Smithco 2000D Quick start guide

Spray Star 2000D
Model 20-700-A
SN: 200D324
January 2019
Product Support: Hwy SS & Poplar Ave; Cameron WI 54822
1-800-891-9435 [e-mail]
Parts & Service

Introduction Service Diagrams Parts Accessories Reference
CONTENTS
Introduction............................................1-3
Introduction........................................................................ 1
General Safe Practices...................................................... 2
 ................................................................... 3
Optional Spray Equipment................................................. 3
Service....................................................4-9
Maintenance...................................................................4-6
Storage.............................................................................. 6
Adjustments....................................................................... 7
Service Chart..................................................................8-9
Diagrams ............................................10-15
Main Wiring Diagram.................................................. 10-11
Engine Wiring Diagram...............................................12-13
Hydraulic Diagram......................................................14-15
Parts....................................................16-49
Body & Frame ............................................................16-17
Nose Cone .................................................................18-21
Linkage.......................................................................22-23
Front Axle .................................................................24-25
Oil Tank and Fuel Tank ...............................................26-27
Seat Panel..................................................................28-29
Engine and Pumps .....................................................30-33
Spray Pump................................................................34-35
Rear Axle....................................................................36-37
Spray Tank..................................................................38-39
Turbo Quad Agitator .................................................. 40-41
15-301 Orbitor ...........................................................42-43
16-998 Hypro®Pump ...................................................... 44
76-197 Eaton Gear Pump................................................ 45
76-638 Hydrostatic Pump...........................................46-47
43-116 Wheel Motor ...................................................48-49
Accessories .....................................50-114
Plumbing 2002D System (Radion®8140) ..................50-51
Plumbing 2004D System (TeeJet®744) ....................52-53
Wiring 2004 System (TeeJet®744).................................. 54
Wiring 2002 System (Radion®8140) .............................. 55
Plumbing Star Command I & II ................................... 56-57
Star Command I Module Mounts..................................... 58
Star Command I Wiring System ...................................... 59
Star Command II Module Mounts.................................... 60
Star Command II Wiring System .................................... 61
20-817 Regulator Valve ................................................... 62
20-785 Regulator Valve ................................................. 63
15-737/14-628 Flanged Strainer...................................... 64
15-743 Manifold Ball Valve .............................................. 65
14-801 Agitation Strainer................................................. 67
17-580 20’ HD Boom ..................................................68-71
17-580 20’ HD Boom 744 and Radion Plumbing............. 72
17-580 20’ HD Boom Star Command I Plumbing............ 73
17-580 20’ HD Boom Star Command II Plumbing........... 74
17-585 18’ HD Boom Star Command II Plumbing........... 75
17-585 18’ HD Boom ..................................................76-79
17-585 18’ HD 744 and Radion Plumbing ....................... 80
17-585 18’ HD Boom Star Command I Plumbing............ 81
17-601 15’ HD Boom ..................................................82-85
17-601 15’ HD Boom 744 and Radion Plumbing............. 86
17-601 15’ HD Boom Star Command I Plumbing............ 87
17-601 15’ HD Boom Star Command II Plumbing........... 88
Standard Nozzle Assembly.............................................. 89
Star Command I Nozzle Assembly............................. 90-91
Star Command II Nozzle Assembly................................. 92
14-515 Water Meter Kit (Gallons).................................... 93
15-618 Water Meter Kit (Liters) ....................................... 93
30-010 Electric Hose Reel .........................................94-96
30-009 Hose Reel ........................................................... 97
Hose Reel Installation.................................................98-99
Hose Reel Adjustments ................................................... 99
30-004 Foam Marker Installation............................ 100-103
14-291 Foamer Replacement Parts .......................104-105
20-758 Fresh Water Tank - Front Mount........................ 106
30-006 Fresh Water Tank - Rear Mount ........................ 107
20-503 Chemical Cleanload System ......................108-109
15-620 Chemical Cleanload Replacement Parts.....110-111
15-835 Tank Rinsing System........................................ 112
20-760 26Gallon Rinse Tank ......................................... 113
Reference .......................................115-116
Decal List....................................................................... 115
Quick Reference Replacement Parts ............................ 116
Warranty ..............................................................................

1
Introduction
INTRODUCTION
Thank you for purchasing a Smithco product.
Read this manual and all other manuals pertaining to the Spray Star 2000 Diesel carefully as they contain
safety, operating, assembly and maintenance instructions. Failure to do so could result in personal injury or
equipment damage.
Keep manuals in a safe place after operator and maintenance personnel have read them. Right and left sides
are from the operator’s seat, facing forward.
All Smithco machines have a Serial Number and Model Number. Both numbers are needed when ordering
parts. Refer to engine manual for placement of engine serial number.

www.Smithco.com.
Information needed when ordering replacement parts:
1. Model Number of machine
2. Serial Number of machine
3. Name and Part Number of part
4. Quantity of parts
For easy access record your Serial and Model numbers here.
SMITHCO CUSTOMER SERVICE 1-800-891-9435
 
WARNING
Failure to follow cautious operating practices can re-
sult in serious injury to the operator or other persons.
The owner must understand these instructions, and
must allow only trained persons who understand these
instructions to operate this vehicle.
WARNING:
Engine exhaust and some of its constituents are
known to the State of California to cause cancer,
birth defects, and other reproductive harm.
For more information visit
www.P65Warning.ca.gov

2
Introduction
SAFE PRACTICES
1. It is your responsibility to read this manual and all publications associated with this machine.
2. Never allow anyone to operate or service the machine or its optional equipment without proper training
and instructions. Never allow minors to operate any equipment.
3. Learn the proper use of the machine, the location and purpose of all the controls and gauges before
you operate the equipment. Working with unfamiliar equipment can lead to accidents.
4. Wear all the necessary protective clothing and personal safety devises to protect your head, eyes, ears,

  
Beware of overhead obstructions and underground obstacles. Stay alert for hidden hazards.
6. Never operate equipment that is not in perfect working order or without decals, guards, shields, or other
protective devices in place.
7. Never disconnect or bypass any switch.
8. Carbon monoxide in the exhaust fumes can be fatal when inhaled, never operate a machine without
proper ventilation.
  
10. Keep engine clean. Allow the engine to cool before storing and always remove the ignition key.
11. Disengage all drives and set park brake before starting the engine.
  
cause serious injury.
13. This machine demands your attention. To prevent loss of control or tipping of the vehicle:
A. Use extra caution in backing up the vehicle. Ensure area is clear.
B. Do not stop or start suddenly on any slope.
C. Reduce speed on slopes and in sharp turns. Use caution when changing directions on slopes.
D. Stay alert for holes in the terrain and other hidden hazards.
14. Before leaving operator’s position:
A. Disengage all drives.
B. Set park brake.
 󰀨
D. If engine has to run to perform any maintenance keep hands, feet, clothing and all other parts of
body away from moving parts.
15. Keep hands, feet and clothing away from moving parts. Wait for all movement to stop before you clean,
adjust or service the machine.
16. Keep the area of operation clear of all bystanders.
17. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase.
18. Use parts and materials supplied by Smithco only. Do not modify any function or part.
19. Use caution when booms are down as they extend out beyond the center line of the machine.
  
These machines are intended for professional maintenance on golf courses, sports turf, and any other
area maintained turf and related trails, paths and lots. No guaranty as to the suitability for any task is
expressed or implied.

3
Introduction
SPECIFICATIONS SPRAY STAR 2000
WEIGHTS AND DIMENSIONS
Length 132" (335cm) - w/ booms 137" (348 cm) - w/ Cleanload 151" (384 cm)
Width 72" (183cm)
Height w/ Booms Folded 110" (279 cm)
Wheel Base 61" (155cm)
Weight Empty 2090 lbs (948kg)
Weight Loaded 3705 lbs (1681 kg)
SOUND LEVEL (DB)
At ear level 98 dBA
ENGINE
Make Kubota
Model# D1105-E3B
Horsepower 25 hp (18.5 kW)
Fuel No.1-D or No. 2-D, S500: Low Sulfur Diesel (LSD) less than 500 ppm or 0.05 wt.%
No.1-D or No.2-D, S15: Ultra Low Sulfur Diesel (ULSD) less than 15 ppm or 0.0015 wt.%
Cooling System Liquid Cooled
Lubrication System Full Pressure
Alternator 15 Amp
WHEELS & TIRE Front: Two 20 x 10.00 x 10 NHS Multi-Rib; 20 psi (1.4 bar)
Rear: Two 24 x 13.00 x 12 NHS Multi-Trac; 18 psi (1.3 bar)
SPEED
  
BATTERY Automotive type 24F - 12 volt
BCI Group Size 24
Cold Cranking Amps 900 minimum
Ground Terminal Polarity Negative (-)
Maximum Length 10.25" (26 cm)
Maximum Width 6.88" (17 cm)
Maximum Height 10" (25 cm)
FLUID CAPACITY
Crankcase Oil See Engine Manual
Fuel 7 gallon (26.5 liters)
Hydraulic Fluid 5 gallon (19 liters)
Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or higher Motor Oil
OPTIONAL EQUIPMENT
15-618 Water Meter Kit (liters) 14-515 Water Meter Kit (Gallons)
20-503 Chemical Cleanload Safe Fill 15-850 Sunshade Canopy
30-009 Manual Rewind Hose Reel, 200-foot/61-meter capacity
30-010 Electric Rewind Hose Reel, 200-foot/61-meter capacity
30-004 Foam Marker 30-006 Fresh Water Wash Tank- Rear Mount
15-835 Tank Rinsing System 20-758 Fresh Water Wash Tank - Front Mount
17-585 18' HD Super Boom 17-580 20' HD Super Boom
31-004 All Weather Top 20-760 26 Gal Wash System

4
Service
MAINTENANCE
Before servicing or making adjustments to machine, stop engine and remove
key from ignition.
Use all procedures and parts prescribed by the manufacturer's. Read the en-
gine manual before operation.
Use No. 2 General purpose lithium base grease
and lubricate every 100 hours. The Spray Star

A. One on each pedal mount.
B. Pedal relay.
C. Right and left spindles.
D. All three rod ends.
E. Idler arm.
F. Brake relay.
G. Top and bottom pivot bolts on boom
ELECTRICAL CONNECTIONS
Use dielectric grease on all electrical connections.
WHEEL MOUNTING PROCEDURE
  󰀨
2. Block wheel on opposite corner.
3. Loosen nuts slightly on wheel to be removed.
4. Jack up machine being careful not to damage underside of machine.
5. Place wheel on hub lining up bolt holes.
  
hours thereafter.
7. Lower machine to ground and remove blocks and jack.
TIRE PRESSURE


reduce tire life considerably.

5
Service
MAINTENANCE
ENGINE OIL
󰀨
CF-4 and CG-4 engine oils have been developed for use
with low sulfur fuels, for On-Highway vehicle engines. When
Non-Road engines run on high sulfur fuel, it is advisable to

Number (a minimum TBN of 10 is recommended).
Check the engine oil before starting or more than 5 minutes



type of Engine oil according to the ambient temperature.
Starting Temperature Range Anticipated Before Next Oil Change
HYDRAULIC OIL
1. Use SAE 10W-40 API Service SJ or higher motor oil.
  

  
4. After changing oil, run the machine for a few minutes. Check oil level and for leaks.
5. -
taminants. Check and service more frequently when operating in extremely cold, hot or dusty conditions.
  -
lem exists.
  
  

9. In extreme temperatures you can use straight weight oil. We recommend SAE 30W API Service SG
when hot (above 90°F (33°C)) and SAE 10W API Service SJ or higher when cold (below 32°F (0°C)
ambient temperature. Use either motor oil or hydraulic oil, but do not mix.
10. Oil being added to the system must be the same as what is already in the tank. 
as to which type you put in.

6
Service
MAINTENANCE
BATTERY

any ignited object to come near the battery. When charging or working near battery, always shield your eyes
and always provide proper ventilation.
Battery cable should be disconnected before using “Fast Charge”.
Charge battery at 15 amps for 10 minutes or 7 amps for 30 minutes. Do not exceed the recommended
charging rate. If electrolyte starts boiling over, decrease charging.

1. Filling batteries in well-ventilated areas.
2. Wear eye protection and rubber gloves.
3. Avoid breathing fumes when electrolyte is added.
4. Avoid spilling or dripping electrolyte.
Battery Electrolyte is an acidic solution and should be handled with care. If
electrolyte is splashed on any part of your body, ush all contact areas imme-
diately with liberal amounts of water. Get medical attention immediately.
Use of booster battery and jumper cables. Particular care should be used
when connecting a booster battery. Use proper polarity in order to prevent
sparks.
TO JUMP START (NEGATIVE GROUNDED BATTERY):
1. Shield eyes.
2. Connect ends of one cable to positive (+) termi-

3. Connect one end of other cable to negative (-)
terminal of "good" battery (C).
4. Connect other end of cable (D) to engine block
on unit being started (NOT to negative (-) termi-
nal of battery)
To prevent damage to other electrical components on
unit being started, make certain that engine is at idle speed before disconnecting jumper cables.
STORAGE
If the engine will be out of service for two or more months, use the following storage procedure.
1. Clean the exterior surfaces of the engine.
  
3. The fuel system must be completely emptied, or the gasoline must be treated with a stabilizer to pre-
vent deterioration.
If you choose to use a stabilizer, follow manufacturers recommendations, and add the correct amount
for the capacity of fuel system. Fill fuel tank with clean, fresh fuel. Run engine for 2-3 minutes to get
󰀨
To empty the system, drain fuel tank and carburetor, or run engine until tank and system are empty.
4. Remove the spark plugs. Add one tablespoon of engine oil into each spark plug hole. Install plugs, but
do not connect the plug leads. Crank the engine two or three revolutions.
5. Store machine in a clean, dry place.

7
Service
ADJUSTMENTS
WHEEL CREEP
"Creep" is when the engine is running and hydrostatic transmission is in neutral, but due to inadequate align-
ment, wheels still move. Do the following procedure to stop this
motion.
  󰀨
and can turn freely.
2. In the engine compartment, the hydrostatic transmission is on
the left side. The shift arm (D) is under the pump and comes
out the side. The idler arm (B) has a bearing that runs in the
notch of the shift arm. Loosen bolt (A).
3. With engine running, move bearing (B) so it centers on the
shift arm (D) and 'wheel creep' stops.
4. Tighten all fasteners and test by using foot pedal linkage to
see that 'creep' is removed.
  󰀨
SPRAY PUMP WITH BELT
Located to the right of the engine. The belt should have approximately 1/2
of the top strand. Loosen and tighten the 3/8-16 x 11/4bolts located on the foot of the pump mount.
MASTER BOOM SWITCH (FOOT SWITCH)

󰀨For the TeeJet System the Mas-
ter Switch on the computer must be on for the master boom control switch to work.
GROUND SPEED CONTROL (FOOT SWITCH)
The ground speed control does not work the same as an automotive type cruise. The ground speed control is

TO ENGAGE:
1. Flip rocker switch ‘On’ (green light).
2. Obtain desired speed with foot pedal.
3. Step on foot switch to lock speed.
4. Push foot switch again to disengage.
SPRAY BOSS CONTROL - ORANGE
Engages and disengages speed boss. Forward is engage and all the way back is disengage. When the lever
is engaged it sets a stop for the accelerator. The accelerator pedal must be used to maintain this speed. To
adjust speed use the knob on the end of the lever, counter clockwise increases speed and clockwise decreas-
es speed. Disengage the lever and you will have full accelerator pedal range.
TANK AGITATION
󰀨
󰀨
and rotate back up to turn on..

8
Service
SERVICE CHART
Before servicing or making adjustments to the machine, stop engine, block
wheels and remove key from ignition.
Follow all procedures and ONLY use parts prescribed by the manufacturer.
Read the engine manual before maintenance.
󰀨
but as a supplement. You must adhere to the guidelines established by the manufacturer for warranty cover-
age. In adverse conditions such as dirt, mud or extreme temperatures, maintenance should be more frequent.
Duplicate this page for routine use
Maintenance Check Item For the week of:
Mon Tues. Wed. Thurs. Fri. Sat. Sun.
Check the Safety Seat Switch
Check Steering Operation
Check the fuel level
Check the engine oil level.


Check for unusual engine noises
Check the hydraulic oil level


Check the tire pressure (20-30 psi)
Check the Instrumentation
Inspect electrical system for frayed wires
Check neutral start

Change oil.
Lubricate Machine and Booms
Ensure all warning decals are intact.
Areas of Concern
Inspection Performed by:
Item Date Information

9
Service
SERVICE CHART
Item Maintenance Procedure
 Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))

Before each use daily
Check the engine oil level.
󰀪

Check the tire pressure.

Check for oil or water leaks.
Proper function of glow lamp timer.
 Change Hydraulic Oil Filter.

Every 100 hours
1&2
 1
Lubricate machine.

Check fan belt tension and damage.
Every 200 hours
Check radiator hoses and clamp bands.
Change engine oil.1
Check idle speed.
1
1
Check air intake line.1
Torque the wheel lug nuts. (64-74 ft/lb (87-100 Nm))
Every 500 hours or yearly Clean Water Jacket and radiator interior.
Replace fan belt.
Every 800 hours Check valve clearance.
Every 1500 hours Check injection nozzle pressure.
Every 3000 hours
Check turbo charger.
Check injection pump.
Check injection timing.
Every 2 years
Change radiator coolant (L.L.C.)
Replace radiator hoses and clamp bands.
Replace fuel hoses and clamps.
Replace intake air lines.
1In dusty conditions or when airborne debris is present, clean more often.
2Replace after every 6 times of cleaning

10
Service
20-612 MAIN WIRE HARNESS DIAGRAM
Use dielectric grease on all electrical connections.
Color Code Chart
Bl Blue
Br Brown
Y Yellow
G Green
O Orange
R Red
B Black
P Purple
W White

11
Service
20-612 MAIN WIRE HARNESS PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 20-730 Speedometer 1
2 12-804 Hour Meter 1
3 13-488 Ignition Switch 1
4 32-014 Lights 2
5 Lights
15-725 Mount Panel End 1
   󰀨 
15-727 Rocker - No light 1
6 Cruise
15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-732 Rocker , Green 1
7 Pump
15-729 Mount Panel Middle 1
15-726 Lighted Switch 1
15-731 Rocker, Amber 1
8 Left Boom
15-729 Mount Panel Middle 1
   󰀨 
15-727 Rocker - No light 1
9 Right Boom
15-725 Mount Panel End 1
15-727 Rocker - No light 1
   󰀨 
10 77-207 Buzzer 1
11 16-998 Spray Pump 1
12 33-480 Pressure Switch 1
13 33-084 Magnetic Coil 1
14 33-509 Master Boom Switch 1
15 14-292 Seat Switch 1
16 20-730-01 Speedometer Antenna 1
17 50-359 Glo - Oil - Temperature Lights 3
18 20-733 10AMP Circuit Breaker 1
8977 Red Circuit Breaker Boot 1
19 9016 Weather Pack 1
9018 Seal 2
20 9017 Weather Pack Terminal 2

12
Service
20-613 ENGINE WIRE HARNESS DIAGRAM
Use dielectric grease on all electrical connections.
To reset circuit breaker on ball valve, you must disconnect power to computer.
Color Code Chart
Bl Blue
Br Brown
Y Yellow
G Green
O Orange
R Red
B Black
P Purple
W White

13
Service
20-613 ENGINE WIRE HARNESS PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 77-223 Timer 1
2 30-042-06 Glo Relay 1
3 30-042-06 Power Relay 1
4 Fuel Pump 1
5 Fuel Solenoid 1
6 Alternator 1
7 33-216 Battery 1
8-603 Battery Strap 1
8 48-147 Negative Battery Cable 1
9 50-323 Red Battery Cable 1
10 Starter 1
11 20-693 50A Breaker 2
8977 Red Circuit Breaker Boot 2
12 18-372 3-Way Ball Valve 1
13 33-271 Buss Fuse Block 1
All wires 14GA unless stated in drawing.

14
Diagrams
HYDRAULIC DIAGRAM
Use dielectric grease on all electrical connections.

15
Diagrams
HYDRAULIC DIAGRAM PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 43-116 Wheel Motors 2
14-080 Wheel Motor Seal Kit 2
2 15-681 Hose 4
3 20-572 Hydraulic Hose 1
4 20-574 Hydraulic Hose 1
5 8832-29 3/4 Suction Hose 1
18-040 Hose Clamp 2
6 15-839 Hydraulic Cylinder 1
14-531 Cylinder Seal Kit 1
7 20-575 Hydraulic Hose 2
8 15-301 Orbitor 1
15-301-01 Orbitor Seal Kit 1
9 20-573 Hydraulic Hose 1
10 60-473 Oil Tank 1
11 20-564 Hydraulic Hose 1
12 20-576 Oil Filter Assembly 1
20-576-01 Replacement Filter 1
13 20-563 Hydraulic Hose 1
14 76-638 Hydrostatic Pump 1
77-239-22 Hydrostatic Pump Seal Kit 1
15 76-197 Gear Pump 1
76-197-08 Gear Pump Seal Kit 1
16 15-624 Oil Cooler 1
17 20-570 Hydraulic Hose 1
18 8832-27 3/4Suction Hose 1
18-040 Hose Clamp 2
19 20-571 Hydraulic Hose 1
PUMP DISPLACEMENT
76-638 Hydrostatic Pump
Displacement Variable to 1.44 in3/R (23.6 cm3/R)
22.44 gpm (84.94 lpm) at 3600 rpm
Max Operating Speed 3600 rpm
Rated Pressure 3000 psi (206.8 bar)
Max Pressure 5000 psi (344.7 bar)
Max Inlet Vacuum 6 in Hg (.203 bar)
Max Inlet Temperature 225°F (107°C)
Max Allowable Case Pressure 25 psi (1.72 bar)
76-197 Gear Pump
Displacement .40 in3/R (6.6 cm3/R) 6.23 gpm (25.39 lpm)


16
Diagrams
BODY & FRAME DRAWING

Parts
17
BODY & FRAME PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 16-953 16" Lid 1
16-953-01 Gasket for Lid 1
16-169 Strainer Basket 1
2 14-365 Air Gap Filler 1
3 16-961 Adapter 1
4 16-962 Coupler 1
16-962-01 Buna-N Gasket 1
5 20-592 200 Gallon Tank (Fiberglass) 1
20-529 Decal, Spray Star 2000 2
20-593 Decal, Site Gauge 1
    
7 20-611 Roll Bar 1
8 20-780 Roll Bar Base 1
9 31-045 Seat Assembly (Fiberglass) 1
10 14-294 Seat (includes * items) 2
*14-292 Seat Switch 1
*14-800 Seat Rail 2
*HSP-1260-340-250 Seat Spacers 8
11 13-718 Steering Wheel 1
13-726 Center Cap 1
12 76-364 Square Boot 1
76-362 Mini Tilt steering 1
13 20-734 Dash Panel 1
    
15 32-014 Head Light 2
16 20-535 Main Frame 1
17 76-443 Black Handle 3
HSTP-516-18-100 Phillips Machine Screw, 5/16 -18 x 1 6
HNFL-516-18 Flange Whiz-loc Nut, 5/16 -18 6
18 16-857 Front Tire and Wheel 2
16-857-01 Tire, 20 x 10.00 - 10NHS 4-ply 2
42-161-02 Wheel 2
19 76-198-03 Seat Belt 2
20 20-552 Accessory Mount 1
21 16-225 Tire & Wheel 2
16-225-01 Tire, 24 x 13.00 - 12NHS 4 Ply 2
16-225-02 Wheel 2
22 17-615 Boom Support Tube 2
23 16-557 Square Cap 2
24 16-851 1" Nipple 1
25 18-448 1" Ball Valve 1

18
Parts
NOSE CONE DRAWING
