TigerSwitch 10/100/1000
Gigabit Ethernet Switch
◆12 auto-MDI/MDI-X 10/100/1000BASE-T ports
◆4 ports shared with 4 SFP transceiver slots
◆Non-blocking switching architecture
◆Support for a redundant power unit
◆Spanning Tree Protocol
◆Up to six LACP or static 4-port trunks
◆Layer 2/3/4 CoS support through four priority queues
◆Full support for VLANs with GVRP
◆IGMP multicast filtering and snooping
◆Support for jumbo frames up to 9 KB
◆Manageable via console, Web, SNMP/RMON
Management Guide
SMC8612T
b_mgmt.book Page i Tuesday, July 8, 2003 5:24 PM

b_mgmt.book Page ii Tuesday, July 8, 2003 5:24 PM

38 Tesla
Irvine, CA 92618
Phone: [phone]
TigerSwitch 10/100/1000
Management Guide
From SMC’s Tiger line of feature-rich workgroup LAN solutions
July 2003
Pub. # 150200034800A
b_mgmt.book Page iii Tuesday, July 8, 2003 5:24 PM

Information furnished by SMC Networks, Inc. (SMC) is believed to
be accurate and reliable. However, no responsibility is assumed by
SMC for its use, nor for any infringements of patents or other rights
of third parties which may result from its use. No license is granted
by implication or otherwise under any patent or patent rights of
SMC. SMC reserves the right to change specifications at any time
without notice.
Copyright © 2003 by
SMC Networks, Inc.
38 Tesla
Irvine, CA 92618
All rights reserved. Printed in Taiwan
Trademarks:
SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are trademarks of
SMC Networks, Inc. Other product and company names are trademarks or registered
trademarks of their respective holders.
b_mgmt.book Page iv Tuesday, July 8, 2003 5:24 PM

v
L IMITED W ARRANTY
Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products
to be free from defects in workmanship and materials, under normal use and
service, for the applicable warranty term. All SMC products carry a standard 90-day
limited warranty from the date of purchase from SMC or its Authorized Reseller.
SMC may, at its own discretion, repair or replace any product not operating as
warranted with a similar or functionally equivalent product, during the applicable
warranty term. SMC will endeavor to repair or replace any product returned under
warranty within 30 days of receipt of the product.
The standard limited warranty can be upgraded to a Limited Lifetime* warranty by
registering new products within 30 days of purchase from SMC or its Authorized
Reseller. Registration can be accomplished via the enclosed product registration
card or online via the SMC web site. Failure to register will not affect the standard
limited warranty. The Limited Lifetime warranty covers a product during the Life of
that Product, which is defined as the period of time during which the product is an
“Active” SMC product. A product is considered to be “Active” while it is listed on
the current SMC price list. As new technologies emerge, older technologies become
obsolete and SMC will, at its discretion, replace an older product in its product line
with one that incorporates these newer technologies. At that point, the obsolete
product is discontinued and is no longer an “Active” SMC product. A list of
discontinued products with their respective dates of discontinuance can be found
at:
http://www.smc.com/index.cfm?action=customer_service_warranty.
All products that are replaced become the property of SMC. Replacement products
may be either new or reconditioned. Any replaced or repaired product carries
either a 30-day limited warranty or the remainder of the initial warranty, whichever
is longer. SMC is not responsible for any custom software or firmware,
configuration information, or memory data of Customer contained in, stored on, or
integrated with any products returned to SMC pursuant to any warranty. Products
returned to SMC should have any customer-installed accessory or add-on
components, such as expansion modules, removed prior to returning the product
for replacement. SMC is not responsible for these items if they are returned with the
product.
Customers must contact SMC for a Return Material Authorization number prior to
returning any product to SMC. Proof of purchase may be required. Any product
returned to SMC without a valid Return Material Authorization (RMA) number
clearly marked on the outside of the package will be returned to customer at
customer’s expense. For warranty claims within North America, please call our
toll-free customer support number at [phone]. Customers are responsible for
all shipping charges from their facility to SMC. SMC is responsible for return
shipping charges from SMC to customer.
WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS
WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY SHALL BE REPAIR OR
REPLACEMENT OF THE PRODUCT IN QUESTION, AT SMC’S OPTION. THE
b_mgmt.book Page v Tuesday, July 8, 2003 5:24 PM

L IMITED W ARRANTY
vi
FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU
OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, EITHER
IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING
WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. SMC NEITHER ASSUMES NOR AUTHORIZES ANY OTHER
PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH
THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS. SMC
SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THE ALLEGED DEFECT IN THE PRODUCT DOES NOT
EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE,
NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS
TO REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED
USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.
LIMITATION OF LIABILITY: IN NO EVENT, WHETHER BASED IN CONTRACT OR
TORT (INCLUDING NEGLIGENCE), SHALL SMC BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE, LOSS OF BUSINESS, OR OTHER FINANCIAL LOSS
ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF ITS
PRODUCTS, EVEN IF SMC OR ITS AUTHORIZED RESELLER HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.
SOME STATES DO NOT ALLOW THE EXCLUSION OF IMPLIED WARRANTIES OR
THE LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
CONSUMER PRODUCTS, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY
SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS.
* SMC will provide warranty service for one year following discontinuance from the
active SMC price list. Under the limited lifetime warranty, internal and external
power supplies, fans, and cables are covered by a standard one-year warranty from
date of purchase.
SMC Networks, Inc.
38 Tesla
Irvine, CA 92618
b_mgmt.book Page vi Tuesday, July 8, 2003 5:24 PM

vii
C ONTENTS
1
Switch Management 1-1
Connecting to the Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Required Connections . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Remote Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Basic Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Console Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Setting Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Setting an IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Enabling SNMP Management Access . . . . . . . . . . . . . . 1-10
Saving Configuration Settings . . . . . . . . . . . . . . . . . . . 1-12
Managing System Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
System Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
2
Configuring the Switch 2-1
Using the Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Navigating the Web Browser Interface . . . . . . . . . . . . . . . . . . 2-2
Home Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Panel Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Basic Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-8
Displaying System Information . . . . . . . . . . . . . . . . . . . 2-8
Setting the IP Address . . . . . . . . . . . . . . . . . . . . . . . . 2-11
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Configuring the Logon Password . . . . . . . . . . . . . . . . . 2-14
Configuring RADIUS/TACACS+ Logon Authentication . 2-16
Configuring HTTPS . . . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Replacing the Default Secure-site Certificate . . . . . . . . 2-23
Configuring SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
Managing Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Downloading System Software from a Server . . . . . . . . 2-26
Saving or Restoring Configuration Settings . . . . . . . . . . 2-28
b_mgmt.book Page vii Tuesday, July 8, 2003 5:24 PM

C ONTENTS
viii
Copying the Running Configuration to a File . . . . . . . 2-30
Displaying Bridge Extension Capabilities . . . . . . . . . . 2-31
Displaying Switch Hardware/Software Versions . . . . . 2-34
Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
Displaying Connection Status . . . . . . . . . . . . . . . . . . . 2-36
Configuring Interface Connections . . . . . . . . . . . . . . . 2-38
Setting Broadcast Storm Thresholds . . . . . . . . . . . . . . 2-41
Configuring Port Mirroring . . . . . . . . . . . . . . . . . . . . . 2-42
Configuring Port Security . . . . . . . . . . . . . . . . . . . . . . 2-44
Address Table Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-47
Setting Static Addresses . . . . . . . . . . . . . . . . . . . . . . . 2-47
Displaying the Address Table . . . . . . . . . . . . . . . . . . . 2-49
Changing the Aging Time . . . . . . . . . . . . . . . . . . . . . 2-51
Spanning Tree Protocol Configuration . . . . . . . . . . . . . . . . . 2-51
STP Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-53
STP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-57
STP Port and Trunk Information . . . . . . . . . . . . . . . . . 2-61
STP Port and Trunk Configuration . . . . . . . . . . . . . . . 2-65
VLAN Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-70
Assigning Ports to VLANs . . . . . . . . . . . . . . . . . . . . . . 2-71
Forwarding Tagged/Untagged Frames . . . . . . . . . . . . 2-73
Displaying Basic VLAN Information . . . . . . . . . . . . . . 2-74
Displaying Current VLANs . . . . . . . . . . . . . . . . . . . . . 2-75
Creating VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-77
Adding Interfaces Based on Membership Type . . . . . . 2-79
Adding Interfaces Based on Static Membership . . . . . . 2-82
Configuring VLAN Behavior for Interfaces . . . . . . . . . 2-83
Class of Service Configuration . . . . . . . . . . . . . . . . . . . . . . . 2-87
Setting the Default Priority for Interfaces . . . . . . . . . . 2-87
Mapping CoS Values to Egress Queues . . . . . . . . . . . . 2-89
Setting the Service Weight for Traffic Classes . . . . . . . 2-92
Mapping Layer 3/4 Priorities to CoS Values . . . . . . . . . 2-93
Selecting IP Precedence/DSCP Priority . . . . . . . . . . . 2-94
Mapping IP Precedence . . . . . . . . . . . . . . . . . . . . . . . 2-94
Mapping DSCP Priority . . . . . . . . . . . . . . . . . . . . . . . 2-97
Port Trunk Configuration . . . . . . . . . . . . . . . . . . . . . . . . . .2-100
Dynamically Configuring a Trunk with LACP . . . . . . .2-102
b_mgmt.book Page viii Tuesday, July 8, 2003 5:24 PM

C ONTENTS
ix
Statically Configuring a Trunk . . . . . . . . . . . . . . . . . . 2-104
Configuring SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-106
Setting Community Access Strings . . . . . . . . . . . . . . 2-107
Specifying Trap Managers . . . . . . . . . . . . . . . . . . . . 2-109
SNMP IP Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-110
Multicast Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-113
Configuring IGMP Parameters . . . . . . . . . . . . . . . . . . 2-113
Interfaces Attached to a Multicast Router . . . . . . . . . . 2-117
Displaying Port Members of Multicast Services . . . . . . 2-119
Adding Multicast Addresses to VLANs . . . . . . . . . . . . 2-121
Showing Device Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . 2-122
801.1X Port Authentication . . . . . . . . . . . . . . . . . . . . . . . . . 2-129
802.1x Port Configuration . . . . . . . . . . . . . . . . . . . . . 2-131
802.1x Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-134
Statistical Values . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-134
3
Command Line Interface 3-1
Using the Command Line Interface . . . . . . . . . . . . . . . . . . . . . 3-1
Accessing the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Console Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Telnet Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Entering Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Keywords and Arguments . . . . . . . . . . . . . . . . . . . . . . . 3-4
Minimum Abbreviation . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Command Completion . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Getting Help on Commands . . . . . . . . . . . . . . . . . . . . . 3-5
Partial Keyword Lookup . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Negating the Effect of Commands . . . . . . . . . . . . . . . . . 3-7
Using Command History . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Understanding Command Modes . . . . . . . . . . . . . . . . . 3-7
Exec Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Configuration Commands . . . . . . . . . . . . . . . . . . . . . . . 3-9
Command Line Processing . . . . . . . . . . . . . . . . . . . . . 3-10
Command Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
General Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
b_mgmt.book Page ix Tuesday, July 8, 2003 5:24 PM

C ONTENTS
x
disable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
configure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
show history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
reload . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-18
exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
quit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Flash/File Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20
copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23
dir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-24
whichboot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
boot system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26
System Management Commands . . . . . . . . . . . . . . . . . . . . . 3-27
hostname . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-29
username . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
enable password . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31
jumbo frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32
ip http port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-33
ip http server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-34
ip http secure-server . . . . . . . . . . . . . . . . . . . . . . . . . 3-35
ip http secure-port . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
ip ssh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-37
ip ssh server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-38
disconnect ssh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-39
show ssh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-40
show ip ssh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-40
logging on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-41
logging history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-42
logging host . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44
logging facility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-45
logging trap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-45
clear logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-47
show logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-47
show startup-config . . . . . . . . . . . . . . . . . . . . . . . . . . 3-48
show running-config . . . . . . . . . . . . . . . . . . . . . . . . . 3-51
show system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-52
b_mgmt.book Page x Tuesday, July 8, 2003 5:24 PM

C ONTENTS
xi
show users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-53
show version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-54
Authentication Commands . . . . . . . . . . . . . . . . . . . . . . . . . . 3-55
authentication login . . . . . . . . . . . . . . . . . . . . . . . . . . 3-56
radius-server host . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
radius-server port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
radius-server key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59
radius-server retransmit . . . . . . . . . . . . . . . . . . . . . . . 3-60
radius-server timeout . . . . . . . . . . . . . . . . . . . . . . . . . 3-60
show radius-server . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-61
tacacs-server host . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-61
tacacs-server port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-62
tacacs-server key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-63
show tacacs-server . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-63
SNMP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-64
snmp-server community . . . . . . . . . . . . . . . . . . . . . . . 3-65
snmp-server contact . . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
snmp-server location . . . . . . . . . . . . . . . . . . . . . . . . . 3-66
snmp-server host . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-67
snmp-server enable traps . . . . . . . . . . . . . . . . . . . . . . 3-69
snmp ip filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-70
show snmp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-71
IP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-73
ip address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-74
ip dhcp restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-75
ip default-gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-76
show ip interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-77
show ip redirects . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-78
ping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-78
Line Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-80
line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-81
login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-82
password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-83
exec-timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-84
password-thresh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-85
silent-time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-86
databits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-87
b_mgmt.book Page xi Tuesday, July 8, 2003 5:24 PM

C ONTENTS
xii
parity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-88
speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-89
stopbits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-90
show line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-90
Interface Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-91
interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-92
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-93
speed-duplex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-94
negotiation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-95
capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-96
flowcontrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-97
shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-99
switchport broadcast . . . . . . . . . . . . . . . . . . . . . . . . .3-100
port security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-101
clear counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-102
show interfaces status . . . . . . . . . . . . . . . . . . . . . . . .3-103
show interfaces counters . . . . . . . . . . . . . . . . . . . . . .3-104
show interfaces switchport . . . . . . . . . . . . . . . . . . . . .3-106
Address Table Commands . . . . . . . . . . . . . . . . . . . . . . . . . .3-107
mac-address-table static . . . . . . . . . . . . . . . . . . . . . . .3-108
show mac-address-table . . . . . . . . . . . . . . . . . . . . . . .3-109
clear mac-address-table dynamic . . . . . . . . . . . . . . . .3-111
mac-address-table aging-time . . . . . . . . . . . . . . . . . . .3-111
show mac-address-table aging-time . . . . . . . . . . . . . .3-112
Spanning Tree Commands . . . . . . . . . . . . . . . . . . . . . . . . .3-113
spanning-tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-114
spanning-tree mode . . . . . . . . . . . . . . . . . . . . . . . . . .3-115
spanning-tree forward-time . . . . . . . . . . . . . . . . . . . .3-116
spanning-tree hello-time . . . . . . . . . . . . . . . . . . . . . .3-117
spanning-tree max-age . . . . . . . . . . . . . . . . . . . . . . .3-118
spanning-tree priority . . . . . . . . . . . . . . . . . . . . . . . .3-119
spanning-tree pathcost method . . . . . . . . . . . . . . . . .3-120
spanning-tree transmission-limit . . . . . . . . . . . . . . . . .3-121
spanning-tree cost . . . . . . . . . . . . . . . . . . . . . . . . . . .3-122
spanning-tree port-priority . . . . . . . . . . . . . . . . . . . . .3-123
spanning-tree portfast . . . . . . . . . . . . . . . . . . . . . . . .3-124
spanning-tree edge-port . . . . . . . . . . . . . . . . . . . . . . .3-125
b_mgmt.book Page xii Tuesday, July 8, 2003 5:24 PM

C ONTENTS
xiii
spanning-tree protocol-migration . . . . . . . . . . . . . . . 3-126
spanning-tree link-type . . . . . . . . . . . . . . . . . . . . . . . 3-127
show spanning-tree . . . . . . . . . . . . . . . . . . . . . . . . . 3-128
VLAN Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-130
vlan database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-131
vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-132
interface vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-133
switchport mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-134
switchport acceptable-frame-types . . . . . . . . . . . . . . 3-135
switchport ingress-filtering . . . . . . . . . . . . . . . . . . . . 3-136
switchport native vlan . . . . . . . . . . . . . . . . . . . . . . . 3-137
switchport allowed vlan . . . . . . . . . . . . . . . . . . . . . . 3-138
switchport forbidden vlan . . . . . . . . . . . . . . . . . . . . . 3-139
show vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-140
GVRP and Bridge Extension Commands . . . . . . . . . . . . . . . 3-141
switchport gvrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-142
show gvrp configuration . . . . . . . . . . . . . . . . . . . . . . 3-143
garp timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-144
show garp timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-145
bridge-ext gvrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-146
show bridge-ext . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-147
IGMP Snooping Commands . . . . . . . . . . . . . . . . . . . . . . . . 3-148
ip igmp snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-149
ip igmp snooping vlan static . . . . . . . . . . . . . . . . . . . 3-150
ip igmp snooping version . . . . . . . . . . . . . . . . . . . . . 3-151
show ip igmp snooping . . . . . . . . . . . . . . . . . . . . . . 3-152
show mac-address-table multicast . . . . . . . . . . . . . . . 3-152
ip igmp snooping querier . . . . . . . . . . . . . . . . . . . . . 3-153
ip igmp snooping query-count . . . . . . . . . . . . . . . . . 3-154
ip igmp snooping query-interval . . . . . . . . . . . . . . . . 3-155
ip igmp snooping query-max-response-time . . . . . . . 3-156
ip igmp snooping router-port-expire-time . . . . . . . . . 3-157
ip igmp snooping vlan mrouter . . . . . . . . . . . . . . . . . 3-158
show ip igmp snooping mrouter . . . . . . . . . . . . . . . . 3-159
Priority Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-160
switchport priority default . . . . . . . . . . . . . . . . . . . . . 3-161
queue bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-162
b_mgmt.book Page xiii Tuesday, July 8, 2003 5:24 PM

C ONTENTS
xiv
queue cos-map . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-163
show queue bandwidth . . . . . . . . . . . . . . . . . . . . . . .3-165
show queue cos-map . . . . . . . . . . . . . . . . . . . . . . . .3-166
map ip precedence (Global Configuration) . . . . . . . . .3-166
map ip precedence (Interface Configuration) . . . . . . .3-167
map ip dscp (Global Configuration) . . . . . . . . . . . . . .3-169
map ip dscp (Interface Configuration) . . . . . . . . . . . .3-170
show map ip precedence . . . . . . . . . . . . . . . . . . . . . .3-171
show map ip dscp . . . . . . . . . . . . . . . . . . . . . . . . . . .3-172
Mirror Port Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-174
port monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-174
show port monitor . . . . . . . . . . . . . . . . . . . . . . . . . .3-175
Port Trunking Commands . . . . . . . . . . . . . . . . . . . . . . . . . .3-177
channel-group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-178
lacp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-179
A
Troubleshooting A-1
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
B
Upgrading Firmware via the Serial Port B-1
Glossary
Index
b_mgmt.book Page xiv Tuesday, July 8, 2003 5:24 PM

1-1
C HAPTER 1
S WITCH M ANAGEMENT
Connecting to the Switch
Configuration Options
The TigerSwitch 10/100/1000 includes a built-in network
management agent. The agent offers a variety of management
options, including SNMP, RMON and a Web-based interface. A PC
may also be connected directly to the switch for configuration and
monitoring via a command line interface (CLI).
Note: The IP address for this switch is assigned via DHCP by
default. To change this address, see “Setting an IP Address”
on page 1-7.
The switch’s HTTP Web agent allows you to configure switch
parameters, monitor port connections, and display statistics
graphically using a standard Web browser such as Netscape
Navigator version 6.2 and higher or Microsoft IE version 5.0 and
higher. The switch’s Web management interface can be accessed
from any computer attached to the network.
The switch’s management agent is based on SNMP (Simple
Network Management Protocol). This SNMP agent permits the
switch to be managed from any system in the network using
management software.
The CLI program can be accessed by a direct connection to the
RS-232 serial console port on the switch, or remotely by a Telnet
connection over the network.
b_mgmt.book Page 1 Tuesday, July 8, 2003 5:24 PM

S WITCH M ANAGEMENT
1-2
The switch’s CLI configuration program, Web interface, and SNMP
agent allow you to perform the following management functions:
• Set user names and passwords for up to 16 users
• Set an IP interface for a management VLAN
• Configure SNMP parameters
• Enable/disable any port
• Set the speed/duplex mode for any port
• Configure up to 255 IEEE 802.1Q VLANs
• Enable GVRP automatic VLAN registration
• Configure IGMP multicast filtering
• Upload and download of system firmware via TFTP
• Upload and download of switch configuration files via TFTP
• Configure Spanning Tree parameters
• Configure Class of Service (CoS) priority queuing
• Configure up to six static or LACP trunks
• Enable jumbo frame support
• Enable port mirroring
• Set broadcast storm control on any port
• Display system information and statistics
b_mgmt.book Page 2 Tuesday, July 8, 2003 5:24 PM

C ONNECTING TO THE S WITCH
1-3
Required Connections
The switch provides an RS-232 serial port that enables a
connection to a PC or terminal for monitoring and configuring the
switch. A null-modem console cable is provided with the switch.
Attach a VT100-compatible terminal, or a PC running a terminal
emulation program to the switch. You can use the console cable
provided with this package, or use a null-modem cable that
complies with the wiring assignments shown in Appendix C.
To connect a terminal to the console port, complete the following
steps:
1. Connect the console cable to the serial port on a terminal, or a
PC running terminal emulation software, and tighten the
captive retaining screws on the DB-9 connector.
2. Connect the other end of the cable to the RS-232 serial port on
the switch.
3. Make sure the terminal emulation software is set as follows:
• Select the appropriate serial port (COM port 1 or COM
port 2).
• Set the data rate to 9600 baud.
• Set the data format to 8 data bits, 1 stop bit, and no parity.
• Set flow control to none.
• Set the emulation mode to VT100.
• When using HyperTerminal, select Terminal keys, not
Windows keys.
b_mgmt.book Page 3 Tuesday, July 8, 2003 5:24 PM

S WITCH M ANAGEMENT
1-4
Note: When using HyperTerminal with Microsoft®Windows®
2000, make sure that you have Windows 2000 Service Pack
2 or later installed. Windows 2000 Service Pack 2 fixes the
problem of arrow keys not functioning in HyperTerminal’s
VT100 emulation. See www.microsoft.com for information
on Windows 2000 service packs.
4. Once you have set up the terminal correctly, the console login
screen will be displayed.
Note: Refer to “Line Commands” on page 3-80 for a complete
description of console configuration options.
For a description of how to use the CLI, see “Using the Command
Line Interface” on page 3-1. For a list of all the CLI commands and
detailed information on using the CLI, refer to “Command Groups”
on page 3-12.
Remote Connections
Prior to accessing the switch’s onboard agent via a network
connection, you must first configure it with a valid IP address,
subnet mask, and default gateway using a console connection,
DHCP or BOOTP protocol.
The IP address for this switch is assigned via DHCP by default. To
manually configure this address or enable dynamic address
assignment via DHCP or BOOTP, see “Setting an IP Address” on
page 1-7.
Note: This switch supports four concurrent Telnet sessions.
After configuring the switch’s IP parameters, you can access the
onboard configuration program from anywhere within the
attached network. The onboard configuration program can be
accessed using Telnet from any computer attached to the network.
The switch can also be managed by any computer using a Web
b_mgmt.book Page 4 Tuesday, July 8, 2003 5:24 PM

B ASIC C ONFIGURATION
1-5
browser (Internet Explorer 5.0 or above, or Netscape Navigator 6.2
or above), or from a network computer using network
management software.
Note: The onboard program only provides access to basic
configuration functions. To access the full range of SNMP
management functions, you must use SNMP-based network
management software.
Basic Configuration
Console Connection
The CLI program provides two different command levels —
normal access level (Normal Exec) and privileged access level
(Privileged Exec). The commands available at the Normal Exec
level are a limited subset of those available at the Privileged Exec
level and allow you to only display information and use basic
utilities. To fully configure switch parameters, you must access the
CLI at the Privileged Exec level.
Access to both CLI levels are controlled by user names and
passwords. The switch has a default user name and password for
each level. To log into the CLI at the Privileged Exec level using
the default user name and password, perform these steps:
1. To initiate your console connection, press <Enter>. The “User
Access Verification” procedure starts.
2. At the Username prompt, enter “admin.”
3. At the Password prompt, also enter “admin.” (The password
characters are not displayed on the console screen.)
4. The session is opened and the CLI displays the “Console#”
prompt indicating you have access at the Privileged Exec level.
b_mgmt.book Page 5 Tuesday, July 8, 2003 5:24 PM

S WITCH M ANAGEMENT
1-6
Setting Passwords
Note: If this is your first time to log into the CLI program, you
should define new passwords for both default user names
using the “username” command, record them and put them
in a safe place.
Passwords can consist of up to eight alphanumeric characters and
are case sensitive. To prevent unauthorized access to the switch,
set the passwords as follows:
1. Open the console interface with the default user name and
password “admin” to access the Privileged Exec level.
2. Type “configure” and press <Enter>.
3. Type “username guest password 0 password,” for the Normal
Exec level, where password is your new password. Press
<Enter>.
4. Type “username admin password 0 password,” for the
Privileged Exec level, where password is your new password.
Press <Enter>.
Username: admin
Password:
CLI session with the SMC8624T is opened.
To end the CLI session, enter [Exit].
Console#configure
Console(config)#username guest password 0 [password]
Console(config)#username admin password 0 [password]
Console(config)#
b_mgmt.book Page 6 Tuesday, July 8, 2003 5:24 PM
