SolarEdge storedge User manual

Installation Guide
StorEdge Single Phase Inverter
with HD-Wave Technology and SetApp
Configuration
Version 1.1

Disclaimers
Important Notice
Copyright © SolarEdge Inc. All rights reserved.
No part of this document may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photographic,
magnetic or otherwise, without the prior written permission of SolarEdge Inc.
The material furnished in this document is believed to be accurate and reliable.
However, SolarEdge assumes no responsibility for the use of this material. SolarEdge
reserves the right to make changes to the material at any time and without notice. You
may refer to the SolarEdge web site (www.solaredge.com) for the most updated version.
All company and brand products and service names are trademarks or registered
trademarks of their respective holders.
Patent marking notice: see http://www.solaredge.com/patent
The general terms and conditions of delivery of SolarEdge shall apply.
The content of these documents is continually reviewed and amended, where
necessary. However, discrepancies cannot be excluded. No guarantee is made for the
completeness of these documents.
The images contained in this document are for illustrative purposes only and may vary
depending on product models.
Emission Compliance
This equipment has been tested and found to comply with the limits applied by the
local regulations.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, you are encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Disclaimers 1
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1

Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance may void the user’s authority to operate the equipment.
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
2 Emission Compliance

Revision History
Version 1.1 (September 2019)
Added Running a Battery Self-test on page 41.
Version 1.0 (July 2019)
First version of this guide
Revision History 3
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1

Contents
Disclaimers 1
Important Notice 1
Emission Compliance 1
Revision History 3
HANDLING AND SAFETY INSTRUCTIONS 6
Safety Symbols Information 6
IMPORTANTSAFETYINSTRUCTIONS 7
Chapter 1: Overview 10
The StorEdge Solution Components 10
Additional References 11
Installation Equipment List 11
Inverter Transport and Storage 12
Chapter 2: Installing the Power Optimisers 13
Safety 13
Installation Guidelines 14
Step 1: Mounting the Power Optimisers 16
Step 2: Connecting a PV Module to a Power Optimizer 16
Step 3: Connecting Power Optimizers in Strings 17
Step 4: Verifying Proper Power Optimiser Connection 18
Chapter 3: Installing the Inverter 19
Inverter Package Contents 19
Identifying the Inverter 19
Inverter Interfaces 20
Mounting the Inverter 24
Chapter 4: Installing the Battery 28
Chapter 5: Connecting the Inverter 29
Connecting the ACGrid to the Inverter 29
Connecting the Strings to the Inverter 31
Connecting the Energy Meter 31
Connecting the Battery 33
Chapter 6: Activating, Commissioning and Configuring the System 35
Step 1: Activating the Installation 35
Step 2: Commissioning and Configuring the Installation 36
Step 3: Verifying Proper Activation and Commissioning 40
Configuring Communication with the Battery and Energy Meter 40
Running a Battery Self-test 41
Configuring StorEdge Applications 42
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
4 Revision History

Viewing System Status 43
Reporting and Monitoring Installation Data 49
Chapter 7: Setting Up Communication to the Monitoring Platform 53
Communication Options 53
Communication Connectors 55
Removing the Inverter Cover 55
Removing the Connection Unit Cover 56
Creating an Ethernet (LAN) Connection 56
Creating an RS485 Bus Connection 59
Verifying the Connection 62
Chapter 8: Errors and Troubleshooting 64
Identifying Errors 64
Troubleshooting Communication 65
Power Optimiser Troubleshooting 67
Appendix A: Mechanical Specifications 69
Appendix B: Replacing and Adding System Components 70
Replacing an Inverter 70
Adding, Removing, or Replacing Power Optimizers 72
Appendix C: Powering the LG Chem Battery Off and On 73
Appendix D: Connecting and Powering Systems with a DC DisconnectSwitch 74
Appendix E: SafeDC™ 76
Support Contact Information 77
Revision History 5
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1

HANDLING AND SAFETY INSTRUCTIONS
During installation, testing and inspection, adherence to all the handling and safety
instructions is mandatory. Failure to do so may result in injury or loss of life and
damage to the equipment.
Safety Symbols Information
The following safety symbols are used in this document. Familiarize yourself with the
symbols and their meaning before installing or operating the system.
WARNING!
Denotes a hazard. It calls attention to a procedure that, if not correctly
performed or adhered to, could result in injury or loss of life. Do not proceed
beyond a warning note until the indicated conditions are fully understood and
met.
CAUTION!
Denotes a hazard. It calls attention to a procedure that, if not correctly
performed or adhered to, could result in damage or destruction of the
product. Do not proceed beyond a caution sign until the indicated conditions
are fully understood and met.
NOTE
Denotes additional information about the current subject.
IMPORTANTSAFETYFEATURE
Denotes information about safety issues.
Disposal requirements under the Waste Electrical and Electronic Equipment (WEEE)
regulations:
NOTE
Discard this product according to local regulations or send it back to SolarEdge.
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
6 HANDLING AND SAFETY INSTRUCTIONS

IMPORTANTSAFETYINSTRUCTIONS
SAVETHESEINSTRUCTIONS
WARNING!
The inverter cover must be opened only after switching the inverter ON/OFF/P
switch located at the bottom of the inverter to OFF. This disables the DC voltage
inside the inverter. Wait five minutes before opening the cover. Otherwise, there
is a risk of electric shock from energy stored in the capacitors.
WARNING!
Before operating the inverter, ensure that the inverter AC power cable and wall
outlet are grounded properly. This product must be connected to a grounded,
metal, permanent wiring system, or an equipment-grounding conductor must
be run with the circuit conductors and connected to the equipment grounding
terminal or lead on the product.
WARNING!
Opening the inverter and repairing or testing under power must be performed
only by qualified service personnel familiar with this inverter.
WARNING!
Do not touch the PV panels or any rail system connected when the inverter
switch is ON, unless grounded.
WARNING!
SafeDC complies with IEC60947-3 when installing the system with a worst case
SafeDC voltage (under fault conditions) < 120V.
The worst case voltage is defined as: Voc,max+ (String Length-1)*1V, where:
Voc,max = Maximum Voc (at lowest temperature) of the PV models in the
string (for a string with multiple models, use the max value)
String Length = number of power optimizers in the string
CAUTION!
This unit must be operated according to the technical specification datasheet
provided with the unit.
CAUTION!
HEAVY OBJECT. To avoid muscle strain or back injury, use proper lifting
techniques, and if required - a lifting aid.
NOTE
Use PV models rated according to IEC 61730 class A.
IMPORTANTSAFETYINSTRUCTIONS 7
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1

NOTE
The symbol appears at grounding points on the SolarEdge equipment. This
symbol is also used in this manual.
NOTE
A SolarEdge inverter may be installed in a site with a generator. SolarEdge
requires installing a physical or electronic interlock, which will signal to the
inverter when the grid has been disconnected. Interlock procurement,
installation, maintenance and support are the responsibility of the installer.
Damage to the inverter due to incorrect interlock installation or use of an
interlock that is incompatible with the SolarEdge system will render the
SolarEdge warranty invalid.
For more information, refer to
https://www.solaredge.com/sites/default/files/se-inverter-
support-of-voltage-sources.pdf.
NOTE
The following warning symbols appear on the inverter warning label:
Risk of electric shock
Risk of electric shock from energy stored in the capacitor. Do not
remove cover until 5 minutes after disconnecting all sources of
supply.
Hot surface – To reduce the risk of burns, do not touch.
WARNING!
Before operating the system, ensure that the been grounded properly.
WARNING!
When handling the battery, adhere to all manufacturer safety instructions.
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
8 IMPORTANTSAFETYINSTRUCTIONS

WARNING!
The battery must be powered off before and during wiring.
To power off the battery:
1. Turn off the circuit breaker.
2. Turn off the disconnect/auxiliary power switch.
To power the battery back on:
1. Turn on the disconnect/auxiliary power switch.
2. Turn on the circuit breaker.
For details, see Powering the LG Chem Battery Off and On on page 73.
CAUTION!
This unit must be operated under the specified operating conditions as
described in the technical specifications supplied with the unit.
NOTE
The battery used must be NRTL certified.
NOTE
For battery decommissioning and disposal, follow the manufacturer
requirements and instructions.
IMPORTANTSAFETYINSTRUCTIONS 9
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1

Chapter 1: Overview
Power is stored in the battery and can be used for various applications such as
maximized self-consumption and time of use profile programming. For backup power,
an inverter specifically designed for backup applications is required; this inverter is not
in the scope of this document.
The StorEdge Solution Components
The Inverter - manages the battery and system energy, in addition to its traditional
functionality as a DC-optimized PV inverter.
The Energy Meter - is used by the inverter for export, import, production and
consumption readings, and for Smart Energy Management applications, such as:
export limitation and maximizing self-consumption.
One battery - a DC-coupled battery designed to work with the SolarEdge system.
Figure 1: StorEdge system components
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
10 Chapter 1: Overview

NOTE
Additional SolarEdge inverters (without batteries) can be connected over
RS485. The inverters will participate in export limitation and Smart Energy
Management.
PV modules connected to power optimizers are not mandatory for charge/
discharge profile programming.
Additional References
This document describes basic system connection and configuration - PVsystem
(power optimizer strings), one inverter, one battery, and one meter.
For additional configuration options refer to the StorEdge Solution Applications -
Connection and Configuration Guide, available at:
https://www.solaredge.com/sites/default/files/storedge_applications_
connection_and_configuration_guide.pdf
Installation Equipment List
Standard tools can be used during the installation of the SolarEdge
system. The following is a recommendation of the equipment needed for installation:
Allen screwdriver for 5mm screw type for the inverter enclosure screws.
Allen screwdriver for M5/M6/M8 screw types
Standard flat-head screwdrivers set
Non-contact voltage detector
Cordless drill (with a torque clutch)or screwdriver and bits suitable for the surface
on which the inverter and optimizers will be installed. Use of an impact driver is not
allowed.
Appropriate mounting hardware (for example: stainless bolts, nuts, and washers)
for attaching:
the mounting brackets to the mounting surface
the power optimizer to the racking (not required for smart modules)
MC4 crimper
Wire cutters
Wire strippers
Chapter 1: Overview 11
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1

Voltmeter
Mobile phone with latest SetApp version
For installing the communication options, you may also need the following:
For Ethernet:
CAT5/6 twisted pair Ethernet cable with RJ45 connector
If using a CAT5/6 cable spool: RJ45 plug and RJ45 crimper
For RS485 and battery:
Four- or six-wire shielded twisted pair cable
Watchmaker precision screwdriver set
Inverter Transport and Storage
Transport the inverter in its original packaging, facing up and without exposing it to
unnecessary shocks. If the original package is no longer available, use a similar box that
can withstand the weight of the inverter (refer to the inverter weight in the specification
datasheet provided with the unit), has a handle system and can be closed fully.
Store the inverter in a dry place where ambient temperatures are -25°C to +65°C /
-13°F to 149°F.
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
12 Inverter Transport and Storage

Chapter 2: Installing the Power Optimisers
Safety
WARNING!
When modifying an existing installation, turn OFF the inverter ON/OFF/P
switch, the Connection Unit (if applicable) and the AC circuit breaker on the
main AC distribution panel.
CAUTION!
Power optimizers are IP68/NEMA6P rated. Choose a mounting location where
optimizers will not be submerged in water.
CAUTION!
This unit must be operated according to the operating specifications provided
with the unit.
CAUTION!
Cutting the power optimizer input or output cable connector is prohibited and
will void the warranty.
CAUTION!
All PV models must be connected to a power optimizer.
CAUTION!
If you intend to mount the optimizers directly to the modelor modele frame, first
consult the model manufacturer for guidance regarding the mounting location
and the impact, if any, on model warranty. Drilling holes in the model frame
should be done according to the model manufacturer instructions.
Chapter 2: Installing the Power Optimisers 13
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1



CAUTION!
Installing a SolarEdge system without ensuring compatibility of the model
connectors with the optimizer connectors may be unsafe and could cause
functionality problems such as ground faults, resulting in inverter shut down. To
ensure mechanical compatibility of the power optimizers’ connectors with the PV
model’ connectors to which they are connected:
Use identical connectors from the same manufacturer and of the same type
on both the power optimizers and on the models; or
Verify that the connectors are compatible in the following way:
The model connector manufacturer should explicitly verify compatibility
with the SolarEdge optimizer connector; and
A third-party test report by one of the listed external labs (TUV, VDE,
Bureau Veritas UL, CSA, InterTek) should be obtained, verifying the
compatibility of the connectors.
For more information, refer to
https://www.solaredge.com/sites/default/files/optimizer-input-
connector-compatibility.pdf


Installation Guidelines
The minimum and maximum string length guidelines are stated in the power
optimizer datasheets. Refer to the Designer for string length verification. The
Designer is available on the SolarEdge website at
https://www.solaredge.com/products/installer-tools/designer#/.
Frame-mounted power optimizers are mounted directly on the
module frame, regardless of racking system (rail-less or with rails). For
installation of frame-mounted power optimizers, refer to
http://www.solaredge.com/sites/default/files/installing_frame_
mounted_power_optimizers.pdf.
The power optimizer can be placed in any orientation.
If connecting more modules than optimizer inputs in parallel, use a branch cable.
Some commercial power optimizer models have a dual input.
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
14 Installation Guidelines

Position the power optimizer close enough to its module so that their cables can be
connected.
Make sure to use power optimizers that have the required output conductor length:
Do not use extension cables between a module and a power optimizer,
between two modules connected to the same optimizer, or between two
optimizers other than in the cases specified below.
You can use extension cables between power optimizers only from row to row,
around obstacles or pathways within a row, and from the end of the string to
the inverter, as long as the maximum distance is not exceeded.
NOTE
Use at least 11 AWG/ 4 mm² DC cables.
The total cable length of the string (excluding power optimizers’
cables) should not exceed 1000ft./300 m from DC+ to DC- of the
inverter.
Completely shaded modules may cause their power optimizers to temporarily shut
down. This will not affect the performance of the other power optimizers in the
string, as long as the minimum number of unshaded power optimizers connected in
a string of modules is met. If under typical conditions fewer than the minimum
optimizers are connected to unshaded modules, add more optimizers to the string.
To allow for heat dissipation, maintain a minimum of 2.5 cm / 1" clearance between
the power optimizer and other surfaces, on all sides except the mounting bracket
side.
Figure 2: Power optimizer clearance
When installing modules in a confined space, for example, if installing Building-
integrated photovoltaic (BIPV) modules, ventilation measures may be needed to
Chapter 2: Installing the Power Optimisers 15
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1

ensure the power optimizers are not be exposed to temperatures outside their
specifications.
Step 1: Mounting the Power Optimisers
For each of the power optimizers(1):
1. Determine the power optimizer mounting location and use the power
optimizer mounting brackets to attach the power optimizer to the
support structure . It is recommended to mount the power optimizer
in a location protected from direct sunlight. For frame-mounted
power optimizers follow the instructions supplied with the optimizers,
or refer to https://www.solaredge.com/sites/default/files/installing_frame_
mounted_power_optimizers.pdf.
2. If required, mark the mounting hole locations and drill the hole.
CAUTION!
Drilling vibrations may damage the power optimizer and will void the
warranty. Use a torque wrench or an electric drill with adjustable clutch that
meets the mounting torque requirements. Do not use impact drivers for
mounting the power optimizer.
Do not drill through the power optimizer or through the mounting holes.
3. Attach each power optimizer to the rack using M6 (1/4'') stainless steel bolts, nuts
and washers or other appropriate mounting hardware. Apply torque of 9-10 N*m /
6.5-7 lb*ft.
4. Verify that each power optimizer is securely attached to the model support structure.
5. Record power optimizer serial numbers and locations, as described in Reporting and
Monitoring Installation Data on page 49.
Step 2: Connecting a PV Module to a Power Optimizer
NOTE
Images are for illustration purposes only. Refer to the label on the product to
identify the plus and minus input and output connectors.
For each of the power optimizers:
(1)Not applicable to smart models.
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
16 Step 1: Mounting the Power Optimisers

Connect the Plus (+) output connector of the module to the Plus (+) input
connector of the power optimizer.
Connect the Minus (-) output connector of the module to the Minus (-) input
connector of the power optimizer.
Figure 3: Power optimizer connectors
Step 3: Connecting Power Optimizers in Strings
You can construct parallel strings of unequal length, that is, the number
of power optimizers in each string does not have to be the same. The
minimum and maximum string lengths are specified in the power
optimizer datasheets. Refer to the Designer for string length verification.
1. Connect the Minus (-) output connector of the string’s first power optimizer to the
Plus (+) output connector of the string’s second power optimizer.
2. Connect the rest of the power optimizers in the string in the same manner.
WARNING!
If using a dual-input power optimizer and some inputs are not used, seal the
unused input connectors with the supplied pair of seals.
Chapter 2: Installing the Power Optimisers 17
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1

Figure 4: Power optimizers connected in series
3. If you intend to monitor the installation, using the monitoring platform, record the
physical location of each power optimizer, as described in Creating Logical and
Physical Layout using Installation Information on page 50.
Step 4: Verifying Proper Power Optimiser Connection
When a model is connected to a power optimizer, the power optimizer outputs a safe
voltage of 1V (±0.1V). Therefore, the total string voltage should equal 1V times the
number of power optimizers connected in series in the string. For example, if 10 power
optimizers are connected in a string, then 10V should be produced.
Make sure the PVmodels are exposed to sunlight during this process. The power
optimizer will only turn ON if the PVmodel provides at least 2W.
In SolarEdge systems, due to the introduction of poweroptimizers between the PV
models and the inverter, the short circuit current ISC and the open circuit voltage VOC
hold different meanings from those in traditional systems.
For more information about the SolarEdge system’s string voltage and
current, refer to the VOC and ISC in SolarEdge Systems Technical Note ,
available on the SolarEdge website at:
https://www.solaredge.com/sites/default/files/isc_and_voc_in_solaredge_
sytems_technical_note.pdf
To verify proper power optimizer connection:
Measure the voltage of each string individually before connecting it to the other strings
or to the inverter. Verify correct polarity by measuring the string polarity with a
voltmeter. Use a voltmeter with at least 0.1V measurement accuracy.
NOTE
Since the inverter is not yet operating, you may measure the string voltage and
verify correct polarity on the DC wires inside the Connection Unit.
For troubleshooting power optimizer operation problems, refer to Power Optimiser
Troubleshooting on page 67.
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
18 Step 4: Verifying Proper Power Optimiser Connection

Chapter 3: Installing the Inverter
Install the inverter either before or after the models and power optimizers have been
installed.
CAUTION!
Do not rest the connectors at the bottom of the inverter on the ground, as it
may damage them. To rest the inverter on the ground, lay it on its back.
Inverter Package Contents
One inverter with Connection Unit
Mounting bracket kit
Connection Unit sealing cover (if applicable, for use in case of inverter replacement)
Installation guide
Identifying the Inverter
Refer to the sticker on the inverter that specifies its Serial Number and its Electrical
Ratings. Provide the serial number when contacting SolarEdge support. The serial
number is also required when opening a new site in the monitoring platform.
Chapter 3: Installing the Inverter 19
StorEdge Single Phase Inverter with HD-Wave Technology MAN-01-00627-1.1
