 35.9 15.6
AS321F-03-07(S)A 1/4"
3/8 19
11.2
16.6
21.8 32.1 28.7 42.3 40.7 37.1 35.5
13.3 31 (32)
AS321F-03-09(S)A 5/16" 13.2 22.7 33 14.2
AS321F-03-11(S)A 3/8" 15.5 26.7 37 28.2 15.6 32 (33)
AS421F-04-11(S)A 3/8" 1/2 24
(23.8)
15.5 18.8 27.4 40.3 (40.2) 36.2 50.8 49.2 43.7 42.1 15.6 54 (53)
AS421F-04-13(S)A 1/2" 19.3 30.9 43.8 (43.7) 34.7 17 56 (55)
Model d T H D1 D3 L1 L2 L3 L4 Note 1) ANote 2) MWeight
[g]
Unlocked Locked Unlocked Locked
AS221F-01-23(S)A 3.2
1/8 13
(12.7)
7.2
12
19.1 26.2
19.1 30.6 29.2 27.5 26.1
13.3 9 (9)
AS221F-01-04(S)A 4 8.2
AS221F-01-06(S)A 6 10.4 10 (9)
AS221F-01-08(S)A 8 13.2 22.4 29.5 14.2 11 (10)
AS221F-01-10(S)A 10 15.9 25.3 32.4 15.6 12 (11)
AS221F-02-23(S)A 3.2
1/4 17
(17.5)
7.2
13
20.9 30.2 (30.3)
22.6 36.6 35 31.1 29.5
13.3 18 (19)
AS221F-02-04(S)A 4 8.2
AS221F-02-06(S)A 6 10.4 23.4 32.7 (32.8)
AS221F-02-08(S)A 8 13.2 23.9 33.2 (33.3) 14.2 19 (20)
AS221F-02-10(S)A 10 15.9 26.9 36.2 (36.3) 15.6 20 (21)
AS321F-02-06(S)A 6
1/4 19
10.4
16.6
21.8 32.1 36.4
50 48.4 44.5 42.9
13.3 40 (40)
AS321F-02-08(S)A 8 13.2 22.7 33 14.2 41 (41)
AS321F-02-10(S)A 10 15.9 26.7 37 35.7 15.6 42 (42)
AS321F-02-12(S)A 12 18.5 29.7 40 34.5 17 43 (43)
AS321F-03-06(S)A 6
3/8 19
10.4
16.6
21.8 32.1 28.7
42.3 40.7 37.1 35.5
13.3 31 (32)
AS321F-03-08(S)A 8 13.2 22.7 33 14.2
AS321F-03-10(S)A 10 15.9 26.7 37 28 15.6 32 (33)
AS321F-03-12(S)A 12 18.5 29.7 40 26.8 17 34 (35)
AS421F-04-10(S)A 10
1/2 24
(23.8)
15.9
18.8
27.4 40.3 (40.2) 36.2
50.8 49.2 43.7 42.1
15.6 54 (53)
AS421F-04-12(S)A 12 18.5 30.8 43.7 (43.6) 35.1 17 56 (55)
AS421F-04-16(S)A 16 23.8 34.8 47.7 (47.6) 32.7 20.6 60 (59)
For R, NPT thread Series AS
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

Series AS
11
L5
A
L2
L1
T
øD2
øD1 øD3
Applicable tubing O.D. ød
H
(Width across flats)
L4
L3
M
Seal method: Sealant
For R, NPT thread
Metric Size
Note 1) Reference dimensions Note 2) Reference dimensions of threads after installation Note 3) ( ) are the dimensions of NPT thread.
[mm]
Inch Size
Note 1) Reference dimensions Note 2) Reference dimensions of threads after installation Note 3) ( ) are the dimensions of NPT thread.
[mm]
Dimensions/ Universal type
Model d T H D1 D2 D3 L1 L2 L3 L4 L5 Note 1) ANote 2) MWeight
[g]
Unlocked Locked
Unlocked
Locked
AS23 1F-01-01(S)A 1/8"
1/8 13
(12.7)
7.2 9.6
12
13.3 24 17.5 36
30.6 29.2 27.5 26.1 13.3 10 (10)
AS23 1F-01-03(S)A 5/32" 8.2 13.9 25.1
AS23 1F-01-07(S)A 1/4" 11.2 10.2 16.4 29.1 20.2 38.7 11 (10)
AS23 1F-01-09(S)A 5/16" 13.2 30.1 21.5 40 14.2 12 (12)
AS23 1F-02-03(S)A 5/32"
1/4 17
(17.5)
8.2
12.9 13
16.5 29.9 (30) 17.5 40.1
36.6 35 31.1 29.5
13.3 19 (20)
AS23 1F-02-07(S)A 1/4" 11.2 19 33.8 (33.9) 21.4 43.9 21 (22)
AS23 1F-02-09(S)A 5/16" 13.2 34.9 (35) 23.5 46 14.2 22 (22)
AS23 1F-02-11(S)A 3/8" 15.9 20.9 38.1 (38.2) 24.7 47.3 15.6 23 (24)
AS33 1F-02-07(S)A 1/4"
3/8 19
11.2 12.9 16.6 20.2 36 21.4 57.8
50 48.4 44.5 42.9
13.3 42 (42)
AS33 1F-02-09(S)A 5/16" 13.2 37.1 23.5 59.9 14.2 43 (43)
AS33 1F-02-11(S)A 3/8" 15.9 17.4 23 41.2 26.1 62.5 15.6 46 (46)
AS33 1F-03-07(S)A 1/4"
3/8 19
11.2 12.9 16.6 20.2 36 21.4 50.1
42.3 40.7 37.1 35.5
13.3 34 (35)
AS33 1F-03-09(S)A 5/16" 13.2 37.1 23.5 52.2 14.2 35 (36)
AS33 1F-03-11(S)A 3/8" 15.9 17.4 23 41.2 26.1 54.8 15.6 38 (39)
AS43 1F-04-11(S)A 3/8" 1/2 24
(23.8)
15.9 17.4 18.8 25.6 46.4 (46.3) 26.1 61.2 50.8 49.2 43.7 42.1 15.6 61 (59)
AS43 1F-04-13(S)A 1/2" 18.5 21 26.2 48.3 (48.2) 28.3 63.4 17 64 (63)
Model d T H D1 D2 D3 L1 L2 L3 L4 L5 Note 1) ANote 2) MWeight
[g]
Unlocked Locked Unlocked Locked
AS231F-01-23(S)A 3.2
1/8 13
(12.7)
7.2
9.6 12
13.3 24 17.5 36
30.6 29.2 27.5 26.1 13.3 10 (10)
AS231F-01-04(S)A 4 8.2 13.9 25.1
AS231F-01-06(S)A 6 10.4 26.2 20.4 38.8 11 (10)
AS231F-01-08(S)A 8 13.2 10.2 16.4 30.1 21.5 40 14.2 12 (12)
AS231F-02-04(S)A 4
1/4 17
(17.5)
8.2
12.9 13
16.5 29.9 (30) 17.5 40.1
36.6 35 31.1 29.5
13.3 19 (20)
AS231F-02-06(S)A 6 11.2 19 33.8 (33.9) 21.4 43.9 21 (22)
AS231F-02-08(S)A 8 13.2 34.9 (35) 23.5 46 14.2 22 (22)
AS231F-02-10(S)A 10 15.9 20.9 38.1 (38.2) 24.7 47.3 15.6 23 (24)
AS331F-02-06(S)A 6
1/4 19
11.2 12.9
16.6
20.2 36 21.4 57.8
50 48.4 44.5 42.9
13.3 42 (42)
AS331F-02-08(S)A 8 13.2 37.1 23.5 59.9 14.2 43 (43)
AS331F-02-10(S)A 10 15.9 17.4 23 41.2 26.1 62.5 15.6 46 (46)
AS331F-02-12(S)A 12 18.5 42.5 28.3 64.7 17 48 (48)
AS331F-03-06(S)A 6
3/8 19
11.2 12.9
16.6
20.2 36 21.4 50.1
42.3 40.7 37.1 35.5
13.3 34 (35)
AS331F-03-08(S)A 8 13.2 37.1 23.5 52.2 14.2 35 (36)
AS331F-03-10(S)A 10 15.9 17.4 23 41.2 26.1 54.8 15.6 38 (39)
AS331F-03-12(S)A 12 18.5 42.5 28.3 57 17 40 (41)
AS431F-04-10(S)A 10 1/2 24
(23.8)
15.9 17.4 18.8 25.6 46.4 (46.3) 26.1 61.2 50.8 49.2 43.7 42.1 15.6 61 (59)
AS431F-04-12(S)A 12 18.5 21 26.2 48.3 (48.2) 28.3 63.4 17 64 (63)
For R, NPT thread
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

ASAS-FGUni-AS
12
Speed Controller with One-touch Fitting
L4
A
L3
H
(Width across flats) L2
L1
MT
øD1
Applicable tubing O.D. ød
ø
D3
Seal method: Face seal
For G thread
Metric Size [mm]
Dimensions/ Elbow type
Model d T H D1 D3 L1 L2 L3 L4 A MWeight
[g]
Unlocked Locked Unlocked Locked
AS22 1F-G01-23A 3.2
1/8 13
7.2
12
19.1 26.2
18.8 30.3 28.9 24.8 23.4
13.3 10
AS22 1F-G01-04A 4 8.2
AS22 1F-G01-06A 6 10.4
AS22 1F-G01-08A 8 13.2 22.4 29.5 14.2 11
AS22 1F-G01-10A 10 15.9 25.3 32.4 15.6 12
AS22 1F-G02-23A 3.2
1/4 17
7.2
13
20.9 30.2
22.6 36.6 35 30.1 28.5
13.3 21
AS22 1F-G02-04A 4 8.2
AS22 1F-G02-06A 6 10.4 23.4 32.7
AS22 1F-G02-08A 8 13.2 23.9 33.2 14.2 22
AS22 1F-G02-10A 10 15.9 26.9 36.2 15.6 23
AS32 1F-G02-06A 6
1/4 21
10.4
16.6
21.8 33 36.4
50 48.4 43.5 41.9
13.3 50
AS32 1F-G02-08A 8 13.2 22.7 33.9 14.2
AS32 1F-G02-10A 10 15.9 26.7 37.9 35.7 15.6 52
AS32 1F-G02-12A 12 18.5 29.7 40.9 34.5 17 53
AS32 1F-G03-06A 6
3/8 21
10.4
16.6
21.8 33 28.7
42.3 40.7 34.8 33.2
13.3 38
AS32 1F-G03-08A 8 13.2 22.7 33.9 14.2 39
AS32 1F-G03-10A 10 15.9 26.7 37.9 28 15.6 40
AS32 1F-G03-12A 12 18.5 29.7 40.9 26.8 17 42
AS42 1F-G04-10A 10
1/2 27
15.9
18.8
27.4 41.8 36.2
50.8 49.2 41.8 40.2
15.6 72
AS42 1F-G04-12A 12 18.5 30.8 45.2 35.1 17 74
AS42 1F-G04-16A 16 23.8 34.8 49.2 32.7 20.6 78
For G thread Series AS
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

Series AS
13
L5
A
L2
L1
øD3øD1
øD2
H
(Width across flats)
L4
L3
M
T
Applicable tubing O.D.ød
Seal method: Face seal
For G thread
Metric Size [mm]
Dimensions/ Universal type
Model d T H D1 D2 D3 L1 L2 L3 L4 L5 A MWeight
[g]
Unlocked Locked Unlocked Locked
AS23 1F-G01-23A 3.2
1/8 13
7.2
9.6 12
13.3 24.0 17.5 35.7
30.3 28.9 24.8 23.4 13.3
10
AS23 1F-G01-04A 4 8.2 13.9 25.1 11
AS23 1F-G01-06A 6 10.4 26.2 20.4 38.5 11
AS23 1F-G01-08A 8 13.2 10.2 16.4 30.1 21.5 39.7 14.2 12
AS23 1F-G02-04A 4
1/4 17
8.2
12.9 13
16.5 29.9 17.5 40.1
36.6 35 30.1 28.5
13.3 22
AS23 1F-G02-06A 6 10.4 19 33.8 21.4 43.9 24
AS23 1F-G02-08A 8 13.2 34.9 23.5 46.0 14.2 25
AS23 1F-G02-10A 10 15.9 20.9 38.1 24.7 47.3 15.6 26
AS33 1F-G02-06A 6
1/4 21
10.4 12.9
16.6
20.2 36.6 21.4 57.8
50 48.4 43.5 41.9
13.3 51
AS33 1F-G02-08A 8 13.2 38.0 23.5 59.9 14.2 52
AS33 1F-G02-10A 10 15.9 17.4 23 42.2 26.1 58.0 15.6 55
AS33 1F-G02-12A 12 18.5 43.5 28.3 59.9 17 57
AS33 1F-G03-06A 6
3/8 21
10.4 12.9
16.6
20.2 36.6 21.4 50.1
42.3 40.7 34.8 33.2
13.3 41
AS33 1F-G03-08A 8 13.2 38.0 23.5 52.2 14.2 42
AS33 1F-G03-10A 10 15.9 17.4 23 42.2 26.1 50.3 15.6 46
AS33 1F-G03-12A 12 18.5 43.5 28.3 52.2 17 47
AS43 1F-G04-10A 10 1/2 27 15.9 17.4 18.8 25.6 47.9 26.1 61.2 50.8 49.2 41.8 40.2 15.6 78
AS43 1F-G04-12A 12 18.5 21 26.2 49.8 28.3 63.4 17 82
For G thread
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

ASAS-FGUni-AS
14
X12
Laser printing
X21
Laser printing
X214
Laser printing
10-
Laser printing
Brass
Electroless
nickel plated
Elbow Universal
Lubricant: Vaseline
1-X12
Example) AS2201F-01-04SA-X12
Restrictor (Without check valve)
3-X214
Example) AS2201F-01-04SA-X214
Example) AS2201F-01-04SA-X21
Note 1) Fluorine grease is used.
Note 2) The particulate generation grade is 3.
Note 3) Excluding G thread type.
Clean Series
410-
Example) 10-AS2201F-01-04SA
Series AS
Made to Order
Please contact SMC for detailed dimensions, specifications and delivery.
Grease-free (Seal: Fluorine-coated) + Restrictor (Without check valve)
2-X21
Note 1) Not particle-free
Note 2) The restrictor is only compatible with the part number of the meter-out type.
Note 3) Only the needle and O-ring are fluorine-coated.
Note) The restrictor is only compatible with the part number of the meter-out type.
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

15
Stainless steel
Elbow Universal
Note) Use caution at the max. operating pressure when using soft nylon or polyurethane tubing.
(Refer to the WEB catalog or the Best Pneumatics No. 6 for details.)
RoHS
Speed Controller with One-touch Fitting
Stainless Steel Type
Elbow Type/Universal Type
Series AS-FG
Flow Direction Symbols on Body
Caution
Note 1) 10-32UNF has the same specification as M5.
Note 2) C and b values are for controlled flow with the needle fully open and free flow with the needle
fully closed.
Specifications
Flow Rate and Sonic Conductance
Be sure to read this before handling.
Refer to the backcover for Safety In-
structions. For Flow Control Equip-
ment Precautions, referto“Handling
Precautions for SMC Products” and
the Operation Manual on SMC web-
site, http://www.smcworld.com
Model
Note 1) “Without sealant” type can be selected as a standard option.
Note 2) Only polyurethane tubing is applicable for ø2.
Note 3) Universal type is not available.
Model
Port size Seal
method
Applicable tubing O.D.
Metric size Inch size
Elbow type Universal type 2
Note 2)
3.2 4 6 8 10 12 16 1/8" 5/32" 1/4" 5/16" 3/8" 1/2"
AS12 1FG-M5 AS13 1FG-M5 M5 x 0.8 Gasket
seal
Note 3)
AS12 1FG-U10/32 AS13 1FG-U10/32
10-32UNF
Note 3)
AS22 1FG- 01 AS23 1FG- 01
R
NPT
1/8
Note 1)
Sealant
Note 3)
AS22 1FG- 02 AS23 1FG- 02 1/4
Note 3) Note 3)
AS32 1FG- 02 AS33 1FG- 02 1/4
AS32 1FG- 03 AS33 1FG- 03 3/8
AS42 1FG- 04 AS43 1FG- 04 1/2
Note 3)
AS22 1FG-G01 AS23 1FG-G01
G
1/8
Face seal
Note 3)
AS22 1FG-G02 AS23 1FG-G02 1/4
Note 3)
AS32 1FG-G02 AS33 1FG-G02 1/4
AS32 1FG-G03 AS33 1FG-G03 3/8
AS42 1FG-G04 AS43 1FG-G04 1/2
Note 3)
Model
AS12 1FG-M5
AS13 1FG-M5
AS22 1FG- 01
AS23 1FG- 01
AS22 1FG- 02
AS23 1FG- 02
AS32 1FG
AS33 1FG
AS42 1FG
AS43 1FG
Tubing
O.D.
Metric
size ø2
ø3.2
ø4
ø6
ø3.2 ø4
ø6
ø8
ø10
ø3.2 ø4 ø6 ø8
ø10 ø6 ø8 ø10 ø12 ø10 ø12 ø16
Inch
size —
ø1/8"
ø1/4"
ø5/32"
ø1/8" ø5/32"
ø1/4"
ø5/16"
ø1/8" ø5/32" —
ø1/4"
ø5/16"
ø3/8"
ø1/4" ø5/16" ø3/8" ø3/8" ø1/2"
C values:
Sonic
conductance
dm3/(s·bar)
Free
flow 0.2 0.3 0.4 0.6 0.6 0.7 1.0 1.3 1.5 1.6 1.7 2.5 4.4 4.8
Controlled
flow
0.2 0.3 0.4 0.7 0.8 0.6 0.9 1.3 2.1 2.4 3.3 4.4 4.9
b values:
Critical
pressure
ratio
Free
flow 0.3 0.4 0.2 0.3 0.3 0.4 0.4 0.3 0.3
Controlled
flow
0.2 0.2 0.3 0.3 0.3 0.3
Meter-out Meter-in
Symbol
Fluid Air
218 psi [1.5 MPa]
145 psi [1 MPa]
14.5 psi [0.1 MPa]
23 to 140°F [−5 to 60°C] (No freezing)
Proof pressure
Max. operating pressure
Min. operating pressure
Ambient and fluid temperature
Applicable tubing material Nylon, Soft nylon, Polyurethane Note), FEP, PFA
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

ASAS-FGUni-AS
16
Stainless steel
Elbow Universal
AS
AS
How to Order
0 SF A12 01 06
0 F A11 M5 06
Body size
Type
Thread type
Port size
Port size
Seal method
Push-lock type
Applicable tubing O.D. Note1)
Metric size Inch size Note 3)
Applicable tubing O.D. Note1)
Metric size Inch size
Control type Note)
Body size
Stainless steel type
(Stainless steel 303)
Made to Order
Refer to page 26 for
details.
G
G
2Elbow
3Universal
1M5 x 0.8
10-32UNF
0Meter-out
1Meter-in
21/8, 1/4
33/8
41/2
01 ø1/8"
03 ø5/32"
07 ø1/4"
02 ø2
23 ø3.2 Note 2)
04 ø4
06 ø6
01 ø1/8"
03 ø5/32"
07 ø1/4"
09 ø5/16"
11 ø3/8"
13 ø1/2"
23 ø3.2 Note 2)
04 ø4
06 ø6
08 ø8
10 ø10
12 ø12
16 ø16
Nil Without sealant
SWith sealant
M5 M5 x 0.8
U10/32 10-32UNF
01 1/8
02 1/4
03 3/8
04 1/2
Nil R
NNPT
GG
Body size 2/3/4
Body size 1
2
2
Speed Controller with One-touch Fitting
Stainless Steel Type Series AS-FG
Note 1) For selecting applicable tubing O.D.,
refer to the “Model” on page 15.
The color of the release button is
white (metric, inch).
Note 2) Use ø1/8" tube.
Note) Face seal method is used for
the G thread type.
Select “Nil/Without sealant.”
Example) AS2201FG-G01-06A
Note 1) For selecting applicable tubing O.D.,
refer to the “Model” on page 15.
The color of the release button is
white (metric, inch).
Note 2) Use ø1/8" tube.
Note 3) Only the metric size is available for
the G thread type.
Note 1) The material can be visually identified
by color of the release button.
Stainless steel type: White
Note 2) White is also used for inch size.
Note) Meter-out and meter-in types can
be visually identified by color of the
handle.
Meter-out: Gray
Meter-in: Light blue
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

17
Series AS-FG
Inlet pressure: 73 psi [0.5 MPa]
0
1.8
[50]
3.5
[100]
50 10
Number of needle rotations
Flow rate scfm [L/min (ANR)]
02
01, 23, 03, 04, 06, 07
01, 23, 03, 04, 06, 07
Inlet pressure: 73 psi [0.5 MPa]
0
3.5
[100]
7.1
[200]
10.6
[300]
50 10
Number of needle rotations
Flow rate scfm [L/min (ANR)]
01, 23
03, 04
06, 07, 08, 09, 10
0
3.5
[100]
7.1
[200]
10.6
[300]
14.1
[400]
17.7
[500]
21.2
[600]
50 10
Number of needle rotations
Flow rate scfm [L/min (ANR)]
Inlet pressure: 73 psi [0.5 MPa]
03, 04
01, 23
06, 07
08, 09, 10, 11
Inlet pressure: 73 psi [0.5 MPa]
0
17.7
[500]
35.3
[1000]
50 10
Number of needle rotations
Flow rate scfm [L/min (ANR)]
06, 07
10, 11, 12
08, 09
Inlet pressure: 73 psi [0.5 MPa]
0
17.7
[500]
35.3
[1000]
53.0
[1500]
50 10
Number of needle rotations
Flow rate scfm [L/min (ANR)]
12, 13, 16
10, 11
Needle Valve/Flow-rate Characteristics
AS2201FG-01, AS2211FG-01
AS2301FG-01, AS2311FG-01
AS2201FG-02, AS2211FG-02
AS2301FG-02, AS2311FG-02
AS3201FG, AS3211FG
AS3301FG, AS3311FG
AS4201FG, AS4211FG
AS4301FG, AS4311FG
AS1201FG-M5, AS1211FG-M5
AS1301FG-M5, AS1311FG-M5
Note) -U10/32 has the same specification as M5.
Note) The numbers above the flow-rate characteristic curves in the charts show the applicable tubing outside diameter as defined by the product number.
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

ASAS-FGUni-AS
18
Speed Controller with One-touch Fitting
Stainless Steel Type Series AS-FG
e
!0
o
q
t
r
u
i
y
w
!2
e
!0
o
q
t
r
u
i
y
w
e
q
t
r
i
y
w
!1
u
o !0
Meter-in type
Meter-out type
Component Parts
Construction/ Elbow type
Seal method: Gasket seal
For M5, 10-32UNF
Seal method: Sealant
For R, NPT thread
Meter-in type Meter-out type
Meter-in type
Meter-out type
Seal method: Face seal
For G thread
No. Description Material Note
1Body A PBT
2Body B Stainless steel
3Handle POM
4Needle PBT
5Needle guide Stainless steel
6U-seal HNBR
7O-ring NBR
8O-ring NBR
9Cassette —
10 Seal NBR
11 Gasket NBR/Stainless steel
12 Seal NBR
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com

19
Series AS-FG
r
q
y
t
i
o
u
e
!1
!2
!0
w
r
q
y
t
i
o
u
e
!5
w
!1
!2
!0
r
q
w
y
t
i
o
u
e
!4
!1
!2
!0
!3
Component Parts
Construction/ Universal type
Seal method: Gasket seal
For M5, 10-32UNF
Seal method: Sealant
For R, NPT thread
Seal method: Face seal
For G thread
Meter-in type
Meter-in type
Meter-in type
Meter-out type
Meter-out type
Meter-out type
Note) Spacer is included only for the applicable tubing O.D. ø3.2 and ø1/8".
No. Description Material Note
1Body A PBT
2Elbow body PBT
3Body B Stainless steel
4Handle POM
5Needle PBT
6Needle guide Stainless steel
7U-seal HNBR
8O-ring NBR
9O-ring NBR
10 O-ring NBR
11 Cassette —
12 Seal NBR
13 Spacer PBT Note)
14 Gasket NBR/Stainless steel
15 Seal NBR
Courtesy of CMA/Flodyne/Hydradyne ▪Motion Control ▪Hydraulic ▪Pneumatic ▪Electrical ▪Mechanical ▪[phone] ▪www.cmafh.com
