SoftBank 930N User manual

7
7-1
Camera
Overview...................................................... 7-2
Viewfinder Indicators........................................... 7-3
Switching Cameras ............................................... 7-5
Capturing Still Images ................................. 7-6
Capturing Still Images.......................................... 7-6
Recording Videos......................................... 7-8
Recording Videos ................................................. 7-8
Various Features ........................................ 7-10
Using Smile Mode .............................................. 7-10
Continuous Shooting ......................................... 7-10
Add Frames to Images ....................................... 7-11
Auto Timer.......................................................... 7-11
Panoramic Shooting........................................... 7-11
SpeedMovie ....................................................... 7-12
Chance Capture .................................................. 7-12
Recording Only Sound....................................... 7-12
Advanced Features .................................... 7-14
During Shooting................................................. 7-14
After Shooting.................................................... 7-14

7-2
7
Camera
Overview
SoftBank
Handsets
Non-SoftBank
Mobile Phones
PCs
Capture Still Images/Videos
Select image size accordingly. Use
small sizes for S! Mail attachments
and larger sizes for savinghigh
resolution images.
Wide Range of Image Sizes
Features include:
Auto Timer
Continuous Shooting
AddingFrames
()
Send by S!Mail
VariousFeatures
Select a mode suited to the
subject/scene such as Portrait,
Scenery, and Sports mode.
Photo Modes
Shutter automaticallyreleases when
Camera detects a smile ( ).
Smile Mode
Capture still images andrecordvideos with handset camera.
When Auto-change Screen is set to ON, turn
handset on its left side while using Camera for
Landscape View.
･Still images are saved in JPEG format and
videos in MPEG4 format.
･Clean the lens with soft cloth. Fingerprints or
grime on the lens may result in blurred
images.
･Handset movement during shooting may
cause image blurring when Shake Correction
is OFF. Setting Shake Correction to Auto is
recommended.
･Although Camera is made with high-precision
technology, some pixels may appear brighter
and some darker.
･Shooting or saving images when handset is
warm may affect image quality.
･Exposing the lens to direct sunlight for an
extended period may result in discoloration of
photo images.
･Shutter click and Auto Timer tone sound at a
fixed volume even in Manner Mode.
P. 7-10, P. 7-11
P. 7-10

7-3
Overview
7
Camera
Viewfinder Indicators
Landscape View
Portrait View
Photo Viewfinder
Video Viewfinder
⑩
①②
③④ ⑨⑧⑦⑥⑤ ⑫ ⑭
②⑯
④ ⑭⑬⑰⑨⑧⑦⑥⑤
⑪
③
⑮
⑬
Photo Viewfinder
Video Viewfinder
①
④⑤ ⑦⑧⑨ ⑭
⑥
⑯⑮
④⑤ ⑦ ⑨⑧⑥⑭⑬
⑰
⑬
②
③
⑩
②
③
⑪
⑫
①Focus Frame (Still Images)
A white frame appears for Auto Focus.
Focus Frame is green when focus is locked,
and red if focusing failed.
②Shake Correction
Auto
③Storage Location (Still Image)
Handset Memory Card
Storage Capacity (Still Image)1
White number: 11 or more files
Yellow number: 10 or less files
Red number: No memory space
Storage Location (Video)
Handset Memory Card
Storage Capacity (Video)1
Blue: 500 KB or more
Yellow: Less than 500 KB
Red: No memory space
④Camera Mode
Movie Mode
Speed Movie
Chance Capture
Photo Mode
Auto Continuous Shooting
Manual Continuous Shooting
Voice Mode
Panorama Cap. Mode

7-4
Overview
7
Camera
1 Approximate value.
2SwitchestoQVGA (320×240) (Landscape
View) in Speed Movie.
3 Available when Select Size is QCIF
(176×144).
4 Available only when Photo Mode is set to OFF
(in normal and continuous shooting modes).
Auto Save
Capturedstill images andvideos are
automatically savedto handset.
Shake Correction
Camera is equippedwith Shake Correction.
This function reduces camera shake in 6axial
directions for still images and4 axial
directions for videos taken with the rear
camera.
Set Shake Correction off when not needed.
⑤Image Size (Still Image/Video)
・Photo Mode/Continuous Shooting
8M (2448 ×3264) to QCIF
(176×144)
・Panorama Cap. Mode
Panorama (4096 ×480 : Vertical)
Panorama (2738 ×480 : Horizontal)
・Movie Mode/Speed Movie2/Chance
Capture
VGA (640 ×480) to QCIF
(176 ×144)
⑥Image Quality (Still Image)
Super Fine Normal
Fine
File Size (Video)
Mail attachment
3
Long time
Up to 2 MB
⑦Photo Mode
Auto
Sports Mode
Portrait Night Mode
Smile Pet
Scenery Food
Backlight OFF
⑧Brightness
-2 to +2
⑨White Balance
4
Auto Light bulb
Fine Fluorescent lamp
Cloudy
⑩AF Mode (Still Image)
Face ON (Face detection ＋AF ON)
AF ON
Close-up
AF OFF
⑪AF Guidance (Still Images)
For AF toggle and focus lock
⑫Face Select Mode (Still Image)
Face selecting mode
⑬Auto Timer
Auto Timer set
⑭Zoom (16steps)
Minimum to Maximum
⑮Recording Type (Video)
Normal (Video & Sound)
Video only Sound only
⑯Image Quality (Video)
Long time Fine
Normal Super Fine
⑰Recording Status (Video)
Recording ready
Recording
Tip
･To set so that a preview window appears after
recording:
[Photo Viewfinder]/[Video Viewfinder]
 Uu

Auto Save Set

Xd

OFF

Xd

7-5
Overview
7
Camera
SwitchingCameras
[Photo Viewfinder]/[Video
Viewfinder]

u

Front
Camera or Rear Camera

d
Rear Camera
Use for people, animals and scenery. Image
appearing on Display appear as seen.
Front Camera
Use to photograph yourself. Image appearing on
Display is in mirror display, but the saved image is
displayed normally.
1
Rear CameraFront Camera

7-6
7
Camera
CapturingStill Images
CapturingStill Images
i 
Camera

d

Mode

d
Frame image in Viewfinder

d
When the focus locks, Focus Frame turns
green andshutter is released.
Image is automatically saved.
Photo Preview Window
Appears when Auto Save Set is set to OFF. Press
dto save image.
■To Discard the Shot Image and Return to
Viewfinder

t

YES

d
Available Functions
1 Available when AF is set to Face ON.
2 Available when Photo Mode is set to OFF.
3 Available when Auto-change Screen is set to
OFF.
Tip
･Alternatively, press and hold Txto activate
Camera in Photo Mode.
1
2
Photo Viewfinder
Tip
･Attach still images to S!Mail or set as
wallpaper (P. 7-15).
･Still images are stored in My Picture under
Data Folder. See P. 14-23 for details on
changing the storage location to Memory
Card.
･Shutter clicks even if focusing fails and Focus
Frame turns red.
Photo Preview
Window
AF Change f
AF Lock g
Face Select Mode1Press and hold g
・Press oor pand
move Focus Frame
to the subject. Press
and hold gagain.
Zoom In j
Zoom Out h
Open Menu o
Toggle Camera Mode1
Select Size 2
Quality Setting 3
Photo Mode4
Adjust Brightness 5
White Balance26
Toggle Viewfinders39
Help 0

7-7
CapturingStill Images
7
Camera
More Features
Advanced
During Shooting
●Use Camera Menu
●Switch Color Modes
●Reduce Flicker
●Check Storage Capacity
●Set Shake Correction
●Attach Location Information During Shooting
(
P. 7-14)
After Shooting
●Zoom In/Out
●Upload Still Image to Blog
●Send Still Image with Graphic Mail
●Attach Still Image to Mail and Send
●Show Mirror Image of Shot Still Image
●Save Mirror Image of Shot Still Image
●Show Shot Still Image in Standby
●Attach Location Information After Shooting
(
P. 7-14)
Customize
Camera Settings
●Set Shutter Sound
●Set Display for Landscape View Shooting
(
P. 14-23)
File Storage
●Set Storage Location for Shot Still Images
(
P. 14-23)

7-8
7
Camera
RecordingVideos
RecordingVideos
i 
Camera

d

Movie
Mode

d
Frame image in Viewfinder

d
Recording starts.
d
Recording ends.
Video is automatically saved.
Video Preview Window
Appears when Auto Save Set is set to OFF. Press
dto save video.
■To Discard the Recording and Return to
Viewfinder

t

YES

d
Available Functions
* Available when Auto-change Screen is set to
OFF.
1
Video Viewfinder
2
3Tip
･Video is saved to Videos in Data Folder. The
storage location can be changed to memory
card (P. 14-23).
Video Preview Window
Zoom In j
Zoom Out h
Open Menu o
Toggle Camera Mode1
Select Size 2
File Size Setting 3
Photo Mode4
Adjust Brightness 5
White Balance 6
Toggle Viewfinders* 9
Help 0
Tip
･Key operation tones may be recorded if you
adjust zoom, etc. while recording a video.

7-9
RecordingVideos
7
Camera
More Features
Advanced
During Shooting
●Use Camera Menu
●Set Image Quality
●Switch Color Modes
●Reduce Flicker
●Check Storage Capacity
●Change Video Type
●Set Shake Correction
(
P. 7-14)
After Shooting
●Upload Video to Blog
●Attach Video to Mail and Send
●Show Recorded Video in Standby
●Edit Title of Video
(
P. 7-14)
Customize
Video Settings
●Set Shutter Sound
●Set Display for Landscape View Shooting
(
P. 14-23)
File Storage
●Set Storage Location for Shot Videos
(
P. 14-23)

7-10
7
Camera
Various Features
UsingSmile Mode
Camera automatically detects a smile and
automatically releases the shutter.
[Photo Viewfinder]

4


d
Frame image in Viewfinder
d
When the person in Focus Frame smiles,
the shutter is automatically released.
flashes while the smile is being detected.
Image is automatically saved.
Continuous Shooting
Shoot up to 20 still images continuously.
Automatic continuous shooting mode:
Automatically shoots a set number of images
at set intervals after you release the shutter.
Manual continuous shooting mode:
Shoots a set number of images, each of which
is shot by releasing the shutter manually.
●See P. 14-23 for details on setting interval/
number of shots for Continuous Shooting.
[Photo Viewfinder]/[Video
Viewfinder]

1

or

d
Frame image in Viewfinder
d
Image is automatically saved.
Thumbnail Preview Window
Appears when Auto Save Set is set to OFF.
Press and hold p, Save or Mirror Save and
press dto save all still images.
■To Discard Shot Images and Return to
Viewfinder

t

YES

d
1
Smile Mode Viewfinder
2
1
Continuous Shooting
Viewfinder (Manual)
2
Tip
･Image size can only be set to WQVGA, QVGA
V. or QCIF.
Thumbnail Preview Window

7-11
Various Features
7
Camera
Add Frames to Images
[Photo Viewfinder]

u

Select Frame

d

Select a
folder

d

Select a frame

d
Compose image in the frame

d
Image is automatically saved.
Framed Image Preview Window
Appears when Auto Save Set is set to OFF. Press
dto save image.
■To Discard Shot Images and Return to
Viewfinder

t

YES

d
Auto Timer
●Auto Timer returns to OFF after shooting.
[Photo Viewfinder]/[Video
Viewfinder]

u

Auto Timer

d
ON

d

Enter time

d
Frame image in Viewfinder

d
Auto Timer starts countdown, and
Illumination flashes blue. About five
seconds before shooting, a countdown
tone sounds andIllumination flashes
rapidly.
To stop Auto Timer, press oor t.
For Still Images
Images are automatically saved.
For Videos
d
Recording ends. Videos are
automatically saved.
Panoramic Shooting
Create a single panorama shot automatically
by moving handset horizontally while
shooting.
●Letting handset move up or down during
shooting may produce a shot with a reduced
height or blurring.
●A moving subject may be difficult to shoot.
●Shooting may fail with a subject having a
simple pattern or no pattern.
[Photo Viewfinder]/[Video
Viewfinder]

1
 
d
1
2
FramedImage Preview Window
Tip
･To shoot manually during Auto Timer
countdown, press Xd.
1
2
3
1
Panorama Cap. Window

7-12
Various Features
7
Camera
Display one end of subject

d
Panorama shooting starts.
Pan left or right as horizontally as
possible so the subject does not deviate
up or down from the displayedgreen
line. Keep a goodpanning speedso that
appears. If the speedis too fast,
appears andthe scene cannot be
capturedproperly.
d
Panorama shooting ends.
Image is automatically saved.
Shooting automatically ends if the
maximum storable capacity is reached.
Speed Movie
Use to check fast-moving subjects. Video is
playedback in slow-motion.
●Available in Landscape View.
[Photo Viewfinder]/[Video
Viewfinder]

1
 
d
Frame image in Viewfinder

d
Recording starts.
d
Recording ends.
Video is automatically saved.
Chance Capture
Continue recording a video until you shoot
the desiredscene even when the available
recording time is over.
[Photo Viewfinder]/[Video
Viewfinder]

1
 
d
Frame image in Viewfinder

d
Recording starts.
When the available recording time is
over, the remaining time indication
flashes.
d
Recording ends.
Video is automatically saved.
RecordingOnlySound
Recordonly audio in Movie Mode (Voice
Mode).
[Photo Viewfinder]/[Video
Viewfinder]

1
 
d
d
Recording starts.
d
Recording ends.
Video is automatically saved.
2
Panorama Shooting
3
1
2
3
1
2
Note
･When recorded video exceeds available
memory, handset saves the maximum
recordable time from the end of recording.
Initial portion is deleted.
Tip
･To activate Voice Mode from Main Menu:
Ii 
Camera

Xd

Voice Mode

Xd
3
1
2
3

7-13
Various Features
7
Camera
More Features
Advanced
After Shooting
●View Images
●Save One Frame
●Save Only Selected Images
●Save as Animation
●Open an Image as Mirror Image
●Attach to Mail
●Change Frame before Saving Image
(
P. 7-14)
Customize
Camera Settings
●Set Level of Smile for Smile Mode
●Set Interval for Continuous Shooting
●Set Number of Shots for Continuous Shooting
(
P. 14-23)
File Storage
●Set Storage Location for Shot Still Images
(
P. 14-23)

7-14
7
Camera
Advanced Features
DuringShooting
Start Here
【Photo Viewfinder】
............................... P. 7-6
【Video Viewfinder】
............................... P. 7-8
After Shooting
Start Here
【Photo Preview】
window ...................... P. 7-6
【Video Preview】
window ...................... P. 7-8
【Thumbnail Preview】
window ............ P. 7-10
【Framed Image Preview】
window ...... P. 7-11
Use Camera Menu
【Photo Viewfinder】/【Video Viewfinder】

o

Select an item

d
Set Image Quality
【Video Viewfinder】 
u

Quality
Setting

d

Select an item

d
Switch Color Modes
【Photo Viewfinder】
/
【Video Viewfinder】 
u 
Camera Settings

d

Effect

d 
Full Color, Sepia or Monochrome

d
Reduce Flicker
【Photo Viewfinder】/【Video Viewfinder】

u

Camera Settings

d

Flicker

d

Auto,Mode 1 (50Hz) or Mode 2
(60Hz)

d
Check Storage Capacity
【Photo Viewfinder】
/
【Video Viewfinder】 
u 
Memory Info

d
Change Video Type
【Video Viewfinder】 
u

Movie Type
Set

d

Normal , Video or Voice

d
Set Shake Correction
【Photo Viewfinder】
/
【Video Viewfinder】 
u 
Shake Correction

d

Auto or
OFF

d
Attach Location Information During
Shooting
【Photo Viewfinder】 
u

Attach
Location

d

From Position Loc.,From
Loc. History,From Phonebook or From
Owner Details

d(

Enter Security
Code

d) (

Select location information

d)
To check the attached Location Information,
select Loc. Info Detail and press d.
To delete the attached Location Information,
select Delete Loc. Info and press d.
Zoom In/Out
【Photo Preview】
window

p

oor
pto zoom in or out.
Press uto return to original size.
Upload Still Image/Video to Blog
【Photo Preview】window/ 【Video Preview】
window

o

Blog Cont. or Blog
Contribution

d (

Attach Mail, QVGA
Scale Down or VGA Scale Down

d )

Create S!Mail

o
Specify a blog upload destination beforehand
with Blog/Mail Member (P. 5-4).
You may not be able to upload depending on
video image size.

7-15
Advanced Features
7
Camera
Send Still Image with Graphic Mail
【Photo Preview】window 
o

Insert

d

Insert Mail or SubQCIF
Scale Down

d

Create Graphic Mail

o
Attach Still Image/Video to Mail and Send
【
Photo Preview
】
window/
【
Video Preview
】
window

o

Attach Image or Compose
Message

d(

Attach Mail , QVGA Scale
Down
or VGA Scale Down

d )

Compose S!Mail

o
You may not be able to upload depending on
video image size.
Show Mirror Image of Shot Still Image
【Photo Preview】
window

u

Mirror
Display

d
Save Mirror Image of Shot Still Image
【Photo Preview】
window

u

Mirror
Save

d
Show Shot Still Image in Standby
【Photo Preview】
window

u

Set as
Display

d

Stand-by Display

d

Select a layout

d

Check preview

d
Attach Location Information After
Shooting
【Photo Preview】window 
u

Attach
Location

d

From Position Loc.,From
Loc. History,From Phonebook or From
Owner Details

d(

Enter Security
Code

d) (

Select location information

d)
To check the attached Location Information,
select Loc. Info Detail and press d.
To delete the attached Location Information,
select Delete Loc. Info and press d.
Show Recorded Video in Standby
【Video Preview】
window

u

Set as
Stand-by

d
Edit Title of Video
【Video Preview】
window

u

Edit
Title

d

Edit title

d
View Images
【Thumbnail Preview】
window

Select an

o
Press vto switch to the previous/next
image.
Save One Frame
【Thumbnail Preview】
window

Select an

d

p

Save or Mirror Save

d
Save Only Selected Images
【Thumbnail Preview】
window

Select an

d

Repeat the same step

p 
Save or Mirror Save

d
Select a checked image and press dto
cancel the selection.
Save as Animation
【Thumbnail Preview】
window

u

Store All&Anime

d

Save or Mirror
Save

d

Select a destination

d
Open an Image as Mirror Image
【Thumbnail Preview】
window

u

Mirror Display or Normal Display

d

7-16
Advanced Features
7
Camera
Attach to Mail
【Thumbnail Preview】
window

Select an

o(twice)

Attach Image

d
(

Attach Mail/QVGA Scale Down

d)

Compose S!Mail

o
Change Frame before Saving Image
【FramedImage Preview】
window

u

Change Frame

d

Select a folder

d 
Select a frame

d(twice)
