Sole Fitness E98 User manual

PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE
OWNER’S MANUAL

2
T ABLE OF C ONTEN T S
I mpo r ta n t S a f e t y I nstru c tions 3
I mpo r ta n t Ele c t r ical I n f o r m a tion 4
I mpo r ta n t Ope r a tion I nstru c tions 5
T r anspo r t I nstru c tions 5
A ssembly I nstru c tions 8
Elliptical F e a tu r es 13
Ope r a tion of Y our New Elliptical 14
P r o gr ammable F e a tu r es 17
U sing Hea r t R a t e M onit or 23
G ene r al M ai n tenan c e 25
Exploded View Diagram 26
Parts List 27
A T TENTION
THIS ELLIPTI C AL IS INTENDED FOR RESIDENTIAL USE ON L Y AND IS W ARRANTED FOR THE
APPLI C A TION. A N Y O THER APPLI C A TION V OIDS THIS W ARR AN T Y IN I T S ENTIR E T Y .
XE869A-YE21_1111(N)A

3
IMPOR T ANT SAFE T Y INSTR UCTIONS
W ARNING - R ead all instruc tions bef or e using this applianc e .
D ANGER - T o r educ e the r isk of elec tric shock disc onnec t y our SOLE elliptical fr om the elec trical outlet
pr ior t o cleaning and/or ser vice w or k .
W ARNING - T o r educ e the risk of bur ns , fir e , elec tric shock, or injur y t o persons , install
the elliptical on a flat lev el sur fac e with ac c ess to a 110- v olt , 15-amp g r ounded outlet with only the
elliptical plugged in t o the cir cuit .
DO NO T USE AN EX TENSION CORD UNLESS IT IS A 14A W G OR BE T TER, WITH ONLY ONE
OUTLET ON THE END: DO NO T A T TEMPT T O DISABLE THE GR OUNDED PL UG B Y USING
IMPR OPER AD APTERS, OR IN AN Y W AY MODIFY THE C ORD SE T .
A ser ious shock or fir e hazar d ma y r esult along with c omput er malfunctions . S ee Gr ounding I nstructions , page 3.
 D o not oper a t e elliptical on deeply padded , plush or shag car pet . Damage to both car pet and
elliptical ma y r esult .
 Keep children a w a y fr om the elliptical . T her e ar e obvious pinch points and other caution ar eas tha t
can cause har m.
 Keep hands a w a y fr om all mo ving par ts .
 Nev er oper a t e the elliptical if it has a damaged cor d or plug . I f the elliptical is not w or k ing pr oper ly ,
call y our dealer .
 Keep the c ord a w a y fr om hea t ed surfac es .
 D o not oper a t e wher e aerosol spr a y pr oduc ts ar e being used or wher e o x y gen is being
administ er ed . Spar ks fr om the mot or ma y ig nit e a highly gaseous en vir onmen t .
 Nev er dr op or inser t an y object in t o any openings .
 D o not use outdoors .

T o disc onnect , tur n all c on trols t o the off position, then r emo v e the plug fr om the outlet .
 D o not a ttempt t o use your elliptical f or any pur pose other than f or the pur pose it is intended .
 T he hand pulse sensors ar e not medical devic es . V arious fac t ors , including the user ’ s mo v ement ,
ma y aff ect the ac curac y of hear t r a t e r eadings . T he pulse sensors are in tended only as e x er cise
aids in det er mining hear t r a t e tr ends in gener al .
 W ear pr oper shoes . H igh heels , dr ess shoes, sandals or bar e f eet ar e not suitable for use on y our
elliptical . Q ualit y a thletic shoes ar e r ec ommended t o a v oid leg fa tigue .
SA VE THESE INSTR UC TIONS - THINK SAFE T Y!
Grounded Outlet
Grounding Pin
Grounded Outlet Box
Adapter
Metal Screw
Tab of
Grounding Screw

4
IMPOR T ANT ELEC TRICAL INSTR UCTIONS
W ARNING!
NE VER r emo v e an y c o ver without first disc onnec ting A C po w er .
I f v oltage v aries b y t en per c en t (10%) or mor e , the per f or manc e of y our elliptical ma y be affec ted . Such
c onditions ar e not c o v er ed under your warr an t y. I f y ou suspec t the v oltage is lo w , c on tac t y our
local po w er c ompan y or a lic ensed elec trician for pr oper t esting .
NE VER e xpose this elliptical t o r ain or moisture . T his pr oduc t is NO T desig ned f or use out doors , near a
pool or spa, or in an y other high humidit y en vir onmen t . T he oper ating tempera tur e specification is 40 t o
120 deg
r ees F ahr enheit, and humidit y is 95% non- c ondensing
(no w a t er dr ops for ming on sur fac es).
GR OUNDING INSTRUC TIONS
T his pr o duc t must b e gr ounded . I f the elliptical should malfunc tion or br eakdo wn, g r ound - ing
pr o vides a pa th of least r esistanc e f or electr ic cur r ent , r educing the r isk of elec tric shock . T his pr oduc t is
equipped with a cor d having an equipmen t - g r ounding plug . T he plug must be plugged int o an
appr opr ia t e outlet tha t is pr oper ly installed and g r ounded in ac c or danc e with all local c odes and
or dinanc es .
D ANGER - I m p r o p e r c o nn e c t i o n o f th e e q u i p m e nt - g r o un d i n g c o n d u c t o r c a n r e s u l t i n a
r i s k o f e l e c t r i c s h o c k . C h e c k w i th a q u a l i fi e d e l e c t r i c i a n o r s e r v i c e m a n i f y o u a r e i n d o u b t
a s t o w h e th e r th e p r o d u c t i s p r o p e r l y g r o un d e d . D o n o t m o d i f y th e p l u g p r o v i d e d w i th
th e p r o d u c t i f i t w i ll n o t fi t th e o ut l e t ; h a v e a p r o p e r o ut l e t i n s t a ll e d b y a q u a l i fi e d
e l e c t r i c i a n . T his pr oduc t is f or use on a nominal 230-volt cir cuit , and has a g r ounding plug tha t looks like
the plug illustr a t ed belo w . A t empor ar y adapt er that looks like the adapt er illustr a t ed belo w ma y be used
to c onnec t this plug t o a 2-pole r ec eptacle as sho wn belo w if a pr oper ly g r ounded outlet is not a v ailable .
T he t empor ar y adapt er should be used only un til a pr oper ly g r ounded outlet , (sho wn belo w) can be
installed b
y a qualified electr ician. T he g r een c olor ed r ig id ear -lug , or the like , ex t ending fr om the adapt er ,
must be c onnect ed t o a per manen t g r ound such as a pr oper ly g r ounded outlet bo x c o v er . Whenev er
the adapt er is used , it must be held in place b y a metal scr ew .

5
IMPOR T ANT OPER A TION INSTR UCTIONS
 NE VER oper a t e this elliptical without r eading and c omplet ely understanding the r esults of an y
oper a tional change y ou request fr om the c omput er .
 Understand tha t changes in resistanc e and incline do not oc cur immedia t ely . S et y our de - sir ed
r esistance on the c omput er c onsole and r elease the adjustmen t key . T he c omput er will obey the
c ommand g r adually .
 NE VER use y our elliptical during an elec tr ical st or m. Sur ges ma y occur in your facilit y or
household pow er supply tha t c ould damage elliptical c omponen ts . Unplug the elliptical dur ing
an elec tr ical st or m as a pr ecaution.

U se caution while par ticipa ting in other activities while pedaling on y our elliptical; such as
w a t ching t elevision, r eading , et c . T hese distr ac tions ma y r esult in ser ious injur y .
 A lw a y s hold on t o a handr ail or hand bar while making c on tr ol changes (incline , r esistance , et c .).
 D o not use e x c essiv e pressure on c onsole c on trol key s . T hey are precision set t o func tion pr oper ly
with little finger pressur e . P ushing har der is not going to make the unit go fast er or slo w er . I f y ou
f eel the butt ons ar e not func tioning proper ly with nor mal pr essur e c on tac t y our dealer .
PO WER C ONNEC T OR - FR ONT , LEFT SIDE OF UNIT
TR ANSPOR T INSTR UCTIONS
T he elliptical is equippped with t w o tr anspor t wheels which ar e engaged when the rear
of the elliptical is lif ted .

ASSEMBL Y P A CK CHECKLIST
1 HARDW ARE STEP 1
#158. 3/8” x 19 x 1.5T
F la t W asher (2 pcs)
#154 . 5/16” x 20 x 1.5T
F la t W asher (4 pcs)
#164 . 3/8” x 23 x 2T
C ur v ed W asher (2 pcs)
#167 . 3/8” x 2T
Split W asher (1 pc)
#128. M5 x 10mm
P hillips Head S cr ew (4 pcs)
#145 . 3/8” x 7T
Nyloc Nut (2 pcs)
#166 . 5/16” x 1.5T
Split W asher (4 pcs)
#168 . 5/16”
S tar W asher (4 pcs)
#116 . 3/8” x 3/4”
He x Head B olt (2 pcs)
#115
. 5/16” x 2-1/4”
He x Head B olt (4 pcs)
#117
. 3/8” x 1-1/2”
He x Head B olt (2 pcs)
#118
. 3/8” x 2-1/4”
He x Head B olt (1 pc)

7
2 HARDW ARE STEP 2
3 HARDW ARE STEP 3
4 HARDW ARE STEP 4
#163 . 25mm
Wa v e W asher (4 pcs)
#160 . 3/8” x 30 x 2T
F
la t W asher (2 pcs)
#132 . 3.5 x 12mm
Sheet M etal S cr ew (8 pcs)
#116. 3/8” x 3/4”
He x Head B olt (2 pcs)
#154 . 5/16” x 20 x 1.5T
F la t W asher (2 pcs)
#143 . 5/16” x 7T
Nyloc Nut (2 pcs)
#114 . 5/16” x 1-1/4”
He x Head B olt (2 pcs)
#132
. 3.5 x 12mm
Sheet M etal S cr ew (10 pcs)
#129
. M5 x 15mm
P hillips Head S cr ew (29 pcs)
#131
. M6 x 10mm
P hillips Head S cr ew (4 pcs)

8
ASSEMBL Y T OOLS
#171 . P hillips Head S cr ew dr iv er #170 . Shor t P hillips Head S cr ew dr iv er
#172 . 12/14mm W r ench #169 . 13/14mm W r ench
ASSEMBL Y INSTRUC TIONS
PRE - ASSEMBL Y
1. Using a r az or k nif e (B o x C utt er) cut the outside , bottom, edge of box along the
dott ed Line . Lif t B o x o v er the unit and unpack .
2. C ar efully r emo v e all par ts fr om car t on and inspec t f or an y damage or missing par ts . I f
damaged par ts ar e f ound , or parts ar e missing , c on tac t y our dealer immediat ely .
3. L oca t e the har dw ar e pack age . R emo ve the t ools first . R emo ve the har dw ar e f or each
st ep as needed to avoid c onfusion. T he numbers in the instructions tha t ar e in
par en thesis (#) ar e the it em number fr om the assembly dr a wing f or r ef er enc e .

9
1 INCLINE R AIL & C ONSOLE M AST
HARDW ARE STEP 1
1. I nstall the Incline R ail A ssembly ( 2 ) in t o the U- channel br acket of the M ain Fr ame ( 1 ). S ecur e
with the six bolts & associa t ed har dw ar e as f ollo w s: F r om the sides install t w o He x Head Bolts
( 117 ) with t w o F la t W ashers ( 158 ) and t w o N ylon Nuts ( 145 ). F r om the t op install four He x
Head Bolts ( 115 ), f our Split W ashers ( 166 ), f our F la t W ashers ( 154 ), and four S tar W ashers
( 168 ), and tight en with the W r enches pr o vided ( 169 & 172 ).
2. C onnec t the thr ee I ncline M ot or P o w er lines b y ma t ching the R ed , W hit e and Black c olor
c odes of the wir es ( 43 ) and the 3-pin position Sensor C onnec t or ( 44 ). L oca t e the C onsole
M
ast ( 12 ) and C onsole M ast C o v er ( 83 ) and slide the C o ver on t o the M ast as far as it will go.
M ake sure the C onsole M ast C o v er is facing the c or r ect w a y . A t the t op opening of the M ain
F r ame of the elliptical is a C omput er C able ( 45 ); S ecur e the fr ee end of the twist tie tha t
e xits thebott om of the console mast ( 12 ) t o this cable . P ull the opposite end of this t wist tie
up thr ough the c onsole mast ( 12 ) until the cable e xits the t op . I nstall the C onsole M ast ( 12 )
in t o the receiving bracket on the top of the M ain Fr ame ( 1 ). P ull slightly on the c omput er
cable a t the t op of the mast while installing . T his will ensur e the cable does not get pinched
and shor t ed dur ing c onsole mast assembly .
3. P ut one Split W asher ( 167 ) on t o the L ong He x Head B olt ( 118 ) and install through the lef t
side of the r eceiving bracket in t o the C onsole M ast ( 12 ). P ut the t w o C ur v ed W ashers ( 164 )
on t o the t w o Shor t He x Head Bolts ( 116 ) and install thr ough the fr on t of the c onsole mast .
U sing W r ench ( 172 ), tigh ten the ( 116 ) bolts first , then the ( 118 ) bolt , and lastly the f our th
bolt , which is pr e -installed , fir mly . T hese bolts should be tigh t ened as much as y ou possibly
can. T his is the main joint of the unit . I f not tigh t ened sufficien tly , this c ould lead t o noise
and instabilit y issues .
4. P lug the C omput er C able ( 45 ), t w o Hand pulse C ables ( 52 & 56 ), and g r een Gr ound C able
( 175 ) in t o the back of the c onsole . S ecur e the C onsole ( 40 ) on the c onsole moun ting
pla t e with four Phillips Head S cr ew s ( 128 ).
2 HANDLE B AR
HARDW ARE STEP 2
1. Install two Washers (163) onto the Left and Right sides of the Handle Bar axle.
2. Slide the Left (10) and Right (11) Handle Bars onto the appropriate side of the axle. The
handlebars have a small sticker on them indicating L (left) and R(right). Make sure the
handlebars are facing the correct direction – see illustration.
3. Install two Flat Washers (160) onto the two Hex Head Bolts (116). Insert and and tighten in
the threaded holes at the ends of each axle.
4. Install the Handle Bar Covers (91 to 92) and (93 to 94) over the Console Mast axle
connections and secure with the eight Sheet Metal Screws (132).
#158. 3/8’’ x 19 x 1.5T
Flat Washer (2 pcs)
#154. 5/16’’ x 20 x 1.5T
Flat Washer (4 pcs)
#164. 3/8’’ x 23 x 2T
Curve Washer (2 pcs)
#167. 3/8’’ x 2T
Split Washer (1 pc)
#128. M5 x 10mm
Phillips Screw (4 pcs)
#145. 3/8’’ x 7T
Nylon Nut (2 pcs)
#166. 5/16’’ x 1.5T
Split Washer (4 pcs)
#168. 5/16’’
Star Washer (4 pcs)
#116. 3/8’’ x 3/4’’
Hex Hea Bolt (2 pcs)
#115. 5/16’’ x 2-1/4’’
Hex Hea Bolt (4 pcs)
#117. 3/8’’ x 1-1/2’’
Hex Hea Bolt (2 pcs)
#118. 3/8’’ x 2-1/4’’
Hex Hea Bolt (1 pc)
#163. 25mm
Wave Washer (4 pcs)
#160. 3/8’’ x 30 x 2T
Flat Washer (2 pcs)
#132. 3.5 x 12mm Sheet
Metal Screw (8 pcs)
#116. 3/8’’ x 3/4’’
Hex Hea Bolt (2 pcs)

10
1 ASSEMBL Y STEP 1
2 ASSEMBL Y STEP 2

11
3 C ONNEC TING ARM
HARDW ARE STEP 3
1. Un tie the wire holding the Sleeve Spac er ( 19 ) in plac e on the r od- end bush ings , loca t ed on
the ends of the c onnec ting ar ms ( 8 & 9 ). A lign the hole in the r od ends with the hole in the
br ackets of the lef t and r igh t Handle Bar ( 10 & 11 ). T he r od end should be on the inside of the
Handle Bar bracket . S ecure both sides with a He x Head B olt ( 114 ), F la t W asher ( 154 ) and
N yloc Nut ( 143 ) b y using the wrenches pr o vided ( 169 & 172 ).
4 PLASTIC P ART S
HARDW ARE STEP 4
1. Ma t ch up the console c o v ers ( 81 & 82 ) and secure with thr ee P hillips head scr ew s ( 129 ) and
t w o Sheet M etal S cr ew s ( 132 ) using the shor t P hillips head scr ew dr iv er ( 170 ). T ight en the
Sheet metal scr ew s first .
2. Ma t ch up the C onnec ting A r m C o v ers ( 97 & 98 -inner c o vers and 95 & 96 out er c o v ers). I nstall
the inner c o vers on t o the L eft and R igh t C onnec ting A r ms ( 8 & 9 ) and secure each side with
t w o P hillips Head S cr ew s ( 129 ) and t w o Sheet M etal S cr ew s ( 132 ) b y using the Shor t
P hillips Head S cr ew Dr iv er ( 170 ). I nstall the out er c o vers on t o the left and r igh t handlebars ( 10
& 11 ) and secure each side with t w o P hillips Head S cr ew s ( 129 ) and t w o S elf T apping S cr ew s
( 132 ). M ake sur e the out er c o v ers ar e positioned in rela tion t o the ar r o w on each sticker .
3. I nstall Sliding W heel C o v ers ( 22 ) on each side and secure with four P hillips Head S cr ew s
( 129 ).
4. I nstall the t w o S tabiliz er C o v ers ( 101 & 102 ) on the middle stabilizer bar with t w o P hillips
Head S cr ew s ( 129 ).
5. I nstall the F r on t S tabiliz er C o v er ( 90 ) on the fr on t stabilizer with t w o P hillips Head S cr ew s
( 129 ).
6. I nstall the t w o incline C o v er brackets ( 20 ), with the hole f or moun ting the plastic c o v er on the
ben t tab facing rear w ar d , and secure them on the I ncline Rail A ssembly ( 2 ) with f our Phillips
Head S cr ew s ( 131 ). I nstall the Rear incline bar c o v er ( 100 ) on the r ail base with t w o Scr ew s
( 129 ).
7. I nstall the R ear S tabiliz er C o v er ( 24 ) on the R ear S tabiliz er with f our P hillips Head S cr ew s
( 129 ).
8. T his st ep t o be per f or med af t er the elliptical po w er is plugged in. Run the incline to position 8
and install the incline R ail fr on t c o v er ( 99 ) up against the middle stabiliz er tube with four
Phillips Head S cr ew s ( 129 ).
#154. 5/16’’ x 20 x 1.5T
Flat Washer (2 pcs)
#143. 5/16’’ x 7T
Nyloc Nut (2 pcs)
#114. 5/16’’ x 1-1/4’’
Hex Hea Bolt (2 pcs)
#132. 3.5 x 12mm Sheet
Metal Screw (10 pcs)
#129. M5 x 15mm
Phillips Hea Screw
(29 pcs)
#131. M6 x 10mm
Phillips Hea Screw
(4 pcs)
#20. Bracket (2 pcs)

12
3 ASSEMBL Y STEP 3
4 ASSEMBL Y STEP 4

13
ELLIPTIC AL FEA TURES
C ORREC TL Y ALIGNED ORTHOPEDIC FOO T P ADS
T hr ough r esear ch per f or med with a leading spor ts scien tist and ph y sical r ehabilita tion e xper t;
eng ineering has dev eloped a breakthrough in pedal desig n. No other elliptical , a t an y pr ic e , off ers this
unique f eatur e . T he histor y of elliptical use over the past few y ears t ells us tha t man y users suff er fr om
numb t oes while wor k ing out on elliptical trainers . M an y other users c omplain of ank le , A chilles t endon,
knee and/or hip pain. W hile resear ching a solution t o these c ommon pr oblems eng ineers c onsult ed
R ichar d D eKok , P .T ., M.T .C., of S t . B er nar d ’ s I ndustr ial R ehabilita tion C ent er in Jonesbor o A r k ansas .
T ogether we iden tified the inher ent problem in elliptical designs and developed a solution t o solv e the
pr
oblem. W ha t w e f ound is tha t when you use an elliptical y ou tend to push out w ar d during the po w er
str oke and not just str aigh t back . T his causes str ess on the out er part of the f oot and thr o w s off the
na tur al alig nmen t of the join ts . O ur solution w as simple but eff ec tiv e:
 W e added a 2- deg r ee in w ar d angle t o the f ootpads . T his migh t sound simple but wha t it does is
puts the users joints back in t o a neutral alig nmen t . T his eases the ov er str essing of the ank les ,
k nees and hips .
R AMP INCLINE ADJUSTMENT
T he has an incline f eature tha t will further increase the var iet y of y our w or kouts . When the incline is a t its
lo w est position you get a normal elliptical wor kout . A s the incline incr eases y ou will feel y our knees r ise
higher with each step; which means you are
in v olving mor e muscle fibers, due t o the incr eased r ange of motion.
T he has a c omput er c on tr olled po w er incline . T he po w er incline is c on tr olled by butt ons on the c onsole
and will aut oma tically adjust via the incline motor dur ing the built -in w or kout pr og r am.

14
PROGRAM BUTTONS
(Manual, Hill, Fat Burn,
Cardio, Strength, Interval,
Custom, Fit-Test, 2HR)
DISPLAY
CONTROL KEYS
AUDIO IN JACK
(MP3, CD,OR
SMARTPHONE)
DOT MATRIX
(Program Profiles)
MESSAGE WINDOW
(Time,Program Name,
Distance, RPM, Calories,
Laps,Level,Watts, Incline & Pulse)
FAN POWER SWITCH
HEADPHONE JACK
OPERA TION OF Y OUR ELLIPTIC AL
GE T TING F AMILIAR WITH THE C ONTR OL PANEL
C ONSOLE
PO WER UP
W hen pow er is c onnec t ed t o the Elliptical the console will aut oma tically po w er up . T hese
models ar e c onnec t ed direc tly t o 230 V A C and ther e is a po w er swit ch loca t ed wher e the line cor d plugs in t o the unit on the
lef t side near the fr on t (S ee page 4 for loca tion).
W hen it is first po w er ed on, the console will per f or m an in t ernal self-t est . D ur ing this time all the ligh ts will tur n on. When the
ligh ts go off , the M essage windo w will sho w a sof t w ar e v ersion (i.e .: VER 1.0) and the C alorie windo w will display an odomet er
r eading . T he odomet er r eading displa y s ho w man y vir tual miles the elliptical has gone . T he T ime windo w displa y s ho w man y
hours the elliptical has been used .
T he odomet er and time will r emain displa y ed f or only a few sec onds then the c onsole will go to the star tup displa y . T he dot
ma tr ix displa y will be scr olling through the diff er en t wor kout pr ofiles and the M essage windo w will be scr olling the star t up
message . Y ou ma y no w beg in to use the c onsole .
!!A T TENTION
Y our new elliptical c onsole migh t c ome configur ed in an in-st ore ‘ display mode ’ of oper ation, wher e the c onsole will r emain
pow er ed on unless the main po w er switch is tur ned off . I f this is the case , f ollo w this pr oc edur e t o tur n it off : T o exit the displa y
mode , f or nor mal opera tion, pr ess and hold the S top , En t er and Displa y key s f or fiv e sec onds; the displa y will sho w :
Displa y M o de - ON . U se the Resistance Up key t o change the setting t o OFF then pr ess En t er
COOLING FAN
DATA DISPLAY

15
C ONSOLE OPERA TION
QUICK START
T his is the quickest w a y t o start a w or kout . A f t er the c onsole
po w ers up y ou just pr ess the S tar t key t o beg in, this will initia t e the
Q uick S tar t mode . I n Q uick S tar t the T ime will c oun t up fr om z er o
and the w or k load and the r esistance and incline ma y be adjust ed
manually b y pr essing the Up or D o wn butt ons . T he dot ma trix
display will be sho wing a tr ack with a blink ing dot indica ting your
pr og r ess as it tr a v - els ar ound the tr ack .
B ASIC INFORM A TION
T he M essage W indo w will initially be displa ying the Speed in KPH. Each time the D ispla y Butt on -
loca t ed lef t of the displa y - is pr essed the ne x t set of inf or ma tion will appear . T he inf or ma tion displa y ed will
be: Speed in MPH, R amp Incline , W a tts , ME T s and S egmen t T ime . P r essing the Displa y
Butt on one mor e time will set the displa y t o S c an mode wher e all of the inf or ma tion will be displa y ed
sequen tuially f or 4 sec onds each.
W hen in a pr og r am y ou ma y change the D ot M a tr ix pr ofile (R esistance , I ncline and Laps) view b y
pr essing the En t er butt on. A f t er scr olling thr ough the t w o pr ofiles and Laps the D ot M a tr ix will
aut oma tically scr oll thr ough the thr ee displa y s sho wing each f or 4 sec onds . T he ic on associa t ed with
each displa y will ligh t while tha t view is displa y ed .
If the Stop/Reset key is held down for 3 seconds the console will perform a complete Reset . During
data entry for a program the Stop/Reset key performs a Previous Screen function. This allows you to
go back one step in the programming each time you press the Stop key.
There is an Audio In Jack ( ) on the front of the console and built-in speakers. You may plug any
low-level audio source signal into this port. Audio sources include MP3, iPod, portable radio, CD player
or even a TV or computer audio signal. There is also a
Headphone Jack ( )for private listening.
DO T M A TRIX CENTER DISPLA Y
T he Elliptical has a built in hear t r a t e monit or ing syst em. Simply g r asping the C on tac t H ear t R a t e
S ensors on the sta tionar y handle bars or wearing the chest str ap tr ansmitt er (sold separ a t ely) will star t the
hear t (see Hear t R a t e P r og r ams) Ic on blink ing (this ma y take a f ew sec onds). T he P ulse W indo w will
displa y y our hear t r a t e in bea ts per minut e and the HR bar g r aph will sho w y our cur r en t % in r ela tion t o
pr ojec t ed hear t r a t e maximum. T he chest strap is a mor e ac cur a t e and r eliable method of hear t r a t e r eading .
T he hand pulse sensors are subjec t t o false r eadings depending on user ph y siology and w or kout habits
including ho w one g r ips the sensors or how sw ea t y their hands ar e .
T he S top butt on ac tually has sev er al func tions . Pr essing the S top key once during a pr og r am will P ause
the pr og r am for 5 minut es . I f y ou need t o get a dr ink , answ er the phone or an y of the man y things tha t
c ould in t er rupt y our w or kout , this is a g r ea t f eatur e . T o r esume y our w or kout during P ause just press the
S tar t key . I f the S top butt on is pressed t wice during a wor kout the pr og r am will end and a Wor kout
Summar y is displa y ed . I f the S top key is held do wn f or 3 sec onds the c onsole will per f or m a c omplet e
R
eset . D ur ing da ta en tr y f or a pr og r am the S top key per f or ms a P r evious S cr een func tion. T his allo w s y ou
t o go back one st ep in the pr og r amming each time you pr ess the S top key .

16
PR OGR AMMING THE C ONSOLE
Each of the pr og r ams can be cust omiz ed with your personal infor ma tion and changed t o suit y our needs .
S ome of the inf or ma tion asked f or is nec essar y t o ensur e the r eadouts ar e c or r ec t . Y ou will be asked f or y our
A ge and W eigh t . En t er ing y our A ge is necessar y dur ing the Hear t R a t e c on tr ol pr og r am t o ensur e the
c or r ect settings ar e en t er ed in the pr og r am; en t er ing y our e xac t W eigh t r esults in a more ac cur a t e C alorie
calcula tion. A lthough w e cannot pr o vide an e xact calor ie c oun t we do w an t to be as close as possible .
A message about Calories: C alor ie r eadings on ev er y piec e of e x er cise equipmen t , whether it is in a
gym or a t home , ar e not accur a t e and t end t o vary widely . T hey ar e mean t only as a guide t o monit or y our
pr og r ess fr om w or kout t o wor kout . T he only w a y t o measur e y our calorie burn accur a t ely as in a clinical
setting c
onnect ed t o a host of machines . T his is because ev er y person is diff er en t and bur ns calor ies a t a
diff er en t r a t e .
ENTERING A PR OGR AM AND CHANGING SE T TINGS
P r ess each pr og r am butt on t o scr oll thr ough the pr og r am selec tions . T he pr ofile f or each pr og r am will be
displa y ed in the dot ma tr ix windo w . T he will sho w the incline pr ofile also when the Displa y key is pr essed .
Pr ess the En t er key t o select a pr og r am and beg in cust omizing the settings . I f y ou w an t t o wor kout without
en t er ing new settings , then just pr ess
the S tar t key . T his will bypass the pr og r amming of da ta and take y ou dir ec tly t o the star t of y our w or kout . I f y ou
w an t t o change the personal settings , then just f ollo w the instruc tions in the message windo w . I f y ou star t a
pr og r am without chang ing the settings , the default settings will be used .
N ot e: A ge and W eigh t default settings will change when y ou en t er a new number . S o the last A ge and W eight
ent er ed will be sav ed as the new default settings . I f y ou ent er A ge and W eight the first time you use the
Elliptical y ou will not ha ve t o en t er it ever y time y ou w ork out unless either A ge or W eigh t has changed or
someone else en t ers a differ en t A ge and W eight .

17
PR OGR A MM ABLE FEA TURES
M ANU AL PR OGR AM
T he Manual pr og r am w orks as the name implies , manually . T his means tha t y ou c on tr ol the
w or k load yourself and not the c omput er .
1. P r ess the M anual pr og r am butt on then pr ess the En t er key .
2. T he Message windo w will ask y ou t o en t er y our A ge . Y ou ma y adjust the age
setting using the I ncli ne or Resistanc e Up and D o wn key s , then pr ess the En t er key t o
ac c ept the new number and proceed on to the ne x t scr een.
3. Y ou ar e no w asked t o en t er y our W eigh t . Y ou ma y adjust y our w eigh t setting using the
I ncline or Resistanc e Up and D o wn key s , then pr ess En t er t o c on tinue .
4. Ne x t is the T ime . Y ou ma y adjust the length of T ime b y pr essing the Up or D o wn I ncline
or Resistance key s , then pr ess En t er t o c on tinue ..
5. No w y ou ar e finished editing the settings and can beg in y our w or kout b y pr essing the S tar t key .
Y ou can also go back and modify your settings b y pr essing the S t op key t o go back one lev el of
the pr og r amming screen.
6. Onc e the pr og r am star ts the elliptical will be set to lev el one . T his is the easiest lev el and it is a good
idea t o sta y a t level one for a while t o w ar m up . I f y ou w an t to incr ease the wor k load at an y time
pr ess the Resistance Up key; the Resistance D o wn key will decr ease the w or k load .
7. D uring the Manual pr og r am you will be able t o scr oll thr ough the da ta in the message windo w
b y pr essing the Displa y key .
8. W hen the pr og r am ends the message windo w will sho w a summar y of y our w or kout . T he summar y
will be displa y ed for a shor t time then the c onsole will r eturn t o the star t -up displa y .

18
PRESE T PR OGR AMS
T he Elliptical has five diff er en t pr og r ams that ha v e been designed f or a v ar iet y of w or kouts . T hese fiv e
pr og r ams ha ve fac t or y pr eset w or k lev el pr ofiles f or achieving diff er en t goals .
H ill
T he H ill pr og r am simula t es going up and do wn a hill . T he r esistance in the pedals will st eadily increase and then decrease
dur ing the pr og r am.
W ORK INCLINE
F a t Burn
T he F a t Burn pr og r am is desig ned , as the name implies , t o maximiz e the burning of fa t . T her e ar e man y schools of though t on
the best w a y t o bur n fa t but most e xperts ag r ee tha t a lo w er e x er tion level tha t sta y s a t a st eady w or k load is the best . T he absolut e
best w a y t o bur n fa t is t o keep your hear t r a t e a t ar ound 60% t o 70% of its maximum poten tial . T his pr og r am does not use hear t
r a t e but simula t es a lo w er , st eady e x er tion w or kout .
W ORK INCLINE
C ar dio
T he C ar dio pr og r am is desig ned t o incr ease y our car dio vascular func tion and enduranc e . T his is e x ercise f or y our hear t and lungs .
I t will build up your heart muscle and increase blood flo w and lung capacit y . T his is achieved b y inc or por a ting a higher lev el of
e x er tion with sligh t fluc tua tions in wor k .
W ORK INCLINE
S tr ength
T he S tr ength pr og r am is desig ned t o increase muscular str ength in y our lo w er body . T his pr og r am will steadily incr ease in
r esistanc e t o a high level and for c es y ou t o sustain it . T his is desig ned t o str engthen and t one y our legs and glut es (muscles of the
butt).
W ORK INCLINE
I nt er v al
T he I nt er v al pr og r am takes y ou through high lev els of in t ensit y f ollo w ed b y per iods of low in t ensit y . T his pr og r am incr eases y our
enduranc e by depleting y our o x y gen lev el f ollo w ed b y periods of r ec o v ery to r eplenish o x y gen. Y our car dio v ascular syst em gets
pr og r ammed t o use o x y gen mor e efficiently this w a y . T his pr og r am also f or c es y our body to bec ome mor e efficien t due t o spikes in
hear t r a t e, bet w een rec o v er y per iods . T his aids in hear t r a t e r ec o v er y fr om in t ense activities .
W ORK INCLINE

19
P R OG RAMMING PRES ET BU TT ONS
1. P r ess the desi r ed p r og r am butt on then p r ess the E nt er key .
2. T he message wind o w will ask y ou t o e n t er y our A ge . Y ou m a y adjust the age settin g , using
the I ncline or Resistan c e Up and D o wn ke y s , then p r ess the E nt er key t o a cc ept the new
number and p r o c eed on t o the ne x t sc r een.
3. Y ou a r e n o w asked t o e n t er y our Weig ht . Y ou m a y adjust y our w eig h t using the I ncline or
Resistan c e Up and D o wn ke y s then p r ess E nt er t o c o n tinu e .
4. N e xt is T ime . Y ou m a y adjust the T ime and p r ess E nt er t o c o n tinu e .
5. Now you are asked to adjust the Max Level.This is the peak exertion level you will
experience during the program (the highest colored segment/box of the program profile).Adjust the level and then press
Enter.
6. Now you are asked if you want to turn off the incline profile. Use the I ncline Up or D o wn ke y s t o tu r n the I ncline on or E nt er .
7. Now you are finished editing the settings and can begin your workout by pressing the S ta r t key . Y ou can also go back and
modify
y our settings b y p r essing the S top key t o go back one sc r een or E nt er t o go back t o the be g innin g .
8. I f y ou w a n t t o inc r ease or dec r ease the r esistan ce or incline a t a n y time du r ing the p r og r am p r ess the I ncline or Resis - tan c e Up or
D o wn ke y s .
9. D u r ing the p r og r am y ou will be able t o sc r oll th r ough the da ta in the message wind o w b y p r essing the Displ a y ke y .
10. When the p r og r am ends the message wind o w will sh o w a summa r y of y our w o r kout . T he summa r y will be displ a y ed f or a sho r t time
then the c onsole will r etu r n t o the sta r t -up displ a y .
CUS T OM P R OG R AM
T he cus tomizable User p r og r am all o w s y ou t o build and s a v e y our o wn w o r kout . F oll o w the
instru c tions bel o w .
1. S ele c t the C us t om p r og r am then p r ess E nt er . I f y ou ha ve al r eady s a v ed a p r og r am, it will be displ a y ed and y ou a r e r eady t o be g in.
I f not or someone else ’ s name is sh o wn, y ou will h a v e the option of o v e rr iding or inputting a use r nam e . I n the message wind o w , the
let t er “ A ” will be blin k in g . U se the Up and D o wn I ncline or Resistan c e but t ons t o selec t the swi t ch t o let t er “Z”). P r ess E nt er when
the desi r ed let t er is displ a y e d . R epe a t this p r o c ess u n til all of the cha r a c t ers of S top .
2. I f the r e is a p r og r am al r eady s t o r ed in C us t om when y ou p r ess the ke y , y ou will h a v e an option t o run the p r og r am as it is or dele t e
the p r og r am and build a new on e . A t the w el c ome message sc r een, when p r essing S ta r t or E nt er y ou will be p r omp t ed: Run
P r og r am? U se the Up/ D o wn a rr o w s t o selec t Y es or N o . I f y ou sele c t N o , y ou will then be asked if y ou w a n t t o dele t e the cu rr e n tly
s a v ed p r og r am. I t is ne cessa r y t o dele t e the cu rr e n t p r og r am if y ou w a n t t o build a new on e .
3. T he message wind o w will ask y ou t o e n t er y our A ge . Y ou m a y e n t er y our a g e using the I ncline or Resistan c e Up and D o wn ke y s ,
then p r ess the E nt er key t o a cc ept the new number and p r o c eed on t o the ne x t sc r een.
4. Y ou a r e n o w asked t o e n t er y our Weig ht . Y ou m ay adjust the weight number using the I ncline or Resistan c e Up and
D o wn ke y s , then p r ess E nt er t o c o n tinu e .
5. N e xt is T ime . Y ou m a y adjust the T ime using the I ncline or Resistan c e Up and D o wn ke y s and p r ess E nt er t o c o n tinu e .
6. Now the first column will be blinking and you are asked to adjust the level for the first segment of the workout. When you finish
adjusting the first segment, or if you don’t want to change, then press E nt er t o c o n tinue t o the ne x t se g me n t . T he n e x t se g me n t
will sh o w the same le vel as the p r eviously adjus t ed se g me n t . R epe a t the same p r o c ess as the last se g me n t then p r ess E nt er .
C o n tinue this p r o c ess u n til all tw e n t y se g me n ts h a v e been se t .
7. Now the first column will be blinking again and you are asked to adjust the lncline level for the first segment of the workout. Follow the
same procedure for building the lncline profile as you did for the resistance profile.
8. T he message wind o w will then t ell y ou t o sta r t t o be g in (and s a v e the p r og r am) or E nt er t o modify the p r og r am. P r essing S top will
e xit t o the sta r t up sc r een.
9. If you want to increase or decrease the workload at any time during the program press the Incline or Resistance UP or
Down key. This will only affect the Incline or Resistance for the present column in the profile. When the profile changes
to the next column it will return to the preset work level. to the next column it will return to the preset work level.
10. D u r ing the C us t om p r og r am y ou will be able t o sc r oll th r ough the da ta in the message wind o w b y p r essing the
Displ a y key .
11. When the program ends the message window will show a summary of your workout. The summary will be displayed for a
short time then the console will return to the start-up display.

20
FITNESS TEST PR OGR AM
T he fitness t est will assess y our fitness lev el and g iv e a sc or e a t the end of the t est . T his sc ore is not a V o2
max number , but just a number t o use as a r ef er enc e . Y ou can take the t est ev ery mon th and the score
should be higher as your lev el of fitness impr o v es . T he t est will take an y wher e fr om 6–15 minut es . T he t est
will ask y ou to main tain a pedal speed of 50 RPM and will aut oma tically make adjustmen ts t o the wor k
load depending on y our hear t r a t e r esponse t o set w or k levels . T he test ends when you r each y our tar get
hear t r a t e which is 85% of y our maximum hear t r a t e (M ax HR = 220 – y our age) or if your HR e x ceeds 110
BPM f or 2 c onsecutiv e stages .
F itness T est P r og r amming
1. P r ess the Fit-t est button and pr ess En t er .
2. T he message windo w will ask y ou to en t er y our A ge . Y ou ma y adjust the age setting, using the Resistance Up and D o wn key s then pr ess the
En t er key t o acc ept the new number and proc eed on to the ne xt scr een.
3. Y ou ar e no w asked t o en t er y our W eight . Y ou ma y adjust the w eigh t number using the Resistance Up and D o wn keys then pr ess en t er t o
c on tinue .
4. No w pr ess S tar t t o beg in the t est or En t er t o modify your settings .
B ef or e the test
 M ake sur e y ou are in good health; check with y our ph y sician befor e per f or ming an y e x er cise if y ou ar e over the age of 35 or persons with pre -
existing health c onditions .
 M ake sur e y ou ha ve war med up and stretched bef or e tak ing the t est .
 D o not take in caff eine befor e the test .
 Hold the hand g r ips gen tly , do not t ense up .
D uring the t est
 T he c onsole must be r eceiving a st eady hear t r a t e f or the test t o beg in. Y ou ma y use the hand pulse sensors or wear a hear t r a t e chest str ap
tr ansmitt er .
 Y ou must main tain a steady 50 RP M pedal speed . I f y our pedal speed dr ops belo w 48 RP M or goes abo v e 52 RP M the c onsole will emit a
st eady beeping sound un til y ou ar e within this r ange .
 Y ou ma y scr oll thr ough the v ar ious da ta r eadings in the message window b y pr essing the Displa y button under the message window .
1. T he message windo w will alw a y s displa y y our pedal speed on the r igh t side t o help y ou main tain 50RP M.
2. T he da ta sho wn dur ing the t est is:
a. W or k in K GM is ac tually an abbrevia t ed f or m of kg-m/min. which is a w ork measur emen t of k ilog r am-f or c e meter/minut e
b. W or k in Wa tts (1 w a tt is equal t o 6.11829727787 kg-m/min.)
c. HR is y our actual hear t r a t e; T GT is the tar get hear t r a t e t o r each to end the t est . d . T ime is the t otal elapsed time of the
t est .
A f t er the test
 C ool do wn f or about one t o thr ee minut es .
 T ake not e of y our sc ore because the console will aut oma tically r etur n t o the star t -up mode af t er a f ew minut es .
1st Stage Level 1 (9W)
54 kgm/min
Heart Rate HR<80 HR: 80-90 HR: 90-100
HR>100
2nd Stage
Level 12 (74W) 444 kgm/
min Level 11 (64W) 384 kgm/min
Level 7 (42W)
252 kgm/min
Level 3 (28W)
168 kgm/min
3rd Stage
Level 14 (104W)
624 kgm/min
Level 13 (87W)
522 kgm/min
Level 11 (64W)
384 kgm/min
Level 7 (42W)
252 kgm/min
4th Stage Level 15 (122W)
732 kgm/min
Level 14 (104W)
624 kgm/min
Level 12 (74W)
444 kgm/min
Level 11 (64W)
384 kgm/min
