Smeg CVI638RWN2 User manual

Contents
29
EN
1Instructions 30
1.1 General safety instructions 30
1.2 Appliance purpose 32
1.3 Disposal 33
1.4 Identification plate 33
1.5 This user manual 33
1.6 How to read the user manual 34
2 Description 35
2.1 General Description 35
2.2 Description of parts 36
2.3 Control panel 37
3Use 38
3.1 Instructions 38
3.2 Preliminary operations 38
3.3 First use 38
3.4 Using the control panel 39
3.5 Using the wine cellar compartments 42
3.6 Alarms 44
3.7 Food storage advice 45
4 Cleaning and maintenance 48
4.1 Instructions 48
4.2 Cleaning the appliance 48
4.3 What to do if... 50
5Installation 51
5.1 Electrical connection 51
5.2 Positioning 51
We advise you to read this manual carefully, as it contains all the instructions for maintaining
the appliance’s aesthetic and functional qualities.
For further information on the product: www.smeg.com
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
Apple, App Store and iOS marks belong to Apple Inc.
Google Play Store and Android marks belong to Google Inc.
Wi-Fi is a mark belonging to Wi-Fi Alliance.

Instructions
30
1 Instructions
1.1 General safety instructions
Risk of personal injury
• Keep children under the age of 8
at a safe distance unless they are
constantly supervised.
• According to the current
regulations, children between 3
and 8 years of age can take or
load food from the appliance, but
it is strongly advised against
allowing children under 8 years of
age to perform these operations
and in general to use the
appliance.
• Children must never play with the
appliance.
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the flames
with a fire blanket or other
appropriate cover.
• Cleaning and maintenance must
not be carried out by
unsupervised children.
• Have qualified personnel carry
out installation and assistance
interventions according to the
standards in force.
• Do not modify this appliance.
• Do not insert pointed metal
objects (cutlery or utensils) into the
slots in the appliance.
• Do not try to repair the appliance
yourself or without the intervention
of a qualified technician.
• Do not pull the cable to remove
the plug.
• If the power supply cable is
damaged, contact technical
support immediately and they will
replace it.
• If it is necessary to replace the
power cable, this must be
performed by an authorised
technician from Technical
Support Service.
• DO NOT USE OR STORE
FLAMMABLE MATERIALS NEAR
THE APPLIANCE.
• DO NOT USE AEROSOLS IN
THE VICINITY OF THIS
APPLIANCE WHILST IT IS IN
USE.
• DO NOT MODIFY THIS
APPLIANCE.
• Have qualified personnel carry
out installation and assistance
interventions according to the
standards in force.
Risk of damaging the appliance
• Never rest sharp metal objects
such as knives, forks, spoons and
lids on the appliance during use.
• Do not use abrasive or corrosive
detergents (e.g. scouring
powders, stain removers and

Instructions
31
EN
metallic sponges) on glass parts.
• Do not use rough or abrasive
materials or sharp metal scrapers.
• Do not sit on the appliance.
• Do not rest any weight or sit on
the open door of the appliance.
• Take care that no objects are
stuck in the doors.
• Do not store inflammable,
explosive or volatile substances.
• Organic compounds, acids and
essential oils can corrode the
seals and plastic surfaces if left in
contact with them for extended
periods.
• Bottles with a high alcohol content
must be tightly closed.
• Do not use steam jets to clean the
appliance.
• Do not spray any spray product
near the appliance.
• Do not obstruct ventilation
openings and heat dispersal slots.
• Do not use electrical appliances
inside food storage compartments
unless these are of the type
recommended by the
manufacturer.
• DO NOT USE THE APPLIANCE
TO COOL ROOMS FOR ANY
REASON.
• Never use mechanical devices or
any other means not
recommended by the
manufacturer to accelerate the
defrosting process.
• Always unplug the appliance in
the event of a fault or when
performing cleaning or
maintenance.
• Never use the door to lever the
appliance into place when fitting.
• Avoid exerting too much pressure
on the door when open.
• Do not use the handle to lift or
move this appliance.
• WARNING: When positioning
the appliance, ensure the supply
cord is not trapped or damaged.
• WARNING: Do not locate
multiple portable socket-outlets or
portable power supplies at the
rear of the appliance.
Installation and maintenance
• THIS APPLIANCE MUST NOT BE
INSTALLED IN A BOAT OR
CARAVAN.
• This appliance must not be
installed on a pedestal.
• Position the appliance into the
cabinet cut-out with the help of a
second person.
• To prevent any possible
overheating, the appliance should
not be installed behind a
decoration door or a panel.
• Have qualified personnel carry

Instructions
32
out installation and assistance
interventions according to the
standards in force.
• Have the electrical connection
performed by authorised
technicians.
• The appliance must be connected
to ground in compliance with
electrical system safety standards.
• Use cables withstanding a
temperature of at least 90 °C.
• The tightening torque of the
screws of the terminal board leads
must be 1.5 - 2 Nm.
• Before any operation on the
appliance (installation,
maintenance, positioning or
movement) always wear PPM.
• Before performing any operation
on the appliance, switch off the
power supply.
• Opening the door for long
periods can cause a significant
increase of the temperature in the
compartments of the appliance.
• If the refrigerating appliance is left
empty for long periods, switch off,
defrost, clean, dry, and leave the
door open to prevent mould
developing within the appliance.
1.2 Appliance purpose
• This appliance has been designed
exclusively for storing wine in a
domestic setting. Every other use is
considered inappropriate.
• This appliance may be used by
children aged at least 8 and by
people of reduced physical, sensory
or mental capacity, or lacking in
experience in the use of electrical
appliances, provided that they are
supervised or instructed by adults
who are responsible for their safety.
• This appliance is not suitable for use
by persons (including children) with
reduced physical, sensory or mental
capacity, or by those without
experience or knowledge, unless
they are supervised or instructed on
the use of the appliance by a person
responsible for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance.
• Do not install/use the appliance
outdoors.
• The appliance is not designed to
operate with external timers or with
remote-control systems.
The appliance is designed for use in a
domestic or similar environment, for
instance:
• Staff kitchen areas in shops, offices
and other working environments;
• Farm houses and by guests in hotels,
motels and other residential type
environments;
• bed and breakfast establishments;
• catering and similar non-retail
applications.

Instructions
33
EN
1.3 Disposal
This appliance must be disposed of
separately from other waste
(Directives 2002/95/EC,
2002/96/EC, 2003/108/EC).
The appliance does not contain substances
in quantities sufficient to be considered
hazardous to health and the environment, in
accordance with current European
directives.
To dispose of the appliance:
• Cut the power supply cable and
remove it along with the plug.
• Deliver the appliance to the appropriate
recycling centre for electrical and
electronic equipment waste, or return it
to the retailer when purchasing an
equivalent product, on a one for one
basis.
Our appliances are packaged in non-
polluting and recyclable materials.
• Deliver the packing materials to the
appropriate recycling centre.
1.4 Identification plate
The identification plate bears the technical
data, serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
1.5 This user manual
This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and within the user’s reach for the
whole working life of the appliance.
Read this user manual carefully before using
the appliance.
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part
of it unattended.
• Do not let children play with the plastic
bags.

Instructions
34
1.6 How to read the user manual
This user manual uses the following reading
conventions:
1. Sequence of instructions for use.
• Standalone instruction.
Instructions
General information on this user
manual, on safety and final
disposal.
Description
Description of the appliance and its
accessories.
Use
Information on the use of the
appliance and its accessories.
Cleaning and maintenance
Information for proper cleaning and
maintenance of the appliance.
Installation
Information for the qualified
technician: Installation, operation
and inspection.
Safety instructions
Information
Advice

Description
35
EN
2 Description
2.1 General Description
1 Upper compartment interior lighting
2 Fan (not visible)
3 Activated charcoal filter
4 Lower compartment interior lighting
5 Control panel
6 Door
7 Door seal
8 Magnet
9 Ventilation grille
Removable shelf

Description
36
2.2 Description of parts
Smeg Connect
The appliance is equipped with the
Smeg Connect technology so that the user
can control its operation through an App on
his smartphone or PC tablet.
For further information, refer to the supplied
brochure and/or visit the site
www.smeg.com
Interior lighting
The interior lighting of the appliance turns
on when the door is opened (maximum
brightness) or when the Light Key on
the control panel is pressed (medium
brightness).
Activated charcoal filters
Ensure optimum air quality for wine storage.
Fans (not visible)
Distribute the temperature and reduce
condensation on the shelves and other
surfaces.
Door
Fitted with a seal and magnet, this provides
perfect insulation of the wine cellar from the
surrounding environment.
Removable shelves
The removable shelves allow easy removal
of the bottles of wine.
Fixed shelf
The fixed shelf is designed to hold bottles of
champagne and sparkling wines or other
bottles with a diameter larger than that of
normal wines.
The lower compartment LED lighting is
located beneath the fixed shelf.
When the fans are on, the power
consumption increases.

Description
37
EN
2.3 Control panel
The control panel allows the user to interact
with the appliance. Touch the keys with
symbols to access the available functions.
Upper cellar display key
The display shows the temperature inside
the upper wine cellar.
Decrease key
This key lowers the temperature inside the
upper or lower compartment.
Increase key
This key increases the temperature inside
the upper or lower compartment.
Lower cellar display key
The display shows the temperature inside
the lower wine cellar.
Light key
This key turns the lighting inside the wine
cellar on and off. The lighting turns off after
a maximum period of 15 minutes.
Connection key
By this key you can activate the connectivity
functions.
ON/OFF key
It switches on and off the appliance and
activates the control panel.
Control lock key
This key disables the control panel keys.
Fan key
Through this button you can activate or
deactivate the manual ventilation mode to
increase humidity inside the wine cellar.
The fan activates and deactivates
automatically depending on the
software settings.

Use
38
3 Use
3.1 Instructions
3.2 Preliminary operations
1. Remove any protective film from the
outside or inside of the appliance,
including accessories.
2. Remove any labels (apart from the
technical data plate) from the
accessories and shelves.
3. Remove and wash all the appliance's
accessories (see 4 Cleaning and
maintenance).
3.3 First use
To turn on the appliance:
1. insert the plug into the power socket;
2. press the ON/OFF key on the
control panel:
3. press the upper wine cellar
temperature key and select the
required temperature for the interior of
the upper wine cellar by pressing the
Increase or Decrease keys
(from 5°C to 20°C).
4. press the lower wine cellar
temperature key and select the
required temperature for the interior of
the lower wine cellar by pressing the
Increase or Decrease keys
(from 5°C to 20°C).
To turn off the appliance:
5. press and hold the ON/OFF key
on the control panel for a few seconds.
Improper use
Risk of damage to the appliance
• Do not rest any weight or sit on the
appliance door.
• Do not store inflammable, explosive or
volatile substances.
• Organic compounds, acids and
essential oils can corrode the seals and
plastic surfaces if left in contact with them
for extended periods.
• Do not obstruct the openings of the
ventilation grille in any way.
•Bottleswithahighalcohol content must
be tightly closed.
Each press of the Increase or
Decrease keys changes the
temperature by 1°C.
The set temperature will flash on
the display for around 5 seconds,
and then it remains steadily
displayed.
