Smithco 200G001 User manual

Operator’s
Spray Star 2002/2002D
with Raven 440 System
SN: 200G001
August 2011
Updated February 2013
Product Support: Hwy SS & Poplar Ave; Cameron WI 54822
1-800-891-9435 [e-mail]

Introduction Operation Schematics SprayingProcedures Nozzle Charts Reference
CONTENTS
Introduction................................................................ 1-11
Introduction ................................................................. 1
Symbols................................................................... 2-3
General Safe Practices............................................... 4
Safe Spraying Practices ............................................. 5
2000 Gas Specifications ............................................. 6
Optional Spray Equipment .......................................... 6
2000 Diesel Spcifications............................................ 7
Optional Spray Equipment .......................................... 7
Set Up ......................................................................... 8
Controls & Instruments.........................................10-11
Operation ................................................................. 12-24
Operating Instructions.......................................... 12-14
Console Features ..................................................... 15
Console Programming.............................................. 16
Console Calibration.............................................. 16-17
Initial Programming of Console Computer........... 18-22
InitialConsole Setup ................................................. 22
Spray Operation ................................................... 23-24
Spraying Procedure ................................................ 25-31
Spraying Introduction................................................. 25
TurfManagement ...................................................... 25
Hose & Handgun Spraying ........................................ 26
Nozzles................................................................ 26-27
CalibrationIntroduction ............................................. 28
The Nozzle Chart Method of Calibration .............. 29-30
The “128” Method of Boom Sprayer Calibration ... 30-31
Nozzle Charts .......................................................... 32-37
Nozzle Performance Chart #1 .................................. 32
Nozzle Performance Chart #2 .................................. 33
Nozzle Performance Chart #3 .................................. 34
Nozzle Performance Chart #4 .................................. 35
Nozzle Performance Chart #5 .................................. 36
Nozzle Performance Chart #6 .................................. 37
Reference ................................................................ 38-40
Declaration of Conformity ......................................38-39
Quick Reference .................................................................40

1
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
Informationneededwhenorderingreplacement parts:
1. Model Numberof machine.
2. Serial Number of machine.
3. Name and Part Number of part.
4. Quantity of parts.
INTRODUCTION
Thankyou for purchasinga product.
Readthismanual and all othermanualspertaining to theSpray Star2000 carefullyas they have safety, operat-
ing, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment dam-
age.
Keepmanuals in asafe place afteroperator and maintenancepersonnel have readthem. Right andleft sides are
fromthe operator’sseat, facingforward.
All machineshave aSerialNumber andModel Number.Both numbersare neededwhenordering
parts. The serial number plate on the Spray Star 2000 is located on the right middle main frame. Refer to engine
manualfor placementof engineserial number.
For easy access record your Serial and Model numbers here.
lb/kg Empty lb/kg Full

2
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
SYMBOLS
ParkBrake Park Brake
Release HydraulicOil
Level
Choke- OpenChoke- ClosedHandThrottle
HourMeter HourMeter Fuse
GlowPlugGlowPlug - OffGlow Plug - On
RPM Gasoline Diesel
Water
Temperature
Temperature
Light
EngineOil
Engine - Stop Engine - Start Engine -Run
No Electrical
Power
ElectricalPower
ReadOperator’s
Manual

3
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
SYMBOLS
NoSmoking Moving Parts Manual
Operation
Pinch Point Step HotSurface
HydraulicFluid
Penetration LiftArm Tractor
Engage Disengage PTO
GroundSpeed Fast Slow
HHigh LLow FForward
RReverse NNeutral Warning
Danger
Caution
Up/RaiseDown/LowerUp/DownArrow

4
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
SAFEPRACTICES
1. It is your responsibility to read this manual and all publications associated with this machine.
2. Neverallow anyone tooperate orservice the machineor itsoptionalequipment withoutproper training and
instructions.Never allow minorsto operateanyequipment.
3. Learnthe proper useof the machine, thelocation and purposeofall the controlsand gauges before you
operatethe equipment. Workingwithunfamiliar equipment canlead to accidents.
4. Wear all the necessary protective clothing and personal safety devises to protect your head, eyes, ears,
hands and feet. Operate the machine only in daylight or in good artificial light.
5. Inspect the area where the equipment will be used. Pick up all debris you can find before operating.
Bewareof overheadobstructions andundergroundobstacles. Stayalert forhidden hazards.
6. Neveroperate equipment thatis not inperfectworking order orwithout decals, guards,shields, or other
protectivedevices inplace.
7. Never disconnect or bypass any switch.
8. Carbonmonoxide in theexhaust fumescan be fatalwhen inhaled,neveroperate amachine without proper
ventilation.
9. Fuel is highly flammable, handle with care.
10. Keep engine clean.Allow the engine to cool before storing and always remove the ignition key.
11. Disengageall drives andset park brakebefore starting theengine.
12. Neveruse your hands tosearch for oil leaks. Hydraulicfluid under pressure canpenetratethe skin and
cause serious injury.
13. Thismachine demands yourattention.To prevent lossofcontrol or tippingof the vehicle:
A. Use extra caution in backing up the vehicle. Ensure area is clear.
B. Do not stop or start suddenly on any slope.
C. Reduce speed on slopes and in sharp turns. Use caution when changing directions on slopes.
D. Stay alert for holes in the terrain and other hidden hazards.
14. Beforeleaving operator’sposition:
A. Disengagealldrives.
B. Set park brake.
C. Shut engineoff andremove the ignitionkey.
D. If engine has to run to perform any maintenance keep hands, feet, clothing and all other parts of body
awayfrom movingparts.
15. Keephands, feet andclothingaway from movingparts. Wait for allmovement to stopbeforeyou clean,
adjustor service themachine.
16. Keepthe area ofoperation clear ofallbystanders.
17. Never carry passengers unless second seat and seatbelt s installed.
18. Stop engine beforemaking repairs/adjustmentsor checking/addingoilto the crankcase.
19. Use parts and materials supplied by only. Do not modify any function or part.
20. Use caution when booms are down as they extend out beyond the center line of the machine.
21. The tank is a confined space, take precaution.
These machines are intended for professional maintenance on golf courses, sports turf, and any other
area maintained turf and related trails, paths and lots. No guaranty as to the suitability for any task is
expressed or implied.

5
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
SAFESPRAYINGPRACTICES
Personsengaged in the handling,preparation or applicationof chemicals must followaccepted practices to
insurethe safety ofthemselvesand others,
1. WEAR protectiveclothing including: gloves,hat, respirator,eye protection andskin covering suitablefor
protectionfrom chemicals beingused.
2. BATHE thoroughly afterany exposure to chemicals,giving particularattention to eyes, nose,ears and
mouth.
3. CLEAN equipmentand materials inaccordancewith employer,municipaland stateregulations. Use only
approvedareasand drains.
4. DISPOSE ofchemicals and rinsesolutionsby approved andlegal means.
5. PROVIDE methodsand materials foroperatorsto wash eyesand hands immediatelyduringthe spraying
process.
6. PROVIDE methodsand materials forcontrol,safe dilution andneutralization of chemicalspillsduring
preparation,spraying, transportingand cleanup.
7. Always check and follow the directions and safety warnings of the chemicals to be used.
8. Securethe discharge lines before startingthe pump. An unsecured dischargelinemay whip.
9. Periodically inspect the pump and the system components.
10. Check hoses for weak or worn condition before each use. Make certain that all connections are tight and
secure.
11. Do not operate unit with leaks, frayed, kinked hoses or tubing. Repair or replace immediately.
12. Useonly pipe, hoseand fittings rated formaximum pressure orpressure at whichpressurerelief valve is
set at. When replacing pipe, hose or fittings, use new product.
13. Do not operate any fuel engines in an enclosed area. Be sure the area is well ventilated.
14. Donot use thesepumps for pumping wateror other liquidsforhuman or animalconsumption.
15. Do not pump flammable or explosive fluids such as gasoline, fuel oil, kerosene, etc.
Do not use in explosive atmospheres. The pump should be used only with liquids
compatible with the pump component materials.
16. Besure all exposedmoving parts areguarded and thatall coupling devicesare securely attachedbefore
applyingpower.
17. Before servicing, disconnect all power, make sure all pressure in the system is relieved, drain all liquids
from the system and flush.
18. Protectpump from freezingconditions by drainingliquid and pumpingrust inhibiting antifreezesolution
through the system, coating the pump interior.
19. TRANSPORT - Machine must be stopped to raise or lower booms. Because of cam sytem, if booms are
raisedin transit theycanfall forwardorbackward when comingto a stopor while travelingon uneven
terrain.

6
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
SPECIFICATIONS SPRAYSTAR2000GAS
WEIGHTSANDDIMENSIONS GAS
Length 132" (335cm) - w/ booms 137" (348 cm) - w/ Cleanload 151" (384 cm)
Width 72"(183cm)
Heightw/ Booms Folded 110"(279cm)
Wheel Base 61"(155cm)
Weight Empty 1990lbs (903 kg)
WeightLoaded 3605 lbs(1635 kg)
SOUNDLEVEL(DB)
Atear level 84 dBA
ENGINE
Make Briggs & Stratton
Model# 543477
Type / Spec# 01143E1
Horsepower 31 hp (23 kW)
Fuel Unleaded87 OctaneGasoline Minimum
CoolingSystem Air Cooled
LubricationSystem Full Pressure
Alternator 20Amp
WHEELS&TIRE Front: Two 20 x 10.00 x 10 NHS Multi-Rib; 20 psi (1.4 bar)
Rear: Two 24 x 13.00 x 12 NHS Multi-Trac; 20 psi (1.4 bar)
SPEED
Infinitely Variable 0-10m.p.h.(0-16 kph)
BATTERY Automotive type24F - 12volt
BCI Group Size 24
ColdCrankingAmps 900minimum
GroundTerminal Polarity Negative(-)
MaximumLength 10.25" (26 cm)
MaximumWidth 6.88" (17 cm)
MaximumHeight 10" (25 cm)
FLUID CAPACITY
CrankcaseOil See EngineManual
Fuel 6 gallon(22.7 liters)
HydraulicFluid 5 gallon(19liters)
Grade of Hydraulic Fluid SAE 10W-40API Service SJ or higher Motor Oil
OPTIONALEQUIPMENT
15-618 Water Meter Kit (liters) 14-515 Water Meter Kit (Gallons)
20-503 ChemicalCleanload SafeFill 15-850 Sunshade Canopy
30-009 ManualRewind HoseReel, 200-foot/61-metercapacity
30-010 ElectricRewind HoseReel,200-foot/61-meter capacity
30-004 FoamMarker 30-006 Clear waterWashTank
15-835 Tank Rinsing System 30-141 26 Gal Wash System
17-585 18'HDSuper Boom 17-580 20'HD SuperBoom
17-590 Lazer-BeamAutomaticBoom forHD Booms 31-004 All Weather Top

7
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
SPECIFICATIONS SPRAYSTAR2000DIESEL
WEIGHTSANDDIMENSIONS
Length 132" (335cm) - w/ booms 137" (348 cm) - w/ Cleanload 151" (384 cm)
Width 72"(183cm)
Heightw/ Booms Folded 110"(279cm)
Wheel Base 61"(155cm)
Weight Empty 1990lbs (903 kg)
WeightLoaded 3605 lbs(1635 kg)
SOUNDLEVEL(DB)
Atear level 98 dBA
ENGINE
Make Kubota
Model# D1105-E3B
Horsepower 25 hp (18.5 kW)
Fuel No.1-D or No. 2-D, S500: Low Sulfur Diesel (LSD) less than 500 ppm or 0.05 wt.%
No1-D or No.2-D, S15: Ultra Low Sulfur Diesel (ULSD) less than 15 ppm or 0.0015 wt.%
CoolingSystem Liquid Cooled
LubricationSystem Full Pressure
Alternator 15Amp
WHEELS&TIRE Front: Two 20 x 10.00 x 10 NHS Multi-Rib; 20 psi (1.4 bar)
Rear: Two 24 x 13.00 x 12 NHS Multi-Trac; 18 psi (1.3 bar)
SPEED
Infinitely Variable 0-10m.p.h.(0-16 kph)
BATTERY Automotive type24F - 12volt
BCIGroup Size 24
ColdCrankingAmps 900minimum
GroundTerminalPolarity Negative(-)
MaximumLength 10.25" (26 cm)
Maximum Width 6.88" (17 cm)
MaximumHeight 10" (25 cm)
FLUIDCAPACITY
CrankcaseOil See EngineManual
Fuel 7 gallon(26.5 liters)
HydraulicFluid 5 gallon(19liters)
Grade of Hydraulic Fluid SAE 10W-40API Service SJ or higher Motor Oil
OPTIONALEQUIPMENT
15-618 Water Meter Kit (liters) 14-515 Water Meter Kit (Gallons)
20-503 ChemicalCleanload SafeFill 15-850 Sunshade Canopy
30-009 ManualRewind HoseReel, 200-foot/61-metercapacity
30-010 ElectricRewind HoseReel,200-foot/61-meter capacity
30-004 FoamMarker 30-006 Clear waterWashTank
15-835 Tank Rinsing System 30-141 26 Gal Wash System
17-585 18'HDSuper Boom 17-580 20'HD SuperBoom
17-590 Lazer-BeamAutomaticBoom forHD Booms 31-004 All Weather Top

8
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
SETUP
TheSprayStar2000 arrivesfrom setupand readyfor service.Dependingon freightconditions the
battery may have to be installed.
The spray system is normally shipped attached to the 2000 Prime Mover. If a spray system is to be fitted to a
Prime Mover by a dealer or factory, assemble and attach the components in accordance with the parts drawings
inthe Spray Star2000Parts/Service Manual.
1. Check the tire pressure. The front and rear tires are 20 psi
(1.4bar).
2. Battery is located under the seat. This is a negative
groundingsystem.
Connecting battery cables to the wrong post could
result in personal injury and/or damage to the
electrical system. Make sure battery and cables
do not interfere or rub on any moving part. Con-
nect red positive (+) cable (A) to battery first.
When disconnecting remove black negative (-)
cable (B) first.
3. Checkhydraulic fluid level intank locatedunderthe seat. Removecapand add SAE 10W-40API Service
SJ or higher motor oil if necessary. Fluid level should be about 2-21/2" (5-6.4 cm) from the top of the tank
whencold. DONOT OVERFILL.
4. Fill fuel tank, located on the left side, with Unleaded 87 Octane gasoline (minimum).
Fuel is flammable, caution must be used when storing or handling it. Do not fill fuel tank
while engine is running or an enclosed area, fumes are explosive and dangerous to inhale.
DO NOT SMOKE while filling the fuel tank. DO NOT OVERFILL.
5. Machineshould begreasedbefore starting,refer to SprayStar 2000Parts/Service Manualfor location.
6. Attach the Spray Boom and any other Optional Equipment to the Prime Mover, in accordance with
instructions in the Spray Star 2000 Parts/Service Manual. The nozzles must be the correct distance above
theturfas described in Turf Spraying Guide.Thesprayboom must operate properly andthe outer sec-
tions must break away safely if an object is struck by them, they must then return to normal operation
position.
7. Be sure to double check boom heights, nozzle spacing and displacement before spraying.
8. Machine is shipped with windshield washer fluid in Spray System to prevent freezing. Flush system
completely with clear water. Fill tank with water and retighten the four bolts used to hold the tank in place.
Never allow pump to run dry! The valve on the suction side of the pump (between the pump
and tank) must be fully open whenever the pump is operated.
9. Readoperating instructionsbefore starting.

9
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
NOTES

10
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
CONTROLS&INSTRUMENTS 2000
A. HourMeter-The hour meterindicates hours ofmachine operation. Itoperates only whentheignition
switch is on.
B. Speedometer -The Speedometer indicates groundspeed ofthevehicle inmiles per hour.
C. Oil Light - The oil light should come on when the ignition is on without the engine running and go out when
the engine is running. The oil light will light when the oil pressure is low. If oil light should come on, shut
engineoff immediately andfind the cause.
D. Ignition Switch - The ignition switch has three positions: Off - Run -
Start.
E. TiltSteering -Hold leverdownand adjuststeeringwheel todesired
positionand releaselever.
F. Lights - This rocker switch turns lights on by pushing on the top and
off by pushing on the bottom.
G. Buzzer -The buzzer sounds if the pump is running dry.
H. Ground Speed(Cruise) Control -Thisrocker switch initiatescruise
control by pushing on the top and turning it off by pushing on the
bottom. Works with ground Speed Control Foot switch.
I. Spray Pump - This toggle switch turns the spray pump on by
pushing on the top and off by pushing on the bottom.
J. Left Boom Switch - This rocker switch lifts and lowers the left boom.
K. Right Boom Switch - This rocker switch lifts and lowers the right
boom.
L. Hand Throttle - Thehand throttle isusedto regulate enginespeed.
M. Choke - The choke is used in starting the engine. Pull choke out to
close choke plate when starting a cold engine. Push in when engine
starts.Awarm engine may not require "choking" to start.
N. Park Brake - The park brake is only a parking brake. Pull back to
release, push forward to apply. Some adjustment can be made by
turning the knob clockwise to tighten and counter clockwise to loosen.

11
Introduction
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
CONTROLS&INSTRUMENTS 2000
O. Spray Boss Control - Engages and disengages speed boss. Forward is engage and all the way back is
disengage. When the lever is engaged it sets a stop for the accelerator. The accelerator pedal must be
used to maintain this speed.To adjust speed use the knob on the end of the lever, counter clockwise
increasesspeed and clockwisedecreases speed. Disengagethe lever andyou will havefull accelerator
pedalrange.
P. CupHolder - Holds twox-alrge cups.
Q. Ground Speed (Cruise) Control Foot Switch - When rocker switch is truned on and desired speed is
obtained, push foot speed control switch to set cruise.
R. Master Boom Switch - located on the left floorboard is used to override the master switch on the computer
console of the spray systems. By pushing down it will turn on/off the booms. For the 440 System only
the Master Switch on the computer must be off for the master boom control switch to work.
S. Accelerator Pedal - This pedal controls ground speed. Press pedal to increase speed. Varying the amount
ofmovement ofthepedal willvary theground speed.
T. Reverse Pedal- Thispedalcontrols reverse.Press pedaltomove machinein reverse.
Y. WaterTemperature Light (DieselOnly)-Temperature light will comeon and a buzzer willsound whenthe
enginestarts tooverheat.
Z. Glow Plug (Diesel Only)- When ignition is turned on, glow plug lights when ready to start.
GROUNDSPEEDCONTROL
When pedals are released the hydrostatic transmission centers and stops the vehicle with a braking
action.

12
Operation
PARTS MANUALS AVAILABLE ONLINEAT smithco.com
OPERATION
Beforeoperatingthe Spray Star2000, become familiarwithall controls and functions.Alsocomplete all mainte-
nancerequirementsand read allsafetywarnings. KnowingtheSpray Star 2000 thoroughly,how itoperates,and
by doing the prescribed maintenance steps, you can expect trouble free operation for years to come.
SAFETY
0needs to always bethe concern ofanoperator of amoving vehicle oranymachine with movingparts.
1. Keep all shields and guards in place.
2. Keepthe parking brakeengaged any timethe operatorisaway fromthevehicle orwhenever service is
performed.
3. Alwayswear the necessaryprotective clothing andequipment.
4. Turnengine offwhenrefueling orperforming maintenancenot specificallyrequiringenginepower.
DAILYCHECKLIST
1. Checkthe engine oillevel. Add asneeded. DO NOT OVERFILL.Refer to engineowner's manual foroil
gradeandprocedure.
2. Tirepressure should be20 psi (1.4 bar)maximum.
3. Inspect the electrical system and battery cables for loose connections or frayed wiring. Replace any faulty
equipmentor tighten ifloose.
4. Check hardware for loose or missing nuts, bolts, screws, etc., and tighten or replace as needed.
5. Inspect hydraulic lines for damage or leaks. Never use hands to inspect for leaks.
6. Check the hydraulic fluid level. The hydraulic fluid tank is located on the left side of the machine. The fluid
level should be 2"-2½" (5 - 6.4 cm) from the top of the tank when cold. Use only SAE 10W-40API Service
SJ or higher Motor Oil.
7. Inspectthe steering, throttle and shiftlinkages for good hookups and
cleartravel.
8. Checkcontrols for smooth,proper working operation.Lubricate as
needed.
9. Check park brake adjustments. Adjust as required.
10. Checkanti-vibrationmountsonengineframe.
STARTINGTHE GASENGINE
1. Gas - The ignition switch is located on the dashboard. Insert the key
(A) and turn clockwise until the engine starts (C). Release the key
and it will return to the run position (B). Use the choke and hand
throttle as necessary.
2. Diesel - Insert the key (A) and turn clockwise to (B). When glow plug
light goes off Turn key to (C) until the engine starts. Release the key
and it will return to the run position (B).
3. Allowengine to idleand warm upbefore selecting directionof travel.
STOPPINGTHEENGINE
If the engine has been running under high power, let it run at slow idle speed a few minutes
to cool the engine down, before turning the ignition switch to the OFF position.
1. Disengagespray pump.
2. Movethe throttle leverto“slow” and turnignition key to the“off” position.
3. Removethe ignition keyand engage thepark brake.
Never leave the vehicle unattended with the engine running. Always bring the vehicle to a
complete stop, engage park brake, turn key off and remove key.

13
Operation
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
OPERATION
Before using the Spray Star 2000, the operator and spray technician must familiarize themselves with all of the informa-
tion on chemical spraying contained in the Turf Spray Guide.
All testing and calibrating of sprayers is to be done with water, not chemicals. This insures the safety
to all involved in performing the calibration operation. Only after all calibration procedures are
completed should chemical be added to the sprayer.
TOWING UNIT
When it is necessary to move the Spray Star 2000 without the engine running, the bypass valve built into hydrostatic
pump must be "open" by turning it 1/4turn to open. The valve is located on the back side of the pump. An "open" valve
allows fluid to pass through the wheels freely. When normal driven operation is desired, valve should be "closed" by
turning it clockwise. Failure to "close" the valve with engine running means no power to wheels.
HILLSIDE OPERATION
Do NOT stop or start suddenly on any slope. Be especially cautious when changing direction. Do NOT operate on
slopes greater than 10°.
BATTERY
Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any ig-
nited object to come near the battery. When charging or working near battery, always shield your eyes and always pro-
vide proper ventilation.
Battery cable should be disconnected before using “Fast Charge”.
Charge battery at 15 amps for 10 minutes or 7 amps for 30 minutes. Do not exceed the recommended charging rate. If
electrolyte starts boiling over, decrease charging.
Always remove grounded (-) battery clamp first and replace it last. Avoid hazards by:
1. Filling batteries in well-ventilated areas.
2. Wear eye protection and rubber gloves.
3. Avoid breathing fumes when electrolyte is added.
4. Avoid spilling or dripping electrolyte.
Battery Electrolyte is an acidic solution and should be handled with care. If electrolyte is splashed on
any part of your body, flush all contact areas immediately with liberal amounts of water. Get medical
attention immediately.
JUMP STARTING
Use of booster battery and jumper cables. Particular care should be used when connecting a booster
battery. Use proper polarity in order to prevent sparks.
To jump start (negative grounded battery):
1. Shield eyes.
2. Connect ends of one cable to positive (+) terminals of each
battery, first (A) then (B).
3. Connect one end of other cable to negative (-) terminal of
"good" battery (C).
4. Connect other end of cable (D) to engine block on unit being
started (NOT to negative (-) terminal of battery)
To prevent damage to other electrical components on unit being
started, make certain that engine is at idle speed before discon-
necting jumper cables.

14
Operation
PARTS MANUALS AVAILABLE ONLINEAT smithco.com
OPERATION (CONTINUED)
SPRAYERVALVESETTINGSANDSPRAYTANKAGITATION
The ball valve on the suction side of the pump, between the tank and the pump must be open before pump is
engaged. Close this valve only when necessary to clean the filter with spray material in the spray tank.
There is one manual flow control valve on the discharge side of the spray system. This valve controls the agita-
tor. This valve may be opened as much as necessary to provide hydraulic agitation through the quadrajet agita-
tor in the tank bottom. This valve may be partially closed to prevent or reduce foam buildup from the spray ma-
terials inside the tank. When the liquid level in the spray tank reaches a certain level (usually 1-25 gallons
(3.8-95 Liters) depending on terrain and other conditions) it may be necessary to close the valve in the agitator
line in order to prevent loss of suction prime.
IfyourSprayStarisfittedwitha hosereel,thereis asecondballvalveon thedischargesystemto supplymaterialto
thehosereel.
TheQuadrajetagitationsystemoperateswith fourventuri jetsinthetankbottom.Thesejets havereplaceableorifice
discswhichdischargethefollowingamounts ofspaymaterial.
Input to Input to Agitator Agitator Agitator Agitator
Nozzle Agitator Agitator Pressure Pressure Output Output
Diameter in gpm in L/min in psi in bar in gpm in L/min
1/8" 1.9 7.2 25 1.7 6.3 23.8
1/8" 2.7 10.2 50 3.4 10.0 37.9
1/8" 3.8 14.4 100 6.9 15.0 56.8
5/32" 2.8 10.6 25 1.7 7.6 28.8
5/32" 4.2 15.9 50 3.4 12.2 46.2
5/32" 5.5 20.8 100 6.9 17.5 66.2
3/16" 3.6 13.6 25 1.7 9.1 34.4
3/16" 5.6 21.2 50 33.4 14.3 54.1
3/16" 7.9 29.9 100 6.9 18.7 70.8
You can change orifice disc sizes to enhance spray system performance. Smaller discs reduce amount of agita-
tion (desirable in some foaming materials) and make more dischargeable liquid available for nozzles. Larger (or
none) discs increase amount of agitation and make less dischargeable liquid available for nozzles.
PROCEDURETORE-CALIBRATEFLOWMETER
1. Enter a Meter Cal number of 10 in Meter Cal Button
2. Enter a Total Volume of Calibrating the Pressure Gauge in Total Volume button
3. Switch Off all booms.
4. Remove a boom hose and place in calibrated 5 gallon container
5. Switch on appropriate boom switch and master switch. Pump exactly 10 gallons.
6. Readout in Total Volume is the new Meter Cal Number. Should be within 3% of number stamped on flowmeter.
7. Repeat the procedure several times to ensure accuracy.
8. To verify calibration, fill applicator tank with predetermined amount of measured liquid. DO NOT RELAY ON
GRADUATION NUMBERS ON TANK. Empty tank under normal operatin conditions. If the number under totla
volume is different from the predetermined amount of measure by more than 3% compete calculation in back of
book.
9. Enter corrected Meter Cal before resumin application.

15
Operation
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
DATA
MENU
CONSOLEFEATURES
This Console (PGM F) requires selection of US (acres); SI (hectares) or TU (1,000 sq ft) area
and SP1 (wheel drive, etc).
A. POWER- TurnsConsole power OFForON. Turning ConsoleOFF does notaffectthe data storedin
thecomputer.
B. Select manual or fully automatic control. This can automatically control two rates.
C. Manualoverride controlprovidescapability forspot spraying.
D. Booms can be controlled individually, or all at once with MASTER ON/OFF Switch
E. Displaysoperatingrateof applicationandflashing TipFault.
F. Displays function andcalibration data.
G. CE - Use like you do CE (clear entry) key on a calculator. This key is also used to select an area
basemeasurement of US(acres),SI (Hectares) orTU (1,000 sqft).
H. ENTER - Used only to enter the data into the Console.
SEEQUICKREFERENCE PAGEFOR DATATHAT SHOULD BEENTERED
Calibration Keys: (TopRow)Used toenter Function Keys: (BottomRow) Used todisplaydata.
data into console to calibrate the system.
BOOM1 CAL Length of Boom 1 TOTALAREA TotalArea Sprayed
BOOM2 CAL Length of Boom 2 FIELDAREA FieldArea Sprayed
BOOM3 CAL Length of Boom 3 FIELDVOLUME Volume Applied to Field
SPEEDCAL Measured Off Drive Line DISTANCE Distance Traveled
METERCAL Flow Meter Calibration Number SPEED Speed of Vehicle
VALVECAL Control Valve Response Time VOLUME/TANK Volume Remaining in Carrier Tank
RATE 1 CAL Target Application Rate TIME 24 hour clock (military time)
RATE 2 CAL Target Application Rate
SELFTEST Simulates Vehicle Speed

16
Operation
PARTS MANUALS AVAILABLE ONLINEAT smithco.com
CONSOLEPROGRAMMING
When entering data into the Console computer, the entry sequence is always the same. Data must be entered
into the first eight keys.
1. Depress the key which you wish to enter data. 2. Depress the “Enter” key.An “E” will illuminate
in the DATAdisplay.
3. Depress the keys corresponding to the 4. Complete the entry byagain depressing the
number you wish to enter (i.e. “5”, “7”, “2”). “ENTER”key.
Thenumbers will bedisplayed in theDATA
display as they are entered.
CONSOLECALIBRATION
CALCULATING“BOOMCAL”(BOOM1,BOOM2,BOOM3)
Calculate the width of each boom in inches (centimeters) by multiplying the number of tips times the spacing.
Writetheseboomwidthsdown forfuture referencewhenprogramming theConsole computer.TheConsole is
capableof controlling uptothree (3) booms.
CALCULATING“SPEEDCAL"
1. Enter Speed Cal in key of 785 for GPS or 612 for wheel speed sensor..
2. Place Master and Boom 1 switches to on.
3. Enter “0” in key .
4. Drive 1 mile. Do not use vehicle odometer to determine distance, use section lines or highway markers.
5. Itshould read avalue ofapproximately5280. Ifit reads between5200-5350, the Speed Calforthis vehicle
is 688.
Ifthe Distancedisplay reads anyother value, divideSpeed Calby the valueobserved in Distance,then
multiply by 5280. This will give you the correct value to enter for Speed Cal. You must round off to the
nearest3 digit number (use120 not 120.3).

17
Operation
PARTS MANUALS AVAILABLE ONLINEATsmithco.com
CONSOLECALIBRATION
6. Recheck the new Speed Cal numbers. Zero out Distance display as in step 3. Enter the new Speed Cal
number as in step 1. Repeat steps 4 and 5.
MEASURE CAREFULLY. Be sure tire is properly inflated before measuring. Measure tire in
type of soil in which you will be spraying. Circumference of tire will vary when measured in
soft soil versus hard packed soil. For best results, measure several times and average the
results. Re-measure periodically.
CALCULATING“METERCAL”
The Flow Meter calibration number is stamped on the label attached to each Flow Meter; this number is to be
usedfor gallon perarea applications.To convertoriginal METER CALfrom gallonstodesired unitsof measure
(oz,lbsor liters per area) seeAbbreviationsand Conversions section ofthis manual. Writedown this calibration
numberfor futurereferencewhenprogrammingthe console.
CALCULATING"VALVECAL”
The initial Control Valve calibration number is 2123.After operating the system, you may desire to refine this
number. Seedefinitions below.
Valve Backlash Controls the time of the first correction pulse after a change in correction direction is detected.
Incr to Decr or Decr to Incr Range: 1 to 9, 1-Short Pulse, 9-Long Pulse
ValveSpeedDigitControls theSpeedofthe ControlValvemotor.
Running the Control Valve too fast will cause the system to oscillate.
Range: 1 to 9, 1-slow, 9-Fast
Brake Point Digit Percent Sets the point at which the Control Valve motor begins braking, so as not to over
shoot the desired rate. Digit is percent away from target rate. Range: 0 to 9, 0=5%, 1=10%, 9=90%,
DeadbandDigitAllowable differencebetween targetandactual application rate,where ratecorrection is not
performed. Range: 1 to 9, 1 = 1%, 9 = 9%
CALCULATING"RATE1ANDRATE2CAL"(See SprayingProcedure section)
Determine the application rate at which your chemical should be sprayed. Consult with your Dealer to insure
your spray nozzles are capable of applying at this target rate.
Using CAPACITY = .35 GPM (1.67 lit/min) and pressure = 30 PSI (20 bar) you would select tip number XR8004
from the Nozzle Charts Section, since it comes closest to providing the desired output.
VERIFYINGFLOWRATELIMITS
The flow rate of the sprayer must be within the range of 1 to 55 GPM (4 to 210 lit/min).

18
Operation
PARTS MANUALS AVAILABLE ONLINEAT smithco.com
INITIALPROGRAMMINGOFCONSOLECOMPUTER
Whenyou first turnonConsole power, afterallinstallationprocedureshave been completed,the Console will
flash “CAL” in the RATE display and “US” in the DATAdisplay.This means you must “calibrate” or program the
Consolebefore itcanbe operated.
(This is a one time operation which does not have to be repeated unless you disconnect your battery wires.
Turning OFF the POWER ON/OFF switch does not affect the Console memory.All data is retained).The follow-
ing steps must now be followed.
If an entry selection error is made during steps 1, 2, 3, or 4, the Console can be reset by depressing for
20 seconds (Data displays US and RATE displays CAL.).
1. DisplayingUS, SI or TU
a. Depressing momentarily Steps the DATAdisplay from US (acres) to SI.
b. Depressing momentarily Stepsthe DATAdisplayfromSI (Hectares) toTU.
c. Depressing momentarily Steps the DATAdisplay from TU (1000 sq ft) to US.
2. Selecting US, SI or TU
a. To select US, SI, or TU, step until the desired code is displayed in DATA display.
b. Momentarily depress the DATAdisplay will now display SP1.
3. Displaying SP1 or SP2
a. Depressing momentarily steps the DATAdisplay from SP1 (wheel drives, etc.) to SP2.
b. Depressing momentarily steps the DATAdisplay from SP2 (radar sensor) to SP1.
4. Selecting SP1 OR SP2
a. To select SP1 or SP2, step with until desired code is displayed in DATA display.
b. Momentarily depress the DATAdisplay will now display 0.
5. Enter width in inches (cm) of BOOM 1 in the key labeled:
6. Enter width in inches (cm) of BOOM 2 in the key labeled: If there is only one boom, enter "0" for
width of BOOM 2.
7. Enter width in inches (cm) of BOOM 3 in the key labeled: If there is only one or two boom, enter “0”
forwidthof BOOM 3.
